Entertainment System: Other Mazda 6 GH рестайлинг

Welcome Mode ON/OFF Setting

Note. Welcome mode is controlled by the instrument cluster. Refer to the INSTRUMENT CLUSTER CONFIGURATION

1. Refer to «INSTRUMENTATION/DRIVER INFO. PERSONALIZATION FEATURES SETTING PROCEDURE»(ref-448586-S22330673132012012000000) .

Scheme 81

Scheme 82

1. Switch the ignition to ACC or ON.
2. Turn the audio unit power to ON.
3. Press the AUDIO CONT switch.
4. Select "Welcome ON" or "Welcome OFF".
5. Press the AUDIO CONT switch.
6. Select "ON" or "OFF".

Scheme 83

Scheme 84

1. Switch the ignition to ACC or ON.
2. Turn the car-navigation unit power to ON.
3. Press the DISP switch (panel switch).
4. Select "SETTINGS".
5. Select "ON" or "OFF".

Scheme 85

Rear

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-448657-S11374618932012012000000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-448656-S21764171192012012000000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-448656-S13809786282012012000000) .) Rear console (See «REAR CONSOLE DISASSEMBLY/ASSEMBLY»(ref-448656-S19316369282012012000000) .)
3. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Accessory socket (Rear) (See «ACCESSORY SOCKET REMOVAL NOTE»(ref-448591-S06315850212012012000000) .) 2 Cap (See «CAP REMOVAL NOTE»(ref-448591-S19755771892012012000000) .)
4. Install in the reverse order of removal.

Scheme 86

Front

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-448657-S11374618932012012000000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-448656-S21764171192012012000000) .) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-448656-S13809786282012012000000) .) Accessory socket (Front) (See «ACCESSORY SOCKET REMOVAL/INSTALLATION»(ref-448591-S23320034472012012000000) .)
3. Connect a tester as shown in the illustration and verify that there is continuity.

1. If the continuity cannot be verified, replace the accessory socket (Front).

Scheme 87

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-448657-S11374618932012012000000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-448656-S21764171192012012000000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-448656-S13809786282012012000000) .) Rear console (See «REAR CONSOLE DISASSEMBLY/ASSEMBLY»(ref-448656-S19316369282012012000000) .) Accessory socket (Rear) (See «ACCESSORY SOCKET REMOVAL/INSTALLATION»(ref-448591-S23320034472012012000000) .)
3. Connect a tester as shown in the illustration and verify that there is continuity.

1. If the continuity cannot be verified, replace the accessory socket (Rear).

Scheme 88
