Engine - Intake-Air System (Aj): Other Mazda 6 GG рестайлинг

Open circuit

1. If there is no continuity, there is an open circuit. Repair or replace the harness. VAD control solenoid valve terminal B and PCM terminal 1BB VAD control solenoid valve terminal A and main relay terminal C

Short circuit

1. If there is continuity, there is a short circuit. Repair or replace the harness. VAD control solenoid valve terminal B and body ground VAD control solenoid valve terminal A and power supply

Scheme 199

1. Remove the VAD check valve (one-way). (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [AJ]»(ref-244591-S27284000802006092500000) ).
2. Blow through A and verify that air flows from B.
3. Blow through B and verify that air does not flow from A. If not as specified, replace the VAD check valve (one-way).

1. If there is no continuity, there is an open circuit. Repair or replace the harness. Throttle actuator terminal B and PCM terminal 2A Throttle actuator terminal A and PCM terminal 2B

1. If there is continuity, there is a short circuit. Repair or replace the harness. Throttle actuator terminal B and power supply Throttle actuator terminal B and body ground Throttle actuator terminal A and power supply Throttle actuator terminal A and body ground

Scheme 200

1. Remove in the order indicated in the table.
2. Install in the reverse order of removal.
