Charging System (L3): Overview Mazda 5 I

Scheme 1

Scheme 2

1. Remove in the order indicated in the table.
2. Install in the reverse order of removal. BATTERY COMPONENT CHART 1 Battery cover (See «BATTERY COVER INSTALLATION NOTE» ). 2 Negative battery cable 3 Positive battery cable 4 Battery duct (See «BATTERY DUCT INSTALLATION NOTE» ). 5 Battery box (See «BATTERY BOX INSTALLATION NOTE» ). 6 Battery clamp (See «BATTERY CLAMP INSTALLATION NOTE» ). 7 Battery 8 PCM cover (See «PCM COVER INSTALLATION NOTE» ). 9 Connectors 10 Battery tray and PCM component

Scheme 3

Scheme 4

1. Install with the PCM cover hooks B aligned with the PCM box holes at two points.
2. Install the PCM cover to the PCM box hook.

Scheme 5

1. Assemble the battery clamp so that the arrow on it is pointed toward the front of the vehicle.

Scheme 6

1. Assemble with battery box hooks E aligned with the battery tray holes at two points.

Scheme 7

1. Match the mark of the shroud panel and notch in the battery duct, and install the battery duct to the shroud panel.

Scheme 8

Scheme 9

Scheme 10

Scheme 11

1. Install the battery duct between the battery cover and the battery box.
2. Install with battery cover hooks A aligned with the battery tray holes at two points.
3. Install with battery cover hooks D aligned with the battery tray flange at four points.
4. Set the battery cover to battery tray hooks C at two points.
