Power Window Control (Diagnostics - Introduction): Other Lexus RX III

PRECAUTION

1. PRECAUTION FOR DISCONNECTING CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected: System Name See Procedure Parking Assist Monitor System Refer to «INITIALIZATION»(ref-400649-S12881576452011051800000) Side Monitor System (w/ Parking Assist Monitor System) Back Door Closer System Power Back Door System
2. POWER WINDOW CONTROL SYSTEM PRECAUTIONS WARNING: The power window control system prohibits the auto up/down function when the jam protection function malfunctions. Therefore, troubleshoot the power window control system after confirming that no trouble codes are output. When a power window regulator or a power window regulator motor assembly is replaced, the power window control system must be initialized. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operation at least 5 times: Close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly and holding it at the auto up position. Open the power window by fully pushing down the multiplex network master switch assembly or power window regulator switch assembly. The jam protection function may operate unexpectedly even when the power window control system is normal due to detection of a value different from the operation learned value when the door glass moving speed changes sharply under any of the following conditions: A power window is being opened or closed while the vehicle is driven on a rough road. A power window is being opened or closed while the door is being opened or closed. The voltage changes abruptly. NOTE: Do not disconnect the battery while the engine switch is on (IG). Otherwise, DTC B2311 will be output.

1. PRECAUTION FOR DISCONNECTING CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected: System Name See Procedure Parking Assist Monitor System Refer to «INITIALIZATION»(ref-400649-S34584305262011051800000) Side Monitor System (w/ Parking Assist Monitor System) Back Door Closer System Power Back Door System
2. POWER WINDOW CONTROL SYSTEM PRECAUTIONS WARNING: The power window control system prohibits the auto up/down function when the jam protection function malfunctions. Therefore, troubleshoot the power window control system after confirming that no trouble codes are output. When a power window regulator or a power window regulator motor assembly is replaced, the power window control system must be initialized. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operation at least 5 times: Close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly and holding it at the auto up position. Open the power window by fully pushing down the multiplex network master switch assembly or power window regulator switch assembly. The jam protection function may operate unexpectedly even when the power window control system is normal due to detection of a value different from the operation learned value when the door glass moving speed changes sharply under any of the following conditions: A power window is being opened or closed while the vehicle is driven on a rough road. A power window is being opened or closed while the door is being opened or closed. The voltage changes abruptly. NOTE: Do not disconnect the battery while the engine switch is on (IG). Otherwise, DTC B2311 will be output.

Scheme 139

Scheme 140

Scheme 141

Scheme 142

COMMUNICATION TABLE

CUSTOMIZE PARAMETERS

1. CUSTOMIZING FUNCTION WITH TECHSTREAM (REFERENCE) HINT: The following items can be customized. NOTE: When the customer requests a change in a function, first make sure that the function(s) can be customized. Be sure to make notes of the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Power Window / Customize Setting. Select the setting by referring to the table below. POWER WINDOW Tester Display Default Content Setting Door Key P/W Up ON This function is used to close the windows by operating the mechanical key. ON/OFF Door Key P/W Down ON This function is used to open the windows by operating the mechanical key. ON/OFF P/W Down W/ Transmitter OFF This function is used to open the windows using the wireless key transmitter. ON/OFF P Window Auto Up Avail This function is used to enable or disable the auto up function for the front passenger door window using the power window regulator switch assembly (for front passenger side). Avail/Not Avl P Window Auto Up From Driver Avail This function is used to enable or disable the remote auto up function for the front passenger door window using the multiplex network master switch assembly. Avail/Not Avl RR Window Auto Up Avail This function is used to enable or disable the auto up function using the power window regulator switch assembly (for rear RH side). Avail/Not Avl RR Window Auto Up From Driver Avail This function is used to enable or disable the remote auto up function for the rear RH door window using the multiplex network master switch assembly. Avail/Not Avl RL Window Auto Up Avail This function is used to enable or disable the auto up function using the power window regulator switch assembly (for rear LH side). Avail/Not Avl RL Window Auto Up From Driver Avail This function is used to enable or disable the remote auto up function for the rear LH door window using the multiplex network master switch assembly. Avail/Not Avl

INITIALIZATION

1. INITIALIZE POWER WINDOW CONTROL SYSTEM (POWER WINDOW REGULATOR MOTOR ASSEMBLY (ALL DOORS)) WARNING: When the power window regulator motor assembly is reinstalled or replaced, the power window control system must be initialized. Functions such as the auto up/down, jam protection, remote control and key-off operation do not operate if the initialization is not performed. HINT: When the battery is replaced, it is not necessary to initialize the power window regulator motor assembly. NOTE: When the power window regulator motor assembly is replaced, DTC B2313 is output. Clear the DTC after the initialization. When performing initialization, do not perform any other procedures. When performing initialization, use the power window switch of each door to initialize each door window. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used, due to detection of a value different from the operation learned value of the door glass movement speed. In such cases, the auto up function can be reinitialized by repeating the following operation at least 5 times: Open the power window by fully pushing down the multiplex network master switch assembly or power window regulator switch assembly. Close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly and holding it at the auto up position. If the initialization is not completed properly, the LIN communication system may have a malfunction. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-400663-S10073063542011051800000) . Initialization procedure when replacing the power window regulator motor assembly with a new one: Connect the battery and turn the engine switch on (IG) (at this time, the LED on the multiplex network master switch assembly or power window regulator switch assembly blinks to indicate that it is ready for initialization). Fully open the window by fully pushing down the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully opened. Fully close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully closed to reset the glass position. The LED on the multiplex network master switch assembly or power window regulator switch assembly stops blinking and illuminates to indicate that the initialization is complete. Initialization procedure when removing/installing the power window regulator motor assembly: Connect the battery and turn the engine switch on (IG). Fully close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 6 seconds or more after the window is fully closed (if the power window does not move or stops halfway even when the switch is fully pulled, release the switch and fully pull it again). Fully open the window by pushing down the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully opened. Release the multiplex network master switch assembly or power window regulator switch assembly. Then fully push down and hold the switch for 4 seconds or more. Fully close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully closed to reset the glass position and complete the initialization. Initialization procedure when the power window does not fully open: Connect the battery and turn the engine switch on (IG). Fully close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 6 seconds or more after the window is fully closed (if the power window does not move or stops halfway even when the switch is fully pulled, release the switch and fully pull it again). Fully open the window by pushing down the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully opened. Release the multiplex network master switch assembly or power window regulator switch assembly. Then fully push down and hold the switch for 4 seconds or more. Fully close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully closed to reset the glass position and complete the initialization.

1. INITIALIZE POWER WINDOW CONTROL SYSTEM (POWER WINDOW REGULATOR MOTOR ASSEMBLY (ALL DOORS)) WARNING: When the power window regulator motor assembly is reinstalled or replaced, the power window control system must be initialized. Functions such as the auto up/down, jam protection, remote control and key-off operation do not operate if the initialization is not performed. HINT: When the battery is replaced, it is not necessary to initialize the power window regulator motor assembly. NOTE: When the power window regulator motor assembly is replaced, DTC B2313 is output. Clear the DTC after the initialization. When performing initialization, do not perform any other procedures. When performing initialization, use the power window switch of each door to initialize each door window. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used, due to detection of a value different from the operation learned value of the door glass movement speed. In such cases, the auto up function can be reinitialized by repeating the following operation at least 5 times: Open the power window by fully pushing down the multiplex network master switch assembly or power window regulator switch assembly. Close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly and holding it at the auto up position. If the initialization is not completed properly, the LIN communication system may have a malfunction. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-400663-S41486469882011051800000) . Initialization procedure when replacing the power window regulator motor assembly with a new one: Connect the battery and turn the engine switch on (IG) (at this time, the LED on the multiplex network master switch assembly or power window regulator switch assembly blinks to indicate that it is ready for initialization). Fully open the window by fully pushing down the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully opened. Fully close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully closed to reset the glass position. The LED on the multiplex network master switch assembly or power window regulator switch assembly stops blinking and illuminates to indicate that the initialization is complete. Initialization procedure when removing/installing the power window regulator motor assembly: Connect the battery and turn the engine switch on (IG). Fully close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 6 seconds or more after the window is fully closed (if the power window does not move or stops halfway even when the switch is fully pulled, release the switch and fully pull it again). Fully open the window by pushing down the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully opened. Release the multiplex network master switch assembly or power window regulator switch assembly. Then fully push down and hold the switch for 4 seconds or more. Fully close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully closed to reset the glass position and complete the initialization. Initialization procedure when the power window does not fully open: Connect the battery and turn the engine switch on (IG). Fully close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 6 seconds or more after the window is fully closed (if the power window does not move or stops halfway even when the switch is fully pulled, release the switch and fully pull it again). Fully open the window by pushing down the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully opened. Release the multiplex network master switch assembly or power window regulator switch assembly. Then fully push down and hold the switch for 4 seconds or more. Fully close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly, and hold the switch for 1 second or more after the window is fully closed to reset the glass position and complete the initialization.
