Control System (HVAC): Overview Mazda 6 GG рестайлинг

Scheme 26

Scheme 27

Scheme 28

Scheme 29

1. Disconnect the negative battery cable.
2. Remove the glove compartment.
3. Remove the duct (1). See «A/C UNIT REMOVAL/INSTALLATION [L3, AJ].»
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.

Scheme 30

1. Disconnect the negative battery cable.
2. Remove the glove compartment. See «GLOVE COMPARTMENT REMOVAL/INSTALLATION.»
3. Remove the car navigation unit. See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION.»
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.

Scheme 31

Scheme 32

1. Connect battery positive voltage to terminal G or H and ground to terminal H or G of the air intake actuator.
2. Verify that the air intake actuator operates as shown below. If not as specified, replace the air intake actuator. AIR INTAKE ACTUATOR OPERATION REFERENCE Connection Movement B+ GND G H RECIRCULATE <-- FRESH H G FRESH <-- RECIRCULATE

Scheme 33

Scheme 34

1. Connect battery positive voltage to terminal D or F and ground to terminal F or D of the air intake actuator.
2. Verify that the air intake actuator operates as shown below. If there is any malfunction, replace the air intake actuator. AIR INTAKE ACTUATOR OPERATION REFERENCE Connection Movement B+ GND D F RECIRCULATE --> FRESH F D FRESH --> RECIRCULATE

Scheme 35

1. Disconnect the negative battery cable.
2. Remove the glove compartment.
3. Remove in the order indicated in the table.
4. Install in the reverse order of removal.

Scheme 36

1. Disconnect the negative battery cable.
2. Remove the following parts: Glove compartment. See «GLOVE COMPARTMENT REMOVAL/INSTALLATION.» Console. See «CONSOLE REMOVAL/INSTALLATION.» Meter hood. See «METER HOOD REMOVAL/INSTALLATION.» Instrument cluster. See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION.» ) Column cover. See «COLUMN COVER REMOVAL/INSTALLATION.» Lower panel. See «LOWER PANEL REMOVAL/INSTALLATION.» Steering shaft. See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION.» A-pillar trim. See «A-PILLAR TRIM REMOVAL/INSTALLATION.» Front scuff plate. See «FRONT SCUFF PLATE REMOVAL/INSTALLATION.» Front side trim. See «FRONT SIDE TRIM REMOVAL/INSTALLATION.» Side panel. See «SIDE PANEL REMOVAL/INSTALLATION.»
3. Remove the dashboard. See «DASHBOARD REMOVAL/INSTALLATION.»
4. Remove the A/C unit installation nuts. See «A/C UNIT REMOVAL/INSTALLATION [L3 WITH TC].»
5. Remove the blower unit. See «BLOWER UNIT REMOVAL/INSTALLATION [L3 WITH TC].»
6. Remove the duct (2).
7. Remove in the order indicated in the table.
8. Install in the reverse order of removal.

Scheme 37

Scheme 38

1. Verify that the resistance between the terminals of the air mix actuator is as shown in the table. If not as specified, replace the air mix actuator. AIR MIX ACTUATOR RESISTANCE SPECIFICATIONS Terminal Resistance (ohm) B-A 100 B-C 100 B-D 100 B-F 100
