SYSTEM DESCRIPTION

1. POWER WINDOW CONTROL SYSTEM DESCRIPTION The power window control system controls the power window UP/DOWN function by using regulator motors. This system is mainly controlled by the multiplex network master switch built into the driver's door and multiplex network switches built into passenger's doors. Pressing any of these multiplex network switches or the driver side door window switch mounted on the master switch transmits an UP/DOWN signal to the regulator motor for the corresponding power window, which then operates the power window UP/DOWN. Pressing any switch for the power windows except the driver's power window mounted on the master switch transmits a remote UP/DOWN signal to the body ECU via the BEAN line. Then the body ECU transmits this remote signal to the regulator switch for the corresponding power window via the BEAN line and activates the motor to open/close the power window. The power window control system has the following functions: POWER WINDOW CONTROL SYSTEM FUNCTIONS CHART Function Outline Manual up-and-down function Function that causes window to go up while power window switch is being pulled halfway up and to go down while pushed halfway down. Window stops as soon as the switch is released. All door auto up-and-down function Function that enables window of all doors to be fully opened or closed by one press of power window switch. Jam protection function Function that automatically stops power window and moves it downward if a foreign object gets jammed in door window during auto-up operation. Remote control function Function that allows power window master switch to control AUTO and MANUAL up-and-down operations of front passenger door window and rear door windows. Key-off operation function Function that makes it possible to operate power window for approx. 45 seconds after ignition switch is turned to ACC or LOCK position, if either front door is not opened. Key-linked up-and-down function Function that causes window to go up while driver's door key is turned to lock side for more than 1.5 seconds and to go down while turned to unlock side for more than 1.5 seconds. Window stops as soon as the key is returned to original position. Transmitter-linked down function Function that causes window to go down while unlock switch on transmitter is pressed for more than 2.5 seconds. Window stops as soon as the switch is released. Diagnosis Function that allows the power window switch to make a diagnosis for failed section when power window switch detects a malfunction in power window system. Power window switch light comes on or blinks to inform driver. Fail-safe A fail-safe function to disable a part of power window functions if pulse sensor in power window motor has a malfunction: All door auto up-and-down function and remote control function are disabled. Manual operation is possible by each power window switch.

DESCRIPTION

This circuit supplies power to operate the multiplex network master switch.

Scheme 1

Scheme 2

1. CHECK WIRE HARNESS (MULTIPLEX NETWORK MASTER SWITCH - BATTERY AND BODY GROUND) Disconnect the P22 connector. Measure the voltage and resistance according to the value (s) in the table below. Standard voltage TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition P22-9 (CPUB) - Body ground Always 10 to 14 V P22-10 (BDR) - Body ground Always 10 to 14 V P22-20 (SIG) - Body ground Ignition switch ON 10 to 14 V Standard resistance TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition P22-2 (GND) - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit supplies power to operate the multiplex network switch.

Scheme 3

Scheme 4

1. CHECK WIRE HARNESS (MULTIPLEX NETWORK SWITCH) Disconnect the P19 connector. Measure the voltage and resistance according to the value (s) in the table below. Standard voltage TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition P19-12 (BDR) - Body ground Always 10 to 14 V Standard resistance TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition P19-7 (GND) - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit supplies power to operate the multiplex network switch.

Scheme 5

Scheme 6

1. CHECK WIRE HARNESS (MULTIPLEX NETWORK SWITCH - BATTERY AND BODY GROUND) Disconnect the P20 connector. Measure the voltage and resistance according to the value (s) in the table below. Standard voltage TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition P20-12 (BDR) - Body ground Always 10 to 14 V Standard resistance TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition P20-7 (GND) - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit supplies power to operate the multiplex network switch.

Scheme 7

Scheme 8

1. CHECK WIRE HARNESS (MULTIPLEX NETWORK SWITCH - BATTERY AND BODY GROUND) Disconnect the P21 connector. Measure the voltage and resistance according to the value (s) in the table below. Standard voltage TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition P21-12 (BDR) - Body ground Always 10 to 14 V Standard resistance TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition P21-7 (GND) - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit transmits signals from the multiplex network master switch to power window regulator motor.

Scheme 9

Scheme 10

Scheme 11

1. INSPECT POWER WINDOW REGULATOR MOTOR Remove the power window motor. Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery to any terminals except terminals 1 and 2. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (D) Battery negative (-) --> Terminal 2 (U) Motor gear rotates clockwise Battery positive (+) --> Terminal 2 (U) Battery negative (-) --> Terminal 1 (D) Motor gear rotates counterclockwise NG: REPLACE POWER WINDOW REGULATOR MOTOR OK: Go to next step
2. CHECK WIRE HARNESS (WINDOW REGULATOR MOTOR - MULTIPLEX NETWORK MASTER SWITCH) Disconnect the P22 and P23 connectors. Measure the resistance according to the value (s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition P22-1 (UP) - P23-2 (U) Always Below 1 ohms P22-11 (DN) - P23-1 (D) Always Below 1 ohms P22-1 (UP) - Body ground Always 10 kohms or higher P22-11 (DN) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit transmits signals from the multiplex network switch to power window regulator motor.

Scheme 12

Scheme 13

Scheme 14

1. INSPECT POWER WINDOW REGULATOR MOTOR Remove the power window motor. Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery to any terminals except terminals 1 and 2. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (D) Battery negative (-) --> Terminal 2 (U) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 2 (U) Battery negative (-) --> Terminal 1 (D) Motor gear rotates clockwise NG: REPLACE POWER WINDOW REGULATOR MOTOR OK: Go to next step
2. CHECK WIRE HARNESS (WINDOW REGULATOR MOTOR - MULTIPLEX NETWORK SWITCH) Disconnect the P19 and P24 connectors. Measure the resistance according to the value (s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition P19-1 (DN) - P24-1 (D) Always Below 1 ohms P19-6 (UP) - P24-2 (U) Always Below 1 ohms P19-1 (DN) - Body ground Always 10 kohms or higher P19-6 (UP) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit transmits signals from the multiplex network switch to power window regulator motor.

Scheme 15

Scheme 16

1. INSPECT POWER WINDOW REGULATOR MOTOR Remove the power window motor. Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery to any terminals except terminals 1 and 2. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 2 (D) Battery negative (-) --> Terminal 1 (U) Motor gear rotates clockwise Battery positive (+) --> Terminal 1 (U) Battery negative (-) --> Terminal 2 (D) Motor gear rotates counterclockwise NG: REPLACE POWER WINDOW REGULATOR MOTOR OK: Go to next step
2. CHECK WIRE HARNESS (WINDOW REGULATOR MOTOR - MULTIPLEX NETWORK SWITCH) Disconnect the P20 and P25 connectors. Measure the resistance according to the value (s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition P20-1 (DN) - P25-2 (D) Always Below 1 ohms P20-6 (UP) - P25-1 (U) Always Below 1 ohms P20-1 (DN) - Body ground Always 10 kohms or higher P20-6 (UP) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit transmits signals from the multiplex network switch to power window regulator motor.

Scheme 17

Scheme 18

1. INSPECT POWER WINDOW REGULATOR MOTOR Remove the power window motor. Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery to any terminals except terminals 1 and 2. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 2 (D) Battery negative (-) --> Terminal 1 (U) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 1 (D) Battery negative (-) --> Terminal 2 (U) Motor gear rotates clockwise NG: REPLACE POWER WINDOW REGULATOR MOTOR OK: Go to next step
2. CHECK WIRE HARNESS (WINDOW REGULATOR MOTOR - MULTIPLEX NETWORK SWITCH) Disconnect the P21 and P26 connectors. Measure the resistance according to the value (s) in the table below. Standard resistance TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition P21-1 (DN) - P26-2 (D) Always Below 1 ohms P21-6 (UP) - P26-1 (U) Always Below 1 ohms P21-1 (DN) - Body ground Always 10 kohms or higher P21-6 (UP) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

Scheme 19

1. INSPECT POWER WINDOW REGULATOR MOTOR (FRONT RH) Remove the power window regulator motor. Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery to any terminals except terminals 1 and 2. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (D) Battery negative (-) --> Terminal 2 (U) Motor gear rotates clockwise Battery positive (+) --> Terminal 2 (U) Battery negative (-) --> Terminal 1 (D) Motor gear rotates counterclockwise
2. INSPECT POWER WINDOW REGULATOR MOTOR (FRONT LH) Remove the power window regulator motor. Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery to any terminals except terminals 1 and 2. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (D) Battery negative (-) --> Terminal 2 (U) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 2 (U) Battery negative (-) --> Terminal 1 (D) Motor gear rotates clockwise
3. INSPECT POWER WINDOW REGULATOR MOTOR (REAR RH) Remove the power window regulator motor. Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery to any terminals except terminals 1 and 2. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 2 (U) Battery negative (-) --> Terminal 1 (D) Motor gear rotates clockwise Battery positive (+) --> Terminal 1 (D) Battery negative (-) --> Terminal 2 (U) Motor gear rotates counterclockwise
4. INSPECT POWER WINDOW REGULATOR MOTOR (REAR LH) Remove the power window regulator motor. Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery to any terminals except terminals 1 and 2. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 2 (U) Battery negative (-) --> Terminal 1 (D) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 1 (D) Battery negative (-) --> Terminal 2 (U) Motor gear rotates clockwise

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation (See «AIRBAG SYSTEM»(/lexus/rx/ii-2006-2009/remont/airbag/#supplemental-restraint-system) ).
2. REMOVE FRONT WIPER ARM LH (See «REMOVAL» )
3. REMOVE FRONT WIPER ARM RH (See «REMOVAL» )
4. REMOVE FRONT FENDER TO COWL SIDE SEAL LH
5. REMOVE FRONT FENDER TO COWL SIDE SEAL RH
6. REMOVE COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY (See «REMOVAL» )
7. REMOVE INNER REAR VIEW MIRROR STAY HOLDER COVER (See «REMOVAL» )
8. REMOVE INNER REAR VIEW MIRROR ASSEMBLY (See «REMOVAL» )
9. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP LH
10. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP RH
11. REMOVE FRONT PILLAR GARNISH LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
12. REMOVE FRONT PILLAR GARNISH RH
13. REMOVE MAP LIGHT ASSEMBLY (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
14. REMOVE VISOR ASSEMBLY LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
15. REMOVE VISOR ASSEMBLY RH
16. REMOVE VISOR HOLDER (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
17. REMOVE ASSIST GRIP SUB-ASSEMBLY (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
18. REMOVE ROOF HEADLINING ASSEMBLY (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
19. REMOVE RAIN SENSOR (w/ Rain Sensor) (See «REMOVAL» )
20. REMOVE WINDSHIELD MOLDING OUTSIDE Using a knife, cut off the molding, as shown in the illustration. NOTE: Do not damage the vehicle body with the knife. Remove the remaining molding from the vehicle body. HINT: When removing, make a partial cut, then pull and remove it by hand. Disconnect the connector as shown in the illustration (w/ Deicer).
21. REMOVE WINDSHIELD GLASS Pass a piano wire between the vehicle body and glass from the interior. Tie both wire ends to wooden blocks or similar objects. NOTE: When separating the glass, take care not to damage the paint and the interior and exterior ornaments. To prevent the safety pad from being scratched when removing the glass, place a plastic sheet between the piano wire and safety pad. HINT: Apply protective tape to the outer surface to prevent the surface from being scratched. Cut off the adhesive by pulling the piano wire around the glass. Disengage the stoppers. Using a suction cup, remove the glass. NOTE: Leave as much adhesive on the vehicle body as possible when removing the glass.
22. REMOVE WINDSHIELD GLASS RETAINER Remove the windshield glass retainer.
23. REMOVE WINDSHIELD GLASS NO.2 STOPPER Using a scraper, remove the windshield glass No.2 stoppers.
24. REMOVE WINDSHIELD GLASS NO.1 STOPPER Remove the windshield glass No.1 stoppers.
25. CLEAN WINDSHIELD GLASS Using a scraper, remove the damaged stoppers, dam and adhesive sticking to the glass. Clean the outer circumference of the glass with white gasoline. NOTE: Do not touch the glass surface after cleaning it. Be careful not to damage the glass. Even if using a new glass, clean the glass with white gasoline.

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. INSTALL WINDSHIELD GLASS NO.1 STOPPER Install 2 new stoppers to the vehicle body, as shown in the illustration.
2. INSTALL WINDSHIELD GLASS NO.2 STOPPER Coat the installation part of the stopper with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer G for later use. Do not apply too much primer. Install 2 new windshield glass stoppers onto the glass, as shown in the illustration. Standard dimension DIMENSION CHART Area Dimension A 40.0 mm (1.575 in.) B 9.0 mm (0.354 in.) C 15.0 mm (0.591 in.)
3. INSTALL WINDSHIELD GLASS RETAINER Install a new windshield glass retainer to the glass, as shown in the illustration.
4. INSTALL WINDOW GLASS ADHESIVE DAM Coat the installation part of the dam with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Do not apply too much primer. Install a new dam, applying double-sided tape all the way around the glass except where the dam is installed, as shown in the illustration. Standard dimension DIMENSION CHART Area Dimension a 9.5 mm (0.374 in.) b 50.0 mm (1.969 in.) c 8.0 mm (0.315 in.)
5. INSTALL WINDOW GLASS NO.2 ADHESIVE DAM
6. INSTALL WINDSHIELD GLASS Clean and shape the contact surface of the vehicle body. Using a knife, cut away any rough adhesive on the contact surface of the vehicle body to ensure the appropriate surface shape. NOTE: Be careful not to damage the vehicle body. HINT: Leave as much adhesive on the vehicle body as possible. Clean the contact surface of the vehicle body with a piece of shop rag saturated with cleaner. HINT: Even if all the adhesive has been removed, clean the vehicle body. Position the glass. Using a suction cup, place the glass in the correct position. Check that the whole contact surface of the glass rim is perfectly even. Place reference marks between the glass and vehicle body. NOTE: Check that the stoppers are attached to the vehicle body correctly. HINT: When reusing the glass, check and correct the reference mark positions. Remove the glass. Using a brush, coat the exposed part of the vehicle body on the vehicle side with Primer M. NOTE: Allow the primer coating to dry for 3 minutes or more. Do not coat the adhesive with Primer M. Do not keep any of the opened Primer M for later use. Using a brush or sponge, coat the edge of the glass and the contact surface with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer G for later use. HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean shop rag before it dries. Apply adhesive (Adhesive: Part No. 08850-00801 or equivalent). Cut off the tip of the cartridge nozzle, as shown in the illustration. HINT: After cutting off the tip, use all adhesive within the time described in the table below. Tackfree time TEMPERATURE CHART Temperature Tackfree Time 35°C (95°F) 15 minutes 20°C (68°F) 1 hour 40 minutes 5°C (41°F) 8 hours Load the sealer gun with the cartridge. Coat the glass with adhesive, as shown in the illustration. Standard dimension DIMENSION CHART Area Dimension a 8.0 mm (0.315 in.) b 12.0 mm (0.472 in.) Install the glass. Using a suction cup, position the glass so that the reference marks are aligned, and press it in gently along the rim. NOTE: Allow the primer coating to dry for 3 minutes or more. Check that the stoppers are attached to the vehicle body correctly. Check the clearance between the vehicle body and glass. Lightly press the front surface of the glass to ensure a close fit. Using a scraper, remove any excess or protruding adhesive. NOTE: Take care not to drive the vehicle for the time described in the table below. Minimum time TEMPERATURE CHART Temperature Minimum time prior to driving vehicle 35°C (95°F) 1 hour 30 minutes 20°C (68°F) 5 hours 5°C (41°F) 24 hours HINT: Apply adhesive onto the glass rim.
7. INSTALL WINDSHIELD MOLDING OUTSIDE Using a brush or sponge, coat the edge of the glass and the contact surface with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Do not coat the adhesive with Primer G. Do not keep any of the opened Primer G for later use. Install the windshield molding.
8. CHECK FOR LEAKS AND REPAIR Conduct a leak test after the adhesive has completely hardened. Seal any leaks with auto glass sealer.
9. INSTALL RAIN SENSOR (w/ Rain Sensor) (See «INSTALLATION» )
10. INSTALL ROOF HEADLINING ASSEMBLY (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
11. INSTALL ASSIST GRIP SUB-ASSEMBLY (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
12. INSTALL VISOR HOLDER
13. INSTALL VISOR ASSEMBLY LH (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
14. INSTALL VISOR ASSEMBLY RH
15. INSTALL MAP LIGHT ASSEMBLY (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
16. INSTALL FRONT PILLAR GARNISH LH (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
17. INSTALL FRONT PILLAR GARNISH RH
18. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH
19. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP RH
20. INSTALL INNER REAR VIEW MIRROR STAY HOLDER COVER (See «INSTALLATION» )
21. INSTALL INNER REAR VIEW MIRROR ASSEMBLY (See «INSTALLATION» )
22. INSTALL COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY
23. INSTALL FRONT FENDER TO COWL SIDE SEAL LH
24. INSTALL FRONT FENDER TO COWL SIDE SEAL RH
25. INSTALL FRONT WIPER ARM LH (See «INSTALLATION» )
26. INSTALL FRONT WIPER ARM RH (See «INSTALLATION» )
27. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
28. PERFORM INITIALIZATION NOTE: Some systems need initialization when disconnecting the cable from the negative (-) battery terminal (See «INITIALIZATION» ).

Scheme 38

Scheme 39

Scheme 40

Scheme 41

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation (See «AIRBAG SYSTEM»(/lexus/rx/ii-2006-2009/remont/airbag/#supplemental-restraint-system) ).
2. REMOVE REAR DOOR SCUFF PLATE LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
3. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH
4. REMOVE DECK BOARD SUB-ASSEMBLY (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
5. REMOVE TONNEAU COVER ASSEMBLY
6. REMOVE DECK FLOOR BOX FRONT (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
7. REMOVE DECK FLOOR BOX REAR (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
8. REMOVE NO.2 DECK BOARD SUB-ASSEMBLY (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
9. REMOVE NO.3 DECK BOARD SUB-ASSEMBLY (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
10. REMOVE BACK DOOR WEATHERSTRIP
11. REMOVE JACK CARRIER ASSEMBLY
12. REMOVE DECK SIDE TRIM BOX RH
13. REMOVE DECK SIDE TRIM BOX LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
14. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
15. REMOVE REAR FLOOR FINISH SIDE PLATE LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
16. REMOVE DECK SIDE TRIM COVER LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
17. SEPARATE REAR NO.1 SEAT BELT ASSEMBLY OUTER LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
18. REMOVE REAR SEAT SIDE COVER LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
19. REMOVE ROPE HOOK (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
20. REMOVE DECK TRIM SIDE PANEL ASSEMBLY LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
21. REMOVE NO.2 ROOM LIGHT ASSEMBLY (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
22. REMOVE ROOF SIDE GARNISH ASSEMBLY INNER LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
23. REMOVE QUARTER WINDOW ASSEMBLY LH Pass a piano wire between the vehicle body and glass from the interior. Tie both wire ends to wooden blocks or similar objects. NOTE: When separating the glass, take care not to damage the paint and the interior and exterior ornaments. HINT: Apply protective tape to the outer surface to prevent the surface from being scratched. Cut off the adhesive by pulling the piano wire around the glass. Using a suction cup, remove the glass. NOTE: Leave as much adhesive on the vehicle body as possible when removing the glass.
24. CLEAN QUARTER WINDOW ASSEMBLY LH Clean the outer circumference of the glass with white gasoline. NOTE: Do not touch the glass surface after cleaning it. Be careful not to damage the glass.

Scheme 42

Scheme 43

Scheme 44

1. INSTALL QUARTER WINDOW ASSEMBLY LH Clean and shape the contact surface of the vehicle body. Using a knife, cut away any rough adhesive on the contact surface of the vehicle body to ensure the appropriate surface shape. HINT: Leave as much adhesive on the vehicle body as possible. Clean the contact surface of the vehicle body with a piece of shop rag saturated with cleaner. HINT: Even if all the adhesive has been removed, clean the vehicle body. Using a brush, coat the exposed part of the vehicle body with Primer M. NOTE: Allow the primer coating to dry for 3 minutes or more. Do not coat the adhesive with Primer M. Do not keep any of the opened Primer M for later use. Using a brush or sponge, coat the edge of the glass and the contact surface with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer G for later use. Standard dimension DIMENSION CHART Area Dimension a 9.0 mm (0.354 in.) b S2.0 mm (2.047 in.) c 17.0 mm (0.669 in.) d 12.0 mm (0.472 in.) e 6.0 mm (0.236 in.) HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean shop rag before it dries. Apply adhesive (Adhesive. Part No. 08850-00801 or equivalent). Cut off the tip of the cartridge nozzle, as shown in the illustration. HINT: After cutting off the tip, use all adhesive within the time described in the table below. Tackfree time TEMPERATURE CHART Temperature Tackfree Time 35°C (95°F) 15 minutes 20°C (68°F) 1 hour 40 minutes 5°C (41°F) 8 hours Load the sealer gun with the cartridge. Coat the glass with adhesive, as shown in the illustration. Standard dimension DIMENSION CHART Area Dimension a 12.0 mm (0.472 in.) b 8.0 mm (0.315 in.) c 6.0 mm (0.236 in.) d 550 mm (21.654 in.) e 20 mm (0.787 in.) Install the glass to the vehicle body. Hold the glass in place securely with tape or equivalent to the vehicle body until the adhesive has hardened. NOTE: Allow the primer coating to dry for 3 minutes or more. Check that the clips are attached to the vehicle body correctly. Check the clearance between the vehicle body and glass. Lightly press the front surface of the glass to ensure a close fit. Using a scraper, remove any excess or protruding adhesive. NOTE: Take care not to drive the vehicle for the time described in the table below. Minimum time TEMPERATURE CHART Temperature Minimum time prior to driving vehicle 35°C (95°F) 1 hour 30 minutes 20°C (68°F) 5 hours 5°C (41°F) 24 hours
2. CHECK FOR LEAKS AND REPAIR Conduct a leak test after the adhesive has completely hardened. Seal any leaks with auto glass sealer.
3. INSTALL ROOF SIDE GARNISH ASSEMBLY INNER LH (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
4. INSTALL ROOM LIGHT ASSEMBLY NO.2 (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
5. INSTALL DECK TRIM SIDE PANEL ASSEMBLY LH (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
6. INSTALL ROPE HOOK (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
7. INSTALL REAR SEAT SIDE COVER LH (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
8. INSTALL REAR NO.1 SEAT BELT ASSEMBLY OUTER LH (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
9. INSTALL DECK SIDE TRIM COVER LH (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
10. INSTALL REAR FLOOR FINISH SIDE PLATE LH (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
11. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
12. INSTALL DECK SIDE TRIM BOX LH (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
13. INSTALL DECK SIDE TRIM BOX RH
14. INSTALL JACK CARRIER ASSY
15. INSTALL BACK DOOR WEATHERSTRIP
16. INSTALL NO.2 DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
17. INSTALL NO.3 DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
18. INSTALL DECK FLOOR BOX REAR (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
19. INSTALL DECK FLOOR BOX FRONT (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
20. INSTALL TONNEAU COVER ASSEMBLY
21. INSTALL DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
22. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP LH
23. INSTALL REAR DOOR SCUFF PLATE LH (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
24. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
25. PERFORM INITIALIZATION NOTE: Some systems need initialization when disconnecting the cable from the negative (-) battery terminal (See «INITIALIZATION» ).

Scheme 45

Scheme 46

Scheme 47

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation (See «AIRBAG SYSTEM»(/lexus/rx/ii-2006-2009/remont/airbag/#supplemental-restraint-system) ).
2. REMOVE REAR WIPER ARM AND BLADE ASSEMBLY (See «REMOVAL» )
3. REMOVE BACK DOOR TRIM BOARD (w/ Power Back Door) (See «DISASSEMBLY» )
4. REMOVE BACK WINDOW PANEL TRIM UPPER (w/ Power Back Door) (See «DISASSEMBLY» )
5. REMOVE BACK WINDOW PANEL TRIM UPPER (w/o Power Back Door) (See «DISASSEMBLY» )
6. REMOVE BACK DOOR TRIM PANEL ASSEMBLY UPPER (See «DISASSEMBLY» )
7. REMOVE BACK DOOR TRIM PANEL ASSEMBLY (See «DISASSEMBLY» )
8. REMOVE BACK DOOR TRIM COVER RH (See «DISASSEMBLY» )
9. REMOVE BACK DOOR TRIM COVER LH (See «DISASSEMBLY» )
10. REMOVE REAR SPOILER SUB-ASSEMBLY (See «REMOVAL» )
11. REMOVE REAR WIPER MOTOR ASSEMBLY (See «REMOVAL» )
12. REMOVE REAR COMBINATION LIGHT ASSEMBLY LH (See «REMOVAL» )
13. REMOVE REAR COMBINATION LIGHT ASSEMBLY RH
14. REMOVE BACK DOOR GLASS Disconnect the connector. Pass a piano wire between the vehicle body and glass from the interior, as shown in the illustration. Tie both wire ends to wooden blocks or similar objects. NOTE: When separating the glass, take care not to damage the paint and interior and exterior ornaments. HINT: Apply protective tape to the outer surface to prevent the surface from being scratched. Cut off the adhesive by pulling the piano wire around the glass. NOTE: If the back door glass will be reused, be careful not to damage the clip attached to the glass when you cut off the adhesive. Using a suction cup, remove the glass. NOTE: Leave as much adhesive on the vehicle body as possible when removing the glass.
15. CLEAN BACK DOOR GLASS Using a scraper, remove the damaged stoppers, dam and adhesive sticking to the glass. Clean the outer circumference of the glass with white gasoline. NOTE: Do not touch the glass surface after cleaning it. Be careful not to damage the glass. Even if using a new glass, clean the glass with white gasoline.

Scheme 48

Scheme 49

Scheme 50

Scheme 51

1. INSTALL BACK DOOR GLASS Clean and shape the contact surface of the vehicle body. Using a knife, cut away any rough adhesive on the contact surface of the vehicle body to ensure the appropriate surface shape. HINT: Leave as much adhesive on the vehicle body as possible. Clean the contact surface of the vehicle body with a piece of shop rag saturated with cleaner. HINT: Even if all the adhesive has been removed, clean the vehicle body. Using a brush, coat the exposed part of the vehicle body with Primer M. NOTE: Allow the primer coating to dry for 3 minutes or more. Do not coat the adhesive with Primer M. Do not keep any of the opened Primer M for later use. Using a brush or sponge, coat the edge of the glass and the contact surface with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Do not keep any of the opened Primer G for later use. Standard dimension DIMENSION CHART Area Dimension a 8.0 mm (0.315 in.) b 9.2 mm (0.362 in.) c 9.2 mm (0.362 in.) d 8.0 mm (0.315 in.) e 16.0 mm (0.630 in.) HINT: If an area other than that specified is coated by accident, wipe off the primer with a clean shop rag before it dries. Apply adhesive (Adhesive: Part No. 08850-00801 or equivalent). Cut off the tip of the cartridge nozzle, as shown in the illustration. HINT: After cutting off the tip, use all adhesive within the time described in the table below. Load the sealer gun with the cartridge. Tackfree time TEMPERATURE CHART Temperature Tackfree Time 35°C (95°F) 15 minutes 20°C (68°F) 1 hour 40 minutes 5°C (41°F) 8 hours Coat the glass with adhesive, as shown in the illustration. Standard dimension DIMENSION CHART Area Dimension a 12.0 mm (0.472 in.) b 8.0 mm (0.315 in.) c 8.0 mm (0.315 in.) d 9.2 mm (0.362 in.) Install the glass to the vehicle body. Hold the back window glass in place securely with tape or equivalent to the vehicle body until the adhesive has hardened. NOTE: Allow the primer coating to dry for 3 minutes or more. Check that the clips are attached to the vehicle body correctly. Check the clearance between the vehicle body and glass. Lightly press the front surface of the glass to ensure a close fit. Using a scraper, remove any excess or protruding adhesive. NOTE: Take care not to drive the vehicle for the time described in the table below. Minimum time TEMPERATURE CHART Temperature Minimum time prior to driving vehicle 35°C (95°F) 1 hour 30 minutes 20°C (68°F) 5 hours 5°C (41°F) 24 hours
2. INSTALL BACK WINDOW MOLDING OUTSIDE Coat the installation part of the moldings with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Do not apply too much primer. Install a new moldings, applying double-sided tape all the way around the glass except where the moldings is installed, as shown in the illustration. Standard dimension DIMENSION CHART Area Dimension a 8.0 mm (0.315 in.) b 9.2 mm (0.362 in.) c 9.2 mm (0.362 in.) Connect the connector.
3. INSTALL BACK WINDOW MOLDING LOWER
4. CHECK FOR LEAKS AND REPAIR Conduct a leak test after the adhesive has completely hardened. Seal any leaks with auto glass sealer.
5. INSTALL REAR COMBINATION LIGHT ASSEMBLY LH (See «REASSEMBLY» )
6. INSTALL REAR COMBINATION LIGHT ASSEMBLY RH
7. INSTALL REAR WIPER MOTOR ASSEMBLY (See «INSTALLATION» )
8. INSTALL REAR SPOILER SUB-ASSEMBLY (See «INSTALLATION» )
9. INSTALL BACK DOOR TRIM COVER LH
10. INSTALL BACK DOOR TRIM COVER RH
11. INSTALL BACK DOOR TRIM PANEL ASSEMBLY
12. INSTALL BACK DOOR TRIM PANEL ASSEMBLY UPPER
13. INSTALL BACK WINDOW PANEL TRIM UPPER (w/o Power Back Door)
14. INSTALL BACK WINDOW PANEL TRIM UPPER (w/ Power Back Door)
15. INSTALL BACK DOOR TRIM BOARD (w/ Power Back Door)
16. INSTALL REAR WIPER ARM AND BLADE ASSEMBLY (See «INSTALLATION» )
17. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
18. PERFORM INITIALIZATION NOTE: Some systems need initialization when disconnecting the cable from the negative (-) battery terminal (See «INITIALIZATION» ).

1. GENERAL The defogger system's thin heater wires are attached to the inside of the rear window and defog the window surface quickly. The indicator light illuminates while the system is operating. The system automatically turns off after approximately 15 minutes. HINT: The rear window defogger is linked with the mirror defogger.
2. FUNCTION OF MAIN COMPONENT FUNCTION OF MAIN COMPONENT Component Outline RR-DEF Relay Receives rear defogger activation request signals from A/C amplifier assembly (A/C ECU) and supplies power to rear window defogger. Rear Window Defogger Receives power from DEFOG relay and heats defogger wire. w/ Deicer Deicer Relay Receives front deicer activation request signals from A/C amplifier assembly (A/C ECU) and supplies power to front window deicer. w/ Deicer Front Window Deicer Receives power from DEICER relay and heats deicer wire.
3. DESCRIPTION FUNCTION CHART Function Outline Defogs the rear window surface Receives rear defogger activation request signals from A/C amplifier assembly (A/C ECU) and supplies power to rear window defogger. Receives power from DEFOG relay and heats defogger wire. Defogs the front window surface Receives front deicer activation request signals from A/C amplifier assembly (A/C ECU) and supplies power to front window deicer. Receives power from DEICER relay and heats deicer wire.

1. The rear defogger & mirror heater switch on the multi-display inputs a request signal to the A/C amplifier (ECU). Then, the A/C amplifier turns ON the RR-DEF relay built into the power distributor in response to the input, thus switching ON the rear defogger. (The deicer and mirror heater also turn ON at the same time) HINT: The power distributor is built into the J/B No.2.
2. The RR-DEF relay is built into the J/B No.2. For inspection, use the terminals in the J/B No.2.
3. If RR-DEF relay is malfunctioning, replace the J/B No.2.

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

1. INSPECT COMMUNICATION LINE Use the intelligent tester to check for normal function of the multiplex communication system. (ECU unconnected, communication line malfunctioning) Without DTC B1214, B1215 or B 1262 outputs, proceed to A. (ECU unconnected, communication line malfunctioning) With DTC B1214, B1215 or B 1262 outputs, proceed to B. B:GO TO «MULTIPLEX COMMUNICATION SYSTEM» A: Go to next step
2. INSPECT FUSE (HEATER, RR-DEF) Remove the HEATER fuse from the instrument panel J/ B. Remove the RR-DEF fuse from the FL block. Check the resistance. Standard resistance: Below 1 ohms NG: REPLACE FUSE OK: Go to next step
3. PERFORM ACTIVE TEST Connect the intelligent tester (with CAN VIN) to the DLC3. Turn the ignition switch on. Perform the ACTIVE TEST according to the display on the tester. AIR CONDITIONER: ACTIVE TEST CHART Item Test Details Diagnostic Note DEFOGGER RLY-R Operate rear window defogger OFF/ON - NG: GO TO step 5 OK: Go to next step
4. CHECK AIR CONDITIONING SYSTEM OPERATE NG: GO TO «AIR CONDITIONING SYSTEM» OK: REPLACE AIR CONDITIONING AMPLIFIER ASSEMBLY
5. INSPECT JUNCTION BLOCK Check the voltage of the terminal of the J/B. Standard voltage TESTER CONNECTION SPECIFIED CONDITION Tester Connection Switch Position Specified Condition 2H-12 - Body Ground Ignition switch ON 10 to 14 V 2H-12 - Body Ground Ignition switch OFF Below 1 V 2B-8 - Body Ground Always 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR (POWER SOURCE CIRCUIT) OK: Go to next step
6. INSPECT JUNCTION BLOCK (MODE MONITOR TERMINAL) Check the voltage of the terminal to the following condition. Engine running. A/C switch is OFF. Rear defogger and deicer switch is ON. Result RESULT CHART Result Proceed to More than 5 V A Below 2 V B B: GO TO step 12 A: Go to next step
7. INSPECT JUNCTION BLOCK (RR-DEF RELAY) Remove the junction block No.2. Connect the battery positive (+) lead to terminal 2B-8 and battery negative (-) terminal lead to terminal 2H-12, 2B-7 and 2H-11. Check the voltage of the RR-DEF relay terminals. Standard voltage TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition 2B-7 - 2H-13 Always Below 1 V Connect another battery positive (+) lead to the terminal 2H-12. Check the voltage of the RR-DEF relay terminals. Standard voltage TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition 2B-7 - 2H-13 Ignition switch ON Below 1 V 2B-7 - 2H-13 Ignition switch OFF 10 to 14 V NG: REPLACE JUNCTION BLOCK OK: Go to next step
8. INSPECT AIR CONDITIONING AMPLIFIER ASSEMBLY Disconnect the A8 connector. Measure the voltage according to the value (s) in the table below. Standard voltage TESTER CONNECTION SPECIFIED CONDITION Tester connection Condition Specified condition A8-19 (DFG) - Body ground Ignition switch: ON 10 to 14 V A8-19 (DFG) - Body ground Ignition switch: OFF Below 1 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
9. INSPECT AIR CONDITIONING AMPLIFIER ASSEMBLY Connect the A8 connector. Connect the intelligent tester to the DLC3. Measure the voltage according to the value (s) in the table below. Standard voltage TESTER CONNECTION SPECIFIED CONDITION Tester connection Intelligent tester condition Specified condition A8-19 (DFG) - Body ground ACTIVE TEST: ON (*1) 10 to 14 V A8-19 (DFG) - Body ground ACTIVE TEST: OFF (*1) Below 1 V HINT: *1: Perform the ACTIVE TEST according to the display on the tester. AIR CONDITIONER: ACTIVE TEST CHART Item Test Details Diagnostic Note DEFOGGER RLY-R Operate rear window defogger OFF/ON - NG: REPLACE AIR CONDITIONING AMPLIFIER ASSEMBLY OK: Go to next step
10. INSPECT REAR WINDOW DEFOGGER WIRE NOTE: When cleaning the glass, wipe the glass along the wire using a soft and dry cloth. Take care not to damage the wires. Do not use detergents or glass cleaners that have abrasive ingredients. When measuring voltage, wrap a piece of tin foil around the tip of the negative tester probe and press the foil against the wire with your finger, as shown in the illustration. Turn the ignition switch on. Turn the defogger switch ON. Check the voltage at the center of each defogger wire, as shown in the illustration. Standard voltage VOLTAGE SPECIFICATION Voltage Criteria Approx. 5 V Wire is not broken Approx. 10 or 0 V Wire is broken HINT: If there is approximately 10 V, the wire may be broken between the center of the wire and the wire end on the battery side. If there is no voltage, the wire may be broken between the center of the wire and the end on the ground side. Place the voltmeter positive (+) lead against the defogger wire on the battery side. Place the voltmeter negative (-) lead with the foil strip against the wire on the ground side. Slide the positive (+) lead from the battery side to the ground side. The point where the voltage drops from approximately 10 V to 0 V is where the defogger wire is broken. HINT: If the defogger wire is not broken, the voltmeter indicates 0 V at the positive (+) end of the defogger wire but gradually increases to approximately 12 V as the meter probe moves to the other end. NG: REPAIR REAR WINDOW DEFOGGER WIRE OK: Go to next step
11. CHECK WIRE HARNESS (REAR WINDOW DEFOGGER - JUNCTION BLOCK NO.2) Disconnect the N4, N5 defogger and 2B J/B connectors. Check the resistance of the wire harness side connectors. Standard resistance TESTER CONNECTION SPECIFIED CONDITION Tester Connection Specified Condition N4-1 - 2B-7 Below 1 ohms N4-1 - Body ground 10 kohms or higher NS-1 - Body ground Below 1 ohms N5-1 - 2B-7 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE NOISE FILTER
12. CHECK WIRE HARNESS (REAR WINDOW DEFOGGER - JUNCTION BLOCK NO.2) Disconnect the N4, N5 defogger and 2B J/B connectors. Check the resistance of the wire harness side connectors. Standard resistance TESTER CONNECTION SPECIFIED CONDITION Tester Connection Specified Condition N4-1 - 2B-7 Below 1 ohms N4-1 - Body ground 10 kohms or higher N5-1 - Body ground Below 1 ohms N5-1 - 2B-7 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
13. INSPECT JUNCTION BLOCK (RR-DEF RELAY) Remove the junction block No.2. Connect the battery positive (+) lead to terminal 2B-8 and battery negative (-) terminal lead to terminal 2H-12, 2B-7 and 2H-11. Check the voltage of the RR-DEF relay terminals. Standard voltage TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition 2B-7 - 2H-12 Always Below 1 V Connect another battery positive (+) lead to the terminal 2H-12. Check the voltage of the RR-DEF relay terminals. Standard voltage TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition 2B-7 - 2H-12 Ignition switch ON 10 to 14 V 2B-7 - 2H-12 Ignition switch OFF Below 1 V NG: REPLACE JUNCTION BLOCK OK: REPLACE NOISE FILTER

Scheme 62

Scheme 63

Scheme 64

1. INSPECT BACK WINDOW (DEFOGGER WIRE) NOTE: When cleaning the glass, wipe the glass along the wire using a soft and dry cloth. Take care not to damage the wires. Do not use detergents or glass cleaners that have abrasive ingredients. When measuring voltage, wrap a piece of tin foil around the tip of the negative rester probe and press the foil against the wire with your finger, as shown in the illustration. Turn the ignition switch on. Turn the defogger switch ON. Check the voltage at the center of each defogger wire, as shown in the illustration. Standard voltage VOLTAGE SPECIFICATION Voltage Criteria Approx. 5 V Wire is not broken Approx. 10 or 0V Wire is broken HINT: If there is approximately 10V, the wire may be faulty between the center of the wire and the wire and on the battery side. If there is no voltage, the wire may be faulty between the center of the wire and the wire end on the ground side. Place the voltmeter's positive (+) lead against the defogger wire on the battery side. Place the voltmeter's negative (-) lead with the foil strip against the wire on the ground side. Slide the positive (+) lead from the battery side to the ground side. The point where the voltage drops from approximately 10 V to 0 V is the place where the defogger wire is broken. HINT: If the defogger wire is not broken, the voltmeter should indicate 0 V at the positive (+) end of the defogger wire but gradually increases to approximately 12 V as the meter probe moves to the other end.
2. INSPECT FRONT WINDOW (DEICER WIRE) Check the resistance of the deicer wire. Standard resistance TESTER CONNECTION SPECIFIED CONDITION Tester Connection Condition Specified Condition 1-2 Always Below 1 ohms 3-2 Always Below 1 ohms HINT: If the result is not as specified, replace the front window.

Scheme 65

Scheme 66

1. IF NECESSARY, REPAIR THE DEFOGGER WIRE Clean the broken wire tips with grease, wax and silicone remover. Place the masking tape along both sides of the wire. Thoroughly mix the repair agent (Dupont paste No. 4817 or equivalent). Using a fine tip brush, apply a small amount of the agent to the wire. After a few minutes, remove the masking tape. NOTE: Do not repair the defogger wire again for at least 24 hours.

See also:
• AIRBAG SYSTEM
• REMOVAL
