Lighting: Adjustments Lexus RX II рестайлинг

ADJUSTMENT

HINT

It is possible that a bulb is incorrectly installed, affecting headlight aim. Bulb installation should be considered prior to performing the adjustment procedure.

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

1. VEHICLE PREPARATION FOR HEADLIGHT AIMING ADJUSTMENT Prepare the vehicle according to the following conditions: Ensure that there is no damage or deformation to the body around the headlights. Fill the fuel tank. Make sure that the oil is filled to the specified level. Make sure that the engine coolant is filled to the specified level. Inflate the tires to the appropriate pressure. Unload the trunk and vehicle, ensuring that the spare tire, tools, and jack are in their original positions. Sit a person of average weight (68 kg, 150 lb) in the driver's seat. Vehicles with air suspension should set the vehicle height to the lowest setting prior to adjusting the headlight aim.
2. PREPARATION FOR HEADLIGHT AIMING (Using a tester) Adjust the headlight aim in accordance with the headlight aim test machine instructions.
3. PREPARATION FOR HEADLIGHT AIMING (Using a screen) Prepare the vehicle according to the following conditions: Place the vehicle in a location that is dark enough to clearly observe the cutoff line. The cutoff line is a distinct line, below which light from the headlights can be observed and above which it cannot. Place the vehicle at a 90° angle to the wall. Create a 7.62 m (25 ft.) distance between the vehicle (headlight bulb center) and the wall. Make sure that the vehicle is on a level surface. Bounce the vehicle up and down to settle the suspension. NOTE: A distance of 7.62 m (25 ft.) between the vehicle (headlight bulb center) and the wall is necessary for proper aim adjustment. If sufficient space is not available, secure a distance of exactly 3 m (9.84 ft.) to allow for checking and adjustment of headlight aim. (The size of the target zone will change with the distance, so follow the instructions in the illustration.) Prepare a piece of thick white paper (approximately 2 m (6.6 ft.) (height) x 4 m (13.1 ft.) (width)) to use as a screen. Draw a vertical line down the center of the screen (V line). Set the screen as shown in the illustration. HINT: Stand the screen perpendicular to the ground. Align the V line on the screen with the center of the vehicle. Draw base lines (H, V LH, and V RH lines) on the screen as shown in the illustration. HINT: The base lines differ for "low-beam inspection" and "high-beam inspection." Mark the headlight bulb center marks on the screen. If the center mark cannot be observed on the headlight, use the center of the headlight bulb or the manufacturer's name marked on the headlight as the center mark. H Line (Headlight height): Draw a horizontal line across the screen so that it passes through the center marks. The H line should be at the same height as the headlight bulb center marks of the low-beam headlights. V LH Line, V RH Line (Center mark position of left-hand (LH) and right-hand (RH) headlights): Draw two vertical lines so that they intersect the H line at each center mark (aligned with the center of the low-beam headlight bulbs).
4. HEADLIGHT AIMING INSPECTION Cover the headlight or disconnect the connector of the headlight on the opposite side to prevent light from the headlight that is not being inspected from affecting the headlight aiming inspection. NOTE: Do not keep the headlight covered for more than 3 minutes. The headlight lens is made of synthetic resin, which may melt or be damaged due to excessive heat. HINT: When checking the aim of the high-beam, cover the low-beam or disconnect the connector. Start the engine. Turn on the headlight and check if the cutoff line matches the preferred cutoff line in the following illustration. for Halogen Headlight HINT: Since the low-beam light and the high-beam light are a unit, if the aim on the low-beam is correct, the high-beam should also be correct. However, check both beams just to make sure. Alignment distance is 7.62 m (25 ft.): The cutoff line is 101 mm (4 in.) above and below the H line as well as left and right of the V line with low-beam (SAE J599). Alignment distance is 3 m (9.84 ft.): The cutoff line is 40 mm (1.6 in.) above and below the H line as well as left and right of the V line with low-beam (SAE J599). Alignment distance is 7.62 m (25 ft.): The cutoff line is 101 mm (4 in.) above and below the H line as well as left and right of the V line with high-beam (SAE J599). Alignment distance is 3 m (9.84 ft.): The cutoff line is 40 mm (1.6 in.) above and below the H line as well as left and right of the V line with high-beam (SAE J599). Alignment distance is 7.62 m (25 ft.): The low beam cutoff line should be the same height as the H line (preferred cutoff line target). Alignment distance is 3 m (9.84 ft.): The low beam cutoff line should be the same height as the H line (preferred cutoff line target). for HID Headlight HINT: Since the low-beam light and the high-beam light are a unit, if the aim on the low-beam is correct, the high-beam should also be correct. However, check both beams just to make sure. Alignment distance is 7.62 m (25 ft.): The cutoff line is 101 mm (4 in.) above and below the H line as well as left and right of the V line with low-beam (SAE J599). Alignment distance is 3 m (9.84 ft.): The cutoff line is 40 mm (1.6 in.) above and below the H line as well as left and right of the V line with low-beam (SAE J599). Alignment distance is 7.62 m (25 ft.): The cutoff line is 101 mm (4 in.) above and below the H line as well as left and right of the V line with high-beam (SAE J599). Alignment distance is 3 m (9.84 ft.): The cutoff line is 40 mm (1.6 in.) above and below the H line as well as left and right of the V line with high-beam (SAE J599). Alignment distance is 7.62 m (25 ft.): The cutoff line is 53 mm (2.1 in.) below the H line with low-beam preferred cutoff line target. Alignment distance is 3 m (9.84 ft.): The cutoff line is 21 mm (0.8 in.) below the H line with low-beam preferred cutoff line target.
5. HEADLIGHT AIMING ADJUSTMENT Adjust the aim vertically: Adjust the headlight aim into the specified range by turning the aiming screw with a screwdriver. NOTE: The final turn of the aiming screw should be made in the clockwise direction. If the screw is tightened excessively, loosen it and then retighten it, so that the final turn of the screw is in the clockwise direction. HINT: Since the low-beam light and the high-beam light are a unit, if the aim on the low-beam is correct, the high-beam should also be correct. However, check both beams just to make sure. If it is not possible to correctly adjust headlight aim, check bulb, headlight unit, and headlight unit reflector installation. The headlight aim moves up when turning the aiming screw clockwise, and moves down when turning the aiming screw counterclockwise.

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

1. INSTALL LIGHT REFLECTOR MOTOR (for HID Headlight with AFS) Install the light reflector motor with the 2 screws. Connect the connector.
2. INSTALL HEADLIGHT SWIVEL ECU SUB-ASSEMBLY (for HID Headlight with AFS) Install the headlight swivel ECU sub-assembly with the screw. Connect the connector.
3. INSTALL HEADLIGHT LEVELING MOTOR BASE PACKING (for HID Headlight) Install a new headlight leveling motor base packing. NOTE: After the headlight leveling motor base packing is removed, be sure to replace it with a new one. Failure to do this may cause water ingress.
4. INSTALL HEADLIGHT LEVELING MOTOR (for HID Headlight) Engage the tip of the headlight leveling motor with the reflector. Turn the headlight leveling motor to install it.
5. INSTALL HEADLIGHT GASKET (for HID Headlight) Install a new headlight gasket. NOTE: After the headlight gasket is removed, be sure to replace it with a new one. Failure to do this may cause water ingress.
6. INSTALL LIGHT CONTROL ECU SUB-ASSEMBLY (for HID Headlight without AFS) Install the headlight fitting. Connect the connector. Install the light control ECU sub-assembly to the No. 1 headlight cover with the 3 screws. Install the light control ECU sub-assembly and the No. 1 headlight cover with the 4 screws.
7. INSTALL LIGHT CONTROL ECU SUB-ASSEMBLY (for HID Headlight with AFS) Install the headlight fitting. Connect the connector. Install the light control ECU sub-assembly to the No. 1 headlight cover with the 3 screws. Install the light control ECU sub-assembly and the No. 1 headlight cover with the 4 screws. Install the headlight bracket with the 2 screws. Install the cover with the 2 screws.
8. INSTALL CLEARANCE LIGHT BULB Install the clearance light bulb to the clearance light socket and wire. Turn the clearance light bulb and clearance light socket in the direction indicated by the arrow and install them as a unit.
9. INSTALL FRONT SIDE MARKER LIGHT BULB Install the front side marker light bulb to the front side marker light socket and wire. Turn the front side marker light bulb and front side marker light socket and wire in the direction indicated by the arrow and install them as a unit.
10. INSTALL FRONT TURN SIGNAL LIGHT BULB Install the front turn signal light bulb to the front turn signal light socket. Turn the front turn signal light bulb and front turn signal light socket in the direction indicated by the arrow and install them as a unit.
11. INSTALL NO. 1 HEADLIGHT BULB (for Halogen Headlight) Install the No. 1 headlight bulb as shown in the illustration.
12. INSTALL NO. 1 HEADLIGHT BULB (for HID Headlight) Lock the set spring to install the No. 1 headlight bulb. Turn the socket of the light control ECU sub-assembly in the direction indicated by the arrow to connect the socket.
13. INSTALL HEADLIGHT SOCKET COVER Install the headlight socket cover to the headlight cord. Install the headlight socket cover as shown in the illustration.
14. INSTALL NO. 2 HEADLIGHT BULB Install the No. 2 headlight bulb as shown in the illustration.

Scheme 143

1. INSTALL FRONT NO. 2 BUMPER SIDE SUPPORT Engage the 2 claws and install the front No. 2 bumper side support.
2. INSTALL HEADLIGHT ASSEMBLY (for Halogen Headlight) Connect the connector and clamp. Install the headlight assembly as shown in the illustration. Install the 3 bolts.
3. INSTALL HEADLIGHT ASSEMBLY (for HID Headlight with AFS) Connect the connector and clamp. Install the headlight assembly as shown in the illustration. Install the 4 bolts.
4. INSTALL FRONT BUMPER ASSEMBLY
5. INSTALL FRONT BUMPER STAY CENTER
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL (for HID Headlight)
7. VEHICLE PREPARATION FOR HEADLIGHT AIM ADJUSTMENT (See «ADJUSTMENT»(ref-283014-S31195283042008041400000) )
8. PREPARATION FOR HEADLIGHT AIMING (Using a tester) (See «ADJUSTMENT»(ref-283014-S31195283042008041400000) )
9. PREPARATION FOR HEADLIGHT AIMING (Using a screen) (See «ADJUSTMENT»(ref-283014-S31195283042008041400000) )
10. HEADLIGHT AIMING INSPECTION (See «ADJUSTMENT»(ref-283014-S31195283042008041400000) )
11. HEADLIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-283014-S31195283042008041400000) )
12. VEHICLE PREPARATION FOR FOG LIGHT AIMING (See «ADJUSTMENT»(ref-283014-S31195283042008041400000) )
13. PREPARATION FOR FOG LIGHT AIMING (See «ADJUSTMENT»(ref-283014-S18808260372008041400000) )
14. FOG LIGHT AIMING INSPECTION (See «ADJUSTMENT»(ref-283014-S18808260372008041400000) )
15. FOG LIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-283014-S18808260372008041400000) )

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

1. INSTALL HEADLIGHT PROTECTOR RETAINER UPPER HINT: If the installation area of the headlight assembly is damaged, use the supply bracket for low-cost repair. Ensure that the headlight assembly is not damaged. Cut off the part shaded in the illustration and sand smooth with sandpaper. NOTE: After cutting off the part, place the headlight protector retainer upper against the bosses and gradually file away until installation is possible. Install the headlight protector retainer upper with the 2 screws.
2. INSTALL HEADLIGHT PLATE HINT: If the installation area of the headlight assembly is damaged, use the supply bracket for low-cost repair. Ensure that the headlight assembly is not damaged. Cut off the part shaded in the illustration and sand smooth with sandpaper. NOTE: After cutting off the part, place the headlight plate against the bosses and gradually file away until installation is possible. Install the headlight plate with the screw.
3. INSTALL HEADLIGHT PROTECTOR RETAINER LOWER HINT: If the installation area of the headlight assembly is damaged, use the supply bracket for low-cost repair. Ensure that the headlight assembly is not damaged. Cut off the part shaded in the illustration and sand smooth with sandpaper. NOTE: After cutting off the part, place the headlight protector retainer lower against the bosses and gradually file away until installation is possible. Install the headlight protector retainer lower with the screw.
4. INSTALL HEADLIGHT BRACKET LOWER HINT: If the installation area of the headlight assembly is damaged, use the supply bracket for low-cost repair. Ensure that the headlight assembly is not damaged. Cut off the part shaded in the illustration and sand smooth with sandpaper. NOTE: After cutting off the part, place the headlight bracket lower against the bosses and gradually file away until installation is possible. Install the headlight bracket lower with the 2 screws.

Scheme 152

Scheme 153

1. REMOVE FRONT BUMPER STAY CENTER (See «REMOVAL»(ref-283008-S27414458892008041400000) )
2. REMOVE FRONT BUMPER ASSEMBLY (See «REMOVAL»(ref-283008-S27414458892008041400000) )
3. REMOVE FOG LIGHT PROTECTOR (See «REMOVAL»(ref-283008-S27414458892008041400000) )
4. REMOVE FOG LIGHT ASSEMBLY Disengage the 2 claws and 2 pins and remove the fog light assembly.

Scheme 154

1. REMOVE FOG LIGHT BULB Remove the fog light bulb as shown in the illustration.

Scheme 155

Scheme 156

Scheme 157

Scheme 158

Scheme 159

1. VEHICLE PREPARATION FOR FOG LIGHT AIM Prepare the vehicle: Ensure there is no damage or deformation to the body around the fog lights. Fill the fuel tank. Make sure that the oil is filled to the specified level. Make sure that the coolant is filled to the specified level. Inflate the tires to the appropriate pressure. Place the spare tire, tools, and jack in their original positions. Unload the trunk. Sit a person of average weight (68 kg, 150 lb) in the driver's seat.
2. PREPARATION FOR FOG LIGHT AIMING Prepare the vehicle according to the following conditions: Place the vehicle in a location that is dark enough to clearly observe the cutoff line. The cutoff line is a distinct line, below which light from the fog lights can be observed and above which it cannot. Place the vehicle at a 90° angle to the wall. Create a 7.62 m (25 ft) distance between the vehicle (fog light bulb center) and the wall. Place the vehicle on a level surface. Bounce the vehicle up and down to settle the suspension. NOTE: A distance of 7.62 m (25 ft) between the vehicle (fog light bulb center) and the wall is necessary for proper aim adjustment. If unavailable, secure a distance of exactly 3 m (9.84 ft) for check and adjustment. (The target zone will change with the distance, so follow the instructions in the illustration.) Prepare a piece of thick white paper (approximately 2 m (6.6 ft) (height) x 4 m (13.1 ft) (width)) to use as a screen. Draw a vertical line down the center of screen (V line). Set the screen as shown in the illustration. HINT: Stand the screen perpendicular to the ground. Align the V line on the screen with the center of the vehicle. Draw base lines (H line, V LH, V RH lines) on the screen as shown in the illustration. HINT: Mark the fog light bulb center marks on the screen. If the center mark cannot be observed on the fog light, use the center of the fog light bulb or the manufacturer's name marked on the fog light as the center mark. H Line (Fog light height): Draw a horizontal line across the screen so that it passes through the center marks. The H line should be at the same height as the fog light bulb center marks of the low-beam fog lights. V LH Line, V RH Line (Center mark position of left-hand (LH) and right-hand (RH) fog lights): Draw two vertical lines so that they intersect the H line at each center mark.
3. FOG LIGHT AIMING INSPECTION Cover or disconnect the connector of the fog light on the opposite side to prevent light from the fog light not being inspected from affecting fog light aiming inspection. Start the engine. Turn on the fog light and make sure that the cutoff line falls within the specified area, as shown in the illustration.
4. FOG LIGHT AIMING ADJUSTMENT Adjust the fog light aim into the specified range by turning aiming screw with a screwdriver. NOTE: The final turn of the aiming screw should be made in the clockwise direction. If the screw is tightened excessively, loosen it and then retighten it, so that the final turn of the screw is in the clockwise direction.
