SELECTOR LEVER INSPECTION
| CAUTION | Water or foreign objects entering the connector can cause a poor connection or corrosion. Be sure not to drop water or foreign objects on the connector when disconnecting it. |
Scheme 457
Scheme 457: Selector Lever Inspection
- Switch the ignition to ON.
- Shift the selector lever to each position and inspect the selector lever. If there is any malfunction, adjust the selector cable. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-517496-S37097310912012121200000).) Verify that the selector lever can be shifted as shown in the figure. (Scheme 457): Identifying Selector Lever Shift Positions Verify that the selector lever can be shifted smoothly and moderately.
Scheme 458
Scheme 458: Selector Lever Illumination Light Inspection
Scheme 459
- Disconnect the selector lever component connector. Disconnect the negative battery cable. Remove the side wall. (See «SIDE WALL REMOVAL/INSTALLATION»(ref-517497-S42051367322012121200000).) Remove the front console component. (See «FRONT CONSOLE COMPONENT REMOVAL/INSTALLATION»(ref-517497-S35138574242012121200000).) Disconnect the selector lever component connector. (Scheme 458): Identifying Selector Lever Component Connector
- Inspect the continuity between the selector lever component terminals E and F. (Scheme 459): Identifying Selector Lever Component Terminals If there is any malfunction, replace the selector lever component. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-517496-S37097310912012121200000).)
Scheme 460
Scheme 460: Interlock Cable Inspection
Scheme 461
- Disconnect the interlock cable from the selector lever component. (Scheme 460): Interlock Cable And Selector Lever
- Switch the ignition to ON.
- Verify that the interlock cable moves smoothly when the brake pedal is depressed. (Scheme 461): Identifying Interlock Cable If there is any malfunction, replace the interlock cable. (See «AUTOMATIC TRANSAXLE SHIFT MECHANISM REMOVAL/INSTALLATION»(ref-517496-S37097310912012121200000).)
SHIFT-LOCK SYSTEM INSPECTION
- Switch the ignition to ON.
- Shift the selector lever to the P position.
- Perform the following procedures to inspect the shift-lock system. If there is any malfunction, inspect the interlock cable. (See «SELECTOR LEVER INSPECTION»(ref-517496-S09528932232012121200000) .) Verify that the selector lever cannot be shifted from the P position to the R position when the brake pedal is released. Verify that the selector lever can be shifted from the P position to the R position when the brake pedal is depressed.
KEY INTERLOCK SYSTEM INSPECTION
- Switch the ignition to ON.
- Perform the following procedures to inspect the key interlock system. If there is any malfunction, inspect the interlock cable. (See «SELECTOR LEVER INSPECTION»(ref-517496-S09528932232012121200000) .) Verify that the ignition cannot be turned to the OFF position when the selector lever is not in the P position. Verify that the ignition can be turned to the OFF position when the selector lever is in the P position.
