Evaporative Emissions System: Other Lincoln MKX I рестайлинг

Phase 1 - Leak Verification

1. Run the EVAP Test with the scan tool.
2. If the Evaporative Emission (EVAP) system failed the EVAP Test, then proceed to «PHASE 2»(ref-494625-S23901436032012081400000) .

Phase 2 - System Leak Check

1. Disconnect the fuel vapor tube-to-EVAP canister purge valve quick connect coupling. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
2. Connect the VACUTEC Smoke Machine Fuel EVAP Emissions System Tester to the fuel vapor tube quick connect coupling. For additional information, refer to the manufacturer's instructions.
3. Connect the battery ground cable. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-494597) .
4. Close the canister vent solenoid with the scan tool.
5. Install the supplemental refueling adapter into the Easy Fuel™ (capless) fuel tank filler pipe assembly.
6. Introduce smoke from the VACUTEC Smoke Machine Fuel EVAP Emissions System Tester into the EVAP system and verify that smoke is exiting the fuel tank filler pipe neck area. For additional information, refer to the manufacturer's instructions.
7. Remove the supplemental refueling adapter once smoke is observed exiting the fuel tank filler pipe neck area.
8. Continue to enter smoke into the system for 60 seconds to obtain pressure.
9. Press and release the remote start button in intervals of 15 seconds ON and 15 seconds OFF while checking for exiting smoke.
10. Use the halogen light provided with the VACUTEC Smoke Machine Fuel EVAP Emissions System Tester to follow the EVAP system path and look for smoke exiting at the source of the leak(s).
11. Repair any leaks as necessary.
12. Repeat the EVAP Leak Test until the system passes.

Scheme 128

Scheme 129

Scheme 130

Scheme 131

1. Detach the hose retainer and disconnect the 2 vapor tube quick connect couplings. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
2. Detach the hose retainer and disconnect the vapor tube quick connect coupling. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) .
3. Disconnect the purge valve electrical connector and the vapor tube quick connect coupling and remove the fastener. For additional information, refer to «FUEL SYSTEM - GENERAL INFORMATION»(ref-494614) . To install, tighten to 5 Nm (44 lb-in).
4. Remove the canister purge valve assembly.
5. To install, reverse the removal procedure.

Scheme 132
