Control System - HVAC (Full Auto Air Conditioner): Other Mazda 6 GJ

Automatic HVAC System 5 illustrations ~455 words

Driver's Side

TerminalAir Mix Actuator Operation
AB
GroundB+COLD --> HOT
B+GroundHOT --> COLD

Passenger's side

TerminalAir Mix Actuator Operation
AB
B+GroundCOLD --> HOT
GroundB+HOT --> COLD

Scheme 55

Scheme 55
Scheme 55
  1. 2. Verify that the resistance between terminals D and E, and E and F matches the air mix actuator operation as shown in the graph. If the operation condition and resistance are not normal, replace the air mix actuator. (Scheme 55): Air Mix Actuator Resistance Graph

Scheme 56

Scheme 56: AIRFLOW MODE ACTUATOR REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]
Scheme 56: AIRFLOW MODE ACTUATOR REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]
  1. Disconnect the negative battery cable.
  2. Remove the following parts. Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-581614-S35474389282013101400000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-581614-S27123962102013101400000).) Front scuff plates (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-581614-S36484760642013101400000).) Front side trims (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-581614-S15846352132013101400000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-581614-S15065956352013101400000).) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-581614-S30597239632013101400000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM LOCATION INDEX»(ref-581615-S41865543102013101400000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-581614-S38776581642013101400000).) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-581614-S05740589362013101400000).) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-581663-S24664239442013101400000).) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-581614-S12913222402013101400000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-581656-S24929307862013101400000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-581614-S08723493922013101400000).) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-581610-S10735079002013101400000).) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000).) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-581614-S36009183262013101400000).) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-581620-S26915536712013101400000).) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-581614-S19165313082013101400000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-581651-S30763301102013101400000).) Center panel upper (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-581614-S25330971132013101400000).) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-581616-S32219205692013101400000).) Steering shaft cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000).) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S34424186902013101400000).)(See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-581622-S06798620582013101400000).) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-581614-S07883015262013101400000).) SIRIUS satellite radio unit (See «SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION»(ref-581616-S38070671012013101400000).) Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-581610-S16434598032013101400000).) aa. A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-581614-S20559757112013101400000).) ab. Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-581614-S23273769092013101400000).)
  3. Remove the A/C unit. (See «A/C UNIT REMOVAL/INSTALLATION»(ref-581666-S35905141042013101400000).)
  4. Disassemble the A/C unit (See «A/C UNIT DISASSEMBLY/ASSEMBLY»(ref-581666-S39152968662013101400000).)
  5. Remove in the order indicated in the table. (Scheme 56): Airflow Mode Actuator Components
  6. Install in the reverse order of removal.

Scheme 57

Scheme 57: Airflow Mode Link Set Installation Note
Scheme 57: Airflow Mode Link Set Installation Note

Scheme 58

Scheme 58
Scheme 58
  1. Install the airflow mode sub link as shown in the figure. (Scheme 57): Airflow Mode Sub Link
  2. Install the airflow mode main link as shown in the figure. (Scheme 58): Airflow Mode Main Link

Scheme 59

Scheme 59: Airflow Mode Actuator Installation Note
Scheme 59: Airflow Mode Actuator Installation Note
  1. Insert the airflow mode actuator shaft to the door hole aligned with each shape same as removed position. (Scheme 59): Airflow Mode Actuator Shaft And Door Hole
