HOW TO PROCEED WITH TROUBLESHOOTING

HINT

1. Use this procedure to troubleshoot the power mirror control system.
2. The intelligent tester should be used in steps 3 and 5.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS CHECK AND SYMPTOM CHECK NEXT: Go to next step
3. CHECK COMMUNICATION FUNCTION OF BODY MULTIPLEX COMMUNICATION SYSTEM (BEAN) HINT: See «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-282977-S38607022452008041400000) Use the intelligent tester to check for normal function of the multiplex communication system. (ECU unconnected, communication line malfunctioning) If no code are output, proceed to A. (ECU unconnected, communication line malfunctioning) If any codes are output, proceed to B. B: GO TO «MULTIPLEX COMMUNICATION SYSTEM»(ref-282977-S11093581492008041400000) A: Go to next step
4. PROBLEM SYMPTOMS TABLE HINT: See «PROBLEM SYMPTOMS TABLE»(ref-283024-S07667227542008041400000) NEXT: Go to next step
5. OVERALL ANALYSIS AND TROUBLESHOOTING Data list/Active test HINT: See «DATA LIST / ACTIVE TEST»(ref-283024-S00126176322008041400000) Circuit inspection Terminals of ECU HINT: See «TERMINALS OF ECU»(ref-283024-S05504383722008041400000) NEXT: Go to next step
6. ADJUST, REPAIR OR REPLACE NEXT: END

PROBLEM SYMPTOMS TABLE

Power Mirror Control System

PROBLEM SYMPTOMS REFERENCE

Scheme 14

Scheme 15

1. CHECK OUTER MIRROR CONTROL ECU LH Disconnect the R27 connector. Measure the voltage and resistance according to the value(s) in the table below. Standard voltage ECU TERMINALS REFERENCE Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition BDR (R27-3) - Body ground G - Body ground +B power supply Always 10 to 14 V CPUB (R27-7) - Body ground L-B - Body ground +B power supply Always 10 to 14 V SIG (R27-8) - Body ground GR - Body ground Ignition power supply Ignition switch OFF --> ON 0 V --> 10 to 14 V Standard resistance ECU TERMINALS REFERENCE Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition GND (R27-1) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the R27 connector. Measure the voltage according to the value(s) in the table below. Standard voltage ECU TERMINALS REFERENCE Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition LMVR (R29-1) - Body ground V - Body ground Outer mirror switch signal (Up or Right) Ignition switch ACC, Left/Right adjustment switch L side, Mirror switch OFF-* UP or Right 0 V --> 10 to 14 V HTR+ (R29-4) - HTR- (R29-12) B - B Mirror heater signal Mirror heater switch ON 0 V --> 10 to 14 V LVC (R29-5) - Body ground R-W - Body ground Power source for mirror position sensor Ignition switch OFF --> ACC 0 V --> 0 to 5 V VSSR (R29-6) - Body ground Y-B - Body ground Vertical direction position signal Ignition switch ACC, Left/Right adjustment switch L side, Mirror switch uppermost position --> lowermost, position 0 V --> 1 to 3 V LMHR (R29-9) - Body ground BR - Body ground Outer mirror switch signal (Left or Down) Ignition switch ACC, Left/Right adjustment switch L side, Mirror switch OFF --> LEFT or DOWN 0 V --> 10 to 14 V LM+R (R29-10) - Body ground R - Body ground Outer mirror switch signal (Right or Down) Ignition switch ACC, Left/Right adjustment switch L side, Mirror switch OFF --> RIGHT or DOWN 0 V --> 10 to 14 V HSSR (R29-13) - Body ground P - Body ground Horizontal direction position signal Ignition switch ACC, Left/Right adjustment switch L side, Mirror switch innermost position --> outermost position 0 V --> 1 to 3 V
2. CHECK OUTER MIRROR CONTROL ECU RH Disconnect the R28 connector. Measure the voltage and resistance according to the value(s) in the table below. Standard voltage ECU TERMINALS REFERENCE Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition BDR (R28-3) - Body ground G - Body ground +B power supply Always 10 to 14 V CPUB (R28-7) - Body ground L-B - Body ground +B power supply Always 10 to 14 V SIG (R28-8) - Body ground GR - Body ground Ignition power supply Ignition switch OFF --> ON 0 V --> 10 to 14 V Standard resistance ECU TERMINALS REFERENCE Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition GND (R28-1) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the R28 connector. Measure the voltage according to the value(s) in the table below. Standard voltage ECU TERMINALS REFERENCE Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition RMVR (R30-1) - Body ground V - Body ground Outer mirror switch signal (Up or Right) Ignition switch ACC, Left/Right adjustment switch L side, Mirror switch OFF-* UP or Right 0 V --> 10 to 14 V HTR+ (R30-4) - HTR- (R30-12) B - B Mirror heater signal Mirror heater switch ON 0 V --> 10 to 14 V RVC (R30-5) - Body ground R-W - Body ground Power source for mirror position sensor Ignition switch OFF --> ACC 0 V --> 0 to 5 V VSSR (R30-6) - Body ground Y-B - Body ground Vertical direction position signal Ignition switch ACC, Left/Right adjustment switch L side, Mirror switch uppermost position --> lowermost position 0 V --> 1 to 3 V RMHR (R30-9) - Body ground BR - Body ground Outer mirror switch signal (Left or Down) Ignition switch ACC, Left/Right adjustment switch L side, Mirror switch OFF --> LEFT or DOWN 0 V --> 10 to 14 V RM+R (R30-10) - Body ground R - Body ground Outer mirror switch signal (Right or Down) Ignition switch ACC, Left/Right adjustment switch L side, Mirror switch OFF --> RIGHT or DOWN 0 V --> 10 to 14 V HSSR (R30-13) - Body ground P - Body ground Horizontal direction position signal Ignition switch ACC, Left/Right adjustment switch L side, Mirror switch innermost position --> outermost position 0 V --> 1 to 3 V

Scheme 16

1. DESCRIPTION Data of the system can be read from the Data Link Connector 3 (DLC3) of the vehicle. Therefore, when the system seems to be malfunctioning, use the intelligent tester to check for a malfunction and repair it.
2. CHECK DLC3 The vehicle's ECM uses ISO 9141-2 communication protocol. The terminal arrangement of the DLC3 complies with SAE J1962 and matches the ISO 9141-2 format. Standard DLC3 TERMINALS REFERENCE Tester Connection Condition Specified Condition 7 (Bus + line) - 5 (Signal ground) During communication Pulse generation 4 (Chassis ground) - Body ground Constant Below 1 ohms 5 (Signal ground) - Body ground Constant Below 1 ohms 16 (B+) - Body ground Constant 9 to 14 V HINT: If the screen displays a communication error message after you have connected the cable of the intelligent tester to the DLC3, turned the ignition switch ON and used the intelligent tester, the problem may be on the vehicle side or tester side. If communication is normal when the tester is connected to another vehicle, inspect the DLC3 of the original vehicle. If communication is still impossible when the tester is connected to another vehicle, the problem is probably in the tester itself, so consult the Service Department listed in the tester's instruction manual.

Scheme 17

1. USING INTELLIGENT TESTER Connect the intelligent tester to the DLC3. Monitor the ECU data by following the prompts on the tester screen. HINT: The intelligent tester has a "Snapshot" function which records the monitored data. Refer to the intelligent tester operator's manual for further details.
2. DATA LIST HINT: Using the DATA LIST displayed on the intelligent tester, you can read the value of the switch, sensor, actuator, etc. without parts removal. Reading the DATA LIST as the first step of troubleshooting is one way to shorten the labor time. Connect the intelligent tester to the DLC3. Turn the ignition switch ON. Read the DATA LIST according to the display on the tester. MIRROR-L/MIRROR-R DATA LIST CHART Item Test Details Diagnostic Note MIRR POS SEN V Vertical mirror position/MIN: 0, MAX 5 V Within range from 0 to 5 V MIRR POS SEN H Horizontal mirror position/MIN: 0, MAX 5 V Within range from 0 to 5 V MIRR MEM 1 Mirror position memorized in memory switch M1/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized MIRR MEM 2 Mirror position memorized in memory switch M2/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized MASTER SW DATA LIST CHART Item Test Details Diagnostic Note SEAT SET SW Seat memory set switch signal/ON or OFF ON: Memory set switch is pressed OFF: Memory set switch is not pressed SEAT MEM M1 Seat memory switch M1 signal/ON or OFF ON: Seat memory M1 switch is pressed OFF: Seat memory M1 switch is not pressed SEAT MEM M2 Seat memory switch M2 signal/ON or OFF ON: Seat memory M2 switch is pressed OFF: Seat memory M2 switch is not pressed D-SEAT DATA LIST CHART Item Test Details Diagnostic Note POWER VOLTAGE Power supply for position control ECU & switch/MIN: 0 V, MAX: 19.89 V Within range from 11 to 14 V IG SW Ignition switch status/ON or OFF ON: Ignition switch is ON OFF: ignition switch is OFF KEY UNLOCK SW Key unlock warning switch signal/ON or OFF ON: Key is in ignition key cylinder OFF: Key is not in ignition key cylinder PNP SW Park/Neutral position switch signal/ON or OFF ON: Shift in P position OFF: Shift in any position except neutral M1SW Seat memory switch M1 signal/ON or OFF ON: Seat memory switch M1 is ON OFF: Seat memory switch M1 is OFF M2SW Seat memory switch M2 signal/ON or OFF ON: Seat memory switch M2 is ON OFF: Seat memory switch M2 is OFF SET SW Seat memory set switch signal/ON or OFF ON: Memory set switch is ON OFF: Memory set switch is OFF MEM M1 SW Driving position memorized in seat memory switch MI/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized MEM M2 SW Driving position memorized in seat memory switch M2/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized D-MIRR MEM M1 Driver side mirror position memorized in seat memory switch M1/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized D-MIRR MEM M2 Driver side mirror position memorized in seat memory switch M2/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized P-MIRR MEM M1 Passenger side mirror position memorized in seat memory switch M1/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized P-MIRR MEM M2 Passenger side mirror position memorized in seat memory switch M2/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized D-MIRR MEM POS 1 Driver side mirror position memorized in seat memory switch M1/MIN: 0, MAX: 65535 Within range from 0 to 65535 P-MIRR MEM POS 1 Passenger side mirror position memorized in seat memory switch M1/MIN: 0, MAX: 65535 Within range from 0 to 65535 D-MIRR MEM POS 2 Driver side mirror position memorized in seat memory switch M2/MIN: 0, MAX: 65535 Within range from 0 to 65535 P-MIRR MEM POS 2 Passenger side mirror position memorized in seat memory switch M2/MIN: 0, MAX: 65535 Within range from 0 to 65535 BODY DATA LIST CHART Item Test Details Diagnostic Note MIRR SEL SW R Mirror selection switch signal for RH mirror/ON or OFF ON: Switch is in Right position OFF: Switch is in neutral or Left position MIRR SEL SW L Mirror selection switch signal for LH mirror/ON or OFF ON: Switch is in Left position OFF: Switch is in neutral or Right position MIRR POS SW R Mirror position switch signal (Right)/ON or OFF ON: Switch R is ON OFF: Any switch except R is ON or all switches are OFF MIRR POS SW L Mirror position switch signal (Left)/ON or OFF ON: Switch L is ON OFF: Any switch except L is ON or all switches are OFF MIRR POS SW UP Mirror position switch signal (Up)/ON or OFF ON: Switch UP is ON OFF: Any switch except UP is ON or all switches are OFF MIRR POS SW DWN Mirror position switch signal (Down)/ON or OFF ON: Switch DOWN is ON OFF: Any switch except DOWN is ON or all switches are OFF
3. ACTIVE TEST HINT: Performing the ACTIVE TEST using the intelligent tester allows you to operate the relay, VSV, actuator, etc. without parts removal. Performing the ACTIVE TEST as the first step of troubleshooting is one way to shorten the labor time. It is possible to display the DATA LIST during the ACTIVE TEST. Connect the intelligent tester to the DLC3. Turn the ignition switch ON. Perform the ACTIVE TEST according to the display on the tester. MIRROR-L/MIRROR-R ACTIVE TEST CHART Item Test Details MIRR UP/DOWN Mirror vertical operation: UP/DOWN MIRR RIGHT/LEFT Mirror horizontal operation: RIGHT/LEFT MIRR HEATER Mirror heater operation: OFF/ON

Power Mirror Control System

PROBLEM SYMPTOMS REFERENCE

Scheme 18

Scheme 19

Scheme 20

1. SELECT COMPASS DISPLAY MODE The COMP switch allows you to select the Display or Non-display mode of the compass.
2. SET ZONE Deviation between the "magnetic north" and "actual north" differs depending on the location. Therefore, adjustment of the magnetism is required. Since the magnetic condition differs depending on the area where the vehicle is used, it is necessary for each user to set the zone (Refer to Compass Zone Map). The zone setting can be changed using the COMP switch of the inner mirror.
3. PERFORM CALIBRATION Because each vehicle has its own magnetic field, calibration should be performed for each vehicle. This compass function is used when storing the record of the vehicle's magnetic field.
4. WHEN COMPASS IS MAGNETIZED A compass could be magnetized during shipping by vessels or freight cars. Therefore, make sure to perform calibration and ensure that calibration is performed properly before delivery. If it cannot be done (cannot be completed in spite of driving around several times), it may be caused by magnetization. Demagnetize the vehicle using a demagnetizer and perform calibration again.
5. SET COMPASS
6. ZONE SETTING MODE Pressing the COMP switch for 3 seconds in the normal mode will activate the zone setting mode. A number (1 to 15) is displayed on the compass display. NOTE: In the initial state, "8" is displayed. The displayed number increases by 1 every time the COMP switch is pressed. Referring to the map, check the number for the area where the vehicle will be used and set the zone number. Leave it untouched for several seconds after setting and check that the compass display shows an azimuthal direction (N, NE, E, SE, S, SW, W or NW) or "C".
7. CALIBRATION SETTING MODE Pressing the COMP switch for 6 seconds in the normal mode will activate the calibration setting mode. Drive the vehicle at a slow speed of 8 km/h (5 mph) or less in the circular direction. Driving around the circle 1 to 3 times will display the azimuthal direction on the display, completing the calibration. NOTE: After the calibration is completed, it is not necessary to perform the above procedures unless the magnetic field strength is drastically changed. If this happens, the azimuthal display will be changed to "C".

Scheme 21

1. REMOVE INNER REAR VIEW MIRROR STAY HOLDER COVER Disengage the 2 claws and remove the inner rear view mirror stay holder cover.
2. REMOVE INNER REAR VIEW MIRROR ASSEMBLY Disconnect the connector. Using a "torx" socket wrench (T20), remove the screw and the inner rear view mirror.

Scheme 22

1. INSPECT INNER REAR VIEW MIRROR ASSEMBLY Inspect operation of the electrochromic inner mirror. Connect the positive (+) lead from the battery to terminal 1 and the negative (-) lead to terminal 2. Attach black colored tape to the forward sensor to prevent it from sensing. Light up the mirror with an electric light, and check that the mirror surface changes from bright to dark. Standard: Mirror surface changes from bright to dark If the result is not as specified, replace the mirror assembly.

Scheme 23

1. INSTALL INNER REAR VIEW MIRROR ASSEMBLY Using a "TORX" socket wrench (T20), install the inner rear view mirror with the screw. Torque: 3.5 N*m (36 kgf*cm, 31 in.*lbf) Connect the connector.
2. INSTALL INNER REAR VIEW MIRROR STAY HOLDER COVER Engage the 2 claws and install the inner rear view mirror stay holder cover.

Scheme 24

Scheme 25

Scheme 26

1. REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG (See «DISASSEMBLY»(ref-283005-S15344685922008041400000) )
2. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (See «DISASSEMBLY»(ref-283005-S15344685922008041400000) )
3. REMOVE DOOR ARMREST COVER (See «DISASSEMBLY»(ref-283005-S15344685922008041400000) )
4. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH (See «DISASSEMBLY»(ref-283005-S15344685922008041400000) )
5. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY (See «DISASSEMBLY»(ref-283005-S15344685922008041400000) )
6. REMOVE OUTER REAR VIEW MIRROR ASSEMBLY Disconnect the connector and remove the clamp. Remove the 3 bolts and the outer rear view mirror assembly.
7. REMOVE OUTER REAR VIEW MIRROR Push the upper part of the mirror surface and tilt it. Apply protective tape on the outer rear view mirror assembly. Using a molding remover, disengage the 2 claws at the lower part of the outer rear view mirror. Pull the mirror in the direction indicated by the arrow shown in the illustration to disengage the 2 claws on the upper part of the outer rear view mirror, and separate the outer rear view mirror sub-assembly. Disconnect each connector and remove the outer rear view mirror.

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY RH (w/ Memory) Inspect outer mirror motor operation. Remove the outer rear view mirror assembly. Apply battery voltage and check operation of the mirror face, as shown in the table and illustration. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (RMVR) Battery negative (-) --> Terminal 10 (RM+R) Turns upward (A) Battery positive (+) --> Terminal 10 (RM+R) Battery negative (-) --> Terminal 1 (RMVR) Turns downward (B) Battery positive (+) --> Terminal 9 (RMHR) Battery negative (-) --> Terminal 10 (RM+R) Turns left (C) Battery positive (+) --> Terminal 10 (RM+R) Battery negative (-) --> Terminal 9 (RMHR) Turns right (O) Inspect outer mirror heater operation. Apply battery voltage and check operation of the mirror face, as shown in the table and illustration. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 4 (HTR+) Battery negative (-) --> Terminal 12 (HTR-) Mirror surface temperature becomes higher Inspect electrochromic outer mirror operation. Apply battery voltage and check operation of the mirror face, as shown in the table and illustration. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 7 (EC+) Battery negative (-) --> Terminal 15 (EC) Mirror surface changes to dark
2. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY RH (w/o Memory) Inspect outer mirror motor operation. Remove the outer rear view mirror assembly. Apply battery voltage and check operation of the mirror face, as shown in the table and illustration. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 2 (MV) Battery negative (-) --> Terminal 1 (MH) Turns upward (A) Battery positive (+) --> Terminal 1 (MH) Battery negative (-) --> Terminal 2 (MV) Turns downward (B) Battery positive (+) --> Terminal 6 (M+) Battery negative (-) --> Terminal 1 (MH) Turns left (C) Battery positive (+) --> Terminal 1 (MH) Battery negative (-) --> Terminal 6 (M+) Turns right (0) Inspect outer mirror heater operation. Apply battery voltage and check operation of the mirror face, as shown in the table and illustration. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 7 (HTR+) Battery negative (-) --> Terminal 3 (HTR-) Mirror surface temperature becomes higher Inspect electrochromic outer mirror operation. Apply battery voltage and check operation of the mirror face, as shown in the table and illustration. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 4 (EC+) Battery negative (-) --> Terminal 5 (EC) Mirror surface changes to dark
3. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY LH (w/Memory) Inspect outer mirror motor operation. Remove the outer rear view mirror assembly. Apply battery voltage and check operation of the mirror face, as shown in the table and illustration. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (LMVR) Battery negative (-) --> Terminal 10 (LM+R) Turns upward (A) Battery positive (+) --> Terminal 10 (LM+R) Battery negative (-) --> Terminal 1 (LMVR) Turns downward (B) Battery positive (+) --> Terminal 9 (LMHR) Battery negative (-) --> Terminal 10 (LM+R) Turns left (C) Battery positive (+) --> Terminal 10 (LM+R) Battery negative (-) --> Terminal 9 (LMHR) Turns right (D) Inspect outer mirror heater operation. Apply battery voltage and check operation of the mirror face, as shown in the table and illustration. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 4 (HTR+) Battery negative (-) --> Terminal 12 (HTR-) Mirror surface temperature becomes higher Inspect electrochromic outer mirror operation. Apply battery voltage and check operation of the mirror face, as shown in the table and illustration. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 7 (EC+) Battery negative (-) --> Terminal 15 (EC) Mirror surface changes to dark
4. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY LH (w/o Memory) Inspect outer mirror motor operation. Apply battery voltage and check operation of the mirror face, as shown in the table and illustration. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 2 (MV) Battery negative (-) --> Terminal 1 (MH) Turns upward (A) Battery positive (+) --> Terminal 1 (MH) Battery negative (-) --> Terminal 2 (MV) Turns downward (B) Battery positive (+) --> Terminal 6 (M+) Battery negative (-) --> Terminal 1 (MH) Turns left (C) Battery positive (+) --> Terminal 1 (MH) Battery negative (-) --> Terminal 6 (M+) Turns right (D) Inspect outer mirror heater operation. Apply battery voltage and check operation of the mirror face, as shown in the table and illustration. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 7 (HTR+) Battery negative (-) --> Terminal 3 (HTR-) Mirror surface temperature becomes higher Inspect electrochromic outer mirror operation. Apply battery voltage and check operation of the mirror face, as shown in the table and illustration. Standard MEASUREMENT CONDITION CHART Measurement Condition Specified Condition Battery positive (+) --> Terminal 4 (EC+) Battery negative (-) --> Terminal 5 (EC-) Mirror surface changes to dark

Scheme 35

1. INSTALL OUTER REAR VIEW MIRROR Connect each connector. Engage the 2 claws on the upper part of the outer rear view mirror. Engage the 2 claws on the lower part of the outer rear view mirror as shown in the illustration, and install the outer rear view mirror.
2. INSTALL OUTER REAR VIEW MIRROR ASSEMBLY Install the outer rear view mirror assembly with the 3 bolts. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) Connect the connector and install the clamp.
3. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY
4. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH
5. REMOVE DOOR ARMREST COVER
6. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY
7. REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG

Scheme 36

Scheme 37

1. INSPECT OUTER MIRROR SWITCH (W/ MEMORY SEAT) Inspect the outer mirror switch. Measure the resistance according to the value(s) in the table below when the switch is operated. Standard resistance TESTER CONNECTION SPECIFIED CONDITION Tester Connection Switch Position Specified Condition 2 - 3 OFF 10 kohms or higher UP 225 to 275 ohms DOWN 437 to 503 ohms LEFT 744 to 856 ohms RIGHT 437 to 503 ohms 1 - 2 L 90 to 110 ohms R 10 ohms or less
2. INSPECT OUTER MIRROR SWITCH (W/O MEMORY SEAT) Inspect the outer mirror switch. Measure the resistance according to the value(s) in the table below when the switch is operated. Standard resistance: Select "L" on the left/right adjustment switch TESTER CONNECTION SPECIFIED CONDITION Tester Connection Switch Position Specified Condition 4 - 8 UP Below 1 ohms 6 - 7 4 - 7 DOWN 6 - 8 5 - 8 LEFT 6 - 7 5 - 7 RIGHT 6 - 8 Select "R" on the left/right adjustment switch TESTER CONNECTION SPECIFIED CONDITION Tester Connection Switch Position Specified Condition 3 - 8 UP Below 1 ohms 6 - 7 3 - 7 DOWN 6 - 8 2 - 8 LEFT 6 - 7 2 - 7 RIGHT 6 - 8
