Interior Trim: Removal & Installation Mazda 3 BM

GLOVE COMPARTMENT REMOVAL/INSTALLATION

Scheme 35

1. Pull the stay damper in the direction (1) shown in the figure, and detach the hook A between the glove compartment and the stay damper.
2. Pull up the hook B in the direction of arrow (2) and remove it in the direction of arrow (3) shown in the figure.
3. Lower the glove compartment.
4. Detach the hook C from the dashboard and remove the glove compartment. (Scheme 35): Pulling Stay Damper
5. Install in the reverse order of removal.

Scheme 36

1. Through the wiring harness into the position shown in the figure, remove the side ventilator grille in the direction of arrow. (Scheme 36): Removing Side Ventilator Grille
2. When installing the side ventilator grille, push it for the dashboard.

Scheme 37

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the center panel. (See «CENTER PANEL REMOVAL/INSTALLATION»(ref-579335-S25422129262013100700000) )
3. Push the edge of center panel in the direction of arrow (1) and detach the hooks.
4. Remove the center ventilator grille in the direction of arrow (2) shown in the figure. (Scheme 37): Removing Center Ventilator Grille
5. Install in the reverse order of removal.

Scheme 38

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the following parts: Driver-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Driver-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).) Hood release lever (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-579383-S12047271642013100700000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000).) Driver-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-579335-S33322841732013100700000).)
3. Remove the bolts. (Scheme 38): Identifying Knee Bolster And Bolts With Torque Specification
4. Remove the knee bolster.
5. Install in the reverse order of removal.

Scheme 39

Scheme 40

1. Pull out the side wall in the direction shown in the direction of the arrow shown in the figure, then remove the clips. (Scheme 39): Pulling Out Side Wall
2. Remove the side wall in the direction of the arrow shown in the figure. (Scheme 40): Removing Side Wall And Guide CAUTION: When remove the side wall, be careful not to damage the guide.
3. Install in the reverse order of removal.

Scheme 41

Scheme 42

1. Detach the hooks in the direction of arrow (1) shown in the figure.
2. Pull the dashboard under cover in the direction of arrow (2). (Scheme 41): Pulling Dashboard Under Cover
3. Remove the dashboard under cover, then remove the guide. (Scheme 42): Removing Dashboard Under Cover And Guide
4. Install in the reverse order of removal.

Scheme 43

Scheme 44

1. Pull the upper panel in the direction of the arrow shown in the figure, then remove it while detaching the hook A and hooks B. (Scheme 43): Pulling Upper Panel CAUTION: When removing hook A, press the connecting part of the console with a hand to prevent damage to hook A.
2. Pull the upper panel in the direction of the arrow shown in the figure, then remove it while detaching the hook C and hooks D. (Scheme 44): Pulling Upper Panel
3. Remove the upper panel.
4. Install in the reverse order of removal.

Scheme 45

Scheme 46

1. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).)
2. Remove the selector lever knob. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000) )
3. Pull the shift panel in the direction of the arrow shown in the figure and remove it while detaching the clips A, hook B and guides C. (Scheme 45): Pulling Shift Panel
4. Pull the shift panel in the direction of the arrow (1), (2), (3) while remove the hooks D, E and guide F. (Scheme 46): Pulling Shift Panel With Hooks And Guide
5. Remove the shift panel.
6. Install in the reverse order of removal.

Scheme 47

1. Remove the upper panel. (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).)
2. Remove the shift knob. (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000).)
3. Pull the shift panel in the direction of the arrow shown in the figure and remove it while detaching the clips, hook and guides. (Scheme 47): Pulling Shift Panel
4. Remove the shift panel.
5. Install in the reverse order of removal.

Scheme 48

Scheme 49

Scheme 50

Scheme 51

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the following parts: Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).) Shift knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000).)
3. Remove the bolts. (Scheme 48): Identifying Console And Bolts
4. Remove the screws. (Scheme 49): Identifying Console And Screws
5. Pull the console in the direction of the arrow shown in the figure, then detaching clips A, C hooks B and guides D. (Scheme 50): Pulling Console
6. Disconnect the following connectors. Rear accessory socket Auxiliary jack (vehicles without USB port) Auxiliary jack/USB port (vehicles with USB port) Car-navigation unit (vehicles with audio unit)
7. Pull up the console in the direction of the arrow (1) shown in the figure, move the rear console in the direction of the arrow (2), and remove it avoiding the parking brake lever. (Scheme 51): Pulling Up Console
8. Remove the following parts: Rear accessory socket (See «ACCESSORY SOCKET REMOVAL/INSTALLATION»(ref-579336-S14825488452013100700000).) Auxiliary jack (vehicles without USB port) (See «AUXILIARY JACK REMOVAL/INSTALLATION»(ref-579336-S33571702612013100700000).) Auxiliary jack/USB port (vehicles with USB port) (See «AUXILIARY JACK/USB PORT REMOVAL/INSTALLATION»(ref-579336-S20815023122013102400000).) Car-navigation unit (vehicles with audio unit) (See «CAR-NAVIGATION UNIT REMOVAL/INSTALLATION»(ref-579336-S28117398322013100700000).)
9. Install in the reverse order of removal.

Scheme 52

1. Remove the following parts: Passenger-side front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Passenger-side front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).) Glove compartment (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-579335-S28107266522013100700000).) Passenger-side lower panel (See «LOWER PANEL REMOVAL/INSTALLATION»(ref-579335-S33322841732013100700000).)
2. Remove the screw.
3. Pull the decoration panel in the direction of the arrow (1), (2) shown in the figure, while remove the hook A and hooks B. (Scheme 52): Pulling Decoration Panel
4. Remove the decoration panel.
5. Install in the reverse order of removal.

Scheme 53

Scheme 54

Scheme 55

1. Partially peel back the seaming welt.
2. Pull the upper end of the A-pillar trim in the direction of the arrow shown in the figure and remove clip A and B. (Scheme 53): Pulling Upper End Of A-Pillar Trim
3. Cut the lead wire connecting clip B and grommet using a nipper and pull out the A-pillar trim in the direction of the arrow shown in the figure. (Scheme 54): Pulling Out A-Pillar Trim CAUTION: When pulling out the A-pillar trim, be careful not to damage the tabs C.
4. Move the hook in the direction of arrows (1) and (2) shown in the figure using a flathead screwdriver and detach it from the A-pillar inner panel. (Scheme 55): Moving Hook
5. Remove the grommet in the direction of the arrow (3) shown in the figure.
6. When installing the A-pillar, install the new clip B and grommet to the A-pillar trim in advance.
7. Install in the reverse order of removal.

Scheme 56

1. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).)
2. Partially peel back the seaming welt.
3. Remove the fastener.
4. Pull the front side trim in the direction of the arrow and detach the clip. (Scheme 56): Pulling Front Side Trim
5. Install in the reverse order of removal.

Scheme 57

Scheme 58

1. Remove the rear seat cushion. (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).)
2. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).)
3. Partially peel back the seaming welt.
4. Remove the fastener.
5. Pull the tire house trim in the direction of arrow shown in the figure while remove the clip A, pin B and C. (Scheme 57): Pulling Tire House Trim (4SD)
6. Pull the tire house trim in the direction of arrow shown in the figure while remove the hook D. (Scheme 58): Pulling Tire House Trim (4SD)
7. Remove the tire house trim.
8. Install in the reverse order of removal.

Scheme 59

1. Remove the rear seat cushion. (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).)
2. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).)
3. Partially peel back the seaming welt.
4. Remove the fasteners.
5. Pull the tire house trim in the direction of arrow (1), while remove the hook A and B. (Scheme 59): Pulling Tire House Trim (5HB)
6. Pull the tire house trim in the direction of arrow (2), while remove the hook C, clip D, pin E and F.
7. Remove the tire house trim.
8. Install in the reverse order of removal.

Scheme 60

Scheme 61

1. Remove the following parts: Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).)
2. Fold the rear seat back.
3. Remove the fasteners. (Scheme 60): Identifying Rear Package Trim And Fasteners
4. Pull up the rear package trim in the direction of the arrow (1) shown in the figure while remove the clips and pin, pull the rear package trim in the direction of the arrow (2), and remove it while pulling out the guides. (Scheme 61): Pulling Rear Package Trim
5. Install in the reverse order of removal.

Scheme 62

Scheme 63

1. Remove the front scuff plate. (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000) )
2. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000) )
3. Partially peel back the seaming welt.
4. Pull the B-pillar lower trim in the direction of the arrow (1), (2) shown in the figure, detach tab A, pin B, pin C, clip D. (Scheme 62): Pulling B-Pillar Lower Trim
5. Remove the B-pillar lower trim in the direction of the arrow (3) shown in the figure. (Scheme 63): Removing B-Pillar Lower Trim
6. Install in the reverse order of removal.

Scheme 64

Scheme 65

1. Remove the following parts: Adjuster anchor cover (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) Upper anchor installation bolts on the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).)
2. Partially peel back the seaming welt.
3. Remove the B-pillar lower trim. (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000) )
4. Grasp the lower end of the B-pillar upper trim, pull it in the direction of the arrow shown in the figure, and remove clips A, pin B, and pin C. (Scheme 64): Removing Clips A Of B-Pillar Lower Trim
5. Remove the B-pillar upper trim in the direction of the arrow shown in the figure. (Scheme 65): Removing B-Pillar Upper Trim CAUTION: When removing the B-pillar upper trim, be careful not to damage the tab D.
6. Install in the reverse order of removal.

Scheme 66

Scheme 67

Scheme 68

1. Remove the following parts: Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).)
2. Partially peel back the seaming welt.
3. Pull the C-pillar trim in the direction of the arrow (1), (2) shown in the figure, then detaching clip A and B. (Scheme 66): Pulling C-Pillar Trim
4. Cut the lead wire connecting clip A and grommet using a nipper and pull out the C-pillar trim in the direction of the arrow shown in the figure, while remove the tab C. (Scheme 67): Pulling Out C-Pillar Trim CAUTION: When removing the C-pillar trim, be careful not to damage the tab C.
5. Move the hook in the direction of arrows (1) and (2) shown in the figure using a flathead screwdriver and detach it from the rear pillar inner panel. (Scheme 68): Moving Hook
6. Remove the grommet in the direction of the arrow (3) shown in the figure.
7. When installing the C-pillar, install the new clip A and grommet to the C-pillar trim in advance.
8. Install in the reverse order of removal.

Scheme 69

1. Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) Trunk side trim (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S15499890432013100700000).)
2. Partially peel back the seaming welt.
3. Remove the fastener.
4. Pull the C-pillar trim in the direction of the arrow (1), (2) shown in the figure, then remove the clips A, pin B and C.
5. Pull the C-pillar trim in the direction of the arrow (3) shown in the figure, then remove the clips D and tab E. (Scheme 69): Pulling C-Pillar Trim
6. Remove the C-pillar trim.
7. Install in the reverse order of removal.

Scheme 70

1. Detach tab A while pulling the front scuff plate in the direction of the arrow (1) shown in the figure, then detach hook B, clips C, and pins D while pulling in the direction of the arrow (2).
2. Detach tab E while pulling the front scuff plate in the direction of the arrow (3) shown in the figure, pull the front scuff plate in the direction of the arrow (4), and remove it while detaching hook F. (Scheme 70): Pulling Front Scuff Plate
3. Remove the front scuff plate.
4. Install in the reverse order of removal.

Scheme 71

1. Detach tab A while pulling the rear scuff plate in the direction of the arrow (1) shown in the figure, then detach hook B, clips C, pins D while pulling in the direction of the arrow (2).
2. Detach tab E while pulling the rear scuff plate in the direction of the arrow (3) shown in the figure, pull the rear scuff plate in the direction of the arrow (4) shown in the figure. (Scheme 71): Pulling Rear Scuff Plate
3. Remove the rear scuff plate.
4. Install in the reverse order of removal.

Scheme 72

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Pull the inner garnish in the direction of the arrow shown in the figure and remove it while detaching clips and tab. (Scheme 72): Pulling Inner Garnish CAUTION: When pulling out the inner garnish, be careful not to damage the tab.
3. Disconnect the front tweeter connector. (Vehicles with tweeter)
4. Install in the reverse order of removal.

Scheme 73

Scheme 74

1. Remove the screw. (Scheme 73): Identifying Fuel-Filler Lid Opener Bezel And Screw
2. Pull the fuel-filler lid opener bezel in the direction of the arrow (1) then remove the tab.
3. Move the fuel-filler lid opener bezel in the direction of the arrow (2) shown in the figure. (Scheme 74): Moving Fuel-Filler Lid Opener Bezel
4. Remove the fuel-filler lid opener bezel.
5. Install in the reverse order of removal.

Scheme 75

1. Disassemble in the order shown in the figure. (Scheme 75): Identifying Rear Door Trim Components
2. Assemble in the reverse order of disassembly.

Scheme 76

1. Remove the trunk mat. (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-579335-S24023220232013100700000) )
2. Remove the trunk board. (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-579335-S24023220232013100700000) )
3. Remove the fasteners.
4. Pull the trunk end trim indicated in the arrow shown in the figure, then detach clips A, pins B, pin C, D and tabs E. (Scheme 76): Pulling Trunk End Trim
5. Remove the trunk end trim.
6. Install in the reverse order of removal.

Scheme 77

1. Remove the trunk mat. (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-579335-S24023220232013100700000) )
2. Remove the trunk board. (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-579335-S24023220232013100700000) )
3. Remove the fasteners.
4. Pull the trunk end trim indicated in the arrow shown in the figure, then detach clips A, pins B, pin C, guides D and pins E. (Scheme 77): Pulling Trunk End Trim
5. Remove the trunk end trim.
6. Install in the reverse order of removal.

Scheme 78

1. Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk mat (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-579335-S24023220232013100700000).) Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-579335-S24023220232013100700000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-579335-S26041262432013100700000).) Service hole cover
2. Remove the fasteners. (Scheme 78): Removing Trunk Side Trim Fasteners (Left-Side)
3. Install in the reverse order of removal.

Scheme 79

1. Remove the following parts: Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk mat (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-579335-S24023220232013100700000).) Trunk board (See «TRUNK BOARD REMOVAL/INSTALLATION»(ref-579335-S24023220232013100700000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-579335-S26041262432013100700000).)
2. Remove the fasteners and tab. (Scheme 79): Removing Trunk Side Trim Fasteners (Right-Side)
3. Install in the reverse order of removal.

Scheme 80

Scheme 81

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the following parts: Rear seat (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-579337-S39191899042013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-579335-S26041262432013100700000).) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).)
3. Remove the bolts, then remove the cargo net hooks. (Scheme 80): Identifying Cargo Net Hooks And Bolts With Torque Specification
4. Remove the fasteners.
5. Pull the trunk side trim in the direction of arrow, while remove the clip. (Scheme 81): Pulling Trunk Side Trim
6. Remove the trunk side trim.
7. Disconnect the cargo compartment light connector. (Right-side only)
8. Install in the reverse order of removal.

Scheme 82

1. Remove the rear seat cushion. (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000) )
2. Remove the rear scuff plate. (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000) )
3. Remove the tire house trim. (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000) )
4. Open the cap.
5. Remove the screw.
6. Remove the fasteners.
7. Pull the trunk side upper trim in the direction of arrow, then detach the hooks and clips. (Scheme 82): Pulling Trunk Side Upper Trim
8. Install in the reverse order of removal.

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-579335-S26275577612013100700000) )
3. Move the hook in the direction of arrow shown in the figure using a tape-lapped flathead screwdriver and detach it from the front door trim. (Scheme 83): Moving Hook Using Tape-Lapped Flathead Screwdriver CAUTION: Affix protective tape to the front door trim and assist handle cover to prevent damage.
4. Pull the inner handle cover in the direction of arrow and remove it while detaching tabs. (Scheme 84): Pulling Inner Handle Cover
5. Remove the screws. (Scheme 85): Identifying Screws
6. Pull in the direction of the arrow (1), (2), (3) shown in the figure and remove clips from the door inner panel using a fastener remover. (Scheme 86): Removing Clips From Door Inner Panel Using Fastener Remover
7. Remove the front door trim in the direction of the arrow shown in the figure. (Scheme 87): Removing Front Door Trim
8. Remove the inner handle and move the front door trim shown in the figure. (Scheme 88): Identifying Inner Handle And Tabs
9. Turn the inner handle 90° in the direction of the arrow and remove it from the front door trim. (Scheme 89): Turning Inner Handle
10. Disconnect the driver-side power outer mirror switch connector and driver-side power window main switch connector.
11. Install in the reverse order of removal.

Scheme 90

1. Disassemble in the order shown in the figure. (Scheme 90): Identifying Front Door Trim Components (Driver-Side)
2. Assemble in the reverse order of disassembly.

Scheme 91

1. Disassemble in the order shown in the figure. (Scheme 91): Identifying Front Door Trim Components (Passenger-Side)
2. Assemble in the reverse order of disassembly.

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Move the hook in the direction of arrow shown in the figure using a tape-lapped flathead screwdriver and detach it from the rear door trim. (Scheme 92): Moving Hook Using Tape-Lapped Flathead Screwdriver CAUTION: Affix protective tape to the rear door trim and assist handle cover to prevent damage.
3. Pull the cover of inner handle and remove it while detaching tabs. (Scheme 93): Pulling Cover Of Inner Handle
4. Remove the screws. (Scheme 94): Identifying Screws
5. Pull in the direction of the arrow (1), (2), (3) shown in the figure and remove clips from the door inner panel using a fastener remover. (Scheme 95): Removing Clips From Door Inner Panel Using Fastener Remover
6. Remove the rear door trim in the direction of the arrow shown in the figure. (Scheme 96): Removing Rear Door Trim
7. Remove the inner handle and move the rear door trim in the direction of the arrow shown in the figure. (Scheme 97): Identifying Inner Handle And Tabs
8. Turn the inner handle 90° in the direction of the arrow and remove it from the rear door trim. (Scheme 98): Turning Inner Handle
9. Disconnect the power window subswitch connector.
10. Install in the reverse order of removal.

Scheme 99

Scheme 100

1. Remove the trunk mat in the direction of arrow shown in the figure. (Scheme 99): Removing Trunk Mat
2. Remove the trunk board in the direction of arrow shown in the figure. (Scheme 100): Removing Trunk Board
3. Install in the reverse order of removal.

Scheme 101

Scheme 102

1. Detach tab while pulling the liftgate upper trim in the direction of the arrow (1) shown in the figure, then detach clips and pin while pulling in the direction of the arrow (2). (Scheme 101): Pulling Liftgate Upper Trim
2. Detach tab while pulling the liftgate upper trim in the direction of the arrow (3) shown in the figure, then detach clip while pulling in the direction of the arrow (4). (Scheme 102): Pulling Liftgate Upper Trim
3. Remove the liftgate upper trim.
4. Install in the reverse order of removal.

Scheme 103

Scheme 104

Scheme 105

1. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S06689900982013100700000).)
2. Pull the point A of the strap hanger as shown in the figure. (Scheme 103): Pulling Point A Of Strap Hanger
3. Remove the strap hanger.
4. Remove the fastener.
5. Pull the liftgate side trim in the direction of arrow then remove clip A. (Scheme 104): Pulling Liftgate Side Trim
6. Detach tab B and C while pulling the liftgate side trim in the direction of the arrow (1) shown in the figure, then detach hook D while pulling in the direction of the arrow (2). (Scheme 105): Pulling Liftgate Side Trim Of Tab B And C
7. Install in the reverse order of removal.

Scheme 106

Scheme 107

1. Remove the liftgate upper trim. (See «LIFTGATE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S06689900982013100700000).)
2. Remove the liftgate side trim. (See «LIFTGATE SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S13559719922013100700000).)
3. Remove the screw and fasteners. (Scheme 106): Identifying Liftgate Lower Trim, Screw And Fasteners
4. Pull the liftgate lower trim in the direction of arrow (1), (2), (3), then detach clips A, B, pin C and D from the liftgate. (Scheme 107): Pulling Liftgate Lower Trim
5. Remove the liftgate lower trim.
6. Install in the reverse order of removal.

Scheme 108

1. Remove the fasteners, then remove the trunk lid trim. (Scheme 108): Removing Trunk Lid Trim And Fasteners
2. Install in the reverse order of removal.

Scheme 109

Scheme 110

1. Insert a flathead screwdriver into the service hole and remove the assist handle covers. (Scheme 109): Inserting Flathead Screwdriver Into Service Hole And Assist Handle Covers
2. Remove the assist handle in the direction of the arrow (1) and (2), while detach the clip. (Scheme 110): Removing Assist Handle NOTE: Remove the assist handle by shaking it up and down.

Scheme 111

Scheme 112

1. Push the assist handle in the direction of the arrow shown in the figure. (Scheme 111): Pushing Assist Handle
2. Push the assist handle cover assembled to install the assist handle. (Scheme 112): Pushing Assist Handle Cover

Scheme 113

Scheme 114

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the screw.
3. Rotate the sunvisor in the direction of the arrow.
4. Unhook and remove the sunvisor. (Scheme 113): Rotating Sunvisor
5. Disconnect the vanity mirror illumination connector. (Vehicles with vanity mirror illumination)
6. Press the center adaptor tabs as shown in the figure using two tape-wrapped flathead screwdrivers, and remove the center adaptor. (Scheme 114): Pressing Center Adaptor Tabs
7. Install in the reverse order of removal.

Scheme 115

Scheme 116

Scheme 117

Scheme 118

1. Shift to the D (ATX) or 4th gear (MTX) position. (4SD)
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
3. Remove the rain sensor cover. (Vehicles with auto light/wiper system) (See «RAIN SENSOR REMOVAL/INSTALLATION»(ref-579338-S25845499322013100700000) )
4. Disconnect the rain sensor connector. (Vehicles with auto light/wiper system)
5. Partially peel back the seaming welts.
6. Remove the following parts: Sunroof seaming welt (vehicles with sunroof) A-pillar trim (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S13933682432013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S05905792422013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim (5HB) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-579335-S08810903732013100700000).) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-579340-S25970674822013100700000).) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-579335-S09891259772013100700000).) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-579335-S20965266702013100700000).)
7. Disconnect the microphone connector. (Vehicles with headliner installation type)
8. Disconnect the roof wiring harness connector and remove the roof wiring harness connector clip from the body.
9. Disconnect the rear washer hose. (5HB)
10. Remove the fasteners. (Scheme 115): Identifying Headliner And Fasteners (4SD) (Scheme 116): Identifying Headliner And Fasteners (5HB)
11. Take the headliner out from the opened front passenger-side door. (4SD) (Scheme 117): Opening Headliner Out From Front Passenger-Side Door (4SD)
12. Take the headliner out from the opened liftgate. (5HB) (Scheme 118): Opening Headliner Out From Liftgate (5HB)
13. Install in the reverse order of removal.

FIRE EXTINGUISHER INSTALLATION [Arab Gulf Cooperation Council]

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

1. Switch the ignition to off.
2. Disconnect the negative battery cable and wait 1 min or more. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
3. Remove the following parts: Front seat (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-579337-S11574283732013100700000).) Audio amplifier (Vehicles with Bose ® ) (See «AUDIO AMPLIFIER REMOVAL/INSTALLATION»(ref-579336-S18620911252013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).)
4. Partially peel back the floor covering. (See «FLOOR COVERING REMOVAL/INSTALLATION»(ref-579335-S18601948192013100700000).)
5. Cut the passenger-side rear heater duct cover shown in the figure. CAUTION: When cutting out the portion of the passenger-side rear heat duct, do not cut it outside of the indicated area shown in the figure. Otherwise, the airflow passage could be damaged and cause the air from the heater to leak. (Scheme 119): Cutting Out Portion Of Passenger-Side Rear Heat Duct
6. Drill a 7 mm {0.3 in} diameter hole at the point shown in the figure. (Scheme 120): Drilling Diameter Hole At Point
7. Return the floor covering to its original position and open the slit at the position shown in the figure. (Scheme 121): Identifying Slit Location
8. Install in the order shown in the figure. (Scheme 122): Identifying Bracket Assembly Components
9. Apply silicone sealant to the shaded area on the under body as shown in the figure. (Scheme 123): Applying Silicone Sealant To Shaded Area On Under Body
10. Install the following parts: Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Audio amplifier (Vehicles with Bose ® ) (See «AUDIO AMPLIFIER REMOVAL/INSTALLATION»(ref-579336-S18620911252013100700000).) Front seat (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-579337-S11574283732013100700000).)

Scheme 124

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the following parts: Front seat (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-579337-S11574283732013100700000).) Audio amplifier (Vehicles with Bose ® ) (See «AUDIO AMPLIFIER REMOVAL/INSTALLATION»(ref-579336-S18620911252013100700000).) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Joint cover (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITHOUT ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S31871586872013100700000).) (See «STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION [WITH ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM]»(ref-579349-S03087325462013100700000).) Front side trim (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).) Fuel-filler lid opener lever bezel (See «FUEL-FILLER LID OPENER BEZEL REMOVAL/INSTALLATION»(ref-579335-S29653552942013100700000).) Selector lever knob (ATX) (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-579347-S14598286322013100700000).)) Shift lever knob (MTX) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G35M-R]»(ref-579343-S30160104102013100700000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [G66M-R]»(ref-579344-S32573239452013100700000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [A26M-R]»(ref-579345-S39624684772013100700000).) (See «MANUAL TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION [C66M-R]»(ref-579346-S11482280202013100700000).) Upper panel (See «UPPER PANEL REMOVAL/INSTALLATION»(ref-579335-S17519281862013100700000).) Shift panel (See «SHIFT PANEL REMOVAL/INSTALLATION»(ref-579335-S24715706362013100700000).) Side wall (See «SIDE WALL REMOVAL/INSTALLATION»(ref-579335-S32642470872013100700000).) Console (See «CONSOLE REMOVAL/INSTALLATION»(ref-579335-S16951481782013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Lower anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION [STANDARD DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S26147573312013100700000).) (See «FRONT SEAT BELT REMOVAL/INSTALLATION [TWO-STEP DEPLOYMENT CONTROL SYSTEM]»(ref-579339-S39090590872013100700000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).)
3. Remove fasteners A and B. (Scheme 124): Identifying Floor Covering With Fasteners
4. Take the floor covering out from the opened door.
5. Install in the reverse order of removal.
