Entertainment System: Removal & Installation Mazda 6 GH рестайлинг

AUDIO UNIT REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-448657-S11374618932012012000000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-448656-S21764171192012012000000) .) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-448656-S13809786282012012000000) .) Center panel upper (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-448656-S12464949122012012000000) .) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-448606-S32061511212012012000000) .) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-448607-S20228354472012012000000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 39

PARTS DESCRIPTION CHART

Audio Unit Removal Note

1. Pull the audio unit outward, detach tab, clip from the dashboard, and then remove the audio unit.

Scheme 40

CAR-NAVIGATION UNIT REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-448657-S11374618932012012000000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-448656-S21764171192012012000000) .) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-448656-S13809786282012012000000) .) Center panel upper (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-448656-S12464949122012012000000) .) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-448606-S32061511212012012000000) .) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-448607-S20228354472012012000000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 41

PARTS DESCRIPTION CHART

Car-navigation unit Removal Note

1. Pull the car-navigation unit outward, detach tab, clip from the dashboard, and then remove the car-navigation unit.

Scheme 42

AUDIO AMPLIFIER REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: Front scuff plate (RH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-448656-S24645152862012012000000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-448656-S36262450112012012000000) .)
3. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Connector 2 Bolt 3 Nut 4 Audio amplifier
4. Install in the reverse order of removal.

Scheme 43

Scheme 44

1. Disconnect the negative battery cable.
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-448656-S17163868202012012000000) .)
3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-448656-S34800399052012012000000) .)
4. Remove in the order indicated in the table. With Bose® Without Bose® PARTS DESCRIPTION CHART 1 Screw 2 Front door speaker (See «FRONT DOOR SPEAKER REMOVAL NOTE»(ref-448591-S11343049922012012000000) .) 3 Connector
5. Install in the reverse order of removal.

Scheme 45

Front Door Speaker Removal Note

1. Remove the front door speaker in the direction of the arrow shown in the illustration.

With Bose®

Scheme 46

Without Bose®

Scheme 47

Rear Door Speaker Removal Note

1. Remove the rear door speaker in the direction of the arrow shown in the illustration.

With Bose®

Scheme 48

Without Bose®

Scheme 49

FRONT CENTER SPEAKER REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the center panel upper. (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-448656-S12464949122012012000000) .)
3. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Screw 2 Front center speaker
4. Install in the reverse order of removal.

Scheme 50

REAR CENTER SPEAKER REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: High-mount brake light (See «HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION»(ref-448651-S22360427792012012000000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-448628-S17042362982012012000000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S21191719082012012000000) .) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-448656-S10486747222012012000000) .)
3. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Screw 2 Rear center speaker 3 Connector
4. Install in the reverse order of removal.

Scheme 51

REAR SPEAKER REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: High-mount brake light (See «HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION»(ref-448651-S22360427792012012000000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-448628-S17042362982012012000000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S21191719082012012000000) .) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-448656-S10486747222012012000000) .)
3. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Screw 2 Rear speaker 3 Connector
4. Install in the reverse order of removal.

Scheme 52

TWEETER REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-448656-S17163868202012012000000) .)
3. Remove the tweeter in the direction of the arrow shown in the illustration.
4. Install in the reverse order of removal.

Scheme 53

AudioPilot® 2 MICROPHONE REMOVAL/INSTALLATION

Note. "AudioPilot®2" is a registered trademark of Bose® Corporation.

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Connector 2 Bolt 3 AudioPilot®2 microphone
3. Install in the reverse order of removal.

Scheme 54

SIRIUS SATELLITE RADIO ANTENNA REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the rain sensor cover. (with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-448630-S41753305522012012000000) .)
3. Disconnect the rain sensor connector. (with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-448630-S41753305522012012000000) .)
4. Disconnect the auto-dimming mirror connector. (with auto-dimming mirror) (See «AUTO-DIMMING MIRROR REMOVAL»(ref-448571-S33477634012012012000000) .) (See «AUTO-DIMMING MIRROR INSTALLATION»(ref-448571-S31492841542012012000000) .)
5. Remove the following parts: Sunroof seaming weft (with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S22638988852012012000000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S10692943582012012000000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-448656-S35625955382012012000000) .) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-448671-S24354888492012012000000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-448656-S29824177632012012000000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-448628-S17042362982012012000000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S21191719082012012000000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-448651-S38096746852012012000000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-448656-S17577240092012012000000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-448656-S04086798262012012000000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-448656-S29577759512012012000000) .)
6. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Connector 2 Nut 3 SIRIUS satellite radio antenna (See «SIRIUS SATELLITE RADIO ANTENNA REMOVAL NOTE»(ref-448591-S08381884972012012000000) .)
7. Install in the reverse order of removal.
8. After installation, verify that waterproof rubber of the SIRIUS satellite radio antenna is installed to the roof panel without any gaps.
9. After installing the SIRIUS satellite radio antenna, verify that the gap between the SIRIUS satellite radio antenna and roof panel is within the following range.

Scheme 55

Standard values 0.6 mm {0.02 in}

Maximum values 1.2 mm {0.047 in}

Minimum values 0 mm {0 in}

Side by difference 0.7 mm {0.03 in}

SIRIUS Satellite Radio Antenna Removal Note

1. Remove the SIRIUS satellite radio antenna in the direction of the arrow (2) shown in the illustration while pressing the SIRIUS satellite radio antenna tabs in the direction of the arrow (1).

Scheme 56

ANTENNA AMPLIFIER REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the rain sensor cover. (with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-448630-S41753305522012012000000) .)
3. Disconnect the rain sensor connector. (with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-448630-S41753305522012012000000) .)
4. Disconnect the auto-dimming mirror connector. (with auto-dimming mirror) (See «AUTO-DIMMING MIRROR REMOVAL»(ref-448571-S33477634012012012000000) .) (See «AUTO-DIMMING MIRROR INSTALLATION»(ref-448571-S31492841542012012000000) .)
5. Remove the following parts: Sunroof seaming welt (with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S22638988852012012000000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S10692943582012012000000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-448656-S35625955382012012000000) .) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-448671-S24354888492012012000000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-448656-S29824177632012012000000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-448628-S17042362982012012000000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S21191719082012012000000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-448651-S38096746852012012000000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-448656-S17577240092012012000000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-448656-S04086798262012012000000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-448656-S29577759512012012000000) .)
6. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Clip 2 Bolt 3 Connector A 4 Connector B (See «CONNECTOR B REMOVAL NOTE»(ref-448591-S20186682932012012000000) .) 5 Antenna amplifier
7. Install in the reverse order of removal.

Scheme 57

Connector B Removal Note

1. Remove the connector B in the direction of the arrow (2) shown in the illustration while pressing the glass antenna terminal in the direction of the arrow (1).

Scheme 58

SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-448656-S36262450112012012000000) .)
3. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Screw 2 SIRIUS satellite radio unit 3 Connector
4. Install in the reverse order of removal.

Scheme 59

SIRIUS Satellite Radio Unit Removal Note

1. Spread the SIRIUS satellite radio unit bracket apart in the direction of the arrow shown in the illustration (1) to remove the SIRIUS satellite radio unit (2).

Scheme 60

Scheme 61

1. Disconnect the negative battery cable.
2. Remove the following parts: High-mount brake light (See «HIGH-MOUNT BRAKE LIGHT REMOVAL/INSTALLATION»(ref-448651-S22360427792012012000000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-448628-S17042362982012012000000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S21191719082012012000000) .) Rear package trim (See «REAR PACKAGE TRIM REMOVAL/INSTALLATION»(ref-448656-S10486747222012012000000) .)
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

ANTENNA FEEDER NO. 1 REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-448656-S36262450112012012000000) .) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-448656-S15925168382012012000000) .) Front scuff plates (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Front side trims (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-448656-S24645152862012012000000) .) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM LOCATION INDEX»(ref-448657-S31582424492012012000000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-448656-S21764171192012012000000) .) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-448656-S13809786282012012000000) .) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-448606-S32061511212012012000000) .) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-448607-S20228354472012012000000) .) Rear console (See «REAR CONSOLE REMOVAL/INSTALLATION»(ref-448656-S24311442192012012000000) .) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-448614-S41008846102012012000000) .) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-448656-S04202039792012012000000) .) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-448570-S41657307962012012000000) .) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S01292366382012012000000) .) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S18771656912012012000000) .) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-448656-S12743804542012012000000) .) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-448651-S19122248902012012000000) .) Meter hood (See «METER HOOD REMOVAL/INSTALLATION»(ref-448656-S09959257172012012000000) .) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-448586-S17394319142012012000000) .) Center panel upper (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-448656-S12464949122012012000000) .) Audio unit (With audio system) (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-448591-S42816289752012012000000) .) Car-navigation unit (With car-navigation system) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-448591-S27809871202012012000000) .) Steering shaft cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S01292366382012012000000) .) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S18771656912012012000000) .) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S01292366382012012000000) .) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-448619-S18771656912012012000000) .) Side panel (See «SIDE PANEL REMOVAL/INSTALLATION»(ref-448656-S21955955632012012000000) .) SIRIUS satellite radio unit (With SIRIUS satellite radio system) (See «SIRIUS SATELLITE RADIO UNIT REMOVAL/INSTALLATION»(ref-448591-S17549509352012012000000) .) Passenger-side air bag module (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION»(ref-448570-S05866549032012012000000) .) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S22638988852012012000000) .) Dashboard (See «DASHBOARD REMOVAL/INSTALLATION»(ref-448656-S12911950632012012000000) .)
3. Remove the clips A and B.
4. Remove the antenna feeder No. 1.
5. Install in the reverse order of removal.

Scheme 62

Scheme 63

ANTENNA FEEDER N0.2 REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the rain sensor cover. (with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-448630-S41753305522012012000000) .)
3. Disconnect the rain sensor connector. (with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-448630-S41753305522012012000000) .)
4. Disconnect the auto-dimming mirror connector. (with auto-dimming mirror) (See «AUTO-DIMMING MIRROR REMOVAL»(ref-448571-S33477634012012012000000) .) (See «AUTO-DIMMING MIRROR INSTALLATION»(ref-448571-S31492841542012012000000) .)
5. Remove the following parts: Sunroof seaming welt (with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S22638988852012012000000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S10692943582012012000000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-448656-S35625955382012012000000) .) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-448671-S24354888492012012000000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-448656-S29824177632012012000000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-448628-S17042362982012012000000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S21191719082012012000000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-448651-S38096746852012012000000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-448656-S17577240092012012000000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-448656-S04086798262012012000000) .) Headliner(See «HEADLINER REMOVAL/INSTALLATION»(ref-448656-S29577759512012012000000) .)
6. Peel off the tape and remove antenna feeder No. 2.
7. Install in the reverse order of removal

Scheme 64

Scheme 65

Scheme 66

1. Disconnect the negative battery cable.
2. Remove the following parts: A-pillar trim (RH) (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S22638988852012012000000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .) Rear side seat back (RH) (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-448628-S17042362982012012000000) .) C-pillar trim (RH) (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S21191719082012012000000) .)
3. Disconnect the antenna feeder No. 1.
4. Disconnect the antenna feeder No. 3.
5. Verify that the continuity between antenna feeder No. 2 terminals is as indicated in the table.

1. If not as indicated in the table, replace antenna feeder No. 2.

Scheme 67

Scheme 68

ANTENNA FEEDER N0.3 REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the rain sensor cover. (with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-448630-S41753305522012012000000) .)
3. Disconnect the rain sensor connector. (with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-448630-S41753305522012012000000) .)
4. Disconnect the auto-dimming mirror connector. (with auto-dimming mirror) (See «AUTO-DIMMING MIRROR REMOVAL»(ref-448571-S33477634012012012000000) .) (See «AUTO-DIMMING MIRROR INSTALLATION»(ref-448571-S31492841542012012000000) .)
5. Remove the following parts: Sunroof seaming welt (with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S22638988852012012000000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S10692943582012012000000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-448656-S35625955382012012000000) .) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-448671-S24354888492012012000000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-448656-S29824177632012012000000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-448628-S17042362982012012000000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S21191719082012012000000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-448651-S38096746852012012000000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-448656-S17577240092012012000000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-448656-S04086798262012012000000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-448656-S29577759512012012000000) .)
6. Disconnect the connector.
7. Remove the dips A and B.
8. Remove the antenna feeder No. 3.
9. Install in the reverse order of removal.

Scheme 69

Scheme 70

1. Disconnect the negative battery cable.
2. Remove the rain sensor cover. (with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-448630-S41753305522012012000000) .)
3. Disconnect the rain sensor connector. (with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-448630-S41753305522012012000000) .)
4. Disconnect the auto-dimming mirror connector. (with auto-dimming mirror) (See «AUTO-DIMMING MIRROR REMOVAL»(ref-448571-S33477634012012012000000) .) (See «AUTO-DIMMING MIRROR INSTALLATION»(ref-448571-S31492841542012012000000) .)
5. Remove the following parts: Sunroof seaming welt (with sunroof system) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S22638988852012012000000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S10692943582012012000000) .) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-448656-S35625955382012012000000) .) Front seat belt upper anchor installation bolt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-448671-S24354888492012012000000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-448656-S29824177632012012000000) .) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-448628-S22827010952012012000000) .) Rear side seat back (See «REAR SIDE SEAT BACK REMOVAL/INSTALLATION»(ref-448628-S17042362982012012000000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-448656-S21191719082012012000000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-448651-S38096746852012012000000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-448656-S17577240092012012000000) .) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-448656-S04086798262012012000000) .) Headliner (See «HEADLINER REMOVAL/INSTALLATION»(ref-448656-S29577759512012012000000) .)
6. Disconnect the antenna feeder No. 2.
7. Verify that the continuity between antenna feeder No. 3 terminals is as indicated in the table.

1. If not as indicated in the table, replace antenna feeder No. 3.

Scheme 71

SIRIUS SATELLITE RADIO ANTENNA FEEDER REMOVAL/INSTALLATION

Note. SIRIUS satellite radio antenna feeder is integrated with the antenna feeder.

1. Refer to «ANTENNA FEEDER NO. 1 REMOVAL/INSTALLATION»(ref-448591-S07926824432012012000000) .
2. Refer to «ANTENNA FEEDER NO. 2 REMOVAL/INSTALLATION»(ref-448591-S13940511712012012000000) .
3. Refer to «ANTENNA FEEDER NO. 3 REMOVAL/INSTALLATION»(ref-448591-S35160438202012012000000) .

GPS ANTENNA REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the center panel upper. (See «CENTER PANEL UPPER REMOVAL/INSTALLATION»(ref-448656-S12464949122012012000000) .)
3. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Connector 2 Screw 3 GPS antenna
4. Install in the reverse order of removal.

Scheme 72

GPS ANTENNA FEEDER REMOVAL/INSTALLATION

Note. GPS antenna feeder is integrated with the antenna feeder No. 1.

1. Refer to «ANTENNA FEEDER NO. 1 REMOVAL/INSTALLATION»(ref-448591-S07926824432012012000000) .

MICROPHONE REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the map light. (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-448651-S38096746852012012000000) .)
3. Press the microphone in the direction indicated by the arrow and remove the microphone.
4. Install in the reverse order of removal.

Scheme 73

REAR MOUNT CAMERA REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the trunk lid trim. (See «TRUNK LID TRIM REMOVAL/INSTALLATION»(ref-448656-S28823214402012012000000) .)
3. Remove the rear finisher. (See «REAR FINISHER REMOVAL/INSTALLATION»(ref-448621-S30655826072012012000000) .)
4. Remove the clip.
5. Disconnect the connector.
6. Remove the rear mount camera in the direction of the arrow (2) shown in the illustration while pressing the rear mount camera tab in the direction of the arrow (1).
7. Install in the reverse order of removal.

Scheme 74

Bluetooth UNIT REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: Front scuff plate (RH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-448656-S42845656582012012000000) .) Front side trim (RH) (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-448656-S24645152862012012000000) .) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-448656-S36262450112012012000000) .) Audio amplifier (With Bose®) (See «AUDIO AMPLIFIER REMOVAL/INSTALLATION»(ref-448591-S23931709092012012000000) .)
3. Remove in the order indicated in the table. PARTS DESCRIPTION CHART 1 Nut 2 Connector 3 Bluetooth unit
4. Install in the reverse order of removal.

Scheme 75

Scheme 76

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-448657-S11374618932012012000000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-448656-S21764171192012012000000) .) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-448656-S13809786282012012000000) .)
3. Remove in the order indicated in the table. With keyless entry system With advanced keyless entry and push button start system PARTS DESCRIPTION CHART 1 Accessory socket (Front) (See «ACCESSORY SOCKET REMOVAL NOTE»(ref-448591-S06315850212012012000000) .) 2 Cap (See «CAP REMOVAL NOTE»(ref-448591-S19755771892012012000000) .)
4. Install in the reverse order of removal.

Accessory Socket Removal Note

1. Remove the socket in the direction of the arrow (2) shown in the illustration while opening the caps in the direction of the arrow (1) using a tape-wrapped fastener remover.

Scheme 77

Cap Removal Note

1. Remove the cap in the direction of the arrow (2) shown in the illustration while pressing the cap tabs in the direction of the arrow (1).

Scheme 78

AUXILIARY JACK REMOVAL/INSTALLATION

1. Disconnect the negative battery cable.
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-448656-S41204061692012012000000) .) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-448657-S11374618932012012000000) .) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-448656-S21764171192012012000000) .) Decoration panel (See «DECORATION PANEL REMOVAL/INSTALLATION»(ref-448656-S12186936852012012000000) .) Center panel lower (See «CENTER PANEL LOWER REMOVAL/INSTALLATION»(ref-448656-S13809786282012012000000) .) Rear console (See «REAR CONSOLE DISASSEMBLY/ASSEMBLY»(ref-448656-S19316369282012012000000) .)
3. Remove the auxiliary jack in the direction of the arrow (2) shown in the illustration while pressing the auxiliary jack tabs in the direction of the arrow (1).
4. Install in the reverse order of removal.

Scheme 79
