Windows / Glass (Service Information): Overview Lexus RX III рестайлинг

Windows 4 illustrations ~166 words

Scheme 30

Scheme 30: ILLUSTRATION
Scheme 30: ILLUSTRATION

Scheme 31

Scheme 31: REMOVAL [03/2012 - ]
Scheme 31: REMOVAL [03/2012 - ]

Scheme 32

Scheme 32
Scheme 32
  1. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL. Refer to «DISASSEMBLY [03/2012 - 07/2012] - Step 4»
  2. REMOVE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Remove the 3 screws. Disengage the 4 claws and remove the multiplex network master switch assembly.

Scheme 33

Scheme 33: INSPECTION [03/2012 - ]
Scheme 33: INSPECTION [03/2012 - ]
  1. INSPECT MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Check that the LED illuminates. Apply battery voltage to the multiplex network master switch assembly and check that the LED illuminates. OK Measurement Condition Specified Condition Battery positive (+) --> 18 (LED) Battery negative (-) --> 12 (GND) LED illuminates TEXT IN ILLUSTRATION *1 Component without harness connected (to Multiplex Network Master Switch Assembly) If the result is not as specified, replace the multiplex network master switch assembly.
