Engine - Intake-Air System (Aj): Diagnosis Mazda 6 GG рестайлинг

Mechanical 6 illustrations ~353 words

AIR CLEANER ELEMENT INSPECTION [AJ]

  1. Remove the air cleaner element. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [AJ]»(ref-244591-S27284000802006092500000) ).
  2. Verify that the air cleaner element surface is free of dirt. If there is dirt present, use an air gun or similar tool to clean the element. If the replacement time limit has passed, replace the element.

Scheme 190

Scheme 190: VARIABLE AIR DUCT (VAD) SHUTTER VALVE INSPECTION [AJ]
Scheme 190: VARIABLE AIR DUCT (VAD) SHUTTER VALVE INSPECTION [AJ]
  1. Remove the air cleaner case. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [AJ]»(ref-244591-S27284000802006092500000) ).
  2. Disconnect the vacuum hose from the VAD shutter valve actuator.
  3. Connect a vacuum pump to the VAD shutter valve actuator.
  4. Apply vacuum and verify that the rod moves. If the rod does not move, replace the air cleaner case.
Vacuum kPa {mmHg, inHg}Rod movement
Below-10 {-75,-3.0}Starts to move
Above -35 {-263, -10.4}Fully pulled

VACUUM SPECIFICATIONS

Scheme 191

Scheme 191
Scheme 191

Scheme 192

Scheme 192: VARIABLE AIR DUCT (VAD) CONTROL SOLENOID VALVE INSPECTION [AJ]
Scheme 192: VARIABLE AIR DUCT (VAD) CONTROL SOLENOID VALVE INSPECTION [AJ]

Scheme 193

Scheme 193
Scheme 193
  1. Remove the VAD control solenoid valve. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [AJ]»(ref-244591-S27284000802006092500000) ).
  2. Inspect airflow between the ports under the following conditions. If not as specified, replace the VAD control solenoid valve. If as specified, carry out the "Circuit Open/Short Inspection".

Scheme 194

Scheme 194: Circuit Open/Short Inspection
Scheme 194: Circuit Open/Short Inspection
  1. Disconnect the PCM connector. (See «PCM REMOVAL/INSTALLATION [AJ]»(ref-244588-S05391869182006092500000) ).
  2. Inspect the following wiring harness for open or short circuit (continuity check).

THROTTLE ACTUATOR INSPECTION [AJ]

CAUTIONWhen the ignition switch is turned to the ON position, the PCM operates the throttle actuator to adjust the throttle valve position. At this time, do not touch the valve to open or close it because your fingers could be pinched.

Note. Perform the following inspection only when directed.

Visual Inspection

  1. Verify that no DTCs related stored to the TP or APP sensors have been stored. If any DTCs have been stored, perform the applicable DTC inspection. (See «DTC TABLE [AJ]»(ref-244586-S20995036072006092500000) ).
  2. Remove the air hose from the throttle body. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [AJ]»(ref-244591-S27284000802006092500000) ).
  3. Turn the ignition switch to the ON position.
  4. Operate the accelerator pedal and verify that the throttle valve opens and closes in accordance with the pedal movement. If it cannot be verified, perform the "Continuity Inspection".

Continuity Inspection

  1. Disconnect the negative battery cable.
  2. Disconnect the throttle actuator connector.
  3. Inspect for continuity between the throttle actuator terminals A and B using an ohmmeter. If not as specified, replace the throttle body. (See «INTAKE AIR SYSTEM REMOVAL/INSTALLATION [AJ]»(ref-244591-S27284000802006092500000) ). If as specified, perform the "Circuit Open/Short Inspection".

Scheme 195

Scheme 195: Circuit Open/Short Inspection
Scheme 195: Circuit Open/Short Inspection
  1. Disconnect the PCM connector. (See «PCM REMOVAL/INSTALLATION [AJ]»(ref-244588-S05391869182006092500000) ).
  2. Inspect the following wiring harnesses for open or short circuit (continuity check).
