Lighting Systems: Other Mazda 3 BK

DISCHARGE HEADLIGHT CONTROL MODULE REUSE

1. If the discharge headlight control module is dented or damaged in any way, replace the module with a new one to prevent electrical shock and improper operation.
2. Although the control module may temporarily operate normally even though it has received an impact, it is possible that the interior may have been damaged. When reusing the control module, inspect the following items regarding discharge headlight illumination to verify that there are no malfunctions. Verify that the discharge headlights illuminate normally by testing them several times under cold illumination (headlights off for approx. 10 min or more and then turned on) and hot illumination (headlights on for approx. 15 min or more, turned off for approx. 1 min, and then turned on again) conditions. Inspect the headlight illumination in the period from directly after cold illumination until they are uniformly illuminated (approx. 5 min) and verify that there is no flickering or inconsistent brightness. Turn on the headlights for approx. 30 min with normal condition bulbs and verify that there is no brightness difference between the right and left, and that illumination is consistent.

Discharge type

Scheme 14

1. Disconnect the negative battery cable.
2. Remove the front bumper. (See FRONT BUMPER REMOVAL/INSTALLATION .)
3. Remove the front combination light. (See «FRONT COMBINATION LIGHT REMOVAL/INSTALLATION»(ref-177787-S08872155502005060700000) .)
4. Remove the cover. CAUTION: The bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
5. Remove the connector, then remove the discharge headlight bulb.
6. Install in the reverse order of removal.

Scheme 15

1. Disconnect the negative battery cable.
2. Disconnect the connector. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When replacing the bulb, hold the metal flange, not the glass.
3. Remove the socket, then remove the headlight bulb.
4. Install in the reverse order of removal.

Discharge Headlight Inoperative

Scheme 16

Scheme 17

Scheme 18

Scheme 19

1. Connect the WDS or equivalent to the DLC-2 (16-pin).
2. Select "Module programming" from the menu.
3. Select "Programmable Parameters".
4. Select "Exterior Lighting".
5. Select "Standard" or "Low" on the WDS or equivalent to set the illumination level.

Scheme 20

1. Disconnect the negative battery cable.
2. Disconnect the connector.
3. Remove the socket, then remove the parking light bulb.
4. Install in the reverse order of removal.

Scheme 21

1. Disconnect the negative battery cable.
2. Remove the fasteners and slightly bend back the mudguard.
3. Disconnect the connector.
4. Remove the socket, then remove the front turn light bulb.
5. Install in the reverse order of removal.

Scheme 22

1. Disconnect the negative battery cable.
2. Remove the under cover.
3. Slightly bend back the mudguard.
4. Disconnect the front fog light connector.
5. Remove the screws, then remove the front fog light.
6. Install in the reverse order of removal.
7. Adjust the front fog light aiming. (See «FRONT FOG LIGHT AIMING»(ref-177787-S25813142072005060700000) .)

Scheme 23

Scheme 24

1. Adjust the tire pressure to the specification.
2. Position the unloaded vehicle on a flat, level surface.
3. Seat one person in the driver's seat.
4. Position the vehicle straight ahead and perpendicular to a white screen.
5. Set the fog lights 3 m {9.8 ft} from the white screen.
6. Place an object in front of the fog light not being adjusted to block its light beam.
7. Start the engine so that the battery remains charged.
8. Turn the front fog lights on.
9. Loosen the screw and the adjusting bolt, move the front fog light in the direction of the arrows, and adjust the front fog light beam to the position shown in the figure.
10. Tighten the adjusting bolt, then tighten the screw.

Scheme 25

1. Disconnect the negative battery cable.
2. Slightly bend back the mudguard.
3. Disconnect the front fog light bulb connector and remove the front fog light bulb by turning it in the direction of the arrow. CAUTION: A halogen bulb generates extremely high heat when it is illuminated. If the surface of the bulb is soiled, excessive heat will build up and the life of the bulb will be shortened. When handling the bulb, hold the flange, not the glass.
4. Install in the reverse order of removal.

Scheme 26

1. Disconnect the negative battery cable.
2. Move the front side turn light in the direction of the arrow (1) and detach the tab.
3. Pull area A of the front side turn light in the direction of the arrow (2) and remove the front side turn light.
4. Disconnect the front side turn light connector.
5. Install in the reverse order of removal.

Scheme 27

1. Disconnect the negative battery cable.
2. Remove the trunk end trim. (4 door) (See TRUNK END TRIM REMOVAL/INSTALLATION .)
3. Remove the fasteners and slightly bend back the trunk side trim. (4 door)
4. Remove the service hole cover. (5 door)
5. Remove in the order indicated in the table. REMOVAL ORDER OF REAR COMBINATION LIGHT Removal Order Part 1 Nut 2 Connector 3 Rear combination light 4 Socket 5 Rear turn light bulb 6 Brake light/taillight bulb
6. Install in the reverse order of removal.

Scheme 28

1. Disconnect the negative battery cable.
2. Remove the service hole cover.
3. Disconnect the rear combination light bulb connector.
4. Remove the socket.
5. Remove the rear combination light bulb.
6. Install in the reverse order of removal.

Scheme 29

1. Disconnect the negative battery cable.
2. Remove the trunk lid trim. (4 door) (See TRUNK LID TRIM REMOVAL/INSTALLATION .)
3. Remove the service hole cover. (5 door)
4. Remove in the order indicated in the table. REMOVAL ORDER OF INBOARD LIGHT Removal Order Part 1 Nut 2 Bracket 3 Connector 4 Inboard light (See «Inboard Light Installation Note»(ref-177787-S36955926862005060700000) .) 5 Socket 6 Back-up light bulb
5. Install in the reverse order of removal.

Scheme 30

Scheme 31

1. Insert the inboard light into the trunk lid (liftgate) as shown in the figure, then pivot it inward and fix in place.
2. Push the bracket onto the trunk lid (liftgate) as shown in the figure and install.

Scheme 32

1. Disconnect the negative battery cable.
2. Remove the service hole cover.
3. Disconnect the inboard light bulb connector.
4. Remove the socket.
5. Remove the inboard light bulb.
6. Install in the reverse order of removal.

Scheme 33

1. Disconnect the negative battery cable.
2. Remove the trunk lid trim. (See TRUNK LID TRIM REMOVAL/INSTALLATION .)
3. Remove in the order indicated in the table. REMOVAL ORDER OF HIGH-MOUNT BREAK LIGHT Removal Order Part 1 Connector 2 Socket 3 High-mount brake light bulb 4 Nut 5 High-mount brake light
4. Install in the reverse order of removal.

Scheme 34

1. Disconnect the negative battery cable.
2. Remove the liftgate upper trim. (See LIFTGATE UPPER TRIM REMOVAL/INSTALLATION .)
3. Remove in the order indicated in the table. REMOVAL ORDER OF HIGH-MOUNT LIGHT Removal Order Part 1 Connector 2 Socket 3 High-mount brake light bulb 4 High-mount brake light
4. Install in the reverse order of removal.

Scheme 35

Scheme 36

Scheme 37

1. Disconnect the negative battery cable.
2. Remove the lens, then remove the license plate light bulb.
3. Remove the license plate light from the rear bumper.
4. Remove the trunk end trim. (See TRUNK END TRIM REMOVAL/INSTALLATION .)
5. Remove the fasteners and slightly bend back the trunk side trim (RH).
6. Remove the fasteners and slightly bend back the trunk side trim (LH). (4 door)
7. Remove the service hole cover (LH). (5 door)
8. Remove the rear combination light. (See «REAR COMBINATION LIGHT REMOVAL/INSTALLATION»(ref-177787-S18579508042005060700000) .)
9. Disconnect the license plate light connector.
10. Remove the rear bumper. (See REAR BUMPER REMOVAL/INSTALLATION .)
11. Detach the clips from the rear bumper.
12. Remove the license plate light harness and tape.
13. Install in the reverse order of removal.

Scheme 38

1. Disconnect the negative battery cable.
2. Jack up the vehicle and remove the wheel and tire. (LR)
3. Disconnect the connector.
4. Remove the bolts, then remove the auto leveling sensor.
5. Install in the reverse order of removal.

Scheme 39

1. Disconnect the negative battery cable.
2. Remove the glove compartment. (See GLOVE COMPARTMENT REMOVAL/INSTALLATION .)
3. Disconnect the auto leveling control module connector.
4. Remove the screw, then remove the auto leveling control module.
5. Install in the reverse order of removal.

Scheme 40

1. Disconnect the negative battery cable.
2. Remove the under cover.
3. Disconnect the back-up light switch connector and remove the back-up light switch.
4. Install in the reverse order of removal.

Scheme 41

1. Verify that the continuity between the back-up light switch terminals is as indicated in the table. If not as indicated in the table, replace the back-up light switch.

Scheme 42

1. Disconnect the negative battery cable.
2. Remove the following parts: Driver-side air bag module Steering wheel (See STEERING WHEEL AND COLUMN REMOVAL/INSTALLATION .) Front scuff plate (See FRONT SCUFF PLATE REMOVAL/INSTALLATION .) Front side trim (See FRONT SIDE TRIM REMOVAL/INSTALLATION .) Hood release lever (See HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION. ) Lower panel (See LOWER PANEL REMOVAL/INSTALLATION .) Column cover (See COLUMN COVER REMOVAL/INSTALLATION .) Clock spring
3. Remove in the order indicated in the table. REMOVAL ORDER OF COMBINATION SWITCH Removal Order Part 1 Connector 2 Screw 3 Combination switch (See «Combination Switch Removal Note»(ref-177787-S08015126182005060700000) .)
4. Install in the reverse order of removal.

Scheme 43

1. Pull the combination switch locks in the direction indicated in the figure and disengage the tab.
2. Pull the combination switch outward, then remove it.

Scheme 44

1. Disassemble in the order indicated in the table. DISASSEMBLING ORDER OF COMBINATION OF SWITCH Removal Order Part 1 Screw 2 Wiper and washer switch 3 Light switch 4 Body
2. Assemble in the reverse order of disassembly.

Scheme 45

Scheme 46

1. Verify that the continuity between the front fog light switch terminals is as indicated in the table. If not as indicated in the table, replace the light switch.

Scheme 47

1. Disconnect the negative battery cable.
2. Remove the decoration panel. (See DECORATION PANEL REMOVAL/INSTALLATION .)
3. Remove the dashboard center panel. (See DASHBOARD CENTER PANEL REMOVAL/INSTALLATION .)
4. Disconnect the hazard warning switch connector.
5. Squeeze the tabs of hazard warning switch and pull it outward to remove it.
6. Install in the reverse order of removal.

Scheme 48

Scheme 49

1. Verify that the continuity between the hazard switch terminals is as indicated in the table. If not as indicated in the table, replace the hazard warning switch.

Scheme 50

1. Disconnect the negative battery cable.
2. Detach the hood release lever from the lower panel. (See HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION. )
3. Remove the front scuff plate. (Driver's side) (See FRONT SCUFF PLATE REMOVAL/INSTALLATION .)
4. Remove the front side trim. (Driver's side) (See FRONT SIDE TRIM REMOVAL/INSTALLATION .)
5. Remove the lower panel. (See LOWER PANEL REMOVAL/INSTALLATION .)
6. Remove the headlight leveling switch
7. Disconnect the headlight leveling switch connector.
8. Install in the reverse order of removal.

Scheme 51

Scheme 52

1. Verify that continuity between the headlight leveling switch terminals is as indicated in the table. If not as indicated in the table, replace the headlight leveling switch.

Scheme 53

1. Disconnect the negative battery cable.
2. Remove the following parts: Front scuff plate (Driver's side) (See FRONT SCUFF PLATE REMOVAL/INSTALLATION .) Front side trim (Driver's side) (See FRONT SIDE TRIM REMOVAL/INSTALLATION .) Hood release lever (See HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION. ) Lower panel (See LOWER PANEL REMOVAL/INSTALLATION .) Column cover (See COLUMN COVER REMOVAL/INSTALLATION .)
3. Disconnect the light switch connector.
4. Remove the screws, then remove the light switch.
5. Install in the reverse order of removal.

Scheme 54

Scheme 55

1. Verify that the continuity between the light switch terminals is as indicated in the table. Headlight Switch If not as indicated in the table, replace the light switch.

Turn Switch

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped flathead screwdriver into the gap between the headliner and the map light.
3. Press the tab and remove the map light.
4. Disconnect the map light connector.
5. Remove the socket, then remove the map light bulb.
6. Install in the reverse order of removal.

Scheme 60

Scheme 61

1. Verify that the continuity between the map light terminals is as indicated in the table. If not as indicated in the table, replace the map light.

Scheme 62

Scheme 63

Scheme 64

1. Disconnect the negative battery cable.
2. Insert a tape-wrapped flathead screwdriver into the service hole and pry with the screwdriver in the direction shown by the arrow to remove the lens.
3. Insert a tape-wrapped flathead screwdriver into the gap between the headliner and the interior light.
4. Press the tab and remove the interior light.
5. Disconnect the interior light connector.
6. Install in the reverse order of removal.

Scheme 65

Scheme 66

1. Verify that the continuity between the interior light terminals is as indicated in the table. If not as indicated in the table, replace the interior light.

Scheme 67

1. Disconnect the negative battery cable.
2. Remove the following parts: Front scuff plate (Passenger's side) (See FRONT SCUFF PLATE REMOVAL/INSTALLATION .) Front side trim (Passenger's side) (See FRONT SIDE TRIM REMOVAL/INSTALLATION .) Decoration panel (See DECORATION PANEL REMOVAL/INSTALLATION .) Glove compartment (See GLOVE COMPARTMENT REMOVAL/INSTALLATION .)
3. Remove the socket, then remove the glove compartment light bulb.
4. Install in the reverse order of removal.

Scheme 68

1. Disconnect the negative battery cable.
2. Disengage the tabs by pressing both ends of the lens in the directions indicated by the arrows and remove the lens.
3. Install in the reverse order of removal.

Scheme 69

1. Disconnect the negative battery cable.
2. Remove the cargo compartment light.
3. Disconnect the cargo compartment light connector.
4. Remove the lens.
5. Remove the cargo compartment light bulb.
6. Install in the reverse order of removal.

Scheme 70

Scheme 71

1. Verify that the continuity between the cargo compartment light terminals is as indicated in the table. If not as indicated in the table, replace the cargo compartment light.

Scheme 72

1. Disconnect the negative battery cable.
2. Remove the ashtray panel. (See CONSOLE REMOVAL/INSTALLATION .)
3. Remove the socket, then remove the ashtray illumination bulb.
4. Install in the reverse order of removal.

Scheme 73

1. Disconnect the negative battery cable.
2. Remove the following parts: Front scuff plate (Driver's side) (See FRONT SCUFF PLATE REMOVAL/INSTALLATION .) Front side trim (Driver's side) (See FRONT SIDE TRIM REMOVAL/INSTALLATION .) Hood release lever (See HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION. ) Lower panel (See LOWER PANEL REMOVAL/INSTALLATION .) Column cover (See COLUMN COVER REMOVAL/INSTALLATION .)
3. Remove the ignition key illumination bulb.
4. Install in the reverse order of removal.

Scheme 74

1. Disconnect the negative battery cable.
2. Detach the hood release lever from the lower panel. (See HOOD LATCH AND RELEASE LEVER REMOVAL/INSTALLATION. )
3. Remove the front scuff plate. (Driver's side) (See FRONT SCUFF PLATE REMOVAL/INSTALLATION .)
4. Remove the front side trim. (Driver's side) (See FRONT SIDE TRIM REMOVAL/INSTALLATION .)
5. Remove the lower panel. (See LOWER PANEL REMOVAL/INSTALLATION .)
6. Remove the panel light control switch.
7. Disconnect the panel light control switch connector.
8. Install in the reverse order of removal.
