BODY CONTROL MODULE (BCM) CONFIGURATION

  1. Connect the M-MDS (IDS) to the DLC-2.
  2. After the vehicle is identified, select the following items from the initial screen of the M-MDS. When using the IDS (laptop PC) Select "Module Programming". Select "Programmable Module Installation". Select "BCM/GEM".
  3. Perform the configuration according to the directions on the screen.
  4. Retrieve DTCs by the M-MDS, then verify that there is no DTC present. If a DTC (s) is detected, perform the applicable DTC inspection. (See «DTC TABLE [BCM]»(ref-517478-S18359232532012121200000) .)

Scheme 54

Scheme 54: Removal

Scheme 55

Scheme 55
  1. Disconnect the negative battery cable.
  2. Remove the dashboard under cover. (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-517497-S06456173492012121200000).)
  3. Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-517497-S18570108062012121200000).)
  4. Remove the BCM. (See «BODY CONTROL MODULE (BCM) REMOVAL/INSTALLATION»(ref-517494-S24505124972012121200000).)
  5. Insert a fastener remover in the direction of the arrow (1) shown in the figure and release the tabs. CAUTION: Because the tabs will break if they are bent excessively, bend the tabs only so far as to allow them to release from the BCM. (Scheme 54): BCM Bracket Removal
  6. Pull the BCM in the direction of the arrow (2) as shown in the figure and remove the BCM bracket. (Scheme 55): Removing BCM

Scheme 56

Scheme 56: Installation

Scheme 57

Scheme 57
  1. Bend the tabs in the direction of the arrow (1) so that clearance (a) indicated in the figure is within the specification. (Scheme 56): Identifying Tabs Bending Direction Clearance a: 0.8-1.2 mm {0.032-0.047 in}
  2. Press the BCM in the direction of the arrow (2) as shown in the figure and install it. (Scheme 57): Installing BCM
  3. Install the BCM. (See «BODY CONTROL MODULE (BCM) REMOVAL/INSTALLATION»(ref-517494-S24505124972012121200000).)
  4. Install the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-517497-S18570108062012121200000).)
  5. Install the dashboard under cover. (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-517497-S06456173492012121200000).)
  6. Connect the negative battery cable.
