Scheme 1: ON-VEHICLE INSPECTION
- CHECK COOLING SYSTEM FOR LEAKS CAUTION: Do not remove the radiator cap while the engine and radiator are still hot. Thermal expansion will cause hot coolant and steam to blow out from the radiator. Fill the radiator with coolant and attach a radiator cap tester. Warm up the engine. Using a radiator cap tester, increase the pressure inside the radiator to 118 kPa (1.2 kgf*cm, 17 psi), and check that the pressure does not drop. If the pressure drops, check the hoses, radiator and water pump for leaks. If no external leaks are found, check the heater core, cylinder block and cylinder head.
- CHECK COOLANT LEVEL AT RESERVOIR (for Engine) Check that the coolant level is between the LOW and FULL lines when the engine is cold. If the coolant is low, check for leaks and add "TOYOTA Super Long Life Coolant" or similar high quality ethylene glycol based non-silicate, non-amino, non-nitrite and non-borate coolant with long-life hybrid organic acid technology to the FULL line. NOTE: Do not substitute plain water for coolant.
- CHECK COOLANT QUALITY (for Engine) Remove the radiator cap. CAUTION: Do not remove the radiator cap while the engine and radiator are still hot. Thermal expansion will cause hot coolant and steam to blow out from the radiator. Check if there are any excessive deposits of rust or scales around the radiator cap and radiator filler hole. The coolant should be free of oil. HINT: If excessively dirty, clean the coolant passage and replace the coolant. Install the radiator cap. (Scheme 1): Checking Cooling System For Leaks
Scheme 2: Identifying Cooling Fan System Components Location
Scheme 3: Cooling Fan System Diagram
