FRONT COMBINATION LIGHT REMOVAL/INSTALLATION

WARNINGIncorrect servicing of the discharge headlights could result in electrical shock. Before servicing the discharge headlights, always refer to the discharge headlight service warnings. (See DISCHARGE HEADLIGHT SERVICE WARNINGS ).

Scheme 52

Scheme 52
  1. Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-292887-S30644836642008080600000) ).
  2. Disconnect the negative battery cable.
  3. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-292918-S11216097782008080600000) ).
  4. Remove in the order indicated in the table.
  5. Install in the reverse order of removal.
  6. Adjust the headlight aiming. (See «HEADLIGHT AIMING»(ref-292924-S27445664592008080600000) )

FRONT COMBINATION LIGHT BRACKET REPLACEMENT

Note. Verify that the front combination light is not damaged before using the repair bracket for installation when the original brackets are damaged. If the front combination light component is damaged, replace the light as a single unit.

Scheme 53

Scheme 53: FRONT COMBINATION LIGHT BRACKET REPLACEMENT

Scheme 54

Scheme 54
  1. Cut off the front combination light brackets at the locations shown in the figure. CAUTION: Be careful not to cut off the positioning pin. NOTE: After roughly cutting off the brackets, position the repair bracket using the positioning pins, and gradually smoothen any rough areas to create a shape that facilitates installation.
  2. Smoothen the cut surfaces using sandpaper so that the repair bracket can be properly installed.
  3. Securely attach the repair bracket to the front combination light using the screws.

Scheme 55

Scheme 55: HEADLIGHT AIMING

Scheme 56

Scheme 56
  1. Adjust the tire pressure to the specification.
  2. Position the unloaded vehicle on a flat, level surface.
  3. Seat one person in the driver's seat.
  4. Position the vehicle straight ahead and perpendicular to the white screen.
  5. Set the headlights 3 m {9.8 ft} from the white screen.
  6. Place an object in front of the headlight not being adjusted to block its light beam.
  7. Start the engine so that the battery remains charged.
  8. Turn on the low-beam headlight.
  9. Adjust by turning the aiming adjustment screw so that elbow point is in the position shown in the figure.

Scheme 57

Scheme 57: Halogen type
  1. Disconnect the negative battery cable.
  2. Disconnect the connector. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
  3. Remove the cover.
  4. Remove the socket, then remove the headlight bulb.
  5. Install in the reverse order of removal.

DISCHARGE HEADLIGHT CONTROL MODULE REMOVAL/INSTALLATION

WARNINGIncorrect servicing of the discharge headlights could result in electrical shock. Before servicing the discharge headlights, always refer to the discharge headlight service warnings. (See DISCHARGE HEADLIGHT SERVICE WARNINGS )

Scheme 58

Scheme 58
  1. Disconnect the negative battery cable.
  2. Remove the front bumper. (See «FRONT BUMPER REMOVAL/INSTALLATION»(ref-292918-S11216097782008080600000) ).
  3. Remove the front combination light. (See «FRONT COMBINATION LIGHT REMOVAL/INSTALLATION»(ref-292924-S03161410862008080600000) ).
  4. Remove screws.
  5. Disconnect the connector.
  6. Remove the discharge headlight control module.
  7. Install in the reverse order of removal.

Scheme 59

Scheme 59: Discharge Headlight Inoperative
