Sunroof: Overview Mazda 6 GJ

Scheme 1

Scheme 2

1. Fully open the glass panel.
2. Press the spring in the direction shown by the arrow and remove it from the hook.
3. Remove the deflector.
4. Install in the reverse order of removal.

Scheme 3

Scheme 4

1. Fully close the glass panel.
2. Fully open the sunshade.
3. Remove the screws, and then remove the glass panel.
4. Peel the weatherstrip off the glass panel.
5. Install in the reverse order of removal.
6. Adjust the glass panel. (See «GLASS PANEL ADJUSTMENT»(ref-581735-S23060624902013101400000).)

Scheme 5

Scheme 6

1. Fully close the glass panel.
2. Measure the gap and height between the glass panel and body.
3. If not as specified, loosen the glass panel installation screws and reposition the glass panel. Clearance a: 0.3-2.3 mm {0.02-0.09 in} b: 0 mm {0 in}
4. Tighten the installation screws.
5. Insert a plastic card between the weatherstrip and the body of the vehicle. Verify that the sunroof is shut tightly (there is resistance when the plastic card is moved). If the sunroof is not shut tightly, readjust by performing Steps 3 and 4 .

Scheme 7

1. Disconnect the negative battery cable.
2. Partially peel back the seaming welt.
3. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
4. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
5. Remove the following parts: Sunroof seaming welt A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000).) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000).) B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).)
6. Disconnect the auto-dimming mirror connector. (Vehicles with auto-dimming mirror)
7. Remove the sunvisors. (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000).)
8. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000).)
9. Remove the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000).)
10. Disconnect the roof harness connector, remove the clip, and remove the connector.
11. Remove the headliner. (See «HEADLINER REMOVAL/INSTALLATION»(ref-581614-S06320006622013101400000).)
12. Remove the glass panel. (See «GLASS PANEL REMOVAL/INSTALLATION»(ref-581735-S13635770882013101400000).)
13. Disconnect the front and rear drain hose from the sunroof frame.
14. Remove the bolts.
15. Remove the nuts, and then remove the sunroof unit.
16. Install in the reverse order of removal.
17. Adjust the glass panel. (See «GLASS PANEL ADJUSTMENT»(ref-581735-S23060624902013101400000).)

Note. If the guide or sunroof motor is removed, the glass panel will not be positioned properly after the re-installation. To ensure proper positioning of the glass panel, place alignment marks on the guide pin and frame before removing the guide or sunroof motor.

Scheme 8

1. Disassemble in the order indicated in the table.
2. Assemble in the reverse order of disassembly.

Note. If the guide is removed, the sunroof motor initial position setting has to be performed. After installing the sunroof unit, perform the initial position setting using the following procedure.

1. The initialization mode starts after approx. 13 s from when the tilt up switch has been pressed and held. The glass stops after it has moved approx. 30 mm {1.18 in} towards the closed position. NOTE: Only the tilt up switch is available during the initialization mode. The initialization may finish at the first inching operation depending on the glass position when the motor is installed. If the glass position is between the closed and semi-tilt positions when the motor is removed, the glass moves in the tilt up direction (to the full tilt position stored in the motor). However, if the tilt up switch is pressed and held, the initialization mode starts.
2. When the tilt up switch is pressed again, the glass continues to move approx. 30 mm {1.18 in} and stops.
3. Repeat this procedure several times so that the glass moves to the fully closed, full tilt (normal operation position), and full tilt (mechanical stopper position) positions.
4. After the glass is moved to the full tilt position (mechanical stopper position), it returns to the tilt down direction slightly and the initialization is completed.

Scheme 9

Scheme 10

1. Place an alignment mark on the guide pin and flame.
2. Slide the guide to the rear of the sunroof frame, and remove the guide and decoration link as a single unit.

Scheme 11

1. Move the pin to the position shown in the figure.

Scheme 12

1. Set the guide pin to the decoration link.

Scheme 13

1. Disconnect the negative battery cable.
2. Partially peel back the seaming welt.
3. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-581618-S16481366742013101400000).)
4. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
5. Remove the following parts: Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-581614-S35474389282013101400000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-581614-S27123962102013101400000).) Front scuff plates (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Front side trims (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S15846352132013101400000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM LOCATION INDEX»(/mazda/6/gj-2012-2015/remont/manual-trans/#manual-transaxle-shift-mechanism).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000).) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-581663-S24664239442013101400000).) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-581664-S10963812152013101400000).) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-581614-S12913222402013101400000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-581656-S24929307862013101400000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-581614-S08723493922013101400000).) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-581610-S10735079002013101400000).) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000).) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-581614-S36009183262013101400000).) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-581620-S26915536712013101400000).) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-581614-S19165313082013101400000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-581651-S30763301102013101400000).) Center panel upper (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-581614-S25330971132013101400000).) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-581616-S32219205692013101400000).) Steering shaft cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000).) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000).) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-581614-S07883015262013101400000).) SIRIUS satellite radio unit (See «SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION»(ref-581616-S38070671012013101400000).) Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-581610-S16434598032013101400000).) aa. A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).) ab. Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-581614-S23273769092013101400000).) ac. Audio amplifier (with Bose®) (See «AUDIO AMPLIFIER REMOVAL/INSTALLATION»(ref-581616-S17006069772013101400000).) ad. Sunroof seaming welt ae. A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).) af. Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-581619-S13872678202013101400000).) ag. Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000).) ah. B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-581614-S21790786902013101400000).) ai. B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-581614-S03709703802013101400000).) aj. Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).) ak. Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) al. C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S18739322292013101400000).) am. Sunvisors (See «SUNVISOR REMOVAL/INSTALLATION»(ref-581614-S15387534752013101400000).) an. Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-581620-S12558053102013101400000).) ao. Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-581614-S34345018172013101400000).) ap. Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-581614-S06320006622013101400000).)
6. Disconnect the auto-dimming mirror connector. (vehicles with auto-dimming mirror)
7. Disconnect the roof harness connector, remove the clip, and remove the connector.
8. Disconnect the front drain hose from the sunroof frame.
9. Remove the front drain hose from the clips.
10. Pull the front drain hose into the room side.
11. Remove the front drain hose.
