Security System and Locks System: Overview Mazda 6 GJ

Identifying Lock And Opener System Component Locations. Scheme 15

Identifying Advanced Keyless Entry System And Push Button Start System/Immobilizer System Component Locations (1 Of 2). Scheme 16

Identifying Advanced Keyless Entry System And Push Button Start System/Immobilizer System Component Locations (2 Of 2). Scheme 17

Identifying Keyless Entry System/Immobilizer System Component Locations. Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}. (Scheme 19): Identifying Distance From Top Of Front Door Glass To Upper Part Of Front Beltline Molding
2. Disconnect the negative battery cable.
3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-581614-S33446531912013101400000).) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-581614-S01255683662013101400000).) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-581616-S15222844692013101400000).) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION»(ref-581623-S09056091502013101400000).) Front door module panel (See «FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION»(ref-581690-S33174771762013101400000).) Front door key cylinder (See «FRONT DOOR KEY CYLINDER REMOVAL/INSTALLATION»(ref-581656-S30760356882013101400000).)
4. Disconnect the keyless antenna connector (With advanced keyless entry and push button start system). (Scheme 20): Keyless Antenna Connector (With Advanced Keyless Entry And Push Button Start System)
5. Remove the front outer handle. (Scheme 21): Front Outer Handle
6. Remove the screw. NOTE: The screw cannot be removed because of the stopper. (Scheme 22): Front Outer Handle Screw
7. Press down the rod holder in the direction of arrow (1) and remove the front outer handle bracket in the direction of arrow (2). (Scheme 23): Rod Holder Pressing And Front Outer Handle Bracket Removal Procedures
8. Install in the reverse order of removal.

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. Fully close the rear door glass.
2. Disconnect the negative battery cable.
3. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-581614-S26913575372013101400000).)
4. Remove the hole cover. (Scheme 24): Hole Cover
5. Remove the service hole cover. (Scheme 25): Service Hole Cover
6. Remove the screw from the service hole. (Scheme 26): Identifying Screw Through Service Hole NOTE: The screw cannot be removed because of the stopper.
7. Press the tab on the rear outer handle bracket in the direction of the arrow. (Scheme 27): Rear Outer Handle Bracket Tab
8. Maintaining the condition in procedure 7, remove the outer handle garnish. (Scheme 28): Outer Handle Garnish
9. Remove the rear outer handle. (Scheme 29): Rear Outer Handle
10. Loosen the screw. (Scheme 30): Rear Outer Handle Bracket And Screw
11. Press down the rod holder in the direction of arrow (1) and remove the rear outer handle bracket in the direction of arrow (2). (Scheme 31): Rod Holder And Rear Outer Handle Bracket Removal Procedure
12. Install in the reverse order of removal.

Scheme 32

Scheme 33

1. Disconnect the negative battery cable.
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-581614-S33446531912013101400000).)
3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-581614-S01255683662013101400000).)
4. Disconnect the door lock switch connector. (Scheme 32): Door Lock Switch And Connector
5. Disconnect each cable and remove the front inner handle. (Scheme 33): Front Inner Handle, Cable And Door Lock Knob Cable
6. Install in the reverse order of removal.

Scheme 34

1. Disconnect the negative battery cable.
2. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-581614-S26913575372013101400000).)
3. Disconnect each cable and remove the rear inner handle. (Scheme 34): Rear Inner Handle, Cable And Door Lock Knob Cable
4. Install in the reverse order of removal.

Scheme 35

1. Disconnect the negative battery cable.
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-581614-S33446531912013101400000).)
3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-581614-S01255683662013101400000).)
4. Remove the inner handle. (See «INNER HANDLE REMOVAL/INSTALLATION»(ref-581656-S07035683262013101400000).)
5. Remove the screws, then remove the door lock switch. (Scheme 35): Screws And Door Lock Switch
6. Install in the reverse order of removal.

Scheme 36

Scheme 37

1. Disconnect the negative battery cable.
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-581614-S33446531912013101400000).)
3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-581614-S01255683662013101400000).)
4. Remove the inner handle. (See «INNER HANDLE REMOVAL/INSTALLATION»(ref-581656-S07035683262013101400000).)
5. Inspect for continuity between the door lock switch terminals using an ohmmeter. (Scheme 36): Inspecting For Continuity Between Door Lock Switch Terminals Using An Ohmmeter If not as indicated in the table, replace the door lock switch. (Scheme 37): Door Lock Switch Terminals Continuity Chart
6. Apply battery voltage to hazard switch terminal B, and connect terminal A to ground.
7. Verify that the LED illuminates. If there is any malfunction, replace the door lock switch.

Scheme 38

Scheme 39

1. Open the hood.
2. Disconnect the negative battery cable.
3. Disconnect the hood latch switch connector. (vehicles with theft-deterrent system) (Scheme 38): Hood Latch And Switch Connector
4. Remove the bolts.
5. Remove the hood latch. (Scheme 39): Hood Latch And Bolts With Torque Specifications
6. Install in the reverse order of removal.
7. Adjust the hood. (See «HOOD ADJUSTMENT»(ref-581621-S37070679502013101400000).)

Scheme 40

Scheme 41

Scheme 42

1. Pull the hood release lever. (Scheme 40): Hood Release Lever
2. While maintaining the condition in procedure 1, insert a tape-wrapped flathead screwdriver as shown in the figure, press the ends of the tabs with the screwdriver in the direction of the arrows (1), pull the hood release lever in the direction of arrow (2), and then disconnect the lower panel. (Scheme 41): Hood Release Lever Tabs CAUTION: Remove the hood release lever while being careful not to damage the hood release cable with the flathead screwdriver.
3. Pull the latch release lever outward, remove it from the lower panel, and then disconnect the hood release cable. (Scheme 42): Hood Release Lever And Cable
4. Install in the reverse order of removal.

Scheme 43

1. Disconnect the negative battery cable.
2. Remove the following parts: Side turn lights (See «SIDE TURN LIGHT REMOVAL/INSTALLATION»(ref-581620-S41439623182013101400000).) Front bumper (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-581621-S34011796882013101400000).) Front combination lights (See «FRONT COMBINATION LIGHT REMOVAL/INSTALLATION»(ref-581620-S32963087872013101400000).) Side step molding (See «SIDE STEP MOLDING REMOVAL»(ref-581657-S19911767952013101400000).)(See «SIDE STEP MOLDING INSTALLATION»(ref-581657-S02027692272013101400000).) Front fender molding (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-581657-S30702990112013101400000).) Front mudguard (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-581657-S04390956372013101400000).)
3. Remove the hood release cable from clips A.
4. Remove the clips B.
5. Remove the hood release cable from clips C.
6. Disconnect the hood latch from the hood release cable.
7. Remove the grommet. (See «GROMMET REMOVAL NOTE»(ref-581656-S10130860492013101400000).)
8. Remove the hood release cable from outside of the vehicle. (Scheme 43): Hood Release Cable And Clips
9. Install in the reverse order of removal.

Scheme 44

1. Remove the grommet in the direction of the arrow (2) shown in the figure while pressing the grommet tabs in the direction of the arrow (1). (Scheme 44): Identifying Grommet Tabs

Scheme 45

Scheme 46

Scheme 47

1. Disconnect the negative battery cable.
2. Remove the hood latch. (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-581656-S24929307862013101400000).)
3. Press the latch in using a flathead screwdriver to inspect the latch lever condition. (Scheme 45): Inspecting Latch Lever Condition
4. Verify that the continuity is as indicated in the table. (Scheme 46): Hood Latch Switch If not as indicated in the table, replace the hood latch. (Scheme 47): Hood Latch Switch Terminals Continuity Chart

Scheme 48

1. Disconnect the negative battery cable.
2. Remove the following parts: Front seat (driver's seat) (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-581617-S37007315702013101400000).) Front scuff plate (driver's side) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Rear scuff plate (driver's side) (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S04306764902013101400000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-581614-S18023401772013101400000).) Trunk side trim (driver's side) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S05382445092013101400000).) Fuel-filler lid opener (See «FUEL-FILLER LID OPENER AND LEVER REMOVAL/INSTALLATION»(ref-581656-S38617786642013101400000).)
3. Remove the fuel-filler lid opener cable. (Scheme 48): Fuel-Filler Lid Opener Cable And Clips
4. Install in the reverse order of removal.

Scheme 49

Scheme 50

Scheme 51

1. Open the fuel-filler lid.
2. Remove the following parts: Rear scuff plate (driver's side) (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S02378223002013101400000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-581617-S39478993682013101400000).) Rear seat back (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-581617-S38631910712013101400000).) Tire house trim Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-581614-S18023401772013101400000).) Trunk side trim (driver's side) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S05382445092013101400000).)
3. Open the fuel-filler lid opener cable cover. (Scheme 49): Fuel-Filler Lid Opener Cable Cover
4. Disconnect the release cable from the fuel-filler lid opener cable cover. (Scheme 50): Release Cable And Fuel-Filler Lid Opener Cable Cover
5. Rotate the fuel-filler lid opener in the direction of the arrow (1) as shown in the figure and pull it out in the direction of the arrow (2). (Scheme 51): Identifying Fuel-Filler Lid Opener Rotating And Pulling Directions
6. Install in the reverse order of removal.

Scheme 52

1. Remove the fuel-filler lid opener bezel. (See «FUEL-FILLER LID OPENER BEZEL REMOVAL/INSTALLATION»(ref-581614-S33838077642013101400000).)
2. Remove the bolts. (Scheme 52): Fuel-Filler Lid Opener Cable And Lever With Torque Specifications
3. Disconnect the cable and fuel-filler lid opener lever.
4. Install in the reverse order of removal.

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}. (Scheme 53): Identifying Distance From Top Of Front Door Glass To Upper Part Of Front Beltline Molding
2. Disconnect the negative battery cable.
3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-581614-S33446531912013101400000).) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-581614-S01255683662013101400000).) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-581616-S15222844692013101400000).) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION»(ref-581623-S09056091502013101400000).) Front door module panel (See «FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION»(ref-581690-S33174771762013101400000).)
4. Remove the service hole cover. (Scheme 54): Service Hole Cover
5. Remove the screw from the service hole. NOTE: The screw cannot be removed because of the stopper. (Scheme 55): Screw Through Service Hole
6. Lift the clip in the direction of the arrow (1), and pull out the key rod in the direction of the arrow (2). (Scheme 56): Clip Lifting Direction And Key Rod Pulling Direction
7. Press the tab on the front outer handle bracket in the direction of the arrow. (Scheme 57): Front Outer Handle Bracket Tab
8. Maintaining the condition in Step 7, remove the front key cylinder. (Scheme 58): Front Key Cylinder
9. Using a tape-wrapped fastener remover, press up the collar cap in the direction of the arrow shown in the arrow, press aside the front door key cylinder tabs (1), and remove the collar cover from the front door key cylinder. (Scheme 59): Front Door Key Cylinder, Tabs And Collar Cover
10. Install in the reverse order of removal.

Scheme 60

Scheme 61

Scheme 62

Scheme 63

1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}. (Scheme 60): Distance From Top Of Front Door Glass To Upper Part Of Front Beltline Molding
2. Disconnect the negative battery cable.
3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-581614-S33446531912013101400000).) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-581614-S01255683662013101400000).) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-581616-S15222844692013101400000) ) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION»(ref-581623-S09056091502013101400000).) Front door module panel (See «FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION»(ref-581690-S33174771762013101400000).) Front door latch and lock actuator (See «FRONT DOOR LATCH AND LOCK ACTUATOR REMOVAL/INSTALLATION»(ref-581656-S12903392962013101400000).)
4. If the door lock condition is to be inspected, pull the door lock-link switch cable, or press it in. NOTE: The door lock-link switch cable locks or unlocks only when the latch lever is locked. (Scheme 61): Door Lock-Link Switch Cable
5. Verify that the continuity is as indicated in the table. (Scheme 62): Identifying Door Lock-Link Switch Terminals If not as indicated in the table, replace the front door latch and lock actuator. (Scheme 63): Door Lock-Link Switch Terminals Continuity Chart

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}. (Scheme 64): Distance From Top Of Front Door Glass To Upper Part Of Front Beltline Molding
2. Disconnect the negative battery cable.
3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-581614-S33446531912013101400000).) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-581614-S01255683662013101400000).) Front inner handle (See «DOOR LOCK-LINK SWITCH INSPECTION»(ref-581656-S35333370762013101400000).) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-581616-S15222844692013101400000).) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION»(ref-581623-S09056091502013101400000).) Front door module panel (See «FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION»(ref-581690-S33174771762013101400000).)
4. Disconnect the key rod from the front outer handle bracket. (Scheme 65): Front Outer Handle Bracket And Key Rod
5. Remove the screw (Scheme 66): Front Outer Handle Bracket, Screw And Clips With Torque Specifications
6. Detach the clips.
7. Press down the rod holder of the front door latch and lock actuator in the direction of the arrow. (Scheme 67): Rod Holder, Front Door Latch And Lock Actuator
8. Maintaining the condition in Step 7, remove the front door latch and lock actuator. (Scheme 68): Front Door Latch And Lock Actuator
9. Install in the reverse order of removal.
