# Radio circuit, without bose without center display

# Radio circuit, without bose without center display (1 of 3)

Radio — Radio circuit, without bose without center display — Radio circuit, without bose without center display (1 of 3). Mazda 3 BM (2013-2016)
Components on the diagram

    # Radio circuit, without bose without center display (2 of 3)

    Radio — Radio circuit, without bose without center display — Radio circuit, without bose without center display (2 of 3). Mazda 3 BM (2013-2016)
    Components on the diagram

      # Radio circuit, without bose without center display (3 of 3)

      Radio — Radio circuit, without bose without center display — Radio circuit, without bose without center display (3 of 3). Mazda 3 BM (2013-2016)
      Components on the diagram

        Components on these wiring diagrams 24
