PRECAUTION

Note. When disconnecting the negative (-) battery cable, initialize the following systems after the cable is reconnected.

System NameSee Procedure
Lighting SystemINITIALIZATION
Power Window Control System
Power Door Lock Control System
Power Back Door System
Back Door Closer System
Electrical Back Door Outside Handle System
SFI System

SYSTEM REFERENCE

Scheme 79

Scheme 79: PARTS LOCATION

Scheme 80

Scheme 80

Scheme 81

Scheme 81: SYSTEM DIAGRAM

Scheme 82

Scheme 82

CUSTOMIZE PARAMETERS

HINT

The following items can be customized.

Note. After confirming whether the items requested by the customer are applicable or not for customization, perform customize operations. Be sure to record the current settings before customizing. When troubleshooting, make sure that the item in question is not set to "OFF" as a result of customization. (Example: For the symptom "the wireless function does not operate", first check that the wireless function is not set to "OFF", then perform troubleshooting).

POWER WINDOW

DISPLAY (ITEM)DEFAULT CONTENTSCONTENTSSETTING
UP/DOOR KEY (Door key linked P/W UP)ONFunction that enables all power windows to move up manually, via manual operation, when driver side door key cylinder is held in lock position for 1.5 seconds when ignition switch is off.ON/OFF
DOWN/DOOR KEY (Door key linked P/W DOWN)ONFunction that enables all power windows to move down manually, via manual operation, when driver side door key cylinder is held in unlock position for 1.5 seconds when ignition switch is off.ON/OFF
DOWN/WIRELESS (P/W DOWN w/ transmitter)ONFunction that enables all power windows to move down manually, via manual operation, when unlock switch on transmitter is held for 1.5 seconds when ignition switch is off.ON/OFF
UP/WIRELESS (P/W UP w/ transmitter)ONFunction that enables all power windows to move up manually, via manual operation, when lock switch on transmitter is held for 1.5 seconds when ignition switch is off.ON/OFF

CUSTOMIZE PARAMETERS

INITIALIZATION

  1. RESET (INITIALIZE) POWER WINDOW REGULATOR MOTOR NOTE: Resetting the power window motor (initializing the pulse sensor) is necessary when the battery terminal is disconnected; when the power window regulator master switch, power window regulator switch, wire harness, power window regulator and power window motor are replaced or removed/ installed; or when the PWR fuse, RR DOOR LH fuse, RR DOOR RH and ECU-B fuse are replaced. AUTO operation function, jam protection function and remote operation function via the power window regulator master switch do not operate without resetting. Be sure to reset the power window regulator motors using the power window switch on each door because the motors cannot be reset by remote operation using the power window master switch. In order to prevent a large amount of current from flowing in the wires, do not simultaneously reset 2 or more power window regulator motors. If the power window switch has been continuously operated for a long time, the power window regulator motor will stop so that no additional load will be applied to the motor. Continuing to operate the switch even after the motor has stopped will cause the switch to blink while restricting the AUTO UP/DOWN function and the remote UP/DOWN function. If this happens, reset the motor again after several minutes have passed. Whenever disconnecting the battery terminal, reset all the other systems besides the power window control system. Turn the ignition switch ON. Halfway open the power window by pressing the power window switch. Fully pull up the switch until the power window is fully closed and continue to hold the switch for approx. 1 second after the power window is fully closed. Check that the AUTO UP/DOWN function operates normally. If the AUTO UP/DOWN function operates normally, reset operations have been completed at this time. If not normal, follow steps below. Disconnect the negative battery terminal for 10 seconds. Connect the battery terminal. Turn the ignition switch ON. Halfway open the power window by pressing the power window switch. If the AUTO UP/DOWN function operates normally, reset operations have been completed at this time. If not normal, follow steps below. Turn the ignition switch ON. Halfway open the power window by pressing the power window switch. Fully pull up the switch until the power window is fully closed and continue to hold the switch for approx. 12 seconds after the power window is fully closed. Check that the AUTO UP/DOWN function operates normally.

FAIL-SAFE CHART

  1. CHECK POWER WINDOW FAIL-SAFE FUNCTION HINT: If there is a malfunction in the power window system, some of the power window functions will be disabled. Driver side power window FAIL-SAFE CHART Malfunctioning Part Disabled Function Operative Function Pulse sensor circuit in power window motor AUTO UP/DOWN function Power window operation function after ignition off Manual UP (fully pulled UP position) Manual DOWN Remote (AUTO and manual) Remote function after ignition OFF (AUTO and manual) MANUAL UP/DOWN function via driver side door lock key cylinder MANUAL DOWN function via transmitter CPU in power window master switch AUTO UP/DOWN function Remote function (AUTO and manual) MANUAL UP/DOWN function via driver side door lock key cylinder MANUAL DOWN function via transmitter Manual UP (fully pulled UP position) Manual DOWN Power windows except driver side power window FAIL-SAFE CHART Malfunctioning Part Disabled Function Operative Function Pulse sensor circuit in power window motor CPU in power window master switch Communication between master switch and each power window switch AUTO UP/DOWN function Power window operation function after ignition OFF MANUAL UP/DOWN function via driver side door lock key cylinder MANUAL DOWN function via transmitter Manual UP (fully pulled UP position) Manual DOWN
  1. INITIALIZATION NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected. SYSTEM REFERENCE System Name See Procedure Lighting System «INITIALIZATION»(ref-282976-S16822617822008041400000) Power Window Control System Power Door Lock Control System Power Back Door System Back Door Closer System Electrical Back Door Outside Handle System SFI System

Scheme 83

Scheme 83: PARTS LOCATION

Scheme 84

Scheme 84

Scheme 85

Scheme 85: SYSTEM DIAGRAM
