Automatic Transaxle Shift Mechanism: Overview Mazda 2 II рестайлинг

Scheme 440

Scheme 441

Scheme 442

Scheme 443

1. Disconnect the selector lever component connector. Disconnect the negative battery cable. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-517497-S42051367322012121200000).) Remove the front console component. (See «FRONT CONSOLE COMPONENT REMOVAL/INSTALLATION»(ref-517497-S35138574242012121200000).) Disconnect the selector lever component connector. (Scheme 440): Identifying Selector Lever Component Connector
2. Remove the selector lever component. Disconnect the interlock cable from the selector lever component. (Scheme 441): Interlock Cable And Selector Lever Disconnect the selector cable from the selector lever component. (Scheme 442): Selector Cable And Selector Lever With Torque Specifications Remove the selector lever component. (Scheme 443): Identifying Selector Lever Component With Torque Specifications
3. Install in the reverse order of removal.

Scheme 444

Scheme 445

1. Disconnect the negative battery cable.
2. Remove the clip, and then disconnect the selector cable end from the manual shaft lever. (Scheme 444): Identifying Clip, Selector Cable End And Manual Shaft Lever
3. Disconnect the selector cable from the upper transaxle bracket.
4. Remove the insulator No.1 of the exhaust system. (See «EXHAUST SYSTEM REMOVAL/INSTALLATION [MZR 1.5]»(ref-517448-S29887153912012121200000).)
5. Remove the column cover. (See «COLUMN COVER REMOVAL/INSTALLATION»(ref-517497-S28954925772012121200000).)
6. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-517497-S42051367322012121200000).)
7. Remove the front console component. (See «FRONT CONSOLE COMPONENT REMOVAL/INSTALLATION»(ref-517497-S35138574242012121200000).)
8. Remove in the order indicated in the figure.
9. Install in the reverse order of removal. (Scheme 445): Identifying Automatic Transaxle Shift Mechanism Components With Torque Specifications

Scheme 446

1. Working with two people, one person pushes the ends of the selector cable toward the inside of the vehicle, and at the same time, the other person pulls out the selector cable by pulling the ends of the selector cable. (Scheme 446): Selector Cable Routing

Scheme 447

1. Working with two people, one person pushes the ends of the selector cable toward the lower side of the vehicle from the inside, and at the same time, the other person pulls the ends of the selector cable. (Scheme 447): Selector Cable Routing

Scheme 448

Scheme 449

Scheme 450

Scheme 451

Scheme 452

Scheme 453

1. Install the interlock cable to the key cylinder. Switch the ignition to ACC. Install the interlock cable end to the key cylinder.
2. Install the lock unit to the brake pedal. Align the slide pin with the marking of the lock unit. (Scheme 448): Aligning Slide Pin With Marking Of Lock Unit Insert a snap pin (or a round bar of 1.5 mm {0.059 in} diameter) into hole A with the slide pin inserted completely. (Scheme 449): Slide Pin, Brake Switch And Interlock Cable Insert the other snap pins through hole B and hole C. Replace the brake switch with a new one. (See «BRAKE PEDAL REMOVAL/INSTALLATION»(ref-517456-S11542540532012121200000).) Install the lock unit to the brake pedal bracket. Rotate the slide pin 90° as shown in the figure and verify that the slide pin contacts the brake pedal stopper. (Scheme 450): Rotating Slide Pin 90° Counterclockwise Rotate the slide pin 90° as shown in the figure. (Scheme 451): Rotating Slide Pin 90° Clockwise Verify that the slide pin is aligned with the marking of the lock unit. (Scheme 452): Slide Pin Aligned With Marking Of Lock Unit With the brake pedal released, connect the brake switch connector.
3. Install the interlock cable to the selector lever component. Verify that the selector lever is in the P position. Fit the interlock cable in the U-groove in the selector lever component. Press the lock piece to lock the interlock cable so that no load acts on the cable. (Scheme 453): Identifying Interlock Cable Lock And Unlock Position
4. Pull out the pin from the lock unit.
5. Verify that the interlock cable is properly installed. Inspect the operation of the shift mechanism. (See «SHIFT-LOCK SYSTEM INSPECTION»(ref-517496-S00763353642012121200000).) (See «KEY INTERLOCK SYSTEM INSPECTION»(ref-517496-S16446694222012121200000).) Inspect the brake switch. (See «BRAKE SWITCH INSPECTION [ATX]»(ref-517456-S37704102802012121200000).)

Scheme 454

Scheme 455

Scheme 456

1. Shift the selector lever to the P position.
2. Loosen the nut at the selector cable end. (Scheme 454): Identifying Nut At Selector Cable End
3. Verify that the manual shaft is in the P position. (Scheme 455): Identifying Manual Shaft P Position
4. Tighten the nut at the selector cable end. (Scheme 456): Identifying Nut At Selector Cable End With Torque Specifications
