Entertainment System: Removal & Installation Mazda 6 GG рестайлинг

AUDIO CONTROL SWITCH REMOVAL/INSTALLATION

Note. The audio control switch and the cruise control switch use a common connector.

Scheme 6

1. Disconnect the negative battery cable.
2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION.»(ref-244613-S16650402922006092500000) )
3. Remove the steering wheel.
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.

Scheme 7

Scheme 8

1. Disconnect the negative battery cable.
2. Remove the driver-side air bag module. (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION.»(ref-244613-S16650402922006092500000) )
3. Disconnect the audio control switch connector.
4. Measure the resistance and inspect for continuity between the cruise control switch terminals using an ohmmeter. If not as specified, replace the cruise control switch.

Scheme 9

1. Disconnect the negative battery cable.
2. Remove the front seat (driver-side). (See «FRONT SEAT REMOVAL/INSTALLATION [L3 WITH TC].»(ref-244642-S36408855162006092500000) ) (See «FRONT SEAT REMOVAL/INSTALLATION [EXCEPT L3 WITH TC].»(ref-244642-S08168236352006092500000) )
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 10

1. Disconnect the negative battery cable.
2. Remove the front door trim.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 11

1. Attach the speaker with the wiring harness placed in the groove of the door unit panel. CAUTION: If the speaker is attached with the harness placed outside of the groove, the wiring harness might be broken.

Scheme 12

Scheme 13

1. Inspect for resistance between the front door speaker terminals using an ohmmeter. If not as specified, replace the front door speaker.
2. To verify that the front door speaker outputs sound, apply voltage to the front door speaker and release using a 1.5 V battery. If it does not output sound, replace the front door speaker.

Scheme 14

1. Disconnect the negative battery cable.
2. Remove the rear door trim.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 15

1. Attach the speaker with the wiring harness placed in the groove of the door unit panel. CAUTION: If the speaker is attached with the harness placed outside of the groove, the wiring harness might be broken.

Scheme 16

Scheme 17

1. Inspect for resistance between the rear door speaker terminals using an ohmmeter. If not as specified, replace the rear door speaker.
2. To verify that the rear door speaker outputs sound, apply voltage to the rear door speaker and release using a 1.5 V battery. If it does not output sound, replace the rear door speaker.

Scheme 18

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.

Scheme 19

Scheme 20

1. To verify the front door speaker outputs sound. If it does output sound, then go to next step. If it does not output sound, inspect the front door speaker and related wiring harnesses. (See «FRONT DOOR SPEAKER INSPECTION»(ref-244657-S20920057532006092500000) ).
2. Remove the center panel module. (See «CENTER PANEL UNIT REMOVAL/INSTALLATION»(ref-244657-S17392612222006092500000) ).
3. Inspect for continuity between the tweeter connector terminals and audio unit connector terminals using an ohmmeter. If there is no continuity, replace the related wiring harnesses. If there is continuity, replace the tweeter.

Scheme 21

1. Disconnect the negative battery cable.
2. Remove the rear package trim.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 22

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.

Scheme 23

Scheme 24

1. Inspect for continuity between the audio amplifier connector terminals and woofer connector terminals using an ohmmeter. If not as specified, replace the related wiring harnesses.
2. Verify that there is battery positive voltage at the woofer connector terminal A using a voltmeter. If not as specified, replace the related wiring harness.
3. Inspect continuity between the woofer connector terminal B and body ground using an ohmmeter. If not as specified, replace the related wiring harness. If as specified, replace the woofer.

Scheme 25

Scheme 26

1. Inspect for continuity between the audio amplifier connector terminals and woofer connector terminals using an ohmmeter. If not as specified, replace the related wiring harnesses.
2. Verify that there is battery positive voltage at the woofer connector terminal C using a voltmeter. If not as specified, replace the related wiring harness.
3. Inspect continuity between the woofer connector terminal B and body ground using an ohmmeter. If not as specified, replace the related wiring harness. If as specified, replace the woofer.

Scheme 27

1. Disconnect the negative battery cable.
2. Remove the rear package trim.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 28

1. Disconnect the negative battery cable.
2. Remove the liftgate lower trim.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 29

1. Disconnect the negative battery cable.
2. Remove the liftgate lower trim.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 30

1. Disconnect the negative battery cable.
2. Remove the headliner. (See «HEADLINER REMOVAL/INSTALLATION.»(ref-244641-S23816200972006092500000) )
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.
5. After installation, verify that the rubber of the center roof antenna is installed to the roof panel with no space between them.

Scheme 31

Scheme 32

1. Verify that there is no continuity between the center roof antenna terminals A and C using an ohmmeter.
2. Inspect for continuity between the center roof antenna terminals using an ohmmeter. If not as specified, replace the center roof antenna.

Scheme 33

1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.

Scheme 34

1. Disconnect the negative battery cable.
2. Remove the instrument cluster.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

1. Verify that there is no continuity between the front antenna feeder terminals A and B using an ohmmeter.
2. Inspect for continuity between the front antenna feeder terminals using an ohmmeter. If not as specified, replace the instrument panel harness.

Scheme 40

Scheme 41

1. Verify that there is no continuity between antenna feeder terminals A and B using an ohmmeter.
2. Inspect for continuity between the antenna feeder terminals using an ohmmeter. If not as specified, replace the rear harness.

Scheme 42

Scheme 43

1. Verify that there is no continuity between antenna feeder terminals A and B using an ohmmeter.
2. Inspect for continuity between the antenna feeder terminals using an ohmmeter. If not as specified, replace the rear harness.

Scheme 44

Scheme 45

1. Verify that there is no continuity between antenna feeder terminals A and B using an ohmmeter.
2. Inspect for continuity between the antenna feeder terminals using an ohmmeter. If not as specified, replace the rear harness.

Scheme 46

Scheme 47

1. Verify that there is no continuity between the GPS antenna feeder terminal A and B.
2. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the GPS antenna feeder.

Scheme 48

1. Disconnect the negative battery cable.
2. Remove the panel No.1. (See «CONSOLE REMOVAL/INSTALLATION.»(ref-244641-S30388317692006092500000) )
3. Remove the panel No.2. (See «CONSOLE REMOVAL/INSTALLATION.»(ref-244641-S30388317692006092500000) )
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.

Scheme 49

1. Disconnect the negative battery cable.
2. Remove the console. (See «CONSOLE REMOVAL/INSTALLATION.»(ref-244641-S30388317692006092500000) )
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 50

1. Remove the socket by pushing on the protrusion with a tape-wrapped flathead screwdriver inserted through the socket hole, and pulling the socket toward you.

Scheme 51

1. Pull the cap forward while squeezing the tabs.

Scheme 52

1. Remove the accessory socket. (See «ACCESSORY SOCKET REMOVAL/INSTALLATION»(ref-244657-S31682385562006092600000) ).
2. Inspect for continuity between the accessory socket terminals B and C using an ohmmeter as shown in the figure. If not as specified, replace the accessory socket.
