Sunroof: Removal & Installation Mazda 6 GG рестайлинг

Sun Roof/t-Top/convertible Top 16 illustrations ~1833 words

FRONT DRAIN HOSE INSTALLATION

CAUTIONIf the front drain hose is pinched or bent anywhere, the water in the hose may not discharge and enter the inside of the vehicle. During and after installation of the trims and the headliner, always make sure there is no interference with the front drain hose. Fix any problem if found.
  1. Apply soapy water to the front drain hose inserting area.
  2. Insert one end (the wider end) of the front drain hose into the sunroof frame.
  3. Install the front drain hose to the clips, parallel to the pillar and free of slack.
  4. Insert the front drain hose joint into the hinge pillar inner hole.
  5. Install the headliner. (See «HEADLINER REMOVAL/INSTALLATION.»(ref-244641-S23816200972006092500000) )
  6. Install the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION.»(ref-244641-S31883545592006092500000) )
  7. Install the sunvisors. (See «SUNVISOR REMOVAL/INSTALLATION.»(ref-244641-S23073448042006092500000) )
  8. Connect the auto-dimming mirror connector, (vehicles with auto-dimming mirror only)
  9. Install the following parts: Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION [5-DOOR, SPORT WAGON].»(ref-244635-S36582438962006092500000) ) Front and rear map lights (See «FRONT MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S26300497802006092500000) ) (See «REAR MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S01848108702006092500000) ) D-pillar trims (Sport Wagon) (See «D-PILLAR TRIM REMOVAL/INSTALLATION [SPORT WAGON].»(ref-244641-S02026422192006092500000) ) C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION.»(ref-244641-S20872849472006092500000) ) B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION.»(ref-244641-S01884535062006092500000) ) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION.»(ref-244641-S32266021582006092500000) ) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION.»(ref-244641-S40068604252006092500000) ) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION.»(ref-244641-S13812292832006092500000) ) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION.»(ref-244660-S08344744252006092500000) ) A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION.»(ref-244641-S06297457352006092500000) ) Sunroof seaming welt (vehicles with sunroof only) Microphone (vehicles with car-navigation system). (See «MICROPHONE REMOVAL/INSTALLATION.»(ref-244657-S39323249942006092500000) )
  10. Install the seaming welt.

Scheme 8

Scheme 8: REAR DRAIN HOSE REMOVAL [SPORT SEDAN, 5-DOOR]
Scheme 8: REAR DRAIN HOSE REMOVAL [SPORT SEDAN, 5-DOOR]

Scheme 9

Scheme 9
Scheme 9
  1. Disconnect the negative battery cable.
  2. Partially peel back the seaming welt.
  3. Remove the following parts: Microphone (vehicles with car-navigation system). (See «MICROPHONE REMOVAL/INSTALLATION.»(ref-244657-S39323249942006092500000) ) Sunroof seaming welt (vehicles with sunroof only) A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION.»(ref-244641-S06297457352006092500000) ) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION.»(ref-244660-S08344744252006092500000) ) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION.»(ref-244641-S13812292832006092500000) ) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION.»(ref-244641-S40068604252006092500000) ) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION.»(ref-244641-S32266021582006092500000) ) B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION.»(ref-244641-S01884535062006092500000) ) C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION.»(ref-244641-S20872849472006092500000) ) D-pillar trims (Sport Wagon) (See «D-PILLAR TRIM REMOVAL/INSTALLATION [SPORT WAGON].»(ref-244641-S02026422192006092500000) ) Front and rear map lights (See «FRONT MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S26300497802006092500000) ) (See «REAR MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S01848108702006092500000) ) Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION [5-DOOR, SPORT WAGON].»(ref-244635-S36582438962006092500000) )
  4. Disconnect the auto-dimming mirror connector, (vehicles with auto-dimming mirror only)
  5. Remove the sunvisors. (See «SUNVISOR REMOVAL/INSTALLATION.»(ref-244641-S23073448042006092500000) )
  6. Remove the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION.»(ref-244641-S31883545592006092500000) )
  7. Remove the headliner. (See «HEADLINER REMOVAL/INSTALLATION.»(ref-244641-S23816200972006092500000) )
  8. Remove the trunk side trim. (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION.»(ref-244641-S12672541402006092500000) )
  9. Remove the trunk side upper trim.(5-DOOR). (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION [5-DOOR, SPORT WAGON].»(ref-244641-S11561729072006092500000) )
  10. Disconnect the rear drain hose from the sunroof frame.
  11. Remove the rear drain hose from the clips. SPORT SEDAN 5-DOOR
  12. Pull the rear drain hose into the room side.
  13. Remove the rear drain hose.

Scheme 10

Scheme 10: REAR DRAIN HOSE REMOVAL [SPORT WAGON]
Scheme 10: REAR DRAIN HOSE REMOVAL [SPORT WAGON]
  1. Disconnect the negative battery cable.
  2. Partially peel back the seaming welt.
  3. Remove the following parts: Microphone (vehicles with car-navigation system). (See «MICROPHONE REMOVAL/INSTALLATION.»(ref-244657-S39323249942006092500000) ) Sunroof seaming welt (vehicles with sunroof only) A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION.»(ref-244641-S06297457352006092500000) ) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION.»(ref-244660-S08344744252006092500000) ) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION.»(ref-244641-S13812292832006092500000) ) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION.»(ref-244641-S40068604252006092500000) ) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION.»(ref-244641-S32266021582006092500000) ) B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION.»(ref-244641-S01884535062006092500000) ) C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION.»(ref-244641-S20872849472006092500000) ) D-pillar trims (Sport Wagon) (See «D-PILLAR TRIM REMOVAL/INSTALLATION [SPORT WAGON].»(ref-244641-S02026422192006092500000) ) Front and rear map lights (See «FRONT MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S26300497802006092500000) ) (See «REAR MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S01848108702006092500000) ) Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION [5-DOOR, SPORT WAGON].»(ref-244635-S36582438962006092500000) )
  4. Disconnect the auto-dimming mirror connector, (vehicles with auto-dimming mirror only)
  5. Remove the sunvisors. (See «SUNVISOR REMOVAL/INSTALLATION.»(ref-244641-S23073448042006092500000) )
  6. Remove the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION.»(ref-244641-S31883545592006092500000) )
  7. Remove the headliner. (See «HEADLINER REMOVAL/INSTALLATION.»(ref-244641-S23816200972006092500000) )
  8. Remove the trunk side trim. (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION.»(ref-244641-S12672541402006092500000) )
  9. Remove the trunk side upper trim. (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION [5-DOOR, SPORT WAGON].»(ref-244641-S11561729072006092500000) )
  10. Disconnect the rear drain hose from the sunroof frame.
  11. Remove the rear drain hose from the clips.
  12. Pull the rear drain hose into the room side.
  13. Remove the rear drain hose.

REAR DRAIN HOSE INSTALLATION

CAUTIONIf the rear drain hose is pinched or bent anywhere, the water in the hose may not discharge and enter the inside of the vehicle. During and after installation of the trims and the head liner, always make sure there is no interference with the rear drain hose. Fix any problem if found.
  1. Apply soapy water to the rear drain hose inserting area.
  2. Insert one end (the wider side) of the rear drain hose into the sunroof frame.
  3. Install the rear drain hose to the clips parallel to the pillar and free of slack.
  4. Insert the rear drain hose joint into the rear pillar inner hole.
  5. Install the trunk side trim. (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION.»(ref-244641-S12672541402006092500000) )
  6. Install the trunk side upper trim (5-DOOR, SPORT WAGON). (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION [5-DOOR, SPORT WAGON].»(ref-244641-S11561729072006092500000) )
  7. Install the headliner. (See «HEADLINER REMOVAL/INSTALLATION.»(ref-244641-S23816200972006092500000) )
  8. Install the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION.»(ref-244641-S31883545592006092500000) )
  9. Install the sunvisors. (See «SUNVISOR REMOVAL/INSTALLATION.»(ref-244641-S23073448042006092500000) )
  10. Connect the auto-dimming mirror connector, (vehicles with auto-dimming mirror only)
  11. Install the following parts: Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION [5-DOOR, SPORT WAGON].»(ref-244635-S36582438962006092500000) ) Front and rear map lights (See «FRONT MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S26300497802006092500000) ) (See «REAR MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S01848108702006092500000) ) D-pillar trims (Sport Wagon) (See «D-PILLAR TRIM REMOVAL/INSTALLATION [SPORT WAGON].»(ref-244641-S02026422192006092500000) ) C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION.»(ref-244641-S20872849472006092500000) ) B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION.»(ref-244641-S01884535062006092500000) ) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION.»(ref-244641-S32266021582006092500000) ) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION.»(ref-244641-S40068604252006092500000) ) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION.»(ref-244641-S13812292832006092500000) ) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION.»(ref-244660-S08344744252006092500000) ) A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION.»(ref-244641-S06297457352006092500000) ) Sunroof seaming welt (vehicles with sunroof only) Microphone (vehicles with car-navigation system). (See «MICROPHONE REMOVAL/INSTALLATION.»(ref-244657-S39323249942006092500000) )
  12. Install the seaming welt.

Scheme 11

Scheme 11: SUNROOF UNIT REMOVAL/INSTALLATION
Scheme 11: SUNROOF UNIT REMOVAL/INSTALLATION
  1. Disconnect the negative battery cable.
  2. Partially peel back the seaming welt.
  3. Remove the following parts: Microphone (vehicles with car-navigation system). (See «MICROPHONE REMOVAL/INSTALLATION.»(ref-244657-S39323249942006092500000) ) Sunroof seaming welt (vehicles with sunroof only) A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION.»(ref-244641-S06297457352006092500000) ) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION.»(ref-244660-S08344744252006092500000) ) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION.»(ref-244641-S13812292832006092500000) ) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION.»(ref-244641-S40068604252006092500000) ) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION.»(ref-244641-S32266021582006092500000) ) B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION.»(ref-244641-S01884535062006092500000) ) C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION.»(ref-244641-S20872849472006092500000) ) D-pillar trims (Sport Wagon) (See «D-PILLAR TRIM REMOVAL/INSTALLATION [SPORT WAGON].»(ref-244641-S02026422192006092500000) ) Front and rear map lights (See «FRONT MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S26300497802006092500000) ) (See «REAR MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S01848108702006092500000) ) Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION [5-DOOR, SPORT WAGON].»(ref-244635-S36582438962006092500000) )
  4. Disconnect the auto-dimming mirror connector, (vehicles with auto-dimming mirror only)
  5. Remove the sunvisors. (See «SUNVISOR REMOVAL/INSTALLATION.»(ref-244641-S23073448042006092500000) )
  6. Remove the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION.»(ref-244641-S31883545592006092500000) )
  7. Remove the headliner. (See «HEADLINER REMOVAL/INSTALLATION.»(ref-244641-S23816200972006092500000) )
  8. Remove the glass panel. (See «GLASS PANEL REMOVAL/INSTALLATION»(ref-244685-S21857569762006092600000) ).
  9. Disconnect the front and rear drain hose from the sunroof frame.
  10. Remove the bolt A, and then remove the rear set bracket.
  11. Remove the bolt B and nuts, and then remove the sunroof unit.
  12. Install in the reverse order of removal.
  13. Adjust the glass panel. (See «GLASS PANEL ADJUSTMENT»(ref-244685-S15715735122006092600000) ).

Scheme 12

Scheme 12: SUNROOF UNIT DISASSEMBLY/ASSEMBLY
Scheme 12: SUNROOF UNIT DISASSEMBLY/ASSEMBLY
  1. Disassemble in the order indicated in the table.
  2. Assemble in the reverse order of disassembly.

Scheme 13

Scheme 13: Slider Disassembly Note
Scheme 13: Slider Disassembly Note
  1. Remove the screw.
  2. Slide the slider rearward, and remove it from the sunroof frame.

Scheme 14

Scheme 14: Guide Disassembly Note
Scheme 14: Guide Disassembly Note
  1. Slide the guide rearward, and remove it from the sunroof frame.

Scheme 15

Scheme 15: Decoration Link Assembly Note
Scheme 15: Decoration Link Assembly Note
  1. Set the pin in the decoration link.

Scheme 16

Scheme 16: Guide Assembly Note
Scheme 16: Guide Assembly Note
  1. Move the guide by hand until it comes to the front stopper.
  2. Move the guide by hand until center of pin comes between mark A and B.

Scheme 17

Scheme 17: SUNROOF MOTOR REMOVAL
Scheme 17: SUNROOF MOTOR REMOVAL
  1. Disconnect the negative battery cable.
  2. Partially peel back the seaming welt.
  3. Remove the following parts: Microphone (vehicles with car-navigation system). (See «MICROPHONE REMOVAL/INSTALLATION.»(ref-244657-S39323249942006092500000) ) Sunroof seaming welt (vehicles with sunroof only) A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION.»(ref-244641-S06297457352006092500000) ) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION.»(ref-244660-S08344744252006092500000) ) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION.»(ref-244641-S13812292832006092500000) ) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION.»(ref-244641-S40068604252006092500000) ) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION.»(ref-244641-S32266021582006092500000) ) B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION.»(ref-244641-S01884535062006092500000) ) C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION.»(ref-244641-S20872849472006092500000) ) D-pillar trims (Sport Wagon) (See «D-PILLAR TRIM REMOVAL/INSTALLATION [SPORT WAGON].»(ref-244641-S02026422192006092500000) ) Front and rear map lights (See «FRONT MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S26300497802006092500000) ) (See «REAR MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S01848108702006092500000) ) Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION [5-DOOR, SPORT WAGON].»(ref-244635-S36582438962006092500000) )
  4. Disconnect the auto-dimming mirror connector, (vehicles with auto-dimming mirror only)
  5. Remove the sunvisors. (See «SUNVISOR REMOVAL/INSTALLATION.»(ref-244641-S23073448042006092500000) )
  6. Remove the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION.»(ref-244641-S31883545592006092500000) )
  7. Remove the headliner. (See «HEADLINER REMOVAL/INSTALLATION.»(ref-244641-S23816200972006092500000) )
  8. Disconnect the connector.
  9. Remove the screws, and then remove the sunroof motor.
  1. Connect the sunroof motor connector.
  2. Connect the sunroof switch connector.
  3. Connect the negative battery cable.
  4. Turn the ignition switch to ON position.
  5. Press the CLOSE side of the slide switch until the sunroof motor stops.
  6. Disconnect the sunroof switch connector.
  7. Install the screws, and then install the sunroof motor.
  8. Install the headliner. (See «HEADLINER REMOVAL/INSTALLATION.»(ref-244641-S23816200972006092500000) )
  9. Install the assist handle. (See «ASSIST HANDLE REMOVAL/INSTALLATION.»(ref-244641-S31883545592006092500000) )
  10. Install the sunvisors. (See «SUNVISOR REMOVAL/INSTALLATION.»(ref-244641-S23073448042006092500000) )
  11. Connect the auto-dimming mirror connector, (vehicles with auto-dimming mirror only)
  12. Install the following parts: Cargo compartment light (See «CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION [5-DOOR, SPORT WAGON].»(ref-244635-S36582438962006092500000) ) Front and rear map lights (See «FRONT MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S26300497802006092500000) ) (See «REAR MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S01848108702006092500000) ) D-pillar trims (Sport Wagon) (See «D-PILLAR TRIM REMOVAL/INSTALLATION [SPORT WAGON].»(ref-244641-S02026422192006092500000) ) C-pillar trims (See «C-PILLAR TRIM REMOVAL/INSTALLATION.»(ref-244641-S20872849472006092500000) ) B-pillar upper trims (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION.»(ref-244641-S01884535062006092500000) ) B-pillar lower trims (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION.»(ref-244641-S32266021582006092500000) ) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION.»(ref-244641-S40068604252006092500000) ) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION.»(ref-244641-S13812292832006092500000) ) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION.»(ref-244660-S08344744252006092500000) ) A-pillar trims (See «A-PILLAR TRIM REMOVAL/INSTALLATION.»(ref-244641-S06297457352006092500000) ) Sunroof seaming welt (vehicles with sunroof only) Microphone (vehicles with car-navigation system). (See «MICROPHONE REMOVAL/INSTALLATION.»(ref-244657-S39323249942006092500000) )
  13. Install the seaming welt.

Scheme 18

Scheme 18: Motor
Scheme 18: Motor
  1. Apply battery positive voltage to the sunroof motor terminals and inspect the operation of the sunroof motor. If not as specified, replace the sunroof motor. MOTOR OPERATION REFERENCE Connection Motor operation 2A 2B B+ GND Turn left (Slide close/Tilt up) GND B+ Turn right (Slide open/Tilt down)

Scheme 19

Scheme 19: Limit Switch
Scheme 19: Limit Switch

Scheme 20

Scheme 20
Scheme 20
  1. Inspect for continuity between the sunroof motor terminals using an ohmmeter. If not as specified, replace the sunroof motor.

Note. Sunroof relay is built in the sunroof motor.

  1. Measure the voltage at the sunroof relay terminals as indicated below.
  2. Disconnect the sunroof relay connector before inspecting for continuity at terminal 1G If not as specified, inspect the parts listed under "Action" and the related wiring harnesses. If the parts and wiring harnesses are okay but the system still does not work properly, replace the sunroof relay.

Scheme 21

Scheme 21: Terminal voltage list (Reference)
Scheme 21: Terminal voltage list (Reference)
TerminalSignalConnected toTest conditionVoltage (V)/ContinuityAction
1ATilt downSunroof switchSunroof is tilting down. (Not including position when fully closed)0Inspect sunroof switch (See SUNROOF SWITCH INSPECTION ). Inspect related harness
OtherB+
1BIG2Sunroof motorIgnition switch is at ON position.B+Inspect A/C 15 A fuse Inspect sunroof switch (See SUNROOF SWITCH INSPECTION ). Inspect related harness
Other0
1C
1DSlide closeSunroof switchSunroof is closing. (Including position when fully closed and open)0Inspect sunroof switch (See SUNROOF SWITCH INSPECTION ). Inspect related harness
OtherB+
1E
1FSlide openSunroof switchSunroof is fully opening.0Inspect sunroof switch (See SUNROOF SWITCH INSPECTION ). Inspect related harness
OtherB+
1GSunroof relay groundGNDUnder any condition: inspect for continuity to ground.YesInspect related harness
1HTilt upSunroof switchSunroof is tilting up. (Including position when fully closed)0Inspect sunroof switch (See SUNROOF SWITCH INSPECTION ). Inspect related harness
OtherB+
2ASlide close/tilt upSunroof motorSunroof is opening/tilting down.0Inspect sunroof switch (See SUNROOF SWITCH INSPECTION ). Inspect sunroof motor (See SUNROOF MOTOR INSPECTION ). Inspect related harness
Sunroof is closing/tilting up.B+
Other0
2BSlide open/tilt downSunroof motorSunroof is opening/tilting down.B+Inspect sunroof switch (See SUNROOF SWITCH INSPECTION ). Inspect sunroof motor (See SUNROOF MOTOR INSPECTION ). Inspect related harness
Sunroof is closing/tilting up.0
Other0

TEST CONDITION REFERENCE

Note. The sunroof switch is together with the front map light.

  1. Disconnect the negative battery cable.
  2. Remove the front map light from the headliner. (See «FRONT MAP LIGHT REMOVAL/INSTALLATION.»(ref-244635-S26300497802006092500000) )
  3. Install in the reverse order of removal.

Scheme 22

Scheme 22: SUNROOF SWITCH INSPECTION
Scheme 22: SUNROOF SWITCH INSPECTION

Scheme 23

Scheme 23
Scheme 23
  1. Inspect for continuity between the sunroof switch terminals using an ohmmeter. If not as specified, replace the sunroof switch.
