INSPECTION PROCEDURE
Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.
Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.
Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.
HINT
If DTC B1244 is output together with other DTCs, troubleshoot DTC B1244 first. Refer to DTC B1244: Light Sensor Circuit Malfunction .
HINT
If DTC B1244 is output together with other DTCs, troubleshoot DTC B1244 first. Refer to DTC B1244: Light Sensor Circuit Malfunction .
Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.
Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.
Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.
Scheme 267
- PERFORM ACTIVE TEST USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Air Conditioner / Active Test. Check the operation by referring to the table below. AIR CONDITIONER Tester Display Test Part Control Range Diagnostic Note Blower Motor Blower motor Min.: 0, Max.: 31 - OK Blower motor operates and blower motor speed level changes. Result Result Proceed to OK A NG (Blower motor does not operate) B NG (Blower motor operates but does not change speed) C B --> See step 2 C --> See step 6 A --> See step 7
- CHECK HARNESS AND CONNECTOR (BLOWER MOTOR - BODY GROUND) Disconnect the blower motor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F101-1 (GND) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Blower Motor) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK HARNESS AND CONNECTOR (BLOWER MOTOR - BATTERY) Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition F101-3 (+B) - Body ground Always 11 to 14 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Blower Motor) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK HARNESS AND CONNECTOR (BLOWER MOTOR - A/C AMPLIFIER) Disconnect the A/C amplifier connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F50-23 (BLW) - F101-2 (SI) Always Below 1 ohms F50-23 (BLW) - Body ground Always 10 kohms or higher TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to A/C Amplifier) *2 Front view of wire harness connector (to Blower Motor) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT BLOWER MOTOR Reconnect the blower motor connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition F50-23 (BLW) - Body ground Always 4.5 to 5.5 V TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to A/C Amplifier) NG --> See step 8 OK: Go to next step
- INSPECT A/C AMPLIFIER Remove the A/C amplifier. Reconnect the A/C amplifier connector. Turn the engine switch on (IG). Set the blower speed to LO. Measure the waveform between terminal F50-23 (BLW) of the A/C amplifier and body ground. Item Content Tool setting 1 V/DIV., 500 μs/DIV. Vehicle condition Engine switch on (IG) Blower set to LO OK Waveform is as shown in the illustration. HINT: The waveform varies with the blower speed. TEXT IN ILLUSTRATION *1 Component with harness connected (A/C Amplifier) NG --> See step 9 OK --> See step 8
- PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE [03/2012 - 07/2012]»(ref-602709-S14820398182014030500000)
- REPLACE BLOWER MOTOR. Refer to «REMOVAL [03/2012 - 07/2012]»(ref-602698-S40108702732014030500000)
- REPLACE A/C AMPLIFIER. Refer to «REMOVAL [03/2012 - 07/2012]»(ref-602698-S09243280892014030500000)
