AIR CLEANER ELEMENT INSPECTION [L3]
- Remove the air cleaner element. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [L3]»(ref-244570-S29535323642006092500000) ).
- Verify that the air cleaner element surface is free of dirt. If there is dirt, use an air gun or similar tool to clean the element. If the replacement time limit has passed, replace the element.
Scheme 134
![Scheme 134: VARIABLE AIR DUCT (VAD) SHUTTER VALVE INSPECTION [L3]](https://i.diagnostdata.com/repair/62/62d1e9460a484dd6c1b9307a87bca1bfde7d1ca93cdd8dd17d7b2897d6803a2e.webp)
Scheme 135
- Remove the air cleaner case. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [L3]»(ref-244570-S29535323642006092500000) ).
- Disconnect the vacuum hose from the VAD shutter valve actuator.
- Connect a vacuum pump to the VAD shutter valve actuator.
- Apply vacuum and verify that the rod moves. If the rod does not move, replace the air cleaner. (Scheme 134): Inspecting VAD Shutter Valve Actuator ROD MOVEMENT CHART Vacuum kPa {mmHg, inHg} Rod movement Below-10 {-75,-3.0} Not move Above-35 {-263,-10.4} Fully pulled (Scheme 135): Locating VAD Shutter Valve Actuator
Scheme 136
![Scheme 136: VARIABLE AIR DUCT (VAD) CONTROL SOLENOID VALVE INSPECTION [L3]](https://i.diagnostdata.com/repair/07/07fc8a4b5084eacabd7cbf37925fc669ef4db428b36fb5e5bd39beb86ff344c5.webp)
Scheme 137
- Remove the VAD control solenoid valve. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [L3]»(ref-244570-S29535323642006092500000) ).
- Inspect airflow between the ports under the following conditions. If not as specified, replace the VAD control solenoid valve. If as specified, carry out the "Circuit Open/Short Inspection". (Scheme 136): Checking VAD Control Solenoid Valve (Scheme 137): Identifying VAD Control Solenoid Valve Ports & Connector Terminals
Scheme 138
- Disconnect the PCM connector. (See «PCM REMOVAL/INSTALLATION [L3]»(ref-244558-S14017244512006092500000) ).
- Inspect the following wiring harness for open or short circuit (continuity check). (Scheme 138): Identifying VAD Control Solenoid Valve Connector Terminals
Scheme 139
- If there is no continuity, there is an open circuit. Repair or replace the harness. VAD control solenoid valve terminal B and PCM terminal 1K VAD control solenoid valve terminal A and main relay terminal C (Scheme 139): PCM Connector Terminal Identification
THROTTLE ACTUATOR INSPECTION [L3]
Note. Perform the following inspection only when directed.
Resistance Inspection
- Disconnect the negative battery cable.
- Disconnect the throttle body connector.
- Measure the resistance between the throttle actuator terminals using an ohmmeter. If not as specified, replace the throttle body. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [L3]»(ref-244570-S29535323642006092500000) ). If as specified, carry out the "Circuit Open/Short Inspection".
Specification
| Ambient temperature (°C {°F}) | Resistance (ohm) |
|---|---|
| Approx. 20 {68} | 0.3-100 |
AMBIENT TEMPERATURE SPECIFICATION
Throttle Body Harness Connector. Scheme 140
Scheme 141
- Disconnect the PCM connector. (See «PCM REMOVAL/INSTALLATION [L3]»(ref-244558-S14017244512006092500000) ).
- Inspect the following wiring harnesses for open or short circuit (continuity check). (Scheme 141): Identifying Throttle Actuator Harness Connector Terminals
Scheme 142
- If there is no continuity, there is an open circuit. Repair or replace the harness. Throttle actuator terminal F and PCM terminal 2A Throttle actuator terminal E and PCM terminal 2B (Scheme 142): PCM Connector Terminal Identification
