STARTER REMOVAL/INSTALLATION [L3]
| WARNING | Remove and install all parts when the engine is cold, otherwise they can cause severe burns or serious injury. When the battery cables are connected, touching the vehicle body with starter terminal B will generate sparks. This can cause personal injury, fire, and damage to the electrical components. Always disconnect the negative battery cable before performing the following operation. |
Scheme 20
- Remove the battery cover. (See «BATTERY REMOVAL/INSTALLATION [L3]»(ref-292887-S30644836642008080600000) .)
- Disconnect the negative battery cable.
- Remove the under cover.
- Remove the clutch release cylinder with the pipes still connected. (MTX) (See «MANUAL TRANSAXLE REMOVAL/INSTALLATION [G35M-R]»(ref-292919-S38436963682008080600000) .)
- Remove in the order indicated in the table.
- Install in the reverse order of removal.
Starter Installation Note
Note. If there is peeling on or damage to the insulator, attach a new insulator using the following procedure
Scheme 21
Scheme 22
Scheme 23
- Peel off the insulator from the starter completely using a scraper.
- Degrease the insulator attachment area.
- Attach a new insulator to the starter.
