Automatic Transaxle External Controls: Removal & Installation Lincoln MKX I рестайлинг

Automatic Trans 6 illustrations ~321 words

Removal

All vehicles

Pinpoint Test D

D3 6F50/6F55
  1. 6F50/6F55
D5 6F35
  1. 6F35
D11 All vehicles
  1. All vehicles

Installation

All vehicles

Pinpoint Test D

D3 6F35
  1. 6F35
D11 6F50/6F55
  1. 6F50/6F55
D17 All vehicles
  1. All vehicles

Scheme 7

Scheme 7: MKX Selector Lever
Scheme 7: MKX Selector Lever
ItemPart NumberDescription
178061A16Upper finish molding
27804567BFloor console H-panel
378045A76Selector lever trim panel
4W503926Selector lever bolt (4 required)
57210Selector lever
67804609Upper floor console side trim panel
77804609Lower floor console side trim panel
8Selector lever electrical connector (part of 7210)
97E395Selector lever cable
10W707628Selector lever trim panel screw (8 required)
1178045A76Selector lever trim panel

Scheme 8

Scheme 8: Edge Selector Lever
Scheme 8: Edge Selector Lever
ItemPart NumberDescription
178061A16Upper finish molding
2W790141Selector lever trim panel screw (4 required)
378045A76Selector lever trim panel
4W503926Selector lever bolt (4 required)
57210Selector lever
67804609Floor console side trim panel
778045F54Console plate
8Selector lever electrical connector (part of 7210)
97E395Selector lever cable

All Vehicles

Pinpoint Test D

D4 MKX
  1. MKX
D16 Edge
  1. Edge
D25 All vehicles
  1. All vehicles

Scheme 9

Scheme 9: MKX Selector Lever Knob
Scheme 9: MKX Selector Lever Knob
ItemPart NumberDescription
178061A16Upper finish molding
27804567Floor console H-panel
378045A76Selector lever trim panel
47213Selector lever knob
5Selector lever knob connector (part of 7213)
67277Selector lever boot
77804609LH upper floor console side trim panel
87804609LH lower floor console side trim panel
9W790167Selector lever knob screw (2 required)
10W707628Selector lever trim panel screw (8 required)

Scheme 10

Scheme 10: Edge Selector Lever Knob
Scheme 10: Edge Selector Lever Knob
ItemPart NumberDescription
178061A16RH upper finish moulding
278061A17LH upper finish moulding
3W790141Selector lever trim panel screw (4 required)
478045A76Selector lever trim panel
57213Selector lever knob
6W790167Selector lever knob screw (2 required)
77804609LH floor console side trim panel
878045F54Upper floor console side trim panel
97804608RH floor console side trim panel

All Vehicles

Pinpoint Test D

D4 MKX
  1. MKX
D16 Edge
  1. Edge
D25 All vehicles
  1. All vehicles

Scheme 11

Scheme 11: Selector Lever - Paddle Shift
Scheme 11: Selector Lever - Paddle Shift

Scheme 12

Scheme 12
Scheme 12
  1. Remove the driver air bag module. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-494575) .
  2. Remove the 3 steering wheel switch trim bezel screws.
  3. Disconnect the steering wheel switch electrical connectors.
  4. Remove the steering wheel switch trim.
  5. Remove the paddle shifter. Disconnect the paddle shifter. Remove the 2 bolts and the paddle shifter. To install, tighten to 5 Nm (44 lb-in).
  6. To install, reverse the removal procedure.

Removal and Installation

Note. The SelectShift™ switch is part of the selector lever knob.

  1. To install a new SelectShift™ switch, a new selector lever knob must be installed. For additional information, refer to «SELECTOR LEVER KNOB»(ref-494610-S05758695022012081400000) .

More articles — Automatic Transaxle External Controls
