Wiring diagram
Wiring diagram: Ground distribution — Ground distribution circuit
Mazda 3 BM · 2013-2016
Repair manualAll systems
- Air conditioning 3
- Anti-lock brakes
- Anti-theft
- Body control modules 2
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Electronic power steering
- Engine performance 2.0l skyactiv
- Engine performance 2.5l
- Exterior lights 2
- Ground distribution
- Headlights 5
- Horn
- Instrument cluster
- Interior lights 2
- Navigation 6
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats 2
- Power top/sunroof
- Power windows
- Radio 6
- Shift interlock
- Starting/charging 5
- Supplemental restraints
- Transmission
- Trunk, tailgate, fuel door
- Warning systems
- Wiper/washer 2
Ground distribution circuit (1 of 2) Mazda 3 BM
Components on the diagram
Ground distribution circuit (2 of 2) Mazda 3 BM
Components on the diagram
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
