Washer System & Wiper System: Other Mazda 3 BK

REAR WASHER NOZZLE CLEANING

1. Clean the rear washer nozzle. (See «WINDSHIELD WASHER NOZZLE CLEANING»(ref-177788-S19889330922005060700000) .)

Scheme 36

1. Insert a needle or an equivalent tool into the spray hole of the rear washer nozzle and adjust the nozzle direction as shown.

Scheme 37

Scheme 38

1. Disconnect the negative battery cable.
2. Slightly bend back the mudguard (RH).
3. Disconnect the rear washer hose A from the washer tank.
4. Remove rear washer hose A from clips A.
5. Remove A-pillar trim (RH). (See «A-PILLAR TRIM REMOVAL/INSTALLATION»(ref-177786-S26159187132005060700000) .)
6. Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-177786-S24941703152005060700000) .)
7. Remove the dashboard garnish. (See «DASHBOARD GARNISH REMOVAL/INSTALLATION»(ref-177786-S12783176002005060700000) .)
8. Disconnect joint pipe, then remove the rear washer hose A.
9. Remove rear washer hose B from the clips B.
10. Remove the following parts: Upper anchor of the front seat belt (See «FRONT SEAT BELT REMOVAL/INSTALLATION»(ref-177794-S05376933222005060700000) .) Front scuff plate (See «FRONT SCUFF PLATE REMOVAL/INSTALLATION»(ref-177786-S35097446782005060700000) .) Rear scuff plate (See «REAR SCUFF PLATE REMOVAL/INSTALLATION»(ref-177786-S15571640632005060700000) REAR SCUFF PLATE REMOVAL/INSTALLATION.) B-pillar lower trim (See «B-PILLAR LOWER TRIM REMOVAL/INSTALLATION»(ref-177786-S07584945072005060700000) .) B-pillar upper trim (See «B-PILLAR UPPER TRIM REMOVAL/INSTALLATION»(ref-177786-S05563668902005060700000) N.) Rear seat (See «REAR SEAT REMOVAL/INSTALLATION»(ref-177805-S40569716222005060700000) REAR SEAT REMOVAL/INSTALLATION.) Tire house trim (See «TIRE HOUSE TRIM REMOVAL/INSTALLATION»(ref-177786-S13536083402005060700000) .) Trunk side upper trim (See «TRUNK SIDE UPPER TRIM REMOVAL/INSTALLATION»(ref-177786-S35215762612005060700000) .) C-pillar trim (See «C-PILLAR TRIM REMOVAL/INSTALLATION»(ref-177786-S16755661482005060700000) .) Map light (See «MAP LIGHT REMOVAL/INSTALLATION»(ref-177787-S26550087392005060700000) .) Sunvisor (See «SUNVISOR REMOVAL/INSTALLATION»(ref-177786-S26774954292005060700000) SUNVISOR REMOVAL/INSTALLATION.) Assist handle (See «ASSIST HANDLE REMOVAL/INSTALLATION»(ref-177786-S40787210042005060700000) ASSIST HANDLE REMOVAL/INSTALLATION.)
11. Disconnect the joint pipe B.
12. Remove the headliner. (See «HEADLINER REMOVAL/INSTALLATION»(ref-177786-S31478864142005060700000) .)
13. Remove rear washer hose B and the tapes.
14. Remove clips C from the body.
15. Disconnect the joint pipe C, then remove rear washer hose C.
16. Remove rear washer hose D from the rear washer nozzle.
17. Install in the reverse order of removal.
