Interior Trim: Overview Mazda 3 BM

Locating Front Door Trim Components. Scheme 1

Locating Rear Door Trim Components (4SD). Scheme 2

Locating Rear Door Trim Components (5HB). Scheme 3

Locating Liftgate Side Trim Components (4SD/5HB). Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

1. Set the air intake mode to FRESH.
2. Set the air mix mode to MAX COLD.
3. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
4. Remove the following parts: Front doors (See «FRONT DOOR REMOVAL/INSTALLATION»(ref-579410-S16415067902013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-579335-S39411275542013100700000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-579335-S28107266522013100700000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(/mazda/3/bm-2013-2016/remont/manual-trans/#manual-transaxle-shift-mechanism-g35m-r).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(/mazda/3/bm-2013-2016/remont/manual-trans/#manual-transaxle-shift-mechanism-g66m-r).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(/mazda/3/bm-2013-2016/remont/manual-trans/#manual-transaxle-shift-mechanism-a26m-r).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(/mazda/3/bm-2013-2016/remont/manual-trans/#manual-transaxle-shift-mechanism-c66m-r).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000).) Shift lever component (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(/mazda/3/bm-2013-2016/remont/manual-trans/#manual-transaxle-shift-mechanism-g35m-r).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(/mazda/3/bm-2013-2016/remont/manual-trans/#manual-transaxle-shift-mechanism-g66m-r).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(/mazda/3/bm-2013-2016/remont/manual-trans/#manual-transaxle-shift-mechanism-a26m-r).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(/mazda/3/bm-2013-2016/remont/manual-trans/#manual-transaxle-shift-mechanism-c66m-r).) Selector lever component (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-579383-S12047271642013100700000).) Lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-579335-S33322841732013100700000).) Knee bolster (See «KNEE BOLSTER REMOVAL/INSTALLATION»(ref-579335-S00619224222013100700000).) Driver-side air bag module (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S05413955052013100700000).) (See «DRIVER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S10864358512013100700000).) Steering wheel (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S31871586872013100700000).) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S03087325462013100700000).) Column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000).) Combination switch (See «COMBINATION SWITCH REMOVAL/INSTALLATION»(ref-579340-S24478508062013100700000).) Joint cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S31871586872013100700000).) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S03087325462013100700000).) Steering shaft (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S31871586872013100700000).) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S03087325462013100700000).) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-579335-S25422129262013100700000).) Audio unit (See «AUDIO UNIT REMOVAL/INSTALLATION»(ref-579336-S10029739652013100700000).) Climate control unit (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-579409-S33106125982013100700000).) (See «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION [MANUAL AIR CONDITIONER]»(ref-579407-S37725560872013100700000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-579350-S14408314812013100700000).) Center cover (See «CENTER COVER REMOVAL/INSTALLATION»(ref-579335-S22707828702013100700000).) Dashboard upper panel (See «DASHBOARD UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S10363597352013100700000).) Hole cover (See «HOLE COVER REMOVAL/INSTALLATION»(ref-579335-S15592194102013100700000).) Information display (See «INFORMATION DISPLAY REMOVAL/INSTALLATION»(ref-579350-S16567811822013100700000).) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).) Windshield wiper arm and blade (See «WINDSHIELD WIPER ARM AND BLADE REMOVAL/INSTALLATION»(ref-579338-S36386448362013100700000).) Front fender molding (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-579341-S02671303742013100700000).) Cowl grille (See «COWL GRILLE REMOVAL/INSTALLATION»(ref-579341-S02671303742013100700000).) Windshield wiper motor (See «WINDSHIELD WIPER MOTOR REMOVAL/INSTALLATION»(ref-579338-S15405942432013100700000).)
5. Disconnect The blower motor connector. (See «BLOWER MOTOR REMOVAL [FULL-AUTO AIR CONDITIONER]»(ref-579409-S24338085262013100700000).) (See «BLOWER MOTOR INSTALLATION [FULL-AUTO AIR CONDITIONER]»(ref-579409-S37450180742013100700000).) (See «BLOWER MOTOR REMOVAL [MANUAL AIR CONDITIONER]»(ref-579407-S34623444802013100700000).) (See «BLOWER MOTOR INSTALLATION [MANUAL AIR CONDITIONER]»(ref-579407-S42541266962013100700000).)
6. Disconnect the dashboard harness connectors.
7. Remove the shower duct. (See «A/C UNIT REMOVAL/INSTALLATION»(ref-579378-S31323166662013100700000)
8. Remove the heater case. (See «A/C UNIT REMOVAL/INSTALLATION»(ref-579378-S31323166662013100700000).)
9. Remove the nuts A. (Scheme 5): Identifying Dashboard Nuts A With Torque Specification
10. Remove the bolts B. (Scheme 6): Identifying Dashboard Bolts B With Torque Specification
11. Remove the caps then set the rolled paper.
12. Remove the bolts C. (Scheme 7): Identifying Rolled Paper, Caps And Bolts C With Torque Specification
13. Remove the nuts D and bolts E then remove the dashboard bracket. (Scheme 8): Identifying Dashboard Bracket, Nuts D And Bolts E With Torque Specification
14. Remove the bolts F. (See «BOLT F INSTALLATION NOTE»(ref-579335-S02818952922013100700000) ) (Scheme 9): Identifying Driver/Passenger Side Dashboard Bolts F With Torque Specification
15. Raise the back side of the dashboard rotate it in the direction of the arrow shown in the figure. (Scheme 10): Raising Back Side Of Dashboard WARNING: Removing the dashboard without supporting it can be dangerous. The dashboard may fall and injure you. Always perform the following procedure with at least another person.
16. Remove the dashboard.
17. Take the dashboard off from the front driver-side door opening.
18. Install in the reverse order of removal.

Scheme 11

Scheme 12

Scheme 13

1. Fit the service hole of dashboard and hinge pillar inner shown in the figure. (Scheme 11): Identifying Driver/Passenger Side Service Hole Of Dashboard And Hinge Pillar Inner
2. Partially tighten the bolts F in the order (1), (2), (3), (4) shown in the figure. (Scheme 12): Identifying Driver/Passenger Side Dashboard Bracket Bolts Tightening Sequence
3. Reconfirms fit the service hole of dashboard and hinge pillar inner, then tighten the upper side bolt F. (Scheme 13): Identifying Service Hole Of Dashboard And Hinge Pillar Inner
4. Tighten the all of bolts F.

Scheme 14

Scheme 15

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the following parts: Upper column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-579350-S14408314812013100700000).) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-579335-S25422129262013100700000).) Center cover (See «CENTER COVER REMOVAL/INSTALLATION»(ref-579335-S22707828702013100700000).)
3. Remove the screw.
4. Pull up the dashboard upper panel in the direction of arrow shown in the figure, then remove the clips. (Scheme 14): Pulling Dashboard Upper Panel And Clips
5. Pull up the dashboard upper panel in the direction of arrow shown in the figure, then remove the clips. (Scheme 15): Pulling Dashboard Upper Panel And Clips
6. Remove the dashboard upper panel.
7. Install in the reverse order of removal.

Scheme 16

Scheme 17

Scheme 18

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the following parts: Upper column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-579350-S14408314812013100700000).) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-579335-S25422129262013100700000).) Center cover (See «CENTER COVER REMOVAL/INSTALLATION»(ref-579335-S22707828702013100700000).)
3. Remove the screw.
4. Pull up the dashboard upper panel in the direction of arrow shown in the figure, then remove the clips. (Scheme 16): Pulling Dashboard Upper Panel And Clips
5. Pull up the dashboard upper panel in the direction of arrow shown in the figure, then remove the clips. (Scheme 17): Pulling Dashboard Upper Panel And Clips
6. Remove the dashboard upper panel.
7. Disconnect the center speaker connector.
8. Disconnect the microphone connector.
9. Remove the screws then remove the dashboard upper panel No.2 from the dashboard upper panel No.1. (Scheme 18): Identifying Dashboard Upper Panel No.1, Dashboard Upper Panel No.2 And Screws
10. Install in the reverse order of removal.

Scheme 19

Scheme 20

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the center panel. (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-579335-S25422129262013100700000) )
3. Remove the upper column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000) )
4. Remove the instrument cluster. (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-579350-S14408314812013100700000) )
5. Pull the center cover in the direction of arrow (1) shown in the figure, then remove the hooks. (Scheme 19): Pulling Center Cover (1)
6. Pull the center cover in the direction of arrow (2) shown in the figure, then remove the hook. (Scheme 20): Pulling Center Cover (2)
7. Remove the center cover.
8. Install in the reverse order of removal.

Scheme 21

1. Remove the ventilator grilles. (See «VENTILATOR GRILLE REMOVAL/INSTALLATION»(ref-579335-S42246246892013100700000) )
2. Remove the Passenger-side air bag module. (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S25932256882013100700000) ) (See «PASSENGER-SIDE AIR BAG MODULE REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579329-S29470380822013100700000).)
3. Disassemble in the order indicated in the table.
4. Assemble in the reverse order of disassembly. (Scheme 21): Identifying Dashboard, Center Duct, Dashboard Frame, Wiring Harness And Screw

Scheme 22

Scheme 23

1. Pull down the steering wheel.
2. Pull the upper column cover in the direction of the arrow in the order of (1) and (2), then remove the upper column cover while detaching the hooks and pins. (Scheme 22): Pulling Upper Column Cover
3. Pull up the steering wheel.
4. Remove the ignition key illumination. (See «IGNITION KEY ILLUMINATION REMOVAL/INSTALLATION»(ref-579340-S08050105752013100700000) )
5. Remove the screws.
6. Remove the lower column cover in the direction of the arrow (4) while keeping it open in the direction of the arrow (3) shown in the figure. (Scheme 23): Removing Lower Column Cover
7. Install in the reverse order of removal.

Scheme 24

Scheme 25

Scheme 26

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Affix protective tape to the position shown in the figure. (Scheme 24): Identifying Center Panel And Protective Tape
3. Hold parts (A) shown in the figure with your hands and pull the lower edge of the center panel in the direction of the arrow (1), and remove clips A. CAUTION: Be careful not to damage the center ventilator grille fins by touching them with your fingers. When holding the positions shown by the arrow (A) in the figure, be careful not to touch the fins. (Scheme 25): Pulling Lower Edge Of Center Panel
4. Hold the cross-hatched areas in the figure with your hands and pull the center panel in the direction of the arrow (2), and remove clips B. CAUTION: If the center panel is removed forcefully it could result in damage to the hazard warning switch connector wiring harness. Carefully pull the center panel until clips B are pulled out. (Scheme 26): Pulling Center Panel And Clips
5. Remove the center panel.
6. Disconnect the hazard warning switch connector.
7. Install in the reverse order of removal.

Scheme 27

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the following parts: Upper column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-579350-S14408314812013100700000).) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-579335-S25422129262013100700000).) Center cover (See «CENTER COVER REMOVAL/INSTALLATION»(ref-579335-S22707828702013100700000).) Dashboard upper panel (See «DASHBOARD UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S10363597352013100700000).) Multi information display (See «MULTI INFORMATION DISPLAY REMOVAL/INSTALLATION»(ref-579350-S13703502732013100700000).)
3. Pull the hole cover in the direction of arrow (1), (2) shown in the figure, while remove the clip A, hook B and clips C. (Scheme 27): Pulling Hole Cover
4. Remove the hole cover.
5. Install in the order of removal.

Scheme 28

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the following parts: Upper column cover (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-579335-S02678072422013100700000).) Instrument cluster (See «INSTRUMENT CLUSTER REMOVAL/INSTALLATION»(ref-579350-S14408314812013100700000).) Center panel (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-579335-S25422129262013100700000).) Center cover (See «CENTER COVER REMOVAL/INSTALLATION»(ref-579335-S22707828702013100700000).) Dashboard upper panel (See «DASHBOARD UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S10363597352013100700000).)
3. Pull the hole cover in the direction of arrow (1), (2) shown in the figure, while remove the hook and clips. (Scheme 28): Pulling Hole Cover
4. Remove the hole cover.
5. Install in the order of removal.

Scheme 29

Scheme 30

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the following parts: Driver-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Driver-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-579383-S12047271642013100700000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(/mazda/3/bm-2013-2016/remont/manual-trans/#manual-transaxle-shift-mechanism-g35m-r).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(/mazda/3/bm-2013-2016/remont/manual-trans/#manual-transaxle-shift-mechanism-g66m-r).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(/mazda/3/bm-2013-2016/remont/manual-trans/#manual-transaxle-shift-mechanism-a26m-r).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(/mazda/3/bm-2013-2016/remont/manual-trans/#manual-transaxle-shift-mechanism-c66m-r).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000).)
3. Partially peel back the seaming welt.
4. Remove the screw. (Scheme 29): Identifying Screw And Partially Peel Back Seaming Welt
5. Pull the lower panel in the direction of the arrow in the order of (1) (2), (3) and remove the lower panel while detaching the hooks, clips and guides. (Scheme 30): Pulling Lower Panel
6. Disconnect the switch connector.
7. Disconnect the push button start connector.
8. Install in the reverse order of removal.

Scheme 31

Scheme 32

1. Remove the following parts: Passenger-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Passenger-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).) Dashboard under cover (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-579335-S39411275542013100700000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-579335-S28107266522013100700000).)
2. Partially peel back the seaming welt.
3. Remove the screws. (Scheme 31): Identifying Screws And Partially Peel Back Seaming Welt
4. Pull the lower panel in the direction of the arrow in the order of (1) (2), (3) and remove the lower panel while detaching the hook, clips, guide and pins. (Scheme 32): Pulling Lower Panel
5. Install in the reverse order of removal.

Scheme 33

Scheme 34

1. Insert a tape-wrapped fastener remover into the position indicated by the arrow in the figure.
2. Pull the side panel in the direction of the arrow shown in the figure, then remove the clips and hook. (Scheme 33): Pulling Side Panel
3. Pull the side panel in the direction of the arrow shown in the figure, while detaching the guides. (Scheme 34): Pulling Side Panel And Guides CAUTION: When pulling out the side panel, be careful not to damage the guide.
4. Install in the reverse order of removal.
