INSTALLATION

1. INSTALL FOG LIGHT ASSEMBLY Install the fog light assembly with the 2 claws and the 2 pins.
2. INSTALL FOG LIGHT PROTECTOR
3. INSTALL FRONT BUMPER ASSEMBLY
4. INSTALL FRONT BUMPER STAY CENTER
5. VEHICLE PREPARATION FOR FOG LIGHT AIM (See «FOG LIGHT ASSEMBLY»(ref-283014-S01797243972008041400000) )
6. PREPARATION FOR FOG LIGHT AIMING (See «FOG LIGHT ASSEMBLY»(ref-283014-S01797243972008041400000) )
7. FOG LIGHT AIMING INSPECTION (See «FOG LIGHT ASSEMBLY»(ref-283014-S01797243972008041400000) )
8. FOG LIGHT AIMING ADJUSTMENT (See «FOG LIGHT ASSEMBLY»(ref-283014-S01797243972008041400000) )

Scheme 188

Scheme 189

1. INSPECT REAR COMBINATION LIGHT ASSEMBLY Disconnect the rear combination light assembly connector. Measure the voltage according to the value(s) in the table below. Voltage TESTER CONNECTION SPECIFIED CONDITION REFERENCE CHART Tester connection Condition Specified condition 1 --2 Brake pedal released Below 1 V 1 - 2 Brake pedal depressed 10 to 14 V Measure the resistance of the rear combination light according to the value(s) in the table below. Resistance TESTER CONNECTION SPECIFIED CONDITION REFERENCE CHART Tester connection Condition Specified condition 1 - 2 Always 317 to 347 ohms If the result is not as specified, replace the light.

Scheme 190

1. REMOVE ROOF SIDE INNER GARNISH COVER
2. REMOVE REAR COMBINATION LIGHT ASSEMBLY Disconnect the connector. Remove the 3 nuts. Disengage the 2 pins and remove the rear combination light assembly.

Scheme 191

Scheme 192

1. REMOVE REAR COMBINATION LIGHT BULB Turn in the direction indicated by the arrow and separate the rear combination light bulb and the rear combination light socket and wire sub-assembly as a unit. Remove the rear combination light bulb from the rear combination light socket and wire sub-assembly.
2. REMOVE REAR COMBINATION LIGHT SOCKET AND WIRE SUB-ASSEMBLY Disconnect the connector and remove the rear combination light socket and wire sub-assembly.

1. INSTALL REAR COMBINATION LIGHT ASSEMBLY Install the rear combination light assembly with the 3 nuts and the 2 pins.
2. INSTALL ROOF SIDE INNER GARNISH COVER

Scheme 193

Scheme 194

1. REMOVE BACK DOOR TRIM PANEL ASSEMBLY UPPER (See «DISASSEMBLY»(ref-283005-S05685971372008041400000) )
2. REMOVE BACK-UP LIGHT ASSEMBLY Disconnect each connector. Remove the 3 nuts and disengage the clip, and remove the back-up light assembly.

Scheme 195

1. REMOVE BACK-UP LIGHT BULB Turn in the direction indicated by the arrow and remove the back-up light bulb and No.2 socket plug as a unit.
2. REMOVE NO.2 SOCKET PLUG Remove the back-up light bulb from the No.2 socket plug.

1. INSTALL BACK-UP LIGHT ASSEMBLY Connect each connector. Install the back-up light assembly with the 3 nuts and the clip.
2. INSTALL BACK DOOR TRIM PANEL ASSEMBLY UPPER

Scheme 196

Scheme 197

1. REMOVE BACK DOOR TRIM PANEL ASSEMBLY UPPER (See «DISASSEMBLY»(ref-283005-S05685971372008041400000) )
2. REMOVE BACK DOOR TRIM PANEL ASSEMBLY (See «DISASSEMBLY»(ref-283005-S05685971372008041400000) )
3. REMOVE BACK DOOR GARNISH (See «REMOVAL»(ref-283008-S09416752692008041400000) )
4. REMOVE LICENSE PLATE LIGHT ASSEMBLY Disengage the 2 claws and separate the license plate light assembly. Disconnect the connector and remove the license plate light assembly.

Scheme 198

1. REMOVE LICENSE PLATE LIGHT BULB Turn in the direction indicated by the arrow and remove the license plate light bulb and the license plate light socket as a unit. Remove the license plate light bulb from the license plate light socket.

1. INSTALL LICENSE PLATE LIGHT ASSEMBLY Install the license plate light assembly with the 2 claws. Connect the connector.
2. INSTALL BACK DOOR GARNISH (See «INSTALLATION»(ref-283008-S09797690612008041400000) )
3. INSTALL BACK DOOR TRIM PANEL ASSEMBLY
4. INSTALL BACK DOOR TRIM PANEL ASSEMBLY UPPER

Scheme 199

Scheme 200

1. REMOVE BACK WINDOW PANEL TRIM UPPER (w/o Power Back Door) (See «DISASSEMBLY»(ref-283005-S05685971372008041400000) )
2. REMOVE BACK DOOR TRIM BOARD (w/ Power Back Door) (See «DISASSEMBLY»(ref-283005-S05685971372008041400000) )
3. REMOVE BACK WINDOW PANEL TRIM UPPER (w/ Power Back Door) (See «DISASSEMBLY»(ref-283005-S05685971372008041400000) )
4. REMOVE REAR SPOILER SUB-ASSEMBLY (See «REMOVAL»(ref-283008-S17030090482008041400000) )
5. REMOVE HIGH MOUNTED STOP LIGHT ASSEMBLY Install the strap to the connector of the high mounted stop light assembly. Remove the 2 screws. Pass the connector through the inside of the rear spoiler and remove the high mounted stop light assembly. HINT: Leave the strap inside the rear spoiler.

Scheme 201

1. INSTALL HIGH MOUNTED STOP LIGHT ASSEMBLY Install the strap to the connector of the high mounted stop light assembly. HINT: Leave the strap inside the rear spoiler. Pass the connector through the inside of the rear spoiler and install the high mounted stop light assembly with the 2 screws.
2. INSTALL REAR SPOILER SUB-ASSEMBLY (See «INSTALLATION»(ref-283008-S35134323392008041400000) )
3. INSTALL BACK WINDOW PANEL TRIM UPPER (w/ Power Back Door)
4. INSTALL BACK DOOR TRIM BOARD (w/ Power Back Door)
5. INSTALL BACK WINDOW PANEL TRIM UPPER (w/o Power Back Door)

Scheme 202

Scheme 203

1. REMOVE DECK FLOOR BOX REAR (See «REMOVAL»(ref-282982-S27013933812008041400000) )
2. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(ref-282982-S27013933812008041400000) )
3. REMOVE REAR BUMPER STOPPER UPPER (See «REMOVAL»(ref-283008-S13825116532008041400000) )
4. REMOVE REAR BUMPER ASSEMBLY (See «REMOVAL»(ref-283008-S13825116532008041400000) )
5. REMOVE REAR SIDE MARKER LIGHT ASSEMBLY Remove the screw. Disengage the claw and remove the rear side marker light assembly.

Scheme 204

1. REMOVE REAR SIDE MARKER LIGHT BULB Turn in the direction indicated by the arrow and remove the rear side marker light bulb and rear side marker light socket plug as a unit. Remove the rear side marker light bulb from the rear side marker light socket plug.
2. REMOVE REAR SIDE MARKER LIGHT SOCKET PLUG

1. INSTALL REAR SIDE MARKER LIGHT ASSEMBLY Install the rear side marker light assembly with the screw and the claw.
2. INSTALL REAR BUMPER ASSEMBLY (See «INSTALLATION»(ref-283008-S38188925492008041400000) )
3. INSTALL REAR BUMPER STOPPER UPPER
4. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
5. INSTALL DECK FLOOR BOX REAR (See «INSTALLATION»(ref-282982-S40679876012008041400000) )

Scheme 205

1. INSPECT PERSONAL LIGHT ASSEMBLY Remove the personal light assembly. Connect the battery positive (+) lead to terminal 17 and negative (-) lead to terminal 6. Turn the personal light switch in DOOR position. Check that the light comes on. Connect the battery positive (+) lead to terminal 17 and negative (-) lead to terminal 5. Turn the personal light switch in ON position. Check that the light comes on. OK: Comes on If the light does not come on, replace the personal light assembly.

Scheme 206

1. INSPECT FRONT ROOM LIGHT ASSEMBLY Remove the front room light assembly. Connect the battery positive (+) lead to terminal 1 and negative (-) lead to terminal 2. Turn the front room light switch in DOOR position. Check that the light comes on. Connect the battery positive (+) lead to terminal 1 and negative (-) lead to terminal 3. Turn the front room light switch in ON position. Check that the light comes on. OK: Comes on If the light does not come on, replace the front room light assembly.

Scheme 207

1. INSPECT REAR ROOM LIGHT ASSEMBLY Remove the rear room light assembly. Connect the battery positive (+) lead to terminal 2 and negative (-) lead to terminal 1. Turn on the rear room light switch. Check that the light comes on. OK: Comes on If the light does not comes on, replace the rear room light assembly.

Scheme 208

1. INSPECT STEP LIGHT Remove the step light. Connect the battery positive (+) lead to terminal 2 and negative (-) lead to terminal 1. Check that the light comes on. OK: Comes on If the light does not come on, replace the light.

Scheme 209

1. INSPECT IGNITION KEY CYLINDER LIGHT Remove the transponder key amplifier (ignition key cylinder light). Connect the battery positive (+) lead to terminal 2 and negative (-) lead to terminal 6. Check that the light comes on. OK: Comes on If the light does not come on, replace the transponder key amplifier (ignition key cylinder light).

Scheme 210

1. INSPECT GLOVE BOX LIGHT Remove the glove box light assembly. Connect the battery positive (+) lead to terminal 2 and negative (-) lead to terminal 1. Turn on the glove box light switch. Check that the light comes on. OK: Comes on If the light does not come on, replace the light assembly.

1. INSTALL HEIGHT CONTROL SENSOR 2WD: Install the height control sensor with the 2 bolts. 4WD: Install the height control sensor with the 2 bolts. Install the height control sensor link with the nut. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) Connect the connector.
2. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
3. PERFORM INITIALIZATION
4. VEHICLE PREPARATION FOR HEADLIGHT AIM (See «HEADLIGHT ASSEMBLY»(ref-283014-S07583743702008041400000) )
5. PREPARATION FOR HEADLIGHT AIM (Using a tester) (See «HEADLIGHT ASSEMBLY»(ref-283014-S07583743702008041400000) )
6. PREPARATION FOR HEADLIGHT AIM (Using a screen) (See «HEADLIGHT ASSEMBLY»(ref-283014-S07583743702008041400000) )
7. HEADLIGHT AIMING INSPECTION (See «HEADLIGHT ASSEMBLY»(ref-283014-S07583743702008041400000) )
8. HEADLIGHT AIMING ADJUSTMENT (See «HEADLIGHT ASSEMBLY»(ref-283014-S07583743702008041400000) )

Scheme 211

Scheme 212

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL (See «AIRBAG SYSTEM»(ref-283011-S05295089212008041400000) )
2. REMOVE FRONT DOOR SCUFF PLATE LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
3. REMOVE COWL SIDE TRIM SUB-ASSEMBLY LH (See «REMOVAL»(ref-282983-S14613677712008041400000) )
4. REMOVE INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY LOWER (See «REMOVAL»(ref-282983-S14613677712008041400000) )
5. REMOVE HEADLIGHT SWIVEL ECU Disconnect the connector. Remove the nut and headlight swivel ECU.

1. INSTALL HEADLIGHT SWIVEL ECU Install the headlight swivel ECU with the nut. Torque: 7.0 N*m (71 kgf*cm, 62 in.*lbf) Connect the connector.
2. INSTALL INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY LOWER (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
3. INSTALL COWL SIDE TRIM SUB-ASSEMBLY LH (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
4. INSTALL FRONT DOOR SCUFF PLATE LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
6. PERFORM INITIALIZATION (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )

Scheme 213

Scheme 214

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL (See «AIRBAG SYSTEM»(ref-283011-S05295089212008041400000) )
2. REMOVE FRONT DOOR SCUFF PLATE LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
3. REMOVE COWL SIDE TRIM SUB-ASSEMBLY LH (See «REMOVAL»(ref-282983-S14613677712008041400000) )
4. REMOVE INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY LOWER (See «REMOVAL»(ref-282983-S14613677712008041400000) )
5. REMOVE HEADLIGHT LEVELING ECU Disconnect the connector. Remove the nut and the headlight leveling ECU assembly.

1. INSTALL HEADLIGHT LEVELING ECU Install the headlight leveling ECU with the nut. Torque: 7.0 N*m (71 kgf*cm, 62 in.*lbf) Connect the connector.
2. INSTALL INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY LOWER (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
3. INSTALL COWL SIDE TRIM SUB-ASSEMBLY LH (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
4. INSTALL FRONT DOOR SCUFF PLATE LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
6. PERFORM INITIALIZATION (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )
