Security System and Locks System: Overview Mazda 3 BM

Locating Locks And Openers Related Components (1 Of 2). Scheme 1

Locating Locks And Openers Related Components (2 Of 2). Scheme 2

Locating Advanced Keyless Entry And Push Button Start System/Immobilizer System Related Components. Scheme 3

Locating Keyless Entry System/Immobilizer System Related Components. Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}. (Scheme 5): Identifying Front Door Glass Distance
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-579335-S26275577612013100700000).) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-579335-S20706949142013100700000).) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-579336-S02963356692013100700000).) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION»(ref-579414-S25796711262013100700000).) Front door module panel (See «FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION»(ref-579410-S39962724232013100700000).) Front door key cylinder (See «FRONT DOOR KEY CYLINDER REMOVAL/INSTALLATION»(ref-579383-S07563135292013100700000).)
4. Disconnect the keyless antenna connector (With advanced keyless entry and push button start system). (Scheme 6): Locating Keyless Antenna Connector (With Advanced Keyless Entry And Push Button Start System)
5. Remove the front outer handle. (Scheme 7): Front Outer Handle
6. Remove the screw. NOTE: The screw cannot be removed because of the stopper. (Scheme 8): Identifying Front Outer Handle Screw
7. Press down the rod holder in the direction of arrow (1) and remove the front outer handle bracket in the direction of arrow (2). (Scheme 9): Pressing Down Rod Holder
8. Install in the reverse order of removal.

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. Fully close the rear door glass.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
3. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-579335-S26826772842013100700000).)
4. Remove the service hole cover. (Scheme 10): Identifying Service Hole Cover
5. Remove the screw from the service hole. (Scheme 11): Identifying Service Hole Screw NOTE: The screw cannot be removed because of the stopper.
6. Press the tab on the rear outer handle bracket in the direction of the arrow. (Scheme 12): Pressing Tab On Rear Outer Handle Bracket
7. Maintaining the condition in procedure 6, remove the outer handle garnish. (Scheme 13): Outer Handle Garnish
8. Remove the rear outer handle. (Scheme 14): Rear Outer Handle
9. Loosen the screw. (Scheme 15): Identifying Rear Outer Handle Bracket And Screw
10. Press down the rod holder in the direction of arrow (1) and remove the rear outer handle bracket in the direction of arrow (2). (Scheme 16): Pressing Down Rod Holder
11. Install in the reverse order of removal.

Scheme 17

Scheme 18

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-579335-S26275577612013100700000).)
3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-579335-S20706949142013100700000).)
4. Disconnect the door lock switch connector. (Scheme 17): Identifying Door Lock Switch Connector
5. Disconnect each cable and remove the front inner handle. (Scheme 18): Identifying Door Lock Knob Cable, Inner Handle Cable And Front Inner Handle
6. Install in the reverse order of removal.

Scheme 19

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the rear door trim. (See «REAR DOOR TRIM REMOVAL/INSTALLATION»(ref-579335-S26826772842013100700000).)
3. Disconnect each cable and remove the rear inner handle. (Scheme 19): Identifying Door Lock Knob Cable, Inner Handle Cable And Rear Inner Handle
4. Install in the reverse order of removal.

Scheme 20

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-579335-S26275577612013100700000).)
3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-579335-S20706949142013100700000).)
4. Remove the front inner handle. (See «INNER HANDLE REMOVAL/INSTALLATION»(ref-579383-S01306976542013100700000).)
5. Remove the screws, then remove the door lock switch. (Scheme 20): Identifying Door Lock Switch, Screws And Front Inner Handle
6. Install in the reverse order of removal.

Scheme 21

Scheme 22

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the inner garnish. (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-579335-S26275577612013100700000).)
3. Remove the front door trim. (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-579335-S20706949142013100700000).)
4. Remove the front inner handle. (See «INNER HANDLE REMOVAL/INSTALLATION»(ref-579383-S01306976542013100700000).)
5. Inspect for continuity between the door lock switch terminals using an ohmmeter. (Scheme 21): Door Lock Switch Continuity And Resistance Chart If not as indicated in the table, replace the door lock switch. (Scheme 22): Identifying Door Lock Switch Terminals

Scheme 23

Scheme 24

1. Open the hood.
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
3. Disconnect the hood latch switch connector. (vehicles with theft-deterrent system) (Scheme 23): Locating Hood Latch Switch Connector
4. Remove the bolts. (Scheme 24): Identifying Hood Latch And Bolt With Torque Specification
5. Remove the hood latch.
6. Install in the reverse order of removal.
7. Adjust the hood. (See «HOOD ADJUSTMENT»(ref-579342-S31956471992013100700000).)

Scheme 25

Scheme 26

Scheme 27

1. Pull the hood release lever. (Scheme 25): Pulling Hood Release Lever
2. While maintaining the condition in procedure 1, insert a tape-wrapped flathead screwdriver as shown in the figure, press the ends of the tabs with the screwdriver in the direction of the arrows (1), pull the hood release lever in the direction of arrow (2), and then disconnect the lower panel. (Scheme 26): Pressing Ends Of Tabs CAUTION: Remove the hood release lever while being careful not to damage the hood release cable with the flathead screwdriver.
3. Pull the latch release lever outward, remove it from the lower panel, and then disconnect the hood release cable. (Scheme 27): Identifying Hood Release Cable, Hood Release Lever And Lower Panel
4. Install in the reverse order of removal.

Scheme 28

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the battery tray. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
3. Remove the Front mudguard (LH). (See «FRONT MUDGUARD REMOVAL/INSTALLATION»(ref-579341-S42819834192013100700000).)
4. Remove the hood release cable from clips A. (Scheme 28): Hood Release Cable And Clips A And B
5. Remove the clips B.
6. Disconnect the hood latch from the hood release cable.
7. Remove the hood release cable from outside of the vehicle.
8. Install in the reverse order of removal.

Scheme 29

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the hood latch. (See «HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION»(ref-579383-S12047271642013100700000).)
3. Verify that the continuity is as indicated in the table. If not as indicated in the table, replace the hood latch. (Scheme 29): Hood Latch Switch Circuit And Continuity Table

Note. Press the latch lever in using a flathead screwdriver to inspect the closed condition of the hood latch switch. (Scheme 30): Pressing Latch Lever Using Flathead Screwdriver

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. Open the fuel-filler lid.
2. Remove the following parts: Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-579335-S26041262432013100700000).) Trunk side trim (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S15499890432013100700000).)
3. Remove the nut. (Scheme 31): Lift Spring And Nut With Torque Specification
4. Remove the lift spring. (Scheme 32): Identifying Lift Spring
5. Pull out the fuel-filler lid opener in the direction of the arrow (1). (Scheme 33): Fuel-Filler Lid Opener
6. Disconnect the fuel-filler lid opener from the fuel-filler lid opener cable. (Scheme 34): Fuel-Filler Lid Opener Cable
7. Install in the reverse order of removal.

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. Open the fuel-filler lid.
2. Remove the following parts: Rear scuff plate (RH) (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Rear seat back (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-579337-S39191899042013100700000).) Tire house trim (RH) (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim (RH) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-579335-S26041262432013100700000).) Trunk side trim (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S15499890432013100700000).)
3. Remove the nut. (Scheme 35): Lift Spring And Nut With Torque Specification
4. Remove the lift spring. (Scheme 36): Identifying Lift Spring
5. Pull out the fuel-filler lid opener in the direction of the arrow (1). (Scheme 37): Fuel-Filler Lid Opener
6. Disconnect the fuel-filler lid opener from the fuel-filler lid opener cable. (Scheme 38): Fuel-Filler Lid Opener Cable
7. Install in the reverse order of removal.

Scheme 38

Scheme 39

1. Remove the front scuff plate (LH). (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).)
2. Remove the front side trim (LH). (See «FRONT SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S35549025382013100700000).)
3. Remove the fuel-filler lid opener bezel. (See «FUEL-FILLER LID OPENER BEZEL REMOVAL/INSTALLATION»(ref-579335-S29653552942013100700000).)
4. Partially peel back the floor covering. (Scheme 39): Fuel-Filler Lid Opener Lever And Floor Covering
5. Remove the bolts. (Scheme 40): Fuel-Filler Lid Opener Lever And Bolts With Torque Specification
6. Disconnect the cable and fuel-filler lid opener lever.
7. Install in the reverse order of removal.

Scheme 40

Scheme 41

Scheme 42

Scheme 43

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the following parts: Front seat (LH) (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-579337-S11574283732013100700000).) Front scuff plate (LH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Rear seat back (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-579337-S39191899042013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-579335-S26041262432013100700000).) Trunk side trim (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S15499890432013100700000).) Fuel-filler lid opener (See «FUEL-FILLER LID OPENER AND LEVER REMOVAL/INSTALLATION»(ref-579383-S34040062722013100700000).) Fuel-filler lid opener lever (See «FUEL-FILLER LID OPENER AND LEVER REMOVAL/INSTALLATION»(ref-579383-S34040062722013100700000).)
3. Remove the bolts and nut. (Scheme 41): Filler Lid Opener Cable, Bracket, Nut And Bolt With Torque Specification
4. Remove the bracket.
5. Remove the fuel-filler lid opener cable from clips A and B. (Scheme 42): Fuel-Filler Lid Opener Cable And Clips A And B
6. Remove the fuel-filler lid opener cable from clips C.
7. Remove the fuel-filler lid opener cable from clips D and E. (Scheme 43): Fuel-Filler Lid Opener Cable And Clips D And E
8. Remove the fuel-filler lid opener cable from clips F. (Scheme 44): Fuel-Filler Lid Opener Cable And Clips F
9. Install in the reverse order of removal.

Scheme 44

Scheme 45

Scheme 46

Scheme 47

1. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
2. Remove the following parts: Front seat (LH) (See «FRONT SEAT REMOVAL/INSTALLATION»(ref-579337-S11574283732013100700000).) Front scuff plate (LH) (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S29057485522013100700000).) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-579335-S04781736302013100700000).) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-579335-S14141648622013100700000).) Rear seat cushion (See «REAR SEAT CUSHION REMOVAL/INSTALLATION»(ref-579337-S31479351002013100700000).) Rear seat back (See «REAR SEAT BACK REMOVAL/INSTALLATION»(ref-579337-S39191899042013100700000).) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-579335-S24925364282013100700000).) Trunk side upper trim (RH) (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-579335-S34533080142013100700000).) Trunk end trim (See «TRUNK END TRIM REMOVAL/INSTALLATION»(ref-579335-S26041262432013100700000).) Trunk side trim (RH) (See «TRUNK SIDE TRIM REMOVAL/INSTALLATION»(ref-579335-S15499890432013100700000).) Fuel-filler lid opener (See «FUEL-FILLER LID OPENER AND LEVER REMOVAL/INSTALLATION»(ref-579383-S34040062722013100700000).) Fuel-filler lid opener lever (See «FUEL-FILLER LID OPENER AND LEVER REMOVAL/INSTALLATION»(ref-579383-S34040062722013100700000).)
3. Remove the bolts and nut. (Scheme 45): Filler Lid Opener Cable, Bracket, Nut And Bolt With Torque Specification
4. Remove the bracket.
5. Remove the fuel-filler lid opener cable from clips A and B. (Scheme 46): Fuel-Filler Lid Opener Cable And Clips A And B
6. Remove the fuel-filler lid opener cable from clips C.
7. Remove the fuel-filler lid opener cable from clips D and E. (Scheme 47): Fuel-Filler Lid Opener Cable And Clips D And E
8. Remove the fuel-filler lid opener cable from clips F. (Scheme 48): Fuel-Filler Lid Opener Cable And Clips F
9. Install in the reverse order of removal.

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}. (Scheme 49): Identifying Front Door Glass Distance
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-579335-S26275577612013100700000).) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-579335-S20706949142013100700000).) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-579336-S02963356692013100700000).) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION»(ref-579414-S25796711262013100700000).) Front door module panel (See «FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION»(ref-579410-S39962724232013100700000).)
4. Remove the service hole cover. (Scheme 50): Identifying Service Hole Cover
5. Remove the tab, then remove the door lock-link bracket. (Scheme 51): Door Lock-Link Bracket And Tab With Torque Specifications
6. Remove the service hole cover. (Scheme 52): Service Hole Cover
7. Remove the screw from the service hole. NOTE: The screw cannot be removed because of the stopper. (Scheme 53): Identifying Service Hole Screw
8. Lift the clip in the direction of the arrow (1), and pull out the key rod in the direction of the arrow (2). (Scheme 54): Pulling Out Key Rod
9. Press the tab on the front outer handle bracket in the direction of the arrow. (Scheme 55): Pressing Tab On Front Outer Handle Bracket
10. Maintaining the condition in Step 9, remove the front key cylinder. (Scheme 56): Front Key Cylinder
11. Using a tape-wrapped fastener remover, press up the collar cap in the direction of the arrow shown in the arrow, press aside the front door key cylinder tabs (1), and remove the collar cover from the front door key cylinder. (Scheme 57): Pressing Up Collar Cap
12. Install in the reverse order of removal.

Scheme 57

Scheme 58

Scheme 59

1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}. (Scheme 58): Identifying Front Door Glass Distance
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-579335-S26275577612013100700000).) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-579335-S20706949142013100700000).) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-579336-S02963356692013100700000) ) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION»(ref-579414-S25796711262013100700000).) Front door module panel (See «FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION»(ref-579410-S39962724232013100700000).) Front door latch and lock actuator (See «FRONT DOOR LATCH AND LOCK ACTUATOR REMOVAL/INSTALLATION»(ref-579383-S26390512442013100700000).)
4. Move the rod of the door key cylinder switch in the direction of the arrow shown in the figure, and verify that the continuity is as indicated in the table. (Scheme 59): Door Key Cylinder Switch Circuit And Terminal Identification If not as indicated in the table, replace the front door latch and lock actuator. (Scheme 60): Front Door Latch And Lock Actuator Terminal Continuity And Resistance Chart

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

1. To access the glass installation bolt, position the front door glass so that the distance from the top of the front door glass to the upper part of the front beltline molding is approx. 80 mm {3.1 in}. (Scheme 61): Identifying Front Door Glass Distance
2. Disconnect the negative battery cable. (See «BATTERY REMOVAL/INSTALLATION [MZR 2.0, MZR 2.5]»(ref-579330-S31782573982013100700000).) (See «BATTERY REMOVAL/INSTALLATION [MZR 2.3 DISI TURBO]»(ref-579331-S30971870802013100700000).) (See «BATTERY REMOVAL/INSTALLATION [SKYACTIV-G 2.0]»(ref-579332-S32330103212013100700000).)
3. Remove the following parts: Inner garnish (See «INNER GARNISH REMOVAL/INSTALLATION»(ref-579335-S26275577612013100700000).) Front door trim (See «FRONT DOOR TRIM REMOVAL/INSTALLATION»(ref-579335-S20706949142013100700000).) Front inner handle (See «INNER HANDLE REMOVAL/INSTALLATION»(ref-579383-S01306976542013100700000).) Front door speaker (See «FRONT DOOR SPEAKER REMOVAL/INSTALLATION»(ref-579336-S02963356692013100700000).) Front door glass (See «FRONT DOOR GLASS REMOVAL/INSTALLATION»(ref-579414-S25796711262013100700000).) Front door module panel (See «FRONT DOOR MODULE PANEL REMOVAL/INSTALLATION»(ref-579410-S39962724232013100700000).)
4. Remove the service hole cover (with front door key cylinder). (Scheme 62): Service Hole Cover
5. Remove the tab, then remove the door lock-link bracket (with front door key cylinder). (Scheme 63): Door Lock-Link Bracket And Nut With Torque Specification
6. Disconnect the key rod from the front outer handle bracket. (Scheme 64): Key Rod And Front Outer Handle Bracket
7. Remove the screw. (Scheme 65): Front Outer Handle Bracket Screw And Clip With Torque Specification
8. Detach the clips.
9. Press down the rod holder of the front door latch and lock actuator in the direction of the arrow. (Scheme 66): Pressing Down Rod Holder Of Front Door Latch And Lock Actuator
10. Maintaining the condition in Step 9, remove the front door latch and lock actuator. see scheme 67: Front Door Latch And Lock Actuator
11. Install in the reverse order of removal.
