BODY CONTROL MODULE (BCM) REMOVAL/INSTALLATION
| CAUTION | When replacing the BCM, the configuration procedure must be performed before removing the BCM. Replacing the BCM without performing the configuration procedure will result in system malfunction. |
Scheme 52
Scheme 53
- Perform the BCM configuration when replacing it. (See «BODY CONTROL MODULE (BCM) CONFIGURATION»(ref-517494-S39510232092012121200000).)
- Disconnect the negative battery cable.
- Remove the dashboard under cover. (See «DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(ref-517497-S06456173492012121200000).)
- Remove the glove compartment. (See «GLOVE COMPARTMENT REMOVAL/INSTALLATION»(ref-517497-S18570108062012121200000).)
- Disconnect the connectors at the position shown in the figure. (Scheme 52): Identifying BCM Connectors
- Remove the nuts. (Scheme 53): Identifying BCM Nuts With Torque Specifications
- Remove the BCM.
- Install in the reverse order of removal.
