On-Board Diagnostic - Engine Control System: Overview Mazda 3 BK рестайлинг

Scheme 205

1. Connect the M-MDS to the DLC-2.
2. After the vehicle is identified, select the following items from the initial screen of the M-MDS. When using the IDS (laptop PC) Select the "Toolbox" tab. Select "Self Test". Select "Modules". Select "GEM". When using the PDS (Pocket PC) Select "Module Tests". Select "GEM". Select "Self Test".
3. Verify the DTC according to the directions on the screen. If any DTCs are displayed, perform troubleshooting according to the corresponding DTC inspection.
4. After completion of repairs, clear all DTCs stored in the PJB.

See also:
• PASSENGER JUNCTION BOX (PJB) REMOVAL/INSTALLATION
• DTC TABLE [LF, L3]
• PARKING BRAKE SWITCH INSPECTION
