HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - 07/2012]

HINT

1. Use the following procedure to troubleshoot the power window control system.
2. *: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS In troubleshooting, confirm that the problem symptoms have been accurately identified. Preconceptions should be discarded in order to make an accurate judgment. To clearly understand what the problem symptoms are, it is extremely important to ask the customer about the problem and the conditions at the time the malfunction occurred. Gather as much information as possible for reference. Past problems that seem unrelated may also help in some cases. The following 5 items are important points in the problem analysis: What Vehicle model, system name When Date, time, occurrence frequency Where Road conditions Under what conditions? Driving conditions, weather conditions How did it happen? Problem symptoms NEXT: Go to next step
3. PRE-CHECK Measure the battery voltage. Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding to the next step. Check the fuses and relays. Check the connector connections and terminals to make sure that there are no abnormalities such as loose connections, deformation, etc. NEXT: Go to next step
4. INSPECT COMMUNICATION FUNCTION OF CAN COMMUNICATION SYSTEM* Use the Techstream to check if the CAN communication system is functioning normally. Result Result Proceed to ECU connected, communication line is normally A ECU connected, communication line is malfunctioning B B --> GO TO CAN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - 07/2012]»(ref-602741-S42866298922014030500000) A: Go to next step
5. INSPECT COMMUNICATION FUNCTION OF LIN COMMUNICATION SYSTEM* Use the Techstream to check if the LIN communication system is functioning normally. Refer to «DTC CHECK / CLEAR [03/2012 - ]»(ref-602774-S17650513242014030500000) . Result Result Proceed to No DTCs output A DTCs output B B --> GO TO LIN COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART [03/2012 - ]»(ref-602774-S26691742372014030500000) A: Go to next step
6. CHECK FOR DTC* Check for DTCs and note any codes that are output. Refer to «DTC CHECK / CLEAR [03/2012 - ]»(ref-602570-S28479883682014030500000) . Clear the DTCs. Recheck for DTCs. Result Result Proceed to No DTCs output A DTCs output B B --> GO TO DIAGNOSTIC TROUBLE CODE CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [03/2012 - ]»(ref-602570-S13692277922014030500000) A: Go to next step
7. PROBLEM SYMPTOMS TABLE Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE [03/2012 - ]»(ref-602570-S38864314332014030500000) . Result Result Proceed to Fault is not listed in problem symptoms table A Fault is listed in problem symptoms table B B --> Go to step 9 A: Go to next step
8. OVERALL ANALYSIS AND TROUBLESHOOTING* Operation Check. Refer to «OPERATION CHECK [03/2012 - ]»(ref-602570-S27952816082014030500000) Data List / Active Test. Refer to «DATA LIST / ACTIVE TEST [03/2012 - ]»(ref-602570-S34440256682014030500000) Terminals of ECU. Refer to «TERMINALS OF ECU [03/2012 - ]»(ref-602570-S28141892592014030500000) NEXT: Go to next step
9. ADJUST, REPAIR OR REPLACE Check if any of the door window regulators or power window regulator motor assemblies have been removed and reinstalled. Result Result Proceed to Any of the door window regulators or power window regulator motor assemblies have been removed and reinstalled. A None of the door window regulators or power window regulator motor assemblies has been removed and reinstalled. B B --> Go to step 11 A: Go to next step
10. INITIALIZE POWER WINDOW REGULATOR MOTOR If any of the door window regulators or power window regulator motor assemblies have been removed and reinstalled, perform "Initialize Power Window Control System" (initialization of the pulse sensor) for the applicable door glass. Refer to «INITIALIZATION [03/2012 - ]»(ref-602570-S16724986282014030500000) . HINT: If "Initialize Power Window Control System" (initialization of the pulse sensor) has not been performed, the auto operation function, jam protection function, key-linked operation function, wireless transmitter-linked operation function and key-off operation function will not operate or will operate incorrectly. NEXT: Go to next step
11. CONFIRMATION TEST NEXT --> END

HOW TO PROCEED WITH TROUBLESHOOTING [07/2012 - ]

HINT

1. Use the following procedure to troubleshoot the power window control system.
2. *: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS In troubleshooting, confirm that the problem symptoms have been accurately identified. Preconceptions should be discarded in order to make an accurate judgment. To clearly understand what the problem symptoms are, it is extremely important to ask the customer about the problem and the conditions at the time the malfunction occurred. Gather as much information as possible for reference. Past problems that seem unrelated may also help in some cases. The following 5 items are important points in the problem analysis: What Vehicle model, system name When Date, time, occurrence frequency Where Road conditions Under what conditions? Driving conditions, weather conditions How did it happen? Problem symptoms NEXT: Go to next step
3. PRE-CHECK Measure the battery voltage. Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding to the next step. Check the fuses and relays. Check the connector connections and terminals to make sure that there are no abnormalities such as loose connections, deformation, etc. NEXT: Go to next step
4. INSPECT COMMUNICATION FUNCTION OF CAN COMMUNICATION SYSTEM* Use the Techstream to check if the CAN communication system is functioning normally. Result Result Proceed to ECU connected, communication line is normally A ECU connected, communication line is malfunctioning B B --> GO TO CAN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2012 - ]»(ref-602741-S23471534912014030500000) A: Go to next step
5. INSPECT COMMUNICATION FUNCTION OF LIN COMMUNICATION SYSTEM* Use the Techstream to check if the LIN communication system is functioning normally. Refer to «DTC CHECK / CLEAR [03/2012 - ]»(ref-602774-S17650513242014030500000) . Result Result Proceed to No DTCs output A DTCs output B B --> GO TO LIN COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART [03/2012 - ]»(ref-602774-S26691742372014030500000) A: Go to next step
6. CHECK FOR DTC* Check for DTCs and note any codes that are output. Refer to «DTC CHECK / CLEAR [03/2012 - ]»(ref-602570-S28479883682014030500000) . Clear the DTCs. Recheck for DTCs. Result Result Proceed to No DTCs output A DTCs output B B --> GO TO DIAGNOSTIC TROUBLE CODE CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [03/2012 - ]»(ref-602570-S13692277922014030500000) A: Go to next step
7. PROBLEM SYMPTOMS TABLE Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE [03/2012 - ]»(ref-602570-S38864314332014030500000) . Result Result Proceed to Fault is not listed in problem symptoms table A Fault is listed in problem symptoms table B B --> Go to step 9 A: Go to next step
8. OVERALL ANALYSIS AND TROUBLESHOOTING* Operation Check. Refer to «OPERATION CHECK [03/2012 - ]»(ref-602570-S27952816082014030500000) Data List / Active Test. Refer to «DATA LIST / ACTIVE TEST [03/2012 - ]»(ref-602570-S34440256682014030500000) Terminals of ECU. Refer to «TERMINALS OF ECU [03/2012 - ]»(ref-602570-S28141892592014030500000) NEXT: Go to next step
9. ADJUST, REPAIR OR REPLACE Check if any of the door window regulators or power window regulator motor assemblies have been removed and reinstalled. Result Result Proceed to Any of the door window regulators or power window regulator motor assemblies have been removed and reinstalled. A None of the door window regulators or power window regulator motor assemblies has been removed and reinstalled. B B --> Go to step 11 A: Go to next step
10. INITIALIZE POWER WINDOW REGULATOR MOTOR If any of the door window regulators or power window regulator motor assemblies have been removed and reinstalled, perform "Initialize Power Window Control System" (initialization of the pulse sensor) for the applicable door glass. Refer to «INITIALIZATION [03/2012 - ]»(ref-602570-S16724986282014030500000) . HINT: If "Initialize Power Window Control System" (initialization of the pulse sensor) has not been performed, the auto operation function, jam protection function, key-linked operation function, wireless transmitter-linked operation function and key-off operation function will not operate or will operate incorrectly. NEXT: Go to next step
11. CONFIRMATION TEST NEXT --> END

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

1. CHECK WINDOW LOCK SWITCH HINT: Before performing the window lock switch operation check, make sure that the window lock switch is off (the switch is not pushed in). When the window lock switch of the multiplex network master switch assembly is pushed in, the LED on the switch will illuminate. Check that the power window switch operation indicators for all of switches other than those on the multiplex network master switch are off and that the front passenger and rear windows are disabled. OK Front passenger and rear windows are disabled. HINT: Even when the window lock switch of the multiplex network master switch assembly is pushed in, remote manual up and down and auto up and down functions can be operated. When the window lock switch is pushed in again, the LED on the switch will go off. Check that all of the power window switch operation indicators illuminate and that the front passenger and rear windows can be operated normally. OK Front passenger and rear windows operate normally.
2. CHECK MANUAL UP / DOWN FUNCTION Check that the driver side power window operates as follows: OK Condition Master Switch Switch Operation Power Window Engine switch on (IG) Driver side Pulled halfway up UP (Closes) Pushed halfway down DOWN (Opens) Check that the front passenger side window and rear power windows operate as follows: OK Condition Regulator Switch Switch Operation Power Window Engine switch on (IG) Window lock switch off Front passenger side Pulled halfway up UP (Closes) Pushed halfway down DOWN (Opens) Rear LH side Pulled halfway up UP (Closes) Pushed halfway down DOWN (Opens) Rear RH side Pulled halfway up UP (Closes) Pushed halfway down DOWN (Opens)
3. CHECK AUTO UP / DOWN FUNCTION Check that the driver side power window operates as follows: OK Condition Master Switch Switch Operation Power Window Engine switch on (IG) Driver side Pulled up (One touch operation) AUTO UP (Closes) Pushed down (One touch operation) AUTO DOWN (Opens) Check that the front passenger side window and rear power windows operate as follows: OK Condition Regulator Switch Switch Operation Power Window Engine switch on (IG) Window lock switch off Front passenger side Pulled up (One touch operation) AUTO UP (Closes) Pushed down (One touch operation) AUTO DOWN (Opens) Rear LH side Pulled up (One touch operation) AUTO UP (Closes) Pushed down (One touch operation) AUTO DOWN (Opens) Rear RH side Pulled up (One touch operation) AUTO UP (Closes) Pushed down (One touch operation) AUTO DOWN (Opens)
4. CHECK REMOTE MANUAL UP / DOWN FUNCTION Check that the front passenger side window and rear power windows operate as follows: OK Condition Master Switch Switch Operation Power Window Engine switch on (IG) Front passenger side Pulled halfway up UP (Closes) Pushed halfway down DOWN (Opens) Rear LH side Pulled halfway up UP (Closes) Pushed halfway down DOWN (Opens) Rear RH side Pulled halfway up UP (Closes) Pushed halfway down DOWN (Opens)
5. CHECK REMOTE AUTO UP / DOWN FUNCTION Check that the front passenger side window and rear power windows operate as follows: OK Condition Master Switch Switch Operation Power Window Engine switch on (IG) Front passenger side Pulled up (One touch operation) AUTO UP (Closes) Pushed down (One touch operation) AUTO DOWN (Opens) Rear LH side Pulled up (One touch operation) AUTO UP (Closes) Pushed down (One touch operation) AUTO DOWN (Opens) Rear RH side Pulled up (One touch operation) AUTO UP (Closes) Pushed down (One touch operation) AUTO DOWN (Opens)
6. CHECK POWER WINDOW OPERATION FUNCTION AFTER ENGINE SWITCH IS TURNED OFF Check that all the power windows can be operated with the multiplex network master switch assembly and power window regulator switch assemblies (for front passenger side, rear LH and RH sides) after the engine switch is turned off. HINT: If the window lock switch is on, the windows cannot be operated using the power window regulator switch assemblies (for front passenger, rear LH and RH sides). Therefore, turn the window lock switch off before checking the window operation. Check that the key-off operation function does not operate after the driver side door or front passenger side door is opened. HINT: If the driver door or front passenger door is opened during automatic window operation while the key-off operation function is on, the window will stop operating. Check that all the power windows cannot be operated after more than approximately 45 seconds have elapsed since the engine switch was turned off.
7. CHECK KEY-LINKED FUNCTION USING DRIVER SIDE DOOR KEY CYLINDER Check that all power windows operate as follows: OK Condition Door Key Cylinder Operation Power Window No key is inside vehicle, and all doors are closed Held (LOCK) for more than 1.5 seconds UP (Closes) No key is inside vehicle, and all doors are closed Returned to neutral position STOP No key is inside vehicle, and all doors are closed Held (UNLOCK) for more than 1.5 seconds DOWN (Opens) No key is inside vehicle, and all doors are closed Returned to neutral position STOP
8. CHECK WIRELESS TRANSMITTER-LINKED FUNCTION Check that all power windows operate as follows when operating the transmitter: OK Condition Transmitter Operation Power Window No key is inside vehicle, and all doors are closed and locked UNLOCK switch pressed for more than 3.0 seconds DOWN (Opens) No key is inside vehicle, and all doors are closed and locked UNLOCK switch released STOP
9. CHECK JAM PROTECTION FUNCTION Check the basic function. WARNING: Do not put your fingers between the door frame and door glass to check the jam protection function. Also, prevent any part of your body from being caught during inspection. HINT: The jam protection function is operative during both the auto up and manual up operations while the engine is running or the engine switch is on (IG), and also 45 sec. have elapsed after the engine switch is turned off. Fully open the window. Set a thick book wrapped with a piece of cloth near the window fully closed position. Operate the auto up or manual up function to check that the power window goes down after the book is caught between the window and door frame, and stops when the opening reaches approximately 200 mm (7.87 in.). HINT: The power window moves down approximately 125 mm (4.93 in.). However, when the opening does not reach 200 mm (7.87 in.), the power window continues to go down until the opening reaches 200 mm (7.87 in.) or until approximately 5 seconds elapse. While the power window is moving down, check that the door glass cannot be raised when the power window switch is used.
10. CHECK POWER WINDOW SWITCH LED ILLUMINATION Check the LED illumination (multiplex network master switch assembly). Check that the LEDs located on the multiplex network master switch assembly illuminate when the engine switch is turned on (IG). Check the LED illumination (power window regulator switch assembly (for front passenger side)). Check that the LED located on the power window regulator switch assembly (for front passenger side) illuminates when the engine switch is turned on (IG). HINT: If the window lock switch is on, the LED located on the power window regulator switch assembly (for front passenger side) does not illuminate. Therefore, turn the window lock switch off before checking the LED illumination. Check the LED illumination (power window regulator switch assembly (for rear LH and RH)). Check that the LED located on each power window regulator switch assembly (for rear LH and RH) illuminates when the engine switch is turned on (IG). HINT: If the window lock switch is on, the LEDs located on the power window regulator switch assemblies (for rear LH and RH) do not illuminate. Therefore, turn the window lock switch off before checking the LED illumination.

PROBLEM SYMPTOMS TABLE [03/2012 - ]

HINT

1. Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. Inspect the fuses and relays related to this system before inspecting the suspected areas below.

POWER WINDOW CONTROL SYSTEM

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Disconnect the J7 multiplex network master switch assembly connector. Measure the voltage and resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition J7-11 (B) - J7-12 (E) L - W-B Power supply Always 11 to 14 V J7-12 (E) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the J7 multiplex network master switch assembly connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition J7-15 (D) - J7-12 (E) B - W-B Power window motor DOWN output Engine switch on (IG), driver side power window regulator switch OFF 11 to 14 V J7-15 (D) - J7-12 (E) B - W-B Power window motor DOWN output Engine switch on (IG), driver door power window switch DOWN (Manual operation) Below 1 V J7-18 (LED) - J7-12 (E) Y - W-B LED illumination signal Engine switch on (IG) 11 to 14 V J7-18 (LED) - J7-12 (E) Y - W-B LED illumination signal Approximately 45 seconds after engine switch turned off Below 1 V J7-20 (U) - J7-12 (E) G - W-B Power window motor UP output Engine switch on (IG), driver door power window switch OFF 11 to 14 V J7-20 (U) - J7-12 (E) G - W-B Power window motor UP output Engine switch on (IG), driver door power window switch UP (Manual operation) Below 1 V If the result is not as specified, the multiplex network master switch assembly may have a malfunction.
2. CHECK POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Front Passenger Side) Disconnect the I7 power window regulator switch assembly (for front passenger side) connector. Measure the resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition I7-5 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the I7 power window regulator switch assembly (for front passenger side) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition I7-2 (U) - I7-5 (GND) R - W-B Power window motor UP output Engine switch on (IG), power window regulator switch assembly (for front passenger side) OFF 11 to 14 V I7-2 (U) - I7-5 (GND) R - W-B Power window motor UP output Engine switch on (IG), power window regulator switch assembly (for front passenger side) UP (Manual operation) Below 1 V I7-2 (U) - I7-5 (GND) R - W-B Power window motor UP output Engine switch on (IG), front passenger side power window fully open 11 to 14 V I7-2 (U) - I7-5 (GND) R - W-B Power window motor UP output Engine switch on (IG), front passenger side power window fully UP (AUTO UP position) Below 1 V I7-2 (U) - I7-5 (GND) R - W-B Power window motor UP output Engine switch on (IG), front passenger side power window fully stopped (UP) 11 to 14 V I7-4 (A) - I7-5 (GND) L - W-B Power window motor AUTO UP output Engine switch on (IG), front passenger side power window fully open 11 to 14 V I7-4 (A) - I7-5 (GND) L - W-B Power window motor AUTO UP output Engine switch on (IG), front passenger side power window fully UP (AUTO UP position) Below 1 V I7-4 (A) - I7-5 (GND) L - W-B Power window motor AUTO UP output Engine switch on (IG), front passenger side power window fully stopped (UP) 11 to 14 V I7-4 (A) - I7-5 (GND) L - W-B Power window motor AUTO DOWN output Engine switch on (IG), front passenger side power window fully closed 11 to 14 V I7-4 (A) - I7-5 (GND) L - W-B Power window motor AUTO DOWN output Engine switch on (IG), front passenger side power window fully DOWN (AUTO DOWN position) Below 1 V I7-4 (A) - I7-5 (GND) L - W-B Power window motor AUTO DOWN output Engine switch on (IG), front passenger side power window fully stopped (DOWN) 11 to 14 V I7-8 (LED) - I7-5 (GND) Y - W-B LED illumination signal Engine switch on (IG) 11 to 14 V I7-8 (LED) - I7-5 (GND) Y - W-B LED illumination signal Approximately 45 seconds after the engine switch is turned off Below 1 V I7-10 (D) - I7-5 (GND) B - W-B Power window motor DOWN output Engine switch on (IG), power window regulator switch assembly (for front passenger side) OFF 11 to 14 V I7-10 (D) - I7-5 (GND) B - W-B Power window motor DOWN output Engine switch on (IG), power window regulator switch assembly (for front passenger side) DOWN (Manual operation) Below 1 V I7-10 (D) - I7-5 (GND) B - W-B Power window motor DOWN output Engine switch on (IG), front passenger side power window fully closed 11 to 14 V I7-10 (D) - I7-5 (GND) B - W-B Power window motor DOWN output Engine switch on (IG), front passenger side power window fully DOWN (AUTO DOWN position) Below 1 V I7-10 (D) - I7-5 (GND) B - W-B Power window motor DOWN output Engine switch on (IG), front passenger side power window fully stopped (DOWN) 11 to 14 V If the result is not as specified, the power window regulator switch assembly (for front passenger side) may have a malfunction.
3. CHECK POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear LH Side) Disconnect the L3 power window regulator switch assembly (for rear LH side) connector. Measure the resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition L3-5 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the L3 power window regulator switch assembly (for rear LH side) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition L3-2 (U) - L3-5 (GND) V - W-B Power window motor UP output Engine switch on (IG), power window regulator switch assembly (for rear LH side) OFF 11 to 14 V L3-2 (U) - L3-5 (GND) V - W-B Power window motor UP output Engine switch on (IG), power window regulator switch assembly (for rear LH side) UP (Manual operation) Below 1 V L3-2 (U) - L3-5 (GND) V - W-B Power window motor UP output Engine switch on (IG), rear LH side power window fully open 11 to 14 V L3-2 (U) - L3-5 (GND) V - W-B Power window motor UP output Engine switch on (IG), rear LH side power window fully UP (AUTO UP position) Below 1 V L3-2 (U) - L3-5 (GND) V - W-B Power window motor UP output Engine switch on (IG), rear LH side power window fully stopped (UP) 11 to 14 V L3-4 (A) - L3-5 (GND) Y - W-B Power window motor AUTO UP output Engine switch on (IG), rear LH side power window fully open 11 to 14 V L3-4 (A) - L3-5 (GND) Y - W-B Power window motor AUTO UP output Engine switch on (IG), rear LH side power window fully UP (AUTO UP position) Below 1 V L3-4 (A) - L3-5 (GND) Y - W-B Power window motor AUTO UP output Engine switch on (IG), rear LH side power window fully stopped (UP) 11 to 14 V L3-4 (A) - L3-5 (GND) Y - W-B Power window motor AUTO DOWN output Engine switch on (IG), rear LH side power window fully closed 11 to 14 V L3-4 (A) - L3-5 (GND) Y - W-B Power window motor AUTO DOWN output Engine switch on (IG), rear LH side power window fully DOWN (AUTO DOWN position) Below 1 V L3-4 (A) - L3-5 (GND) Y - W-B Power window motor AUTO DOWN output Engine switch on (IG), rear LH side power window fully stopped (DOWN) 11 to 14 V L3-8 (LED) - L3-5 (GND) G - W-B LED illumination signal Engine switch on (IG) 11 to 14 V L3-8 (LED) - L3-5 (GND) G - W-B LED illumination signal Approximately 45 seconds after the engine switch is turned off Below 1 V L3-10 (D) - L3-5 (GND) W - W-B Power window motor DOWN output Engine switch on (IG), power window regulator switch assembly (for rear LH side) OFF 11 to 14 V L3-10 (D) - L3-5 (GND) W - W-B Power window motor DOWN output Engine switch on (IG), power window regulator switch assembly (for rear LH side) DOWN (Manual operation) Below 1 V L3-10 (D) - L3-5 (GND) W - W-B Power window motor DOWN output Engine switch on (IG), rear LH side power window fully closed 11 to 14 V L3-10 (D) - L3-5 (GND) W - W-B Power window motor DOWN output Engine switch on (IG), rear LH side power window fully DOWN (AUTO DOWN position) Below 1 V L3-10 (D) - L3-5 (GND) W - W-B Power window motor DOWN output Engine switch on (IG), rear LH side power window fully stopped (DOWN) 11 to 14 V If the result is not as specified, the power window regulator switch assembly (for rear LH side) may have a malfunction.
4. CHECK POWER WINDOW REGULATOR SWITCH ASSEMBLY (for Rear RH Side) Disconnect the K3 power window regulator switch assembly (for rear RH side) connector. Measure the resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition K3-5 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the K3 power window regulator switch assembly (for rear RH side) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition K3-2 (U) - K3-5 (GND) V - W-B Power window motor UP output Engine switch on (IG), power window regulator switch assembly (for rear RH side) OFF 11 to 14 V K3-2 (U) - K3-5 (GND) V - W-B Power window motor UP output Engine switch on (IG), power window regulator switch assembly (for rear RH side) UP (Manual operation) Below 1 V K3-2 (U) - K3-5 (GND) V - W-B Power window motor UP output Engine switch on (IG), rear RH side power window fully open 11 to 14 V K3-2 (U) - K3-5 (GND) V - W-B Power window motor UP output Engine switch on (IG), rear RH side power window fully UP (AUTO UP position) Below 1 V K3-2 (U) - K3-5 (GND) V - W-B Power window motor UP output Engine switch on (IG), rear RH side power window fully stopped (UP) 11 to 14 V K3-4 (A) - K3-5 (GND) G - W-B Power window motor AUTO UP output Engine switch on (IG), rear RH side power window fully open 11 to 14 V K3-4 (A) - K3-5 (GND) G - W-B Power window motor AUTO UP output Engine switch on (IG), rear RH side power window fully UP (AUTO UP position) Below 1 V K3-4 (A) - K3-5 (GND) G - W-B Power window motor AUTO UP output Engine switch on (IG), rear RH side power window fully stopped (UP) 11 to 14 V K3-4 (A) - K3-5 (GND) G - W-B Power window motor AUTO DOWN output Engine switch on (IG), rear RH side power window fully closed 11 to 14 V K3-4 (A) - K3-5 (GND) G - W-B Power window motor AUTO DOWN output Engine switch on (IG), rear RH side power window fully DOWN (AUTO DOWN position) Below 1 V K3-4 (A) - K3-5 (GND) G - W-B Power window motor AUTO DOWN output Engine switch on (IG), rear RH side power window fully stopped (DOWN) 11 to 14 V K3-8 (LED) - K3-5 (GND) B - W-B LED illumination signal Engine switch on (IG) 11 to 14 V K3-8 (LED) - K3-5 (GND) B - W-B LED illumination signal Approximately 45 seconds after the engine switch is turned off Below 1 V K3-10 (D) - K3-5 (GND) W - W-B Power window motor DOWN output Engine switch on (IG), power window regulator switch assembly (for rear RH side) OFF 11 to 14 V K3-10 (D) - K3-5 (GND) W - W-B Power window motor DOWN output Engine switch on (IG), power window regulator switch assembly (for rear RH side) DOWN (Manual operation) Below 1 V K3-10 (D) - K3-5 (GND) W - W-B Power window motor DOWN output Engine switch on (IG), rear RH side power window fully closed 11 to 14 V K3-10 (D) - K3-5 (GND) W - W-B Power window motor DOWN output Engine switch on (IG), rear RH side power window fully DOWN (AUTO DOWN position) Below 1 V K3-10 (D) - K3-5 (GND) W - W-B Power window motor DOWN output Engine switch on (IG), rear RH side power window fully stopped (DOWN) 11 to 14 V If the result is not as specified, the power window regulator switch assembly (for rear RH side) may have a malfunction.
5. CHECK POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Driver Side) Disconnect the J1 power window regulator motor assembly (for driver side) connector. Measure the voltage and resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition J1-1 (E) - Body ground W-B - Body ground Ground Always Below 1 ohms J1-2 (B) - Body ground Y - Body ground Power supply Always 11 to 14 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the J1 power window regulator motor assembly (for driver side) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition J1-5 (LED) - J1-1 (E) Y - W-B LED illumination signal Engine switch on (IG) 11 to 14 V J1-5 (LED) - J1-1 (E) Y - W-B LED illumination signal Approximately 45 seconds after engine switch turned off Below 1 V J1-7 (DWN1) - J1-1 (E) B - W-B Power window motor DOWN input Engine switch on (IG), driver side power window regulator switch OFF 11 to 14 V J1-7 (DWN1) - J1-1 (E) B - W-B Power window motor DOWN input Engine switch on (IG), driver door power window switch DOWN (Manual operation) Below 1 V J1-7 (DWN1) - J1-1 (E) B - W-B Power window motor DOWN input Engine switch on (IG), driver side power window fully closed 11 to 14 V J1-7 (DWN1) - J1-1 (E) B - W-B Power window motor DOWN input Engine switch on (IG), driver side power window fully DOWN (AUTO DOWN position) Below 1 V J1-7 (DWN1) - J1-1 (E) B - W-B Power window motor AUTO DOWN input Engine switch on (IG), driver side power window fully stopped (DOWN) 11 to 14 V J1-10 (UP1) - J1-1 (E) G - W-B Power window motor UP input Engine switch on (IG), driver door power window switch OFF 11 to 14 V J1-10 (UP1) - J1-1 (E) G - W-B Power window motor UP input Engine switch on (IG), driver door power window switch UP (Manual operation) Below 1 V J1-10 (UP1) - J1-1 (E) G - W-B Power window motor UP input Engine switch on (IG), driver side power window fully open 11 to 14 V J1-10 (UP1) - J1-1 (E) G - W-B Power window motor UP input Engine switch on (IG), driver side power window fully UP (AUTO UP position) Below 1 V J1-10 (UP1) - J1-1 (E) G - W-B Power window motor UP input Engine switch on (IG), driver side power window fully stopped (UP) 11 to 14 V If the result is not as specified, the power window regulator motor assembly (for driver side) may have a malfunction.
6. CHECK POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Front Passenger Side) Disconnect the I2 power window regulator motor assembly (for front passenger side) connector. Measure the voltage and resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition I2-1 (E) - Body ground W-B - Body ground Ground Always Below 1 ohms I2-2 (B) - Body ground G - Body ground Power supply Always 11 to 14 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the I2 power window regulator motor assembly (for front passenger side) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition I2-4 (AUTO) - I2-1 (E) L - W-B Power window motor AUTO UP input Engine switch on (IG), front passenger side power window fully open 11 to 14 V I2-4 (AUTO) - I2-1 (E) L - W-B Power window motor AUTO UP input Engine switch on (IG), front passenger side power window fully UP (AUTO UP position) Below 1 V I2-4 (AUTO) - I2-1 (E) L - W-B Power window motor AUTO UP input Engine switch on (IG), front passenger side power window fully stopped (UP) 11 to 14 V I2-4 (AUTO) - I2-1 (E) L - W-B Power window motor AUTO DOWN input Engine switch on (IG), front passenger side power window fully closed 11 to 14 V I2-4 (AUTO) - I2-1 (E) L - W-B Power window motor AUTO DOWN input Engine switch on (IG), front passenger side power window fully DOWN (AUTO DOWN position) Below 1 V I2-4 (AUTO) - I2-1 (E) L - W-B Power window motor AUTO DOWN input Engine switch on (IG), front passenger side power window fully stopped (DOWN) 11 to 14 V I2-5 (LED) - I2-1 (E) Y - W-B LED illumination signal Engine switch on (IG) 11 to 14 V I2-5 (LED) - I2-1 (E) Y - W-B LED illumination signal Approximately 45 seconds after engine switch turned off Below 1 V I2-7 (DWN1) - I2-1 (E) B - W-B Power window motor DOWN input Engine switch on (IG), power window regulator switch assembly (for front passenger side) OFF 11 to 14 V I2-7 (DWN1) - I2-1 (E) B - W-B Power window motor DOWN input Engine switch on (IG), power window regulator switch assembly (for front passenger side) DOWN (Manual operation) Below 1 V I2-7 (DWN1) - I2-1 (E) B - W-B Power window motor DOWN input Engine switch on (IG), front passenger side power window fully closed 11 to 14 V I2-7 (DWN1) - I2-1 (E) B - W-B Power window motor DOWN input Engine switch on (IG), front passenger side power window fully DOWN (AUTO DOWN position) Below 1 V I2-7 (DWN1) - I2-1 (E) B - W-B Power window motor DOWN input Engine switch on (IG), front passenger side power window fully stopped (DOWN) 11 to 14 V I2-10 (UP1) - I2-1 (E) R - W-B Power window motor UP input Engine switch on (IG), power window regulator switch assembly (for front passenger side) OFF 11 to 14 V I2-10 (UP1) - I2-1 (E) R - W-B Power window motor UP input Engine switch on (IG), power window regulator switch assembly (for front passenger side) UP (Manual operation) Below 1 V I2-10 (UP1) - I2-1 (E) R - W-B Power window motor UP input Engine switch on (IG), front passenger side power window fully open 11 to 14 V I2-10 (UP1) - I2-1 (E) R - W-B Power window motor UP input Engine switch on (IG), front passenger side power window fully UP (AUTO UP position) Below 1 V I2-10 (UP1) - I2-1 (E) R - W-B Power window motor UP input Engine switch on (IG), front passenger side power window fully stopped (UP) 11 to 14 V If the result is not as specified, the power window regulator motor assembly (for front passenger side) may have a malfunction.
7. CHECK POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear LH Side) Disconnect the L2 power window regulator motor assembly (for rear LH side) connector. Measure the voltage and resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition L2-1 (E) - Body ground W-B - Body ground Ground Always Below 1 ohms L2-2 (B) - Body ground B - Body ground Power supply Always 11 to 14 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the L2 power window regulator motor assembly (for rear LH side) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition L2-4 (AUTO) - L2-1 (E) Y - W-B Power window motor AUTO UP input Engine switch on (IG), rear LH side power window fully open 11 to 14 V L2-4 (AUTO) - L2-1 (E) Y - W-B Power window motor AUTO UP input Engine switch on (IG), rear LH side power window fully UP (AUTO UP position) Below 1 V L2-4 (AUTO) - L2-1 (E) Y - W-B Power window motor AUTO UP input Engine switch on (IG), rear LH side power window fully stopped (UP) 11 to 14 V L2-4 (AUTO) - L2-1 (E) Y - W-B Power window motor AUTO DOWN input Engine switch on (IG), rear LH side power window fully closed 11 to 14 V L2-4 (AUTO) - L2-1 (E) Y - W-B Power window motor AUTO DOWN input Engine switch on (IG), rear LH side power window fully DOWN (AUTO DOWN position) Below 1 V L2-4 (AUTO) - L2-1 (E) Y - W-B Power window motor AUTO DOWN input Engine switch on (IG), rear LH side power window fully stopped (DOWN) 11 to 14 V L2-5 (LED) - L2-1 (E) G - W-B LED illumination signal Engine switch on (IG) 11 to 14 V L2-5 (LED) - L2-1 (E) G - W-B LED illumination signal Approximately 45 seconds after engine switch turned off Below 1 V L2-7 (DWN1) - L2-1 (E) W - W-B Power window motor DOWN input Engine switch on (IG), power window regulator switch assembly (for rear LH side) OFF 11 to 14 V L2-7 (DWN1) - L2-1 (E) W - W-B Power window motor DOWN input Engine switch on (IG), power window regulator switch assembly (for rear LH side) DOWN (Manual operation) Below 1 V L2-7 (DWN1) - L2-1 (E) W - W-B Power window motor DOWN input Engine switch on (IG), rear LH side power window fully closed 11 to 14 V L2-7 (DWN1) - L2-1 (E) W - W-B Power window motor DOWN input Engine switch on (IG), rear LH side power window fully DOWN (AUTO DOWN position) Below 1 V L2-7 (DWN1) - L2-1 (E) W - W-B Power window motor DOWN input Engine switch on (IG), rear LH side power window fully stopped (DOWN) 11 to 14 V L2-10 (UP1) - L2-1 (E) V - W-B Power window motor UP input Engine switch on (IG), power window regulator switch assembly (for rear LH side) OFF 11 to 14 V L2-10 (UP1) - L2-1 (E) V - W-B Power window motor UP input Engine switch on (IG), power window regulator switch assembly (for rear LH side) UP (Manual operation) Below 1 V L2-10 (UP1) - L2-1 (E) V - W-B Power window motor UP input Engine switch on (IG), rear LH side power window fully open 11 to 14 V L2-10 (UP1) - L2-1 (E) V - W-B Power window motor UP input Engine switch on (IG), rear LH side power window fully UP (AUTO UP position) Below 1 V L2-10 (UP1) - L2-1 (E) V - W-B Power window motor UP input Engine switch on (IG), rear LH side power window fully stopped (UP) 11 to 14 V If the result is not as specified, the power window regulator motor assembly (for rear LH side) may have a malfunction.
8. CHECK POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear RH Side) Disconnect the K2 power window regulator motor assembly (for rear RH side) connector. Measure the voltage and resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition K2-1 (E) - Body ground W-B - Body ground Ground Always Below 1 ohms K2-2 (B) - Body ground LG - Body ground Power supply Always 11 to 14 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the K2 power window regulator motor assembly (for rear RH side) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition K2-4 (AUTO) - K2-1 (E) G - W-B Power window motor AUTO UP input Engine switch on (IG), rear RH side power window fully open 11 to 14 V K2-4 (AUTO) - K2-1 (E) G - W-B Power window motor AUTO UP input Engine switch on (IG), rear RH side power window fully open (AUTO UP position) Below 1 V K2-4 (AUTO) - K2-1 (E) G - W-B Power window motor AUTO UP input Engine switch on (IG), rear RH side power window fully stopped (UP) 11 to 14 V K2-4 (AUTO) - K2-1 (E) G - W-B Power window motor AUTO DOWN input Engine switch on (IG), rear RH side power window fully closed 11 to 14 V K2-4 (AUTO) - K2-1 (E) G - W-B Power window motor AUTO DOWN input Engine switch on (IG), rear RH side power window fully DOWN (AUTO DOWN position) Below 1 V K2-4 (AUTO) - K2-1 (E) G - W-B Power window motor AUTO DOWN input Engine switch on (IG), rear RH side power window fully stopped (DOWN) 11 to 14 V K2-5 (LED) - K2-1 (E) B - W-B LED illumination signal Engine switch on (IG) 11 to 14 V K2-5 (LED) - K2-1 (E) B - W-B LED illumination signal Approximately 45 seconds after engine switch turned off Below 1 V K2-7 (DWN1) - K2-1 (E) W - W-B Power window motor DOWN input Engine switch on (IG), power window regulator switch assembly (for rear RH side) OFF 11 to 14 V K2-7 (DWN1) - K2-1 (E) W - W-B Power window motor DOWN input Engine switch on (IG), power window regulator switch assembly (for rear RH side) DOWN (Manual operation) Below 1 V K2-7 (DWN1) - K2-1 (E) W - W-B Power window motor DOWN input Engine switch on (IG), rear RH side power window fully closed 11 to 14 V K2-7 (DWN1) - K2-1 (E) W - W-B Power window motor DOWN input Engine switch on (IG), rear RH side power window fully DOWN (AUTO DOWN position) Below 1 V K2-7 (DWN1) - K2-1 (E) W - W-B Power window motor DOWN input Engine switch on (IG), rear RH side power window fully stopped (DOWN) 11 to 14 V K2-10 (UP1) - K2-1 (E) V - W-B Power window motor UP input Engine switch on (IG), power window regulator switch assembly (for rear RH side) OFF 11 to 14 V K2-10 (UP1) - K2-1 (E) V - W-B Power window motor UP input Engine switch on (IG), power window regulator switch assembly (for rear RH side) UP (Manual operation) Below 1 V K2-10 (UP1) - K2-1 (E) V - W-B Power window motor UP input Engine switch on (IG), rear RH side power window fully open 11 to 14 V K2-10 (UP1) - K2-1 (E) V - W-B Power window motor UP input Engine switch on (IG), rear RH side power window fully UP (AUTO UP position) Below 1 V K2-10 (UP1) - K2-1 (E) V - W-B Power window motor UP input Engine switch on (IG), rear RH side power window fully stopped (UP) 11 to 14 V If the result is not as specified, the power window regulator motor assembly (for rear RH side) may have a malfunction.
9. CHECK INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY, MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) Disconnect the 2F, F14 and 2D junction block connectors. Disconnect the A main body ECU (multiplex network body ECU) connector. Measure the voltage and resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with the connectors disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition 2F-40 (BECU) - Body ground G - Body ground Battery power supply Always 11 to 14 V A-31 (ALTB) - Body ground - Battery power supply Always 11 to 14 V F14-3 (GND2) - Body ground W-B - Body ground Ground Always Below 1 ohms 2D-6 (GND1) - Body ground BR - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction in the wire harness or instrument panel junction block assembly. Reconnect the 2F, F14 and 2D junction block connectors. Reconnect the A main body ECU (multiplex network body ECU) connector. Measure the voltage according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition 2D-26 (FRCY) - Body ground L - Body ground Front passenger side door courtesy switch input Front passenger side door open Below 1 V 2D-26 (FRCY) - Body ground L - Body ground Front passenger side door courtesy switch input Front passenger side door closed 11 to 14 V 2H-26 (FLCY) - Body ground B - Body ground Driver side door courtesy switch input Driver side door open Below 1 V 2H-26 (FLCY) - Body ground B - Body ground Driver side door courtesy switch input Driver side door closed 11 to 14 V F13-11 (L2) - Body ground BR - Body ground Driver door key-linked door lock input Driver door lock cylinder is turned off 11 to 14 V F13-11 (L2) - Body ground BR - Body ground Driver door key-linked door lock input Lock with mechanical key Below 1 V F13-24 (UL3) - Body ground GR - Body ground Driver door key-linked door unlock input Driver door lock cylinder is turned off 11 to 14 V F13-24 (UL3) - Body ground GR - Body ground Driver door key-linked door unlock input Unlock with mechanical key Below 1 V If the result is not as specified, the main body ECU (multiplex network body ECU) or instrument panel junction block assembly may have a malfunction.
10. CHECK CERTIFICATION ECU (SMART KEY ECU ASSEMBLY) Disconnect the F58 certification ECU (smart key ECU assembly) connector. Measure the voltage and resistance according to the value(s) in the table below. HINT: Measure the values on the wire harness side with connector disconnected. Tester Connection Wiring Color Terminal Description Condition Specified Condition F58-1 (+B) - Body ground LG - Body ground +B power supply Always 11 to 14 V F58-15 (E) - Body ground W-B - Body ground Ground Always Below 1 ohms F58-17 (CUTB) - Body ground L - Body ground Dark current cut fuse pin input signal Always 11 to 14 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the F58 certification ECU (smart key ECU assembly) connector. Measure the voltage and check for pulses according to the value(s) in the table below. Tester Connection Wiring Color Terminal Description Condition Specified Condition F58-16 (IG) - Body ground B - Body ground IG power supply Engine switch off Below 1 V F58-16 (IG) - Body ground B - Body ground IG power supply Engine switch on (IG) 11 to 14 V O1-5 (RC0) - F58-15 (E) L - W-B Door control receiver power source Engine switch off Lock or unlock switch on key not pushed Below 1 V O1-5 (RC0) - F58-15 (E) L - W-B Door control receiver power source Engine switch off Lock or unlock switch on key pushed 4.5 to 5.5 V O1-15 (RDA) - F58-15 (E) Y - W-B Door control receiver data input signal Engine switch off Pulse between 11 to 14 V occurs regularly O1-16 (RSSI) - F58-15 (E) R - W-B Door control receiver electric wave existence signal Engine switch off All doors locked Lock or unlock switch on key not pushed 11 to 14 V O1-16 (RSSI) - F58-15 (E) R - W-B Door control receiver electric wave existence signal Engine switch off All doors locked Lock or unlock switch on key pushed Below 2 V If the result is not as specified, the certification ECU (smart key ECU assembly) may have a malfunction.

DIAGNOSIS SYSTEM [03/2012 - ]

1. DESCRIPTION The power window control system data can be read from the Data Link Connector 3 (DLC3) of the vehicle. When the system seems to be malfunctioning, use the Techstream to check for malfunctions and perform repairs.
2. CHECK DLC3 Check the DLC3. Refer to «GENERAL INFORMATION [03/2012 - ]»(ref-602551-S10595751552014030500000) .
3. INSPECT BATTERY VOLTAGE Measure the battery voltage. Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery.

DTC CHECK / CLEAR [03/2012 - ]

1. CHECK DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / (desired system) / Trouble Codes. Check the details of the DTC(s). Refer to «DIAGNOSTIC TROUBLE CODE CHART [03/2012 - ]»(ref-602570-S13692277922014030500000) .
2. CLEAR DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / (desired system) / Trouble Codes. Clear the DTCs.

Scheme 16

Scheme 17

Scheme 18

Scheme 19

1. POWER WINDOW OPERATION IN FAIL-SAFE MODE HINT: If the pulse sensor built into the power window regulator motor malfunctions, the power window control system enters fail-safe mode. The power window control system prohibits the following power window operations when the pulse sensor for the jam protection function has problems and the window position or the learned value is abnormal. MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Power Window Operation Condition Engine switch on (IG) Engine switch off (Key-off operation permitted) Engine switch off (Key-off operation prohibited) Manual up (Driver side door window) X X - Manual down (Driver side door window) o X - Auto up (Driver side door window) (hold switch at auto up position) o* X - Auto up (Driver side door window) X X - Auto down (Driver side door window) X X - Manual up (Remote switch operation) X X - Manual down (Remote switch operation) X X - Auto up (Remote switch operation) (hold switch at auto up position) X X - Auto up (Remote switch operation) X X - Auto down (Remote switch operation) X X - Key-linked open and close - X X Wireless transmitter-linked open - X X HINT: o: Operates X: Operation prohibited *: Operates in manual mode without jam protection POWER WINDOW REGULATOR SWITCH ASSEMBLY (FOR FRONT PASSENGER, REAR LH AND REAR RH SIDES) Power Window Operation Condition Engine switch on (IG) Engine switch off (Key-off operation permitted) Engine switch off (Key-off operation prohibited) Manual up X X - Manual down o X - Auto up (hold switch at auto up position) o* X - Auto up X X - Auto down X X - Key-linked open and close - X X Wireless transmitter-linked open - X X HINT: o: Operates X: Operation prohibited *: Operates in manual mode without jam protection Power window switch LED control HINT: During normal operation (fail-safe is not operating), or during fail-safe mode when there is a pulse sensor malfunction or the window position or learned value is abnormal, the LED illuminates as shown in the illustration. For driver side: For front passenger side, rear LH and rear RH sides: Fail-safe deactivation condition When the pulse sensor is normal, to deactivate fail-safe mode, pull up the power window switch to the auto up position and hold it for at least 1 second to fully close the window from the fully open position. As a result, the auto up/down function will return. Initialization failure HINT: During initialization of the power window regulator motor ECU, when the window position or initialization complete status cannot be properly read from the EEPROM, the power window control system prohibits the operations as follows: MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Power Window Operation Condition Engine switch on (IG) Engine switch off (Key-off operation permitted) Engine switch off (Key-off operation prohibited) Manual up (Driver side door window) X X - Manual down (Driver side door window) o X - Auto up (Driver side door window) (hold switch at auto up position) o* X - Auto up (Driver side door window) X X - Auto down (Driver side door window) X X - Manual up (Remote switch operation) X X - Manual down (Remote switch operation) X X - Auto up (Remote switch operation) (hold switch at auto up position) X X - Auto up (Remote switch operation) X X - Auto down (Remote switch operation) X X - Key-linked open and close - X X Wireless transmitter-linked open - X X HINT: o: Operates X: Operation prohibited *: Operates in manual mode without jam protection POWER WINDOW REGULATOR SWITCH ASSEMBLY (FOR FRONT PASSENGER, REAR LH AND REAR RH SIDES) Power Window Operation Condition Engine switch on (IG) Engine switch off (Key-off operation permitted) Engine switch off (Key-off operation prohibited) Manual up X X - Manual down o X - Auto up (hold switch at auto up position) o* X - Auto up X X - Auto down X X - Key-linked open and close - X X Wireless transmitter-linked open - X X HINT: o: Operates X: Operation prohibited *: Operates in manual mode without jam protection Power window switch LED control HINT: During initialization of the power window regulator motor ECU, when the window position or initialization complete status cannot be properly read from the EEPROM during fail-safe mode, the LED illuminates as shown in the illustration. For driver side: For front passenger side, rear LH and rear RH sides: LIN communication failure HINT: If the LIN communication line malfunctions (communication stop), the power window control system prohibits the operations as follows: MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Power Window Operation Condition Engine switch on (IG) Manual up o* Manual down o Auto up (hold switch at auto up position) X Auto up X Auto down X HINT: o: Operates X: Operation prohibited *: Jam protection can operate. Remote up/down function does not operate. POWER WINDOW REGULATOR SWITCH ASSEMBLY (FOR FRONT PASSENGER, REAR LH AND REAR RH SIDES) Power Window Operation Condition Engine switch on (IG) Manual up o* Manual down o Auto up (hold switch at auto up position) o* Auto up o* Auto down o HINT: o: Operates X: Operation prohibited *: Jam protection can operate. LIN communication failure and pulse sensor failure HINT: If the LIN communication line malfunctions (communication stop) and the pulse sensor for the jam protection function has problems, the power window control system prohibits the operations as follows: MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Power Window Operation Condition Always Manual up X Manual down X Auto up (hold switch at auto up position) X Auto up X Auto down X HINT: o: Operates X: Operation prohibited Driver door window: When the jam protection function does not operate due to a LIN communication failure, the manual up and auto up functions will not operate. Remote switch operation: Not operative during a LIN communication failure POWER WINDOW REGULATOR SWITCH ASSEMBLY (FOR FRONT PASSENGER, REAR LH AND REAR RH SIDES) Power Window Operation Condition Always Manual up X Manual down X Auto up (hold switch at auto up position) X Auto up X Auto down X HINT: o: Operates X: Operation prohibited LIN communication failure and abnormal window position learned value or initialization failure HINT: If the LIN communication line malfunctions (communication stop) and the window position or the learned value is abnormal, the power window control system prohibits the operations as follows: MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Power Window Operation Condition Always Manual up o* Manual down o Auto up (hold switch at auto up position) - Auto up - Auto down - HINT: o: Operates *: Jam protection can operate and window reverses upon reaching the fully closed position. Remote switch operation: Operation is not possible during a LIN communication failure. POWER WINDOW REGULATOR SWITCH ASSEMBLY (FOR FRONT PASSENGER, REAR LH AND REAR RH SIDES) Power Window Operation Condition Always Manual up o* Manual down o Auto up (hold switch at auto up position) o* Auto up X Auto down X HINT: o: Operates X: Operation prohibited *: Jam protection can operate and window reverses upon reaching the fully closed position.

DATA LIST / ACTIVE TEST [03/2012 - ]

1. READ DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / (desired system) / Data List. Read the Data List according to the display on the Techstream. MASTER SWITCH (MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY) Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door P/W Auto SW Driver side power window auto switch signal / ON or OFF ON: Driver side power window auto switch operated OFF: Driver side power window auto switch not operated - P Door P/W Auto SW Front passenger side power window auto up/down switch signal / ON or OFF ON: Front passenger door power window auto switch operated OFF: Front passenger door power window auto switch not operated - RR Door P/W Auto SW Rear RH side power window auto up/down switch signal / ON or OFF ON: Rear RH power window auto switch operated OFF: Rear RH power window auto switch not operated - RL Door P/W Auto SW Rear LH side power window auto up / down switch signal / ON or OFF ON: Rear LH power window auto switch operated OFF: Rear LH power window auto switch not operated - P Door P/W Up SW Front passenger side power window manual up switch signal / ON or OFF ON: Front passenger door power window manual up switch operated OFF: Front passenger door power window manual up switch not operated - RR Door P/W up Switch Rear RH side power window manual up switch signal / ON or OFF ON: Rear RH power window manual up switch operated OFF: Rear RH power window manual up switch not operated - RL Door P/W up Switch Rear LH side power window manual up switch signal / ON or OFF ON: Rear LH power window manual up switch operated OFF: Rear LH power window manual up switch not operated - P Door P/W Down SW Front passenger side power window manual down switch signal / ON or OFF ON: Front passenger door power window manual down switch operated OFF: Front passenger door power window manual down switch not operated - RR Door P/W Down SW Rear RH side power window manual down switch signal / ON or OFF ON: Rear RH power window manual down switch operated OFF: Rear RH power window manual down switch not operated - RL Door P/W Down SW Rear LH side power window manual down switch signal / ON or OFF ON: Rear LH power window manual down switch operated OFF: Rear LH power window manual down switch not operated - Window Lock Switch Status Window lock switch signal / ON or OFF ON: Window lock switch LOCK position OFF: Window lock switch UNLOCK position - Number of Trouble Codes Number of trouble codes / Min.: 0 or Max.: 255 Number of DTCs will be displayed - D-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR DRIVER SIDE)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door P/W Auto SW Driver side power window auto switch signal / ON or OFF ON: Driver door power window auto switch operated OFF: Driver door power window auto switch not operated - D Door P/W Up SW Driver side power window manual up switch signal / ON or OFF ON: Driver door power window manual up switch operated OFF: Driver door power window manual up switch not operated - D Door P/W Down SW Driver side power window manual down switch signal / ON or OFF ON: Driver door power window manual down switch operated OFF: Driver door power window manual down switch not operated - Glass Position (Close - 1/4) Margin for jam protection triggering force of window glass within range of fully closed to 1/4 open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Glass Position (1/4 - 2/4) Margin for jam protection triggering force of window glass within range of 1/4 to 1/2 open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Glass Position (2/4 - 3/4) Margin for jam protection triggering force of window glass within range of 1/2 to 3/4 open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Glass Position (3/4 - Open) Margin for jam protection triggering force of window glass within range of 3/4 to fully open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Number of Trouble Codes Number of trouble codes / Min.: 0 or Max.: 255 Number of DTCs will be displayed - P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER SIDE)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note P Door P/W Auto SW Front passenger side power window auto switch signal / ON or OFF ON: Front passenger door power window auto switch operated OFF: Front passenger door power window auto switch not operated - P Door P/W Up SW Front passenger side power window manual up switch signal / ON or OFF ON: Front passenger door power window manual up switch operated OFF: Front passenger door power window manual up switch not operated - P Door P/W Down SW Front passenger side power window manual down switch signal / ON or OFF ON: Front passenger door power window manual down switch operated OFF: Front passenger door power window manual down switch not operated - Glass Position (Close - 1/4) Margin for jam protection triggering force of window glass within range of fully closed to 1/4 open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Glass Position (1/4 - 2/4) Margin for jam protection triggering force of window glass within range of 1/4 to 1/2 open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Glass Position (2/4 - 3/4) Margin for jam protection triggering force of window glass within range of 1/2 to 3/4 open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Glass Position (3/4 - Open) Margin for jam protection triggering force of window glass within range of 3/4 to fully open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Window Auto Up Auto up operation using the power window regulator switch assembly (for front passenger side) / Avail or Not Avl Customization status displayed - Window Auto Up From Driver Remote auto up operation using the multiplex network master switch assembly / Avail or Not Avl Customization status displayed - Number of Trouble Codes Number of trouble codes / Min.: 0 or Max.: 255 Number of DTCs will be displayed - RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH SIDE)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note RL Door P/W Auto SW Rear LH side power window auto switch signal / ON or OFF ON: Rear LH door power window auto switch operated OFF: Rear LH door power window auto switch not operated - RL Door P/W Up SW Rear LH side power window manual up switch signal / ON or OFF ON: Rear LH door power window manual up switch operated OFF: Rear LH door power window manual up switch not operated - RL Door P/W Down SW Rear LH side power window manual down switch signal / ON or OFF ON: Rear LH door power window manual down switch operated OFF: Rear LH door power window manual down switch not operated - Glass Position (Close - 1/4) Margin for jam protection triggering force of window glass within range of fully closed to 1/4 open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Glass Position (1/4 - 2/4) Margin for jam protection triggering force of window glass within range of 1/4 to 1/2 open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Glass Position (2/4 - 3/4) Margin for jam protection triggering force of window glass within range of 1/2 to 3/4 open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Glass Position (3/4 - Open) Margin for jam protection triggering force of window glass within range of 3/4 to fully open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Window Auto Up Auto up operation using the power window regulator switch assembly (for rear LH side) / Avail or Not Avl Customization status displayed - Window Auto Up From Driver Remote auto up operation using the multiplex network master switch assembly / Avail or Not Avl Customization status displayed - Number of Trouble Codes Number of trouble codes / Min.: 0 or Max.: 255 Number of DTCs will be displayed - RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR RH SIDE)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note RR Door P/W Auto SW Rear RH side power window auto switch signal / ON or OFF ON: Rear RH door power window auto switch operated OFF: Rear RH door power window auto switch not operated - RR Door P/W Up SW Rear RH side power window manual up switch signal / ON or OFF ON: Rear RH door power window manual up switch operated OFF: Rear RH door power window manual up switch not operated - RR Door P/W Down SW Rear RH side power window manual down switch signal / ON or OFF ON: Rear RH door power window manual down switch operated OFF: Rear RH door power window manual down switch not operated - Glass Position (Close - 1/4) Margin for jam protection triggering force of window glass within range of fully closed to 1/4 open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Glass Position (1/4 - 2/4) Margin for jam protection triggering force of window glass within range of 1/4 to 1/2 open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Glass Position (2/4 - 3/4) Margin for jam protection triggering force of window glass within range of 1/2 to 3/4 open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Glass Position (3/4 - Open) Margin for jam protection triggering force of window glass within range of 3/4 to fully open window glass position / OK or Caution OK: Normal manual up operation Caution: Jam detected in the specified range Caution is displayed only while the power window ECU built into the power window regulator motor assembly detects a jam. Window Auto Up Auto up operation using the power window regulator switch assembly (for rear RH side) / Avail or Not Avl Customization status displayed - Window Auto Up From Driver Remote auto up operation using the multiplex network master switch assembly / Avail or Not Avl Customization status displayed - Number of Trouble Codes Number of trouble codes / Min.: 0 or Max.: 255 Number of DTCs will be displayed - MAIN BODY (MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note Door Key SW-Lock Driver side door lock/unlock switch lock signal (key-linked lock switch)/ON or OFF ON: Driver side door key cylinder turned to lock position OFF: Driver side door key cylinder turned to unlock position - Door Key SW-Unlock Driver side door lock/unlock switch unlock signal (key-linked unlock switch)/ON or OFF ON: Driver side door key cylinder turned to unlock position OFF: Driver side door key cylinder turned to lock position - FR Door Courtesy Front door courtesy switch RH signal / ON or OFF ON: Front door RH open OFF: Front door RH closed - FL Door Courtesy Front door courtesy switch LH signal / ON or OFF ON: Front door LH open OFF: Front door LH closed - Door Key P/W Up Door key linked power window up / ON or OFF Customization status displayed - Door key P/W Down Door key linked power window down / ON or OFF Customization status displayed - P/W Down W/Transmitter Wireless transmitter linked power window down / ON or OFF Customization status displayed - Communication D-Door Motor Connection status between power window regulator motor (for driver side) and main body ECU (multiplex network body ECU) / OK or STOP OK: Normal communication STOP: Communication stopped - Communication P-Door Motor Connection status between power window regulator motor (for front passenger side) and main body ECU (multiplex network body ECU) / OK or STOP OK: Normal communication STOP: Communication stopped - Communication RR-Door Motor Connection status between power window regulator motor (for rear RH) and main body ECU (multiplex network body ECU) / OK or STOP OK: Normal communication STOP: Communication stopped - Communication RL-Door Motor Connection status between power window regulator motor (for rear LH) and main body ECU (multiplex network body ECU) / OK or STOP OK: Normal communication STOP: Communication stopped - Communication Master SW Connection status between multiplex network master switch assembly and main body ECU (multiplex network body ECU) / OK or STOP OK: Normal communication STOP: Communication stopped
2. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / (desired system) / Active Test. Perform the Active Test according to the display on the Techstream. WARNING: Be careful to avoid injuries as this test causes vehicle parts to move. During the Active Test, the jam protection function will not operate. D-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR DRIVER SIDE)) Tester Display Test Part Control Range Diagnostic Note Power Window Power window OFF / UP /DOWN - P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER SIDE)) Tester Display Test Part Control Range Diagnostic Note Power Window Power window OFF / UP /DOWN - RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH SIDE)) Tester Display Test Part Control Range Diagnostic Note Power Window Power window OFF / UP /DOWN - RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR RH SIDE)) Tester Display Test Part Control Range Diagnostic Note Power Window Power window OFF / UP /DOWN

DIAGNOSTIC TROUBLE CODE CHART [03/2012 - ]

POWER WINDOW CONTROL SYSTEM
