Power Memory Mirrors: Diagnosis Lincoln Continental IX

Mirrors 12 illustrations ~6313 words

TROUBLE SHOOTING

Before performing individual component tests and system test, check the following for possible cause of system malfunction. Repair any problems as necessary and operate seat to see if malfunction is repaired. If malfunction still exists, go to SYSTEM TESTING.

  1. Blown fuses or faulty circuit breakers.
  2. Loose or corroded connectors.
  3. Damaged wiring.
  4. Damaged mirror assembly.
  5. Faulty switches.

SYSTEM TESTING

Note. Before beginning system testing, perform TROUBLE SHOOTING.

Note. A New Generation Star (NGS) tester is required to test the power mirror system. If NGS tester does not communicate with vehicle, refer to NGS tester manual.

Connect New Generation Star (NGS) tester to data link connector. Perform DATALINK DIAGNOSTIC TEST. See MODULE COMMUNICATIONS NETWORK. If NGS tester responds with CKT 914 and CKT 915=ALL MODULES NO RESPONSE/NOT EQUIPPED, diagnose network concern. See MODULE COMMUNICATIONS NETWORK article. If NGS tester responds with, NO RESPONSE/NOT EQUIPPED for Driver Seat Module (DSM) or exits self-test and returns to normal operating state, go to TEST B under DIAGNOSTIC TESTS. If NGS tester responds with, NO RESPONSE/NOT EQUIPPED for Driver Door Module (DDM) or exits self-test and returns to normal operating state, go to TEST A under DIAGNOSTIC TESTS.

If NGS tester responds with SYSTEM PASSED for all modules, retrieve DTCs for both modules. If any DTCs exist, perform appropriate test. See appropriate DIAGNOSTIC TROUBLE CODE INDEX table. If no DTCs were retrieved, repair system by symptom. See SYMPTOM CHART table and perform appropriate test.

DTCDescriptionGo To Test
B1342DSM Defective(1)
B1663Driver Seat Front Up/Down Circuit Failure(2)
B1664Driver Seat Rear Up/Down Circuit Failure(2)
B1665Driver Seat Fore/Back Circuit Failure(2)
B1666Driver Seat Recline Circuit Failure(2)
B1667Driver Mirror Up/Down Circuit FailureC
B1668Driver Mirror Right/Left Circuit FailureC
B1669Passenger Mirror Up/Down Circuit FailureC
B1670Passenger Mirror Right/Left Circuit FailureC
B1676Battery Voltage Out Of Range(2)
B1950Rear Up/Down Feedback - Circuit Failure(2)
B1953Rear Up/Down Feedback - Short to Ground(2)
B1954Front Up/Down Feedback - Circuit Failure(2)
B1957Front Up/Down Feedback - Short to Ground(2)
B1958Recline Feedback - Circuit Failure(2)
B1961Recline Feedback - Short To Ground(2)
B1962Horizontal Feedback - Circuit Failure(2)
B1965Horizontal Feedback - Short To Ground(2)
B2312Passenger Mirror Horizontal Feedback Potentiometer - Circuit FailureD
B2315Passenger Mirror Horizontal Feedback Potentiometer - Short To GroundD
B2316Passenger Mirror Vertical Feedback Potentiometer - Circuit FailureD
B2319Passenger Mirror Vertical Feedback Potentiometer - Short To GroundD
B2320Driver Mirror Horizontal Feedback Potentiometer - Circuit FailureD
B2323Driver Mirror Horizontal Feedback Potentiometer - Shirt To GroundD
B2324Driver Mirror Vertical Feedback Potentiometer - Circuit FailureD
B2327Driver Mirror Vertical Feedback Potentiometer - Short To GroundD
U1059Invalid/Missing Data, Trans Range(3)
U1135Invalid/Missing Data, Ignition Switch(4)
U1181Invalid/Missing Data, Memory Feature(5)
U1181Invalid/Missing Data, Memory Feature(6)
U1194Invalid/Missing Data, Mirrors(5)
U1200Invalid/Missing Data, Seat Motion/Control(7)
U1262Bus Communication Fault(8)
(1) Replace driver seat module. (2) See POWER SEATS article. (3) DTC caused by powertrain control module. See TESTS W/CODES article in ENGINE PERFORMANCE article. (4) DTC caused by lighting control module. See INSTRUMENT PANEL article. (5) DTC caused by driver door module. Perform DDM self-test. (6) DTC caused by virtual image electronic instrument cluster. See INSTRUMENT PANEL article. (7) DTC caused by driver door module. See POWER SEATS article. (8) Service all other DTCs first. After all other DTCs have been repaired, see MODULE COMMUNICATIONS NETWORK article.
(1)Replace driver seat module.
(2)See POWER SEATS article.
(3)DTC caused by powertrain control module. See TESTS W/CODES article in ENGINE PERFORMANCE article.
(4)DTC caused by lighting control module. See INSTRUMENT PANEL article.
(5)DTC caused by driver door module. Perform DDM self-test.
(6)DTC caused by virtual image electronic instrument cluster. See INSTRUMENT PANEL article.
(7)DTC caused by driver door module. See POWER SEATS article.
(8)Service all other DTCs first. After all other DTCs have been repaired, see MODULE COMMUNICATIONS NETWORK article.

DIAGNOSTIC TROUBLE CODE INDEX (DSM)

DTCDescriptionGo To Test
B1319Left Front Door Ajar Circuit Failure(1)
B1342DDM Defective(2)
B1396Power Door Lock Short To Voltage(3)
B1397Power Door Unlock Short To Voltage(3)
B1525Keyless Entry Short To Voltage(3)
B1541Driver Mirror Short To VoltageC
B1545Power Seat Switch Short To Voltage.(4)
B1549Power Window Switch Short To Voltage(5)
B1554Trunk Release Switch Short To Ground(3)
B1562Door Lock Cylinder Short To Ground(3)
U1041Invalid/Missing Data For Vehicle Speed(6)
U1059Invalid/Missing Data For Transmission Range(7)
U1089Invalid/Missing Data For Suspension(8)
U1181Invalid/Missing Data For Memory Feature(9)
U1262Bus Communication Fault(10)
(1) See ILLUMINATION/INTERIOR LIGHTS wiring diagram in SYSTEM WIRING DIAGRAMS article in the WIRING DIAGRAMS section. (2) Replace driver door module. (3) See REMOTE KEYLESS ENTRY SYSTEM article. (4) See POWER SEATS article. (5) See POWER WINDOWS article. (6) DTC caused by ABS system. See ANTI-LOCK BRAKE SYSTEM article in the BRAKES section. (7) DTC caused by powertrain control module. See TESTS W/CODES article in the ENGINE PERFORMANCE section. (8) DTC caused vehicle dynamic module. See appropriate article in SUSPENSION section. (9) DTC caused by virtual image electronic instrument cluster. See INSTRUMENT PANEL article. (10) Service all other DTCs first. After all other DTC have been repaired, see MODULE COMMUNICATIONS NETWORK article.
(1)See ILLUMINATION/INTERIOR LIGHTS wiring diagram in SYSTEM WIRING DIAGRAMS article in the WIRING DIAGRAMS section.
(2)Replace driver door module.
(3)See REMOTE KEYLESS ENTRY SYSTEM article.
(4)See POWER SEATS article.
(5)See POWER WINDOWS article.
(6)DTC caused by ABS system. See ANTI-LOCK BRAKE SYSTEM article in the BRAKES section.
(7)DTC caused by powertrain control module. See TESTS W/CODES article in the ENGINE PERFORMANCE section.
(8)DTC caused vehicle dynamic module. See appropriate article in SUSPENSION section.
(9)DTC caused by virtual image electronic instrument cluster. See INSTRUMENT PANEL article.
(10)Service all other DTCs first. After all other DTC have been repaired, see MODULE COMMUNICATIONS NETWORK article.

DIAGNOSTIC TROUBLE CODE INDEX (DDM)

SymptomGo To Diagnostic Test
No Communication With DDMA
No Communication With DSMB
Single Mirror InoperativeC
Mirror Operates In One Second IntervalsD
Reverse Tilt Function InoperativeE
Memory Mirror InoperativeF
Auto Dimming Feature InoperativeG
Heated Mirror InoperativeH

SYMPTOM CHART

Scheme 1

Scheme 1: CONNECTOR IDENTIFICATION
Scheme 1: CONNECTOR IDENTIFICATION

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

TEST A: NO COMMUNICATION WITH DRIVER DOOR MODULE

Note. After any repairs are complete, ensure all component are properly installed and all harness connectors are connected properly and repeat data link diagnostic test.

Note. Connectors C315 and C362 are 2 terminal connectors. Identify connectors by wire color. See WIRING DIAGRAMS.

  1. Connect NSG tester to data link connector. Turn ignition switch to RUN position. Monitor Driver Door Module (DDM) PIPs SFWD_SW, SREAR_SW, SFNT_SW and SRCL_SW while activating power seat switch. If TEST/FUNCTION MODULE NOT RESPONDING: DDM is not displayed, go to next step. If TEST/FUNCTION MODULE NOT RESPONDING: DDM is displayed, go to MODULE COMMUNICATION NETWORK article to diagnose network concern.
  2. Ensure transmission is in Park. Turn ignition switch to LOCK position. Check fuse No. 39 (10-amp) in instrument panel fuse box. If fuse is okay, go to next step. If fuse is blown, go to step 6).
  3. Measure voltage at input side of fuse No. 39. If battery voltage exists, go to next step. If battery voltage does not exist, go to step 22).
  4. Install fuse No. 39. Disconnect DDM harness connector C524. Measure voltage at terminal No. 6 (Black/White wire) at DDM harness connector C524. If battery voltage exists, go to next step. If battery voltage does not exist, repair open in Black/White wire between instrument panel fuse box and DDM.
  5. Measure resistance between ground and terminal No. 14 (Black/Light Blue wire) at DDM harness connector C524. If resistance is greater than 5 ohms, repair open in Black/Light Blue wire. If resistance is 5 ohms or less, go to MODULE COMMUNICATIONS NETWORK article to diagnose network concern.
  6. Replace fuse No. 39. DO NOT operate power seat switch. If fuse blows, go to next step. If fuse does not blow, go to step 12).
  7. Remove fuse No. 39. Disconnect DDM harness connector C524, Driver Seat Module (DSM) harness connector C342, driver door lock switch harness connector C505, passenger door lock switch harness connector C602 and power mirror control switch harness connector C550. Measure resistance between ground and terminal No. 6 (Black/White wire) at DDM harness connector C524. If resistance is 10,000 ohms or greater, go to next step. If resistance is less than 10,000 ohms, repair short to ground in Black/White wire.
  8. Connect DSM harness connector C342. Measure resistance between ground and terminal No. 6 (Black/White wire) at DDM harness connector C524. If resistance is 10,000 ohms or greater, go to next step. If resistance is less than 10,000 ohms, replace driver seat module.
  9. Connect DDM harness connector C524. Measure resistance between ground and terminal No. 6 (Black/White wire) at driver door lock switch harness connector C505. If resistance is 10,000 ohms or greater, go to next step. If resistance is less than 10,000 ohms, replace driver door module.
  10. Connect passenger door lock switch harness connector C602. Measure resistance between ground and terminal No. 6 (Black/White wire) at driver door lock switch harness connector C505. If resistance is 10,000 ohms or greater, go to next step. If resistance is less than 10,000 ohms, replace passenger door lock switch.
  11. Connect power mirror control switch harness connector C550. Measure resistance between ground and terminal No. 6 (Black/White wire) at driver door lock switch harness connector C505. If resistance is 10,000 ohms or greater, replace driver door lock switch. If resistance is less than 10,000 ohms, replace power mirror control switch.
  12. Lock and unlock doors at all door lock switches. If fuse No. 39 blows, go to next step. If fuse No. 39 does not blow, go to step 15).
  13. Remove driver and passenger door lock switches. Test both door lock switches. See DOOR LOCK SWITCH under COMPONENT TESTING. If both door lock switches are okay, go to next step. If either door lock switch is defective, replace appropriate door lock switch.
  14. Disconnect Driver Door Module (DDM) harness connector C523. Measure resistance between ground and terminal No. 1 (Pink/Yellow wire) at driver door lock switch harness connector C505. Also, measure resistance between ground and terminal No. 5 (Pink/Light Green wire) at driver door lock switch harness connector C505. If either or both resistance reading are less than 10,000 ohms, repair short to ground in appropriate wire(s). If both resistance readings are 10,000 ohms or greater, replace driver door module.
  15. Press each number on keyless entry pad one at a time. If fuse No. 39 blows, go to next step. If fuse No. 39 does not blow, go to step 17).
  16. Disconnect Driver Door Module (DDM) harness connector C523. Disconnect keyless entry keypad harness connector C525. Measure resistance between ground and appropriate terminals at remote keyless entry keypad harness connector C525. See REMOTE KEYLESS ENTRY TERMINAL IDENTIFICATION table. If all resistance readings are 10,000 ohms or greater, replace driver door module. If any resistance readings are less than 10,000 ohms, repair short to ground in appropriate wire. REMOTE KEYLESS ENTRY TERMINAL IDENTIFICATION Terminal No. Wire Color 1 Red 2 Yellow 3 Yellow/Black 4 Light Green/Red 5 Light Blue/Yellow 9 Light Blue
  17. Activate mirrors in all directions. If fuse No. 39 blows, go to next step. If fuse No. 39 does not blow, go to step 20).
  18. Remove mirror control switch. Test mirror control switch. See MIRROR CONTROL SWITCH under COMPONENT TESTING. If mirror control switch is okay, go to next step. If mirror control switch is defective, replace mirror control switch.
  19. Disconnect Driver Door Module (DDM) harness connector C506. Disconnect mirror control switch harness connector C550. Measure resistance between ground and appropriate terminals at mirror control switch harness connector C550. See MIRROR CONTROL SWITCH TERMINAL IDENTIFICATION table. If all resistance readings are 10,000 ohms or greater, replace driver door module. If any resistance reading are less than 10,000 ohms, repair short to ground in appropriate wire. MIRROR CONTROL SWITCH TERMINAL IDENTIFICATION Terminal No. Wire Color 3 Dark Blue/Orange 4 Red/Orange 6 Yellow/Black 7 Purple/Orange 8 Dark Green/Orange
  20. Activate driver seat control switch in all directions. If fuse No. 39 blows, go to next step. If fuse No. 39 does not blow, system is operating properly at this time.
  21. Disconnect Driver Door Module (DDM) harness connector C506. Disconnect driver seat control switch harness connector C520. Measure resistance between ground and appropriate terminals at driver seat control switch harness connector C520. See DRIVER SEAT CONTROL SWITCH TERMINAL IDENTIFICATION table. If all resistance readings are 10,000 ohms or greater, replace driver door module. If any resistance readings are less than 10,000 ohms, repair short to ground in appropriate wire. DRIVER SEAT CONTROL SWITCH TERMINAL IDENTIFICATION Terminal No. Wire Color 2 Red/White 3 Red/Light Green 4 Red/Light Blue 5 Gray 7 Yellow/White 8 Yellow/Light Green 9 Yellow/Light Blue 10 Gray/Black
  22. Turn ignition switch to LOCK position. Remove 30-amp driver door module fuse (No. 1) from power distribution box in engine compartment. (Scheme 12) If fuse is not blown, go to next step. If fuse is blown, go to step 24).
  23. Measure voltage at input side of fuse No. 1 at power distribution box. If battery voltage exists, repair open in Red wire between power distribution box and instrument panel fuse box. If battery voltage does not exist, replace power distribution box.
  24. Ensure fuse No. 1 is still removed. Disconnect Driver Seat Module (DSM) harness connector C362. Disconnect driver heated seat module harness connector C352. Disconnect driver lumbar switch harness connector C348. Measure resistance between ground and terminal No. 1 (Red wire) at DSM harness connector C362. If resistance is 10,000 ohms or greater, go to next step. If resistance is less than 10,000 ohms, repair short to ground in Red wire.
  25. Connect DSM harness connector C362. Measure resistance between ground and output terminal of fuse No. 1 at power distribution box. If resistance is 10,000 ohms or greater, go to next step. If resistance is less than 10,000 ohms, replace driver seat module.
  26. Replace fuse No. 1 (30-amp) in power distribution box. Connect driver lumbar switch harness connector C348. Operate driver lumbar switch in both directions. If fuse No. 1 blows, go to next step. If fuse No. 1 does not blow, go to step 30).
  27. Remove fuse No. 1 (30-amp) from power distribution box. Measure resistance between ground and output cavity of fuse No. 1 at power distribution box. If resistance is greater than 10,000 ohms, go to next step. If resistance is less than 10,000 ohms, replace driver lumbar switch.
  28. Disconnect driver lumbar switch harness connector C348. Measure resistance between ground and terminal No. 4 (Pink wire) at driver lumbar switch harness connector C348. Also, measure resistance between ground and terminal No. 2 (Brown wire) at driver lumbar switch harness connector C348. If both resistance readings are 10,000 ohms or greater, go to next step. If either reading is less than 10,000 ohms, replace driver lumbar switch.
  29. Disconnect driver lumbar motor harness connector C315. Measure resistance between ground and terminal No. 4 (Pink wire) at driver lumbar switch harness connector C348. Also, measure resistance between ground and terminal No. 2 (Brown wire) at driver lumbar switch harness connector C348. If both resistance readings are 10,000 ohms or greater, replace power lumbar motor. If either reading is less than 10,000 ohms, repair short to ground in appropriate wire.
  30. Disconnect driver heated seat module harness connector C352. Measure resistance between ground and appropriate terminals at driver heated seat module harness connector C352. See HEATED SEAT MODULE CONNECTOR TERMINAL IDENTIFICATION table. If all resistance readings are 10,000 ohms or greater, replace driver heated seat module. If any resistance readings are less than 10,000 ohms, repair short to ground in appropriate wire.
Terminal No.Wire Color
5Black/Light Blue
6Brown/Light Blue
8Yellow/Light Blue
9Gray/Light Blue
10Red/Light Blue
11Orange/Light Blue
12Purple/Light Blue
13White/Light Blue

HEATED SEAT MODULE CONNECTOR TERMINAL IDENTIFICATION

Scheme 12

Scheme 12
Scheme 12

TEST B: NO COMMUNICATION WITH DRIVER SEAT MODULE

Note. After any repairs are complete, ensure all component are properly installed and all harness connectors are connected properly and repeat data link diagnostic test.

  1. Check fuse No. 39 (10-amp) in instrument panel fuse box. If fuse is okay, go to next step. If fuse is blown, perform TEST A: NO COMMUNICATION WITH DRIVER DOOR MODULE.
  2. Measure voltage at input cavity of fuse No. 39 at instrument panel fuse box. If battery voltage exist, go to next step. If battery voltage does not exist, perform TEST A: NO COMMUNICATION WITH DRIVER DOOR MODULE.
  3. Install fuse No. 39. Disconnect DSM harness connector C342. Measure voltage at terminal No. 14 (Black/White wire) at DSM harness connector C342. If battery voltage exists, go to next step. If battery voltage does not exist, repair open in Black/White wire.
  4. Measure resistance between ground and terminal No. 1 (Black/Light Green wire) at DSM harness connector C342. If resistance is less than 5 ohms, diagnose network concern. See MODULE COMMUNICATIONS NETWORK article. If resistance is 5 ohms or greater, repair open in Black/Light Green wire.

TEST C: SINGLE MIRROR INOPERATIVE

Note. Many test steps refer to various connectors. These connectors are identified in illustration. See CONNECTOR IDENTIFICATION.

  1. Connect New Generation Star (NGS) tester to data link connector. Perform Driver Door Module (DDM) self-test. If DDM DTC B1541 does not exist, go to next step. If DDM DTC B2338 exists, go to step 4).
  2. Perform Driver Seat Module (DSM) self-test. If no DSM DTCs exist, go to next step. If any DSM DTCs exist, perform appropriate test or appropriate step. See DTC TEST PROCEDURE table. DTC TEST PROCEDURE DTC (1) Go To B1667 Step 10) B1667 & B1668 TEST D B1667 & B2324 TEST D B1667 & B2327 TEST D B1668 Step 10) B1668 & B2320 TEST D B1668 & B2323 TEST D B1669 Step 14) B1669 & B1670 TEST D B1669 & B2316 TEST D B1669 & B2319 TEST D B1670 Step 14) B1670 & B2312 TEST D B1670 & B2315 TEST D B1667, B1668, B1669 & B1670 TEST D (1) DTCs B1663, B1664, B1665 and B1666 may also be present.
  3. Monitor DDM PIDs MIR_SEL, MIRV_SW and MIRH_SW on scan tool. Select appropriate mirror on mirror control switch. Move mirror control switch through all positions. If PID values do not agree with mirror control switch position, go to next step. If PID values agrees with mirror control switch position, go to step 9).
  4. Disconnect mirror control switch harness connector C550. Turn ignition switch to RUN position. Measure voltage at terminal No. 1 (Black/White wire) at mirror control switch harness connector C550. If battery voltage exists, go to next step. If battery voltage does not exist, repair open in Black/White wire.
  5. Turn ignition switch to LOCK position. Measure resistance between ground and terminal No. 5 (Black/Light Blue wire) at mirror control switch harness connector C550. If resistance is 5 ohms or less, go to next step. If resistance is more than 5 ohms, repair open in Black/Light Blue wire.
  6. Disconnect DDM harness connector C506. Measure resistance in wires between mirror control switch harness connector C550 and DDM harness connector C506. See MIRROR CONTROL RESISTANCE table. If all resistance readings are 5 ohms or less, go to next step. If any resistance reading is more than 5 ohms, repair open in appropriate wire. MIRROR CONTROL RESISTANCE DDM Terminal No. Switch Terminal No. Wire Color 12 6 Yellow/Black 13 8 Dark Green/Orange 14 4 Red/Orange 15 7 Purple/Orange 16 3 Dark Blue/Orange
  7. Ensure ignition switch is in RUN position. Measure voltage at appropriate terminals at driver mirror control switch harness connector C550. See MIRROR SWITCH CIRCUIT table. If voltage does not exist at any terminal, go to next step. If voltage exists at any terminal, repair short to voltage in appropriate wire. MIRROR SWITCH CIRCUIT Terminal No. Wire Color 3 Dark Blue/Orange 4 Red/Orange 6 Yellow/Black 7 Purple/Orange 8 Dark Green/Orange
  8. Test mirror control switch. See MIRROR CONTROL SWITCH under COMPONENT TESTING. If mirror control switch is okay, replace DDM. If mirror control switch is defective, replace mirror control switch.
  9. Place transmission in Park. Select ACTIVE COMMAND POWER MIRROR CONTROL on scan tool. Using scan tool operate both mirrors in all directions. If both mirrors respond correctly, system is okay at this time. If driver mirror did not respond correctly, go to next step. If passenger mirror did not respond correctly, go to step 14).
  10. Disconnect driver mirror harness connector C515. Measure voltage at terminals No. 3 (Red wire), No. 4 (Yellow/Red wire), No. 5 (Yellow/Light Blue wire) and No. 6 (Dark Blue wire) at driver mirror harness connector C515. If voltage does not exist at any terminal, go to next step. If voltage exists at any terminal, go to step 13).
  11. Disconnect DSM harness connector C342. Measure resistance between ground and terminals No. 3 (Red wire), No. 4 (Yellow/Red wire), No. 5 (Yellow/Light Blue wire) and No. 6 (Dark Blue wire) at driver mirror harness connector C515. If all resistance readings are more than 10,000 ohms, go to next step. If any resistance reading is 10,000 ohms or less, repair short to ground in appropriate wire.
  12. Measure resistance in wires between driver mirror harness connector C515 and DSM harness connector C342. See MIRROR DRIVER RESISTANCE table. If all resistance readings are 5 ohms or less, go to step 18). If any resistance reading is more than 5 ohms, repair open in appropriate wire. MIRROR DRIVER RESISTANCE DSM Terminal No. Mirror Terminal No. Wire Color 2 3 Red 3 6 Dark Blue 4 5 Yellow/Light Blue 16 4 Yellow/Red
  13. Disconnect DSM harness connector C342. Measure voltage at terminals No. 3 (Red wire), No. 4 (Yellow/Red wire), No. 5 (Yellow/Light Blue wire) and No. 6 (Dark Blue wire) at driver mirror harness connector C515. If voltage does not exist at any terminal, replace DSM. If voltage exists at any terminal, repair short to voltage in appropriate wire.
  14. Disconnect passenger mirror harness connector C606. Measure voltage at terminals No. 3 (White/Light Green wire), No. 4 (Dark Green wire), No. 5 (White/Purple wire) and No. 6 (Purple wire) at passenger mirror harness connector C606. If voltage does not exist at any terminal, go to next step. If voltage exists at any terminal, go to step 17).
  15. Disconnect DSM harness connector C342. Measure resistance between ground and terminals No. 3 (White/Light Green wire), No. 4 (Dark Green wire), No. 5 (White/Purple wire) and No. 6 (Purple wire) at passenger mirror harness connector C606. If resistance is more than 10,000 ohms, go to next step. If resistance is 10,000 ohms or less, repair short to ground in appropriate wire.
  16. Measure resistance in wires between passenger mirror harness connector C606 and DSM harness connector C342. See PASSENGER MIRROR RESISTANCE table. If all resistance readings are 5 ohms or less, go to step 21). If any resistance reading is more than 5 ohms, repair open in appropriate wire. PASSENGER MIRROR RESISTANCE DSM Terminal No. Mirror Terminal No. Wire Color 5 6 Purple 6 5 White/Purple 7 3 White/Light Green 8 4 Dark Green
  17. Disconnect DSM harness connector C342. Measure voltage at terminals No. 3 (White/Light Green wire), No. 4 (Dark Green wire), No. 5 (White/Purple wire) and No. 6 (Purple wire) at passenger mirror harness connector C606. If voltage does not exist at any terminal, replace DSM. If voltage exists at any terminal, repair short to voltage in appropriate wire.
  18. Disconnect driver mirror harness connector C515. Measure resistance between terminal No. 5 (Yellow/Light Blue wire) and No. 4 (Yellow/Red wire) at driver mirror connector. Also, measure resistance between terminals No. 3 (Red wire) and No. 6 (Dark Blue wire) at driver mirror connector. If resistance readings are more than 10,000 ohms, go to step 24). If resistance readings are 10,000 or less, go to next step.
  19. Measure voltage at terminals No. 3 (Red wire), No. 4 (Yellow/Red wire), No. 5 (Yellow/Light Blue wire) and No. 6 (Dark Blue wire) at driver mirror harness connector C515. If voltage exists at any terminal, go to step 24). If voltage does not exist at any terminal, go to next step.
  20. Measure resistance between ground and terminals No. 3 (Red wire), No. 4 (Yellow/Red wire), No. 5 (Yellow/Light Blue wire) and No. 6 (Dark Blue wire) at driver mirror harness connector C515. If all resistance readings are more than 10,000 ohms, replace DSM. If any resistance reading is 10,000 ohms or less, go to step 24).
  21. Disconnect passenger mirror harness connector C606. Measure resistance between terminal No. 6 (Purple wire) and No. 5 (White/Purple wire) at passenger mirror connector. Also, measure resistance between terminals No. 3 (White/Light Green wire) and No. 4 (Dark Green wire) at passenger mirror connector. If resistance readings are 10,000 or less, go to next step. If resistance readings are more than 10,000 ohms, go to step 25).
  22. Measure voltage at terminals No. 3 (White/Light Green wire), No. 4 (Dark Green wire), No. 5 (White/Purple wire) and No. 6 (Purple wire) at passenger mirror harness connector C606. If voltage does not exist at any terminal, go to next step. If voltage exists at any terminal, go to step 25).
  23. Measure resistance between ground and terminals No. 3 (White/Light Green wire), No. 4 (Dark Green wire), No. 5 (White/Purple wire) and No. 6 (Purple wire) at passenger mirror harness connector C606. If all resistance readings are more than 10,000 ohms, replace DSM. If any resistance reading is 10,000 ohms or less, go to step 25).
  24. Remove driver mirror assembly. Inspect mirror wiring. If wiring is damaged, repair as necessary. If wiring is okay, replace driver mirror assembly.
  25. Remove passenger mirror assembly. Inspect mirror wiring. If wiring is damaged, repair as necessary. If wiring is okay, replace passenger mirror assembly.

TEST D: MIRROR OPERATES IN ONE SECOND INTERVALS

Note. Many test steps refer to various connectors. These connectors are identified in illustration. See CONNECTOR IDENTIFICATION.

  1. Ensure transmission is in Park. Operate both mirrors in all directions. If both mirrors move in all directions, go to next step. If either mirror does not operate in any direction, repair as necessary. See SYMPTOM CHART under SYSTEM TESTING.
  2. Connect New Generation Star (NGS) tester to data link connector. Perform Driver Door Module (DDM) self-test. If no DDM DTCs exist, go to next step. If any DDM DTCs exists, perform appropriate test. See DIAGNOSTIC TROUBLE CODES (DDM) table under SYSTEM TESTING.
  3. Perform Driver Seat Module (DSM) self-test. If no DSM DTCs exist, go to next step. If any DSM DTCs exist, perform appropriate test or appropriate step. See DTC TEST PROCEDURE table. DTC TEST PROCEDURE DTC Go To B1667, B1668, B1669 & B1670 Step 4) B1667, B1668, B1669, B1670, B1663, B1664, B1665 & B1666 Step 11) B1667 & B1668 Step 6) B1667 & B2324 Step 6) B1667 & B2327 Step 5) B1668 & B2320 Step 6) B1668 & B2323 Step 5) B1669 & B1670 Step 9) B1669 & B2316 Step 9) B1669 & B2319 Step 8) B1670 & B2312 Step 9) B1670 & B2315 Step 8)
  4. Ensure transmission is in Park. Position driver and passenger mirrors in center position. Operate both mirrors through complete travel in all directions. If both mirror move smoothly and completely, replace DSM. If driver mirror does not operate properly, go to next step. If passenger mirror does not operate properly, go to step 8). If both mirrors do not operate properly, go to step 11).
  5. Disconnect driver mirror harness connector C521. Disconnect DSM harness connector C342. Measure resistance between ground and terminals No. 3 (Red/White wire) and No. 1 (Dark Blue/White wire) at driver mirror harness connector C521. If both resistance readings are more than 10,000 ohms, go to next step. If either resistance reading is 10,000 ohms or less, repair short to ground in appropriate wire.
  6. Measure resistance in wires between DSM harness connector C342 and driver mirror harness connector C521. See DRIVER POTENTIOMETER CIRCUIT TEST table. If all resistance readings are 5 ohms or less, go to next step. If any resistance reading is more than 5 ohms, repair open in appropriate wire. DRIVER POTENTIOMETER CIRCUIT TEST DSM Terminal No. Mirror Terminal No. Wire Color 9 3 Red/White 10 1 Dark Blue/White 13 4 Gray 15 2 Gray/Red
  7. Measure voltage at terminal No. 1 (Dark Blue/White wire), No. 2 (Gray/Red wire), No. 3 (Red/White wire) and No. 4 (Gray wire) at driver mirror harness connector C521. If voltage does not exist at any terminal, go to step 14). If voltage exists at any terminal, repair short to voltage in appropriate wire.
  8. Disconnect passenger mirror harness connector C605. Disconnect DSM harness connector C342. Measure resistance between ground and terminals No. 1 (Purple/White wire) and No. 3 (Dark Green/White wire) at passenger mirror harness connector C605. If both resistance readings are more than 10,000 ohms, go to next step. If either resistance reading is 10,000 ohms or less, repair short to ground in appropriate wire.
  9. Measure resistance in wires between DSM harness connector C342 and passenger mirror harness connector C605. See PASSENGER POTENTIOMETER CIRCUIT TEST table. If all resistance readings are 5 ohms or less, go to next step. If any resistance reading is more than 5 ohms, repair open in appropriate wire. PASSENGER POTENTIOMETER CIRCUIT TEST DSM Terminal No. Mirror Terminal No. Wire Color 11 3 Dark Green/White 12 1 Purple/White 13 4 Gray 15 2 Gray/Red
  10. Measure voltage at terminal No. 1 (Purple/White wire), No. 2 (Gray/Red wire), No. 3 (Dark Green/White wire) and No. 4 (Gray wire) at passenger mirror harness connector C605. If voltage does not exist at any terminal, go to step 16). If voltage exists at any terminal, repair short to voltage in appropriate wire.
  11. Disconnect DSM harness connector C342, driver mirror harness connector C521 and passenger mirror harness connector C605. Measure resistance in Gary/Red wire between terminal No. 15 at DSM and terminal No. 2 at both mirror harness connectors. Also measure resistance in Gray wire between terminal No. 13 at DSM harness connector C342 and terminal No. 4 at both mirror harness connectors. If all resistance readings are 5 ohms or less, go to next step. If any resistance reading is more than 5 ohms, repair open in appropriate wire.
  12. Measure resistance between ground and terminal No. 2 (Gray/Red wire) at both mirror harness connectors. If resistance is more than 10,000 ohms, go to next step. If resistance is 10,000 ohms or less, repair short to ground in Gray/Red wire.
  13. Measure voltage at terminal No. 2 (Gray/Red wire) at both mirror harness connectors. If voltage does not exist, go to step 18). If voltage exists, repair short to voltage in Gray/Red wire.
  14. Connect DSM harness connector C342. Measure voltage at terminals No. 1 (Dark Blue/White wire), No. 2 (Gray/Red wire) and No. 3 (Red/White wire) at driver mirror harness connector C521. If voltage exists, go to next step. If voltage does not exist, replace DSM.
  15. Measure resistance between ground and terminal No. 4 (Gray wire) at driver mirror harness connector C521. If resistance is more than 10,000 ohms, replace DSM. If resistance is 10,000 ohms or less, go to step 20).
  16. Connect DSM harness connector C342. Measure voltage at terminals No. 1 (Purple/White wire), No. 2 (Gray/Red wire) and No. 3 (Dark Green/White wire) at passenger mirror harness connector C605. If voltage exists, go to next step. If voltage does not exist, replace DSM.
  17. Measure resistance between ground and terminal No. 4 (Gray wire) at passenger mirror harness connector C605. If resistance is more than 10,000 ohms, replace DSM. If resistance is 10,000 ohms or less, go to step 21).
  18. Disconnect driver mirror harness connector C521 and passenger mirror harness connector C605. Measure voltage at terminal No. 2 (Gray/Red wire) at driver and passenger mirror harness connectors. If voltage does not exist, go to next step. If voltage exists at driver mirror harness connector, go to step 20). If voltage exists at passenger mirror, go to step 21).
  19. Measure resistance between ground and terminal No. 2 (Gray/Red wire) at driver and passenger mirror harness connectors. If both resistance reading are more than 10,000 ohms, go to step 22). If resistance is 10,000 ohms or less at driver mirror harness connector, go to next step. If resistance is 10,000 ohms or less at passenger mirror harness connector, go to step 21).
  20. Remove driver mirror assembly. Inspect mirror wiring. If wiring is damaged, repair as necessary. If wiring is okay, replace driver mirror assembly.
  21. Remove passenger mirror assembly. Inspect mirror wiring. If wiring is damaged, repair as necessary. If wiring is okay, replace passenger mirror assembly.
  22. Connect all disconnected components. Perform DSM self-test. If DTCs B1663, B1664, B1665 and B1666 do not exist, replace DSM. If DTCs B1663, B1664, B1665 and B1666 exist, preform appropriate test. See POWER SEATS article.

TEST E: REVERSE TILT FEATURE INOPERATIVE

Note. Many test steps refer to various connectors. These connectors are identified in illustration. See CONNECTOR IDENTIFICATION.

  1. Operate both mirror through all positions. If both mirrors operate properly, go to next step. If both mirrors do not operate properly, repair mirrors as necessary. See SYMPTOM CHART under SYSTEM TESTING.
  2. Turn ignition switch to RUN position. Select REVERSE MIRRORS feature on message center. If REVERSE MIRROR feature is enabled, go to next step. If REVERSE MIRROR feature is not enabled, enable feature and inform customer of proper operation.
  3. Turn ignition switch to RUN position. Set parking brake. Place transmission in Reverse. Wait 15 seconds then place transmission in Park. If mirrors do not move down when transmission is in Reverse and return to previous position when transmission is returned to Park, go to next step. If mirrors move down when transmission is in Reverse and return to previous position when transmission is returned to Park, system is okay at this time.
  4. Connect New Generation Star (NGS) tester to data link connector. Perform Driver Seat Module (DSM) self-test. If no DSM DTCs exist, replace DSM. If any DSM DTCs exist, perform appropriate test. See TILT FEATURE TEST table.
DTCGo To
B1667 & B2324TEST D
B1667 & B2327TEST D
B1669 & B2327TEST D
B1669 & B2319TEST D
U1059(1)
(1) See DIAGNOSTIC TROUBLE CODE INDEX (DSM) table under SYSTEM TESTING.
(1)See DIAGNOSTIC TROUBLE CODE INDEX (DSM) table under SYSTEM TESTING.

TILT FEATURE TEST

TEST F: MEMORY MIRROR INOPERATIVE

  1. Operate both mirror through all positions. If both mirrors operate properly, go to next step. If both mirrors do not operate properly, repair mirrors as necessary. See SYMPTOM CHART under SYSTEM TESTING.
  2. Activate both mirror memory positions from Virtual Image Cluster (VIC). If both memory positions operate at VIC, go to next step. If both memory position do not operate at VIC, perform TEST D.
  3. Activate both mirror memory positions from keyless entry keypad. If both memory positions operate from keypad, go to next step. If both memory position do not operate from keypad, repair remote keyless entry system. See REMOTE KEYLESS ENTRY SYSTEM article.
  4. Activate both mirror memory positions from remote transmitter. If both memory positions operate from transmitter, system is okay at this time. If both memory position do not operate from transmitter, repair remote keyless entry system. See REMOTE KEYLESS ENTRY SYSTEM article.

TEST G: AUTOMATIC DIMMING FUNCTION INOPERATIVE

Note. Many test steps refer to various connectors. These connectors are identified in illustration. See CONNECTOR IDENTIFICATION.

  1. Place transmission in Park. Turn ignition switch to RUN position. Set inside rear view mirror dimming control to HIGH position. Cover light sensor on rear of inside mirror. If inside mirror does not darken, go to next step. If inside mirror darkens and driver mirror does not darken, go to step 7). If both mirrors darken, system is operating properly at this time.
  2. Turn ignition switch to LOCK position. Disconnect inside mirror harness connector C917. Turn ignition switch to RUN position. Measure voltage at terminal No. 8 (Black/Pink wire) at inside mirror harness connector C917. If battery voltage exists, go to step 5). If battery voltage does not exist, go to next step.
  3. Turn ignition switch to LOCK position. Remove fuse No. 4 (10-amp) from instrument panel fuse box. If fuse is okay, repair open in Black/Pink wire. If fuse is blown, go to next step.
  4. Measure resistance between ground and terminal No. 8 (Black/Pink wire) at inside mirror harness connector C917. If resistance is 10,000 ohms or less, repair short to ground in Black/Pink wire and retest. If resistance is more than 10,000 ohms, replace inside mirror and retest.
  5. Measure resistance between ground and terminal No. 7 (Black wire) at inside mirror harness connector C917. If resistance is more than 5 ohms, repair open in Black wire and retest. If resistance is 5 ohms or less, go to next step.
  6. Turn ignition switch to RUN position. Ensure transmission is in Reverse. Measure voltage at terminal No. 6 (Black/Pink wire) at inside mirror harness connector C917. If battery voltage exists, replace inside mirror and retest. If battery voltage does not exist, repair open in Black/Pink wire and retest.
  7. Turn ignition switch to LOCK position. Test driver mirror dimming by connecting a D-size battery (1.5 volts or less), positive to terminal No. 5 (Purple wire) and negative to terminal No. 4 (Light Blue/White wire) at inside mirror harness connector C917. If driver mirror darkens, go to next step. If driver mirror does not darken, replace driver mirror glass and retest.
  8. Turn ignition switch to LOCK position. Disconnect driver mirror harness connector C515. Connect inside mirror harness connector C917. Measure voltage at terminal No. 9 (Light Blue/White wire) at driver mirror harness connector C515. If battery voltage exists, go to next step. If battery voltage does not exist, go to step 10).
  9. Disconnect inside mirror harness connector C917. Measure voltage at terminal No. 9 (Light Blue/White wire) at driver mirror harness connector C515. If battery voltage exists, repair short to voltage in Light Blue/White wire. If battery voltage does not exist, replace inside mirror and retest.
  10. Measure voltage at terminal No. 10 (Purple wire) at driver mirror harness connector C515. If battery voltage exists, go to next step. If battery voltage does not exist, go to step 12).
  11. Disconnect inside mirror harness connector C917. Measure voltage at terminal No. 10 (Purple wire) at driver mirror harness connector C515. If battery voltage exists, repair short to voltage in Purple wire and retest. If battery voltage does not exist, replace inside mirror and retest.
  12. Measure resistance between ground and terminal No. 9 (Light Blue/White wire) at driver mirror harness connector C515. If resistance is 10,000 ohms or less, go to next step. If resistance is more than 10,000 ohms, go to step 14).
  13. Disconnect inside mirror harness connector C917. Measure resistance between ground and terminal No. 9 (Light Blue/White wire) at driver mirror harness connector C515. If resistance is 10,000 ohms or less, repair short to ground in Light Blue/White wire. If resistance is more than 10,000 ohms, replace inside mirror and retest.
  14. Measure resistance between ground and terminal No. 10 (Purple wire) at driver mirror harness connector C515. If resistance is 10,000 ohms or less, go to next step. If resistance is more than 10,000 ohms, go to step 16).
  15. Disconnect inside mirror harness connector C917. Measure resistance between ground and terminal No. 10 (Purple wire) at driver mirror harness connector C515. If resistance is 10,000 ohms or less, repair short to ground in Purple wire and retest. If resistance is more than 10,000 ohms, replace inside mirror and retest.
  16. Disconnect inside mirror harness connector C917. Measure resistance in Light Blue/White wire between terminal No. 4 at inside mirror harness connector C917 and terminal No. 9 at driver mirror harness connector C515. If resistance is 5 ohms or less, go to next step. If resistance is more than 5 ohms, repair open in Light Blue/White wire and retest.
  17. Measure resistance in Purple wire between terminal No. 5 at inside mirror harness connector C917 and terminal No. 10 at driver mirror harness connector C515. If resistance is 5 ohms or less, replace inside mirror. If resistance is more than 5 ohms, repair open in Purple wire and retest.

TEST H: HEATED MIRRORS INOPERATIVE

Note. Many test steps refer to various connectors. These connectors are identified in illustration. See CONNECTOR IDENTIFICATION.

  1. Turn ignition switch to RUN position. Turn defogger on. If rear window defogger works, go to next step. If rear window defogger does not work, repair rear window defogger. See REAR WINDOW DEFOGGERS article.
  2. Turn ignition switch to LOCK position. Check fuse No. 30 (10-amp). If fuse is okay, go to step 6). If fuse is blown, go to next step.
  3. Measure resistance between ground and output side of fuse No. 30. If resistance is 10,000 ohms or less, go to next step. If resistance is more than 10,000 ohms, replace fuse and retest.
  4. Disconnect driver mirror harness connector C515. Measure resistance between ground and output side of fuse No. 30. If resistance is 10,000 ohms or less, go to next step. If resistance is more than 10,000 ohms, replace driver mirror glass and retest.
  5. Disconnect passenger mirror harness connector C606. Measure resistance between ground and output side of fuse No. 30. If resistance is 10,000 ohms or less, repair short to ground in Dark Green/Purple wire and retest. If resistance is more than 10,000 ohms, replace passenger mirror glass and retest.
  6. Remove fuse No. 30. Turn ignition switch to RUN position. Turn defogger on. Measure voltage at input side of fuse No. 30. If battery voltage exists, go to next step. If battery voltage does not exist, repair open in Brown/Light Blue wire and retest.
  7. Turn ignition switch to LOCK position. Disconnect driver mirror harness connector C515. Measure resistance in Dark Green/Purple wire between terminal No. 2 at driver mirror harness connector C515 and output side of fuse No. 30. If resistance is 5 ohms or less, go to next step. If resistance is more than 5 ohms, repair open in Dark Green/Purple wire and retest.
  8. Turn ignition switch to LOCK position. Disconnect passenger mirror harness connector C606. Measure resistance Dark Green/Purple wire between terminal No. 2 at passenger mirror harness connector C606 and output side of fuse No. 30. If resistance is more than 5 ohms, repair open in Dark Green/Purple wire and retest. If resistance is 5 ohms or less, check both mirrors for heat. If driver mirror does not heat, go to next step. If passenger mirror does not heat, go to step 10).
  9. Measure resistance between ground and terminal No. 1 (Black wire) at driver mirror harness connector C515. If resistance is 5 ohms or less, replace driver mirror glass and retest. If resistance is more than 5 ohms, repair open in Black wire and retest.
  10. Measure resistance between ground and terminal No. 1 (Black wire) at passenger mirror harness connector C606. If resistance is 5 ohms or less, replace passenger mirror glass and retest. If resistance is more than 5 ohms, repair open in Black wire and retest.

More articles — Power Memory Mirrors
