Symptom Troubleshooting (L3 with TC): Overview Mazda 3 BK рестайлинг

Testing & Diagnostics 13 illustrations ~282 words

Scheme 180

Scheme 180: SYMPTOM TROUBLESHOOTING WIRING DIAGRAM [L3 WITH TC]

Scheme 181

Scheme 181

Scheme 182

Scheme 182: FOREWORD [L3 WITH TC]
  1. When the customer reports a vehicle malfunction, check the malfunction indicator lamp (MIL) indication and diagnostic trouble code (DTC), then diagnose the malfunction according to the following flowchart: If a DTC exists, diagnose the applicable DTC inspection. (See «DTC TABLE [L3 WITH TC]»(/mazda/3/bk-2006-2009/remont/testing-diagnostics/#on-board-diagnostic-engine-control-system-l3-with-tc).) If no DTC exists and the MIL does not illuminate or flash, diagnose the applicable symptom troubleshooting. (See «QUICK DIAGNOSTIC CHART [L3 WITH TC]» ).
  1. Verify malfunction symptoms using the following diagnostic index, then go to the appropriate troubleshooting chart.

Diagnostic Index

No.TROUBLESHOOTING ITEMDESCRIPTION
1Melting of main or other fuses
2MIL illuminatesMIL is illuminated.
3Will not crankStarter does not work.
4Hard to start/long crank/erratic start/erratic crankStarter cranks engine at normal speed but engine requires excessive cranking time before starting.
5Engine stalls.After start/at idleEngine stops unexpectedly at idle or after start or both.
6Cranks normally but will not startStarter cranks engine at normal speed but engine will not run.
7Slow return to idleEngine takes more time than normal to return to idle speed.
8Engine runs rough/rolling idleEngine speed fluctuates between specified idle speed and lower speed and engine shakes excessively.
9Fast idle/runs onEngine speed continues at fast idle after warm-up. Engine runs after ignition switch is turned off.
10Low idle/stalls during decelerationEngine stops unexpectedly at beginning of deceleration or recovery from deceleration.
11Engine stalls/quits.Acceleration/cruiseEngine stops unexpectedly at beginning of acceleration or during acceleration. Engine stops unexpectedly while cruising.
Engine runs rough.Acceleration/cruiseEngine speed fluctuates during acceleration or cruising.
MissesAcceleration/cruiseEngine misses during acceleration or cruising.
Buck/jerkAcceleration/cruise/decelerationVehicle bucks/jerks during acceleration, cruising, or deceleration.
Hesitation/stumbleAccelerationMomentary pause at beginning of acceleration or during acceleration
SurgesAcceleration/cruiseMomentary minor irregularity in engine output
12Lack/loss of powerAcceleration/cruisePerformance is poor under load. (e.g., power down when climbing hills)
13Knocking/pingingAcceleration/cruiseSound is produced when air/fuel mixture is ignited by something other than spark plug. (e.g., hot spot in combustion chamber)
14Poor fuel economyFuel economy is unsatisfactory.
15Emission complianceFails emissions test.
16High oil consumption/leakageOil consumption is excessive.
17Cooling system concernsOverheatingEngine runs at higher than normal temperature/overheats.
18Cooling system concernsRuns coldEngine does not reach normal operating temperature.
19Exhaust smokeBlue, black, or white smoke from exhaust system
20Fuel odor (in engine compartment)Gasoline fuel smell or visible leakage
21Engine noiseEngine noise from under hood
22Vibration concerns (engine)Vibration from under hood or driveline
23A/C does not work sufficiently.A/C compressor magnetic clutch does not engage when A/C is turned on.
24A/C is always on or A/C compressor runs continuously.A/C compressor magnetic clutch does not disengage.
25A/C is not cut off under WOT conditions.A/C compressor magnetic clutch does not disengage under WOT.
26Exhaust sulphur smellRotten egg smell (sulphur) from exhaust
27Fuel refill concernsFuel tank does not fill smoothly.
28Fuel filling shut off issuesFuel does not shut off properly.
29Spark plug conditionIncorrect spark plug condition

DIAGNOSTIC INDEX DESCRIPTION

Scheme 183

Scheme 183: CONTROL SYSTEM DEVICE AND CONTROL RELATIONSHIP CHART [L3 WITH TC]

Scheme 184

Scheme 184

Scheme 185

Scheme 185: QUICK DIAGNOSTIC CHART [L3 WITH TC]

Scheme 186

Scheme 186

Scheme 187

Scheme 187

Scheme 188

Scheme 188

Scheme 189

Scheme 189

Scheme 190

Scheme 190

Scheme 191

Scheme 191

Scheme 192

Scheme 192: NO.1 MELTING OF MAIN OR OTHER FUSES [L3 WITH TC]
Damaged fuseRelated wiring harness
BTNBTN fuse OBD fuse (PJB) DLC-2
IG KEY1IG KEY1 fuse Ignition switch ENGINE fuse (PJB)
IG KEY2IG KEY 2 fuse Ignition switch Starter relay starter interlock switch
ENG+BENG +B fuse PCM
ENGINEENGINE fuse Main relay ENG BAR 1 fuse ENG BAR 2 fuse ENG BAR 3 fuse PCM
FUEL PUMPFUEL PUMP fuse Fuel pump resistor Fuel pump speed control relay Fuel pump relay Fuel pump unit
INJECTORINJ fuse Injector relay PCM
ETCETC fuse Drive-by-wire relay PCM
ENG BAR 1ENG BAR 1 fuse APP sensor PCM Drive-by-wire relay Oil control valve CKP sensor EGR valve Wastegate control solenoid valve Purge solenoid valve Variable swirl solenoid valve CMP sensor MAF/IAT sensor EVAP system leak detection pump
ENG BAR 2ENG BAR fuse PCM
ENG BAR 3ENG BAR fuse Front HO2S
FANFAN fuse Fan control module
MAINMAIN fuse Generator Starter
STARTERSTARTER fuse Starter relay Starter
ENGINE (PJB)ENGINE fuse (PJB) Fuel pump speed control relay Fuel pump relay PCM Injector relay Ignition coil (No.1, No.2, No.3, No.4) Condenser Rear HO2S

FUSES DESCRIPTION

Main Relay Operation Inspection

  1. Verify that the main relay clicks when the ignition switch is turned to ON position and then off. If there is no operation sound, inspect the following: Main relay (See «RELAY INSPECTION».) Wiring harness and connector between ignition switch and main relay terminal A. Wiring harness and connector between PCM terminal 1 AT and main relay terminal B.

Variable Swirl System Operation Inspection

  1. Connect the M-MDS to the DLC-2.
  2. Access the ECT PID.
  3. Verify that the ECT PID is below 60°C {140°F}.
  4. Start the engine.
  5. Inspect the rod operation under the following conditions

Rod operation

Engine speed3,750 rpm
BelowAbove
Shutter valve actuatorOperateNot operate

ROD OPERATION SPECIFICATIONS

If the rod operation is not specified, inspect as follows

  1. Perform the KOER self-test using the M-MDS and verify that DTCs No. P2004, P2006, P2009 or P2010 are not displayed. If DTC No. P2004, P2006, P2009 or P2010 are displayed, perform DTC inspection. (See «DTC TABLE [L3 WITH TC]»(/mazda/3/bk-2006-2009/remont/testing-diagnostics/#on-board-diagnostic-engine-control-system-l3-with-tc) .)

See also:
DTC TABLE [L3 WITH TC]
