Contents Section: Antenna Systems All sections

Audio / Visual: Overview Lexus RX II рестайлинг

Antenna Systems 77 illustrations ~6371 words

DESCRIPTION

DTC No.DTC Detection ConditionTrouble Area
01-21A malfunction exists in ROM.Radio receiver
01-22A malfunction exists in RAM.

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
01-D5 *1, *3A device that the sub-code shows is (was) disconnected from the system when turning the ignition switch to the ACC or ON position. The communication condition with the device that the code shows cannot be obtained when the engine starts.Power source circuit of the component shown by the sub-code AVC-LAN circuit between the radio receiver and the component shown by the sub-code Component shown by the sub-code
01-D8 *2, *3The device indicated by the sub-code is (was) disconnected from the system after engine start.
01-D9 *1, *3The device that had functioned before the engine stopped is (was) disconnected from the system when turning the ignition switch to the ACC or ON position.
01-DA *3No response is identified when changing mode. Sound and image do not change by switch operation.
01-DB *1, *3A dual alarm is detected.
01-DE *3, *4A slave device has been disconnected after the engine starts.
HINT: *1: Even if no fault is present, this trouble code may be stored depending on the battery condition or engine start voltage. *2: If the power connector is disconnected after the engine starts, this code is stored after 180 seconds. *3: If the device is reported as not existing during verification, check the power source circuit and AVC-LAN circuit for the device. *4: This code may be stored if the engine is started and then the ignition switch is turned to the START position again.

DTC DETECTION CONDITION CHART

Note. Before starting troubleshooting, be sure to clear DTCs to erase codes stored due to the reasons described in the HINT above. Then, check for DTCs and troubleshoot according to the output DTCs. The radio receiver is the master unit. Be sure to clear and recheck DTCs after the inspection is completed to confirm that no DTCs are output.

DTC No.DTC Detection ConditionTrouble Area
01-D6 *1When either of the following conditions is met: The device that stores (stored) the code has (had) been disconnected when turning the ignition switch is turned to the ACC or ON position The master device has (had) been disconnected when this code is storedRadio receiver power source circuit Power source circuit of the component which has stored this code AVC-LAN circuit between the radio receiver and the component which has stored this code Component which has stored this code Radio receiver
01-D7 *2When either of the following conditions is met: The device that stored the code has (had) been disconnected after the engine starts (started) The master device has (had) been disconnected when this code is (was) stored
HINT: *1: Even if no fault is present, this trouble code may be stored depending on the battery condition or engine start voltage. *2: When 210 seconds have elapsed after disconnecting the power supply connector of the master component with the ignition switch turned in the ACC or ON position, this code is stored.

DTC DETECTION CONDITION CHART

Note. Before starting troubleshooting, be sure to clear DTCs to erase codes stored due to the reasons described in the HINT above. Then, check for DTCs and troubleshoot according to the output DTCs. The radio receiver is the master unit. Be sure to clear and recheck DTCs after the inspection is completed to confirm that no DTCs are output.

DTC No.DTC Detection ConditionTrouble Area
01-DC *1Transmission to component shown by sub-code failed (Detecting this DTC does not always mean actual failure)If the same sub-code is recorded in other components, check harness for power supply and communication system of all components shown by code
HINT: *1: This code may be stored if the engine is started, idled for 60 seconds and then the ignition switch is turned to the START position again.

DTC DETECTION CONDITION CHART

Note. The radio receiver is the master unit. Be sure to clear and recheck DTCs after the inspection is completed to confirm that no DTCs are output. Before starting troubleshooting, be sure to clear DTCs to erase codes stored due to the reasons described in the HINT above. Then, check for DTCs and troubleshoot according to the output DTCs.

DTC No.DTC Detection ConditionTrouble Area
01-DD *1The device that should be the master has been disconnected after engine startRadio receiver power source circuit AVC-LAN circuit between the radio receiver and the component which has stored this code Radio receiver Component which has stored this code
01-E1 *2The AMP device records that the AMP output does not function even while the source device operates
HINT: *1: This code may be stored if the engine is started and the ignition switch is turned to the START position again. *2: Even if no fault is present, this trouble code may be stored depending on the battery condition or engine start voltage.

DTC DETECTION CONDITION CHART

Note. Before starting troubleshooting, be sure to clear DTCs to erase codes stored due to the reasons described in the HINT above. Then, check for DTCs and troubleshoot according to the output DTCs. The radio receiver is the master unit. Be sure to clear and recheck DTCs after the inspection is completed to confirm that no DTCs are output.

DTC No.DTC Detection ConditionTrouble Area
01-DF *1The device with a display fails and the master is switched to the audio device. Also when a communication error between the sub-master (audio) and master occurs, this code is stored.Radio receiver power source circuit AVC-LAN circuit between the radio receiver and the component which has stored this code Radio receiver Component which has stored this code
HINT: *1: When 210 seconds have elapsed after disconnecting the power supply connector of the master component with the ignition switch turned in the ACC or ON position, this code is stored.

DTC DETECTION CONDITION CHART

Note. Before starting troubleshooting, be sure to clear DTCs to erase codes stored due to the reasons described in the HINT above. Then, check for DTCs and troubleshoot according to the output DTCs. The radio receiver is the master unit. Be sure to clear and recheck DTCs after the inspection is completed to confirm that no DTCs are output.

DTC No.DTC Detection ConditionTrouble Area
01-E0"Registration complete" signal from the master device cannot be received.
01-E3The registration demand signal from the slave device is output. Or the registration demand signal is output by receiving connection confirmation signal from the sub-master device.
01-E4The multiple frame transmission is incomplete.

DTC DETECTION CONDITION CHART

HINT

Even if no fault is present, this trouble code may be stored depending on the battery condition or engine start voltage.

DTC No.DTC Detection ConditionTrouble Area
01-E2The command for ON/OFF control from the master device has a problem.Radio receiver

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
44-10A mechanical error in the DVD player is detected while the DVD is not being inserted or ejected.Television display assembly
44-11DVD insertion or ejection is failed.
44-12DVD read problem occurs.

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
44-41An unsuitable disc is inserted.DVD Television display assembly
44-42The disc cannot be read.

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
44-43DVD-ROM operation is abnormal.DVD Television display assembly

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
44-44Operation error in the DVD mechanismTelevision display assembly
44-48Excess current is present in the DVD player.
44-50Malfunction in insertion/ejection system

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
44-45Disc cannot be ejected.Television display assembly
44-51Mechanical error occurs during elevator operation.
44-52Error occurs in DVD player clamp.

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
44-46Scratches or dirt is found on DVD surface or DVD is set upside down.DVD Television display assembly

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
44-47Sensor detects that DVD unit temperature is high. (Over 80°C (176°F))Television display assembly

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
44-78An error occurs during the decode process (MP3/WMA).

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
44-7DAn incompatible MP3/WMA file is used. Although the file has an extension of "mp3" or ".wma", the header information cannot be read.DVD Television display assembly
44-7EA disc with no music data is used. Playable files are not on the disc (MP3/WMA).
44-7FA copy-protected file, which cannot be played, is used.

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
60-10AM tuner PLL (phase locked loop) synchronization is impossible.Radio receiver
60-11FM tuner PLL (phase locked loop) synchronization is impossible.

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
60-42The power source of the tuner is abnormal.Radio receiver
60-43The AM tuner is abnormal.
60-44The FM tuner Is abnormal.
60-50A problem occurs in the IC inside the tuner unit and radio reception is not normal.

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
63-10A mechanical error in the CD changer is detected while the CD is not being inserted or ejected.Radio receiver
63-11CD insertion or ejection is failed.
63-12CD read problem occurs.

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
63-41An unsuitable disc is inserted.CD Radio receiver
63-42The disc cannot be read.

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
63-43CD-ROM operation is abnormalCD Radio receiver

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
63-44Operation error in the CD mechanismRadio receiver
63-48Excess current is present in the CD changer.
63-50Malfunction in insertion/ejection system

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
63-45Magazine cannot be ejected.Radio receiver
63-51Mechanical error occurs during elevator operation.
63-52Error occurs in CD changer clamp.

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
63-46Scratches or dirt is found on CD surface or CD is inserted upside down.CD Radio receiver

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
63-47Sensor detects that CD unit temperature is high. (Over 80°C (176°F))Radio receiver

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
63-78An error occurs during the decode process (MP3/WMA)Radio receiver

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
63-7DAn incompatible MP3/WMA file is used. Although the file has an extension of ".mp3" or ".wma", the header information cannot be read.CD Radio receiver
63-7EA disc with no music data is used. Playable files are not on the disc (MP3/WMA).
63-7FA copy-protected file, which cannot be played, is used.

DTC DETECTION CONDITION CHART

DTC No.DTC Detection ConditionTrouble Area
74-40A short is detected in the speaker output circuit.Wire harness Speaker Stereo component amplifier

DTC DETECTION CONDITION CHART

This circuit has a fail-safe function.

  1. When a short in the speaker circuit is detected, all sound outputs are stopped.

Scheme 1

Scheme 1: WIRING DIAGRAM
Scheme 1: WIRING DIAGRAM

Scheme 2

Scheme 2
Scheme 2

This circuit sends an operation signal from the steering pad switch to the radio receiver.

If there is an open in the circuit, the audio system cannot be operated using the steering pad switch.

If there is a short in the circuit, the same condition as that when the switch is continuously depressed occurs.

Therefore, the radio receiver cannot be operated using the steering pad switch, and also the radio receiver itself cannot function.

Scheme 3

Scheme 3: WIRING DIAGRAM
Scheme 3: WIRING DIAGRAM

Power is supplied to the radio receiver and steering pad switch illumination when the light control switch is in the TAIL or HEAD position.

Scheme 4

Scheme 4: WIRING DIAGRAM
Scheme 4: WIRING DIAGRAM

The sound signal that has been amplified by the stereo component amplifier is sent to the speakers from the stereo component amplifier through this circuit.

If there is a short in this circuit, the stereo component amplifier detects it and stops output to the speakers. Thus, sound cannot be heard from the speakers even if there is no malfunction in the stereo component amplifier or speakers.

Scheme 5

Scheme 5: WIRING DIAGRAM
Scheme 5: WIRING DIAGRAM

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7: INSPECTION PROCEDURE
Scheme 7: INSPECTION PROCEDURE

Scheme 8

Scheme 8
Scheme 8
  1. CHECK HARNESS AND CONNECTOR Disconnect the connectors shown in the illustration from the stereo component amplifier and speakers. Measure the resistance between each of the front No. 1 speakers and the stereo component amplifier to check for an open circuit in the wire harness. Standard resistance: Below 1 ohms Measure the resistance between each of the front No. 2 speakers (except the center speaker) and the front stereo component speaker to check for an open circuit in the wire harness. Standard resistance: Below 1 ohms Measure the resistance between each of the front stereo component speakers and the stereo component amplifier to check for an open circuit in the wire harness. Standard resistance: Below 1 ohms with Front Center Speaker: Measure the resistance between the front No. 2 speaker (center speaker) and the stereo component amplifier to check for an open circuit in the wire harness. Standard resistance: Below 1 ohms Measure the resistance between each of the rear speakers and the stereo component amplifier to check for an open circuit in the wire harness. Standard resistance: Below 1 ohms Measure the resistance between each speaker and body ground to check for a short circuit in the wire harness. Standard resistance: 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: GO TO next step.
  2. INSPECT FRONT NO. 1 SPEAKER Resistance check Measure the resistance between the terminals of the speaker. Standard resistance: with Front Center Speaker: 7 to 9 ohms without Front Center Speaker: Approximately 2 ohms HINT: Perform the above inspection on both LH and RH sides. NG: REPLACE FRONT NO. 1 SPEAKER OK: GO TO next step.
  3. INSPECT FRONT NO. 2 SPEAKER Resistance check Measure the resistance between the terminals of the speaker. Standard resistance: with Front Center Speaker: 7 to 9 ohms without Front Center Speaker: Approximately 4 ohms HINT: Perform the above inspection on both LH and RH sides. NG: REPLACE FRONT NO. 2 SPEAKER OK: GO TO next step.
  4. INSPECT FRONT STEREO COMPONENT SPEAKER Check that the malfunction disappears when another speaker in good condition is installed. Standard: Malfunction disappears. HINT: Connect all the connectors to the front stereo component speakers. When there is a possibility that either the right or left front speaker is defective, inspect by interchanging the right one with the left one. Perform the above inspection on both LH and RH sides. OK: REPLACE FRONT STEREO COMPONENT SPEAKER NG: GO TO next step.
  5. INSPECT REAR SPEAKER Resistance check Measure the resistance between the terminals of the speakers. Standard resistance: with Front Center Speaker: 14 to 18 ohms without Front Center Speaker: Approximately 4 ohms HINT: Perform the above inspection on both LH and RH sides. NG: REPLACE REAR SPEAKER OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

The radio receiver sends a sound signal to the stereo component amplifier through this circuit.

The sound signal that has been sent is amplified by the stereo component amplifier, and then is sent to the speakers.

If there is an open or short in the circuit, sound cannot be heard from the speakers even if there is no malfunction in the stereo component amplifier or speakers.

Scheme 9

Scheme 9: WIRING DIAGRAM
Scheme 9: WIRING DIAGRAM

Scheme 10

Scheme 10: INSPECTION PROCEDURE
Scheme 10: INSPECTION PROCEDURE
  1. CHECK HARNESS AND CONNECTOR (RADIO RECEIVER - STEREO COMPONENT AMPLIFIER) Disconnect the connectors from the radio receiver and stereo component amplifier. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition L+ - L+ Always Below 1 ohms L- - L- Always Below 1 ohms R+ - R+ Always Below 1 ohms R- - R- Always Below 1 ohms SLD - SLD Always Below 1 ohms L+ - Body ground Always 10 kohms or higher L- - Body ground Always 10 kohms or higher R+ - Body ground Always 10 kohms or higher R- - Body ground Always 10 kohms or higher SLD - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

The television display assembly sends a sound signal to the radio receiver through this circuit.

The sound signal that has been sent is amplified by the stereo component amplifier, and then is sent to the speakers.

If there is an open or short in the circuit, sound cannot be heard from the speakers even if there is no malfunction in the stereo component amplifier, radio receiver, or speakers.

Scheme 11

Scheme 11: WIRING DIAGRAM
Scheme 11: WIRING DIAGRAM

Scheme 12

Scheme 12: INSPECTION PROCEDURE
Scheme 12: INSPECTION PROCEDURE

Scheme 13

Scheme 13
Scheme 13
  1. CHECK HARNESS AND CONNECTOR (RADIO RECEIVER - TELEVISION DISPLAY ASSEMBLY) Disconnect the connectors from the television display assembly and radio receiver. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition CDR+ - R+ Always Below 1 ohms CDR- - R- Always Below 1 ohms CDL+ - L+ Always Below 1 ohms CDL- - L- Always Below 1 ohms CSLD - SLD9 Always Below 1 ohms R- - Body ground Always 10 kohms or higher L+ - Body ground Always 10 kohms or higher L- - Body ground Always 10 kohms or higher R+ - Body ground Always 10 kohms or higher SLD9 - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: GO TO next step.
  2. INSPECT TELEVISION DISPLAY ASSEMBLY Reconnect the television display assembly connector. Check the waveform according to the conditions shown in the table below. Standard TESTER CONNECTION SPECIFIED CONDITION CHART Tester connection Condition Specified condition R+ - Body ground RSE sound is being produced A waveform synchronized with sound is output R- - Body ground RSE sound is being produced A waveform synchronized with sound is output L+ - Body ground RSE sound is being produced A waveform synchronized with sound is output L- - Body ground RSE sound is being produced A waveform synchronized with sound is output NG: REPLACE TELEVISION DISPLAY ASSEMBLY OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit sends a signal to the stereo component amplifier to mute noise. Because of that, the noise produced by changing the sound source ceases.

If there is an open in the circuit, noise can be heard from the speakers when changing the sound source. If there is a short in the circuit, even though the stereo component amplifier is normal, no sound, or only an extremely small sound, can be produced.

Scheme 14

Scheme 14: WIRING DIAGRAM
Scheme 14: WIRING DIAGRAM

Scheme 15

Scheme 15: INSPECTION PROCEDURE
Scheme 15: INSPECTION PROCEDURE

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17
  1. INSPECT STEREO COMPONENT AMPLIFIER Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION Tester connection Condition Specified condition MUTE - Body ground Turn ignition switch to the ACC position, Audio system is playing --> Changing Above 3.5 V --> Below 1 V OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE NG: GO TO next step.
  2. CHECK HARNESS AND CONNECTOR (RADIO RECEIVER - STEREO COMPONENT AMPLIFIER) Disconnect the radio receiver connector R2 and stereo component amplifier connector S27 or S29. Measure the resistance according to the values in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition MUTE - MUTE Always Below 1 ohms MUTE - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: GO TO next step.
  3. INSPECT STEREO COMPONENT AMPLIFIER (OUTPUT SIGNAL) Reconnect the stereo component amplifier connector S27 or S29. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION Tester connection Condition Specified condition MUTE - Body ground Turn the ignition switch to the ACC position, Audio system is playing Above 3.5 V NG: REPLACE STEREO COMPONENT AMPLIFIER OK: REPLACE RADIO RECEIVER

The radio receiver controls the volume according to the MUTE signal from the television display assembly.

The MUTE signal is sent to reduce noise and a popping sound generated when switching the mode, etc. If there is an open in the circuit, noise can be heard from the speakers when changing the sound source. If there is a short in the circuit, even though the radio receiver is normal, no sound, or only an extremely small sound, can be produced.

Scheme 18

Scheme 18: WIRING DIAGRAM
Scheme 18: WIRING DIAGRAM

Scheme 19

Scheme 19: INSPECTION PROCEDURE
Scheme 19: INSPECTION PROCEDURE

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21
  1. INSPECT TELEVISION DISPLAY ASSEMBLY Measure the voltage according to the value(s) in the table below. Standard voltage - DIAGNOSTIC TROUBLE CODE CHART Tester connection Condition Specified condition MUTE - Body ground Turn the ignition switch to the ACC position, RSE system is playing --> Changing mode Above 3.5 V --> Below 1 V OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE NG: GO TO next step.
  2. CHECK HARNESS AND CONNECTOR (RADIO RECEIVER - TELEVISION DISPLAY) Disconnect the radio receiver connector R3 and television display assembly connector R14. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition MUTE - MUTE Always Below 1 ohms MUTE - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: GO TO next step.
  3. INSPECT TELEVISION DISPLAY ASSEMBLY (OUTPUT SIGNAL) Reconnect the television display assembly connector R14. Measure the voltage according to the value(s) in the table below. Standard voltage - DIAGNOSTIC TROUBLE CODE CHART Tester connection Condition Specified condition MUTE - Body ground Turn ignition switch to ACC, RSE system is playing Above 3.5 V NG: REPLACE TELEVISION DISPLAY ASSEMBLY OK: REPLACE RADIO RECEIVER

Each unit of the audio system connected to the AVC-LAN (communication bus) transfers the signal of each switch by communication.

When a short to +B or short to ground occurs in this AVC-LAN, the audio system will not function normally as the communication is discontinued.

Scheme 22

Scheme 22: INSPECTION PROCEDURE
Scheme 22: INSPECTION PROCEDURE

Scheme 23

Scheme 23
Scheme 23
  1. INSPECT RADIO RECEIVER Disconnect the radio receiver connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition ATX+ - ATX- Always 60 to 80 ohms TX+ - TX- Always 60 to 80 ohms TX+ - TX- Always 60 to 80 ohms NG: REPLACE RADIO RECEIVER OK: GO TO next step.
  2. CHECK HARNESS AND CONNECTOR HINT: For details of the connectors, refer to the " «TERMINALS OF ECU» ". Referring to the AVC-LAN wiring diagram below, check all AVC-LAN circuits. Disconnect all connectors in all AVC-LAN circuits. Check for an open or short in all AVC-LAN circuits. OK: There is no open or short circuit. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit is necessary for the ASL (Auto Sound Leveliser) built into the stereo component amplifier.

Speed signals are received from the combination meter and used for the ASL.

The ASL function automatically adjusts the sound data in order to enable hearing the clear audio sound even when vehicle noise increases (as vehicle noise increases, the volume is turned up etc.).

HINT

  1. A voltage of 12 V or 5 V is output from each ECU and then input to the combination meter. The signal is changed to a pulse signal at the transistor in the combination meter. Each ECU controls the respective system based on the pulse signal.
  2. If a short occurs in an ECU, all systems in the diagram below will not operate normally.

Scheme 24

Scheme 24: WIRING DIAGRAM
Scheme 24: WIRING DIAGRAM

Scheme 25

Scheme 25: INSPECTION PROCEDURE
Scheme 25: INSPECTION PROCEDURE

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28
  1. OPERATION OF SPEEDOMETER Drive the vehicle and check if the function of the speedometer on the combination meter is normal. OK: Actual vehicle speed and the speed indicated on the speedometer are the same. HINT: The vehicle speed sensor is functioning normally when the indication on the speedometer is normal. NG: CHECK COMBINATION METER OK: GO TO next step.
  2. INSPECT STEREO COMPONENT AMPLIFIER Disconnect the stereo component amplifier connector S27 or S29. Measure the voltage. Jack up either one of the drive wheels. Move the shift lever to the neutral position. Turn the ignition switch to the ON position. Measure the voltage between terminal SPD of the wire harness connector and body ground when the drive wheels are turned slowly. OK: Voltage pulses as shown in the illustration. NG: GO TO step 3 OK: REPLACE STEREO COMPONENT AMPLIFIER
  3. CHECK HARNESS AND CONNECTOR (COMBINATION METER - STEREO COMPONENT AMPLIFIER) Disconnect the stereo component amplifier connector S27 or S29 and combination meter connector C8. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition SPD - C8-6 Ignition switch off Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: GO TO next step.
  4. CHECK HARNESS AND CONNECTOR (BODY GROUND - STEREO COMPONENT AMPLIFIER) Disconnect the stereo component amplifier connector S27 or S29. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition SPD - Body ground Ignition switch off 10 kohms or higher HINT: If the resistance between terminal SPD and body ground is less than 10 kohms, there may be a short in a wire harness, connector, or an ECU that is connected to the SPD signal wire. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OR CHECK EACH ECU OK: REPLACE COMBINATION METER

The body ECU sends a panel illumination signal to the radio receiver through this circuit.

The body ECU determines the ambient brightness based on the light level detected by the automatic light control sensor and performs dim control.

Scheme 29

Scheme 29: WIRING DIAGRAM
Scheme 29: WIRING DIAGRAM

Scheme 30

Scheme 30: INSPECTION PROCEDURE
Scheme 30: INSPECTION PROCEDURE

Scheme 31

Scheme 31
Scheme 31
  1. CHECK HARNESS AND CONNECTOR (RADIO RECEIVER - BODY ECU) Disconnect the radio receiver connector R4 and body ECU connector B5. Measure the resistance according to the values in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition ADIM - ACAN Always Below 1 ohms ADIM - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: GO TO next step.
  2. INSPECT RADIO RECEIVER Connect the body ECU connector. Turn the ignition switch to the ON position. Turn the light control switch to the TAIL or HEAD position. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION Tester connection Condition Specified condition ADIM - Body ground Light control switch in TAIL or HEAD 10 to 14 V NG: GO TO «LIGHTING SYSTEM» OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

Scheme 32

Scheme 32: INSPECTION PROCEDURE
Scheme 32: INSPECTION PROCEDURE

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34
  1. IDENTIFY THE COMPONENT SHOWN BY SUB-CODE Enter the diagnostic mode. Press the preset switch "3" to change to "Detailed Information Mode". Identify the component shown by the sub-code. HINT: "190 (radio receiver)" is the component shown by the sub-code in the example shown in the illustration. For details of the DTC display, refer to " «DTC CHECK / CLEAR» ".
  2. CHECK POWER SOURCE CIRCUIT OF COMPONENT SHOWN BY SUB-CODE Inspect the power source circuit of the component shown by the sub-code. If the power source circuit is operating normally, proceed to the next step. Component Table: COMPONENT CHART Component Proceed to Television display assembly (1B0) (See «TELEVISION DISPLAY POWER SOURCE CIRCUIT» ) Stereo component amplifier (440) (See «STEREO COMPONENT AMPLIFIER POWER SOURCE CIRCUIT» ) Radio receiver (190) (See «RADIO RECEIVER POWER SOURCE CIRCUIT» )
  3. INSPECT RADIO RECEIVER Disconnect the radio receiver connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition ATX+ - ATX- Always 60 to 80 ohms TX+ - TX- Always 60 to 80 ohms TX+ - TX- Always 60 to 80 ohms NG: REPLACE RADIO RECEIVER OK: GO TO next step.
  4. CHECK HARNESS AND CONNECTOR (GATEWAY ECU - COMPONENT SHOWN BY SUB-CODE) HINT: Start the check from the circuit that is near the component shown by the sub-code first. For details of the connectors, refer to the " «TERMINALS OF ECU» ". Referring to the AVC-LAN wiring diagram below, check the AVC-LAN circuit between the gateway ECU and the component shown by the sub-code. Disconnect all connectors between the gateway ECU and the component shown by the sub-code. Check for an open or short in the AVC-LAN circuit between the gateway ECU and the component shown by the sub-code. OK: There is no open or short circuit. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: GO TO next step.
  5. REPLACE COMPONENT SHOWN BY SUB-CODE Replace the component shown by the sub-code with a normal one and check if the same problem occurs again. OK: Same problem does not occur. NG: REPLACE GATEWAY ECU OK: END

Scheme 35

Scheme 35: INSPECTION PROCEDURE
Scheme 35: INSPECTION PROCEDURE

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37
  1. IDENTIFY THE COMPONENT SHOWN BY SUB-CODE Enter the diagnostic mode. Press the preset switch "3" to change to "Detailed Information Mode". Identify the component shown by the sub-code. HINT: "190 (radio receiver)" is the component shown by the sub-code in the example shown in the illustration. For details of the DTC display, refer to " «DTC CHECK / CLEAR» ".
  2. CHECK POWER SOURCE CIRCUIT OF COMPONENT SHOWN BY SUB-CODE Inspect the power source circuit of the component shown by the sub-code. If the power source circuit is operating normally, proceed to the next step. Component Table: COMPONENT CHART Component Proceed to Gateway ECU (1C6) (See «GATEWAY ECU POWER SOURCE CIRCUIT» ) Stereo component amplifier (440) (See «STEREO COMPONENT AMPLIFIER POWER SOURCE CIRCUIT» ) Television display assembly (1B0) (See «TELEVISION DISPLAY POWER SOURCE CIRCUIT» )
  3. INSPECT RADIO RECEIVER Disconnect the radio receiver connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition ATX+ - ATX- Always 60 to 80 ohms TX+ - TX- Always 60 to 80 ohms TX+ - TX- Always 60 to 80 ohms NG: REPLACE RADIO RECEIVER OK: GO TO next step.
  4. CHECK HARNESS AND CONNECTOR (RADIO RECEIVER - COMPONENT SHOWN BY SUB-CODE) HINT: Start the check from the circuit that is near the component shown by the sub-code first. For details of the connectors, refer to the " «TERMINALS OF ECU» ". Referring to the AVC-LAN wiring diagram below, check the AVC-LAN circuit between the radio receiver and the component shown by the sub-code. Disconnect all connectors between the radio receiver and the component shown by the sub-code. Check for an open or short in the AVC-LAN circuit between the radio receiver and the component shown by the sub-code. OK: There is no open or short circuit. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: GO TO next step.
  5. REPLACE COMPONENT SHOWN BY SUB-CODE Replace the component shown by the sub-code with a normal one and check if the same problem occurs again. OK: Same problem does not occur. NG: REPLACE RADIO RECEIVER OK: END

Scheme 38

Scheme 38: INSPECTION PROCEDURE
Scheme 38: INSPECTION PROCEDURE

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40
  1. IDENTIFY THE COMPONENT SHOWN BY SUB-CODE Enter the diagnostic mode. Press the preset switch "3" to change to "Detailed Information Mode". Identify the component shown by the sub-code. HINT: "190 (radio receiver)" is the component shown by the sub-code in the example shown in the illustration. For details of the DTC display, refer to " «DTC CHECK / CLEAR» ".
  2. CHECK POWER SOURCE CIRCUIT OF COMPONENT SHOWN BY SUB-CODE Inspect the power source circuit of the component shown by the sub-code. If the power source circuit is operating normally, proceed to the next step. Component Table: COMPONENT CHART Component Proceed to Gateway ECU (1C6) (See «GATEWAY ECU POWER SOURCE CIRCUIT» ) Television display assembly (1B0) (See «TELEVISION DISPLAY POWER SOURCE CIRCUIT» ) Radio receiver (190) (See «RADIO RECEIVER POWER SOURCE CIRCUIT» )
  3. INSPECT RADIO RECEIVER Disconnect the radio receiver connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition ATX+ - ATX- Always 60 to 80 ohms TX+ - TX- Always 60 to 80 ohms TX+ - TX- Always 60 to 80 ohms NG: REPLACE RADIO RECEIVER OK: GO TO next step.
  4. CHECK HARNESS AND CONNECTOR (STEREO COMPONENT AMPLIFIER - COMPONENT SHOWN BY SUB-CODE) HINT: Start the check from the circuit that is near the component shown by the sub-code first. For details of the connectors, refer to the " «TERMINALS OF ECU» ". Referring to the AVC-LAN wiring diagram below, check the AVC-LAN circuit between the stereo component amplifier and the component shown by the sub-code. Disconnect all connectors between the stereo component amplifier and the component shown by the sub-code. Check for an open or short in the AVC-LAN circuit between the stereo component amplifier and the component shown by the sub-code. OK: There is no open or short circuit. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: GO TO next step.
  5. REPLACE COMPONENT SHOWN BY SUB-CODE Replace the component shown by the sub-code with a normal one and check if the same problem occurs again. OK: Same problem does not occur. NG: REPLACE STEREO COMPONENT AMPLIFIER OK: END

Scheme 41

Scheme 41: INSPECTION PROCEDURE
Scheme 41: INSPECTION PROCEDURE

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43
  1. IDENTIFY THE COMPONENT SHOWN BY SUB-CODE Enter the diagnostic mode. Press the preset switch "3" to change to "Detailed Information Mode". Identify the component shown by the sub-code. HINT: "190 (radio receiver)" is the component shown by the sub-code in the example shown in the illustration. For details of the DTC display, refer to " «DTC CHECK / CLEAR» ".
  2. CHECK POWER SOURCE CIRCUIT OF COMPONENT SHOWN BY SUB-CODE Inspect the power source circuit of the component shown by the sub-code. If the power source circuit is operating normally, proceed to the next step. Component Table: COMPONENT CHART Component Proceed to Radio receiver (190) (See «RADIO RECEIVER POWER SOURCE CIRCUIT» ) Stereo component amplifier (440) (See «STEREO COMPONENT AMPLIFIER POWER SOURCE CIRCUIT» ) Gateway ECU (1C6) (See «GATEWAY ECU POWER SOURCE CIRCUIT» )
  3. INSPECT RADIO RECEIVER Disconnect the radio receiver connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition ATX+ - ATX- Always 60 to 80 ohms TX+ - TX- Always 60 to 80 ohms TX+ - TX- Always 60 to 80 ohms NG: REPLACE RADIO RECEIVER OK: GO TO next step.
  4. CHECK HARNESS AND CONNECTOR (TELEVISION DISPLAY ASSEMBLY - COMPONENT SHOWN BY SUB-CODE) HINT: Start the check from the circuit that is near the component shown by the sub-code first. For details of the connectors, refer to " «GATEWAY ECU POWER SOURCE CIRCUIT» ". Referring to the AVC-LAN wiring diagram below, check the AVC-LAN circuit between the television display assembly and the component shown by the sub-code. Disconnect all connectors between the television display assembly and the component shown by the sub-code. Check for an open or short in the AVC-LAN circuit between the television display assembly and the component shown by the sub-code. OK: There is no open or short circuit. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: GO TO next step.
  5. REPLACE COMPONENT SHOWN BY SUB-CODE Replace the component shown by the sub-code with a normal one and check if the same problem occurs again. OK: Same problem does not occur. NG: REPLACE TELEVISION DISPLAY ASSEMBLY OK: END

This circuit provides power to the radio receiver.

Scheme 44

Scheme 44: WIRING DIAGRAM
Scheme 44: WIRING DIAGRAM

Scheme 45

Scheme 45: INSPECTION PROCEDURE
Scheme 45: INSPECTION PROCEDURE
  1. INSPECT RADIO RECEIVER Disconnect the radio receiver connector R2. Measure the resistance according to the value in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition GND - Body ground Always Below 1 ohms Measure the voltage according to the values in the table below. Standard voltage VOLTAGE SPECIFICATION Tester connection Condition Specified condition B - GND Always 10 to 14 V ACC - GND Ignition switch in the ACC position 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit provides power to the stereo component amplifier.

Scheme 46

Scheme 46: WIRING DIAGRAM
Scheme 46: WIRING DIAGRAM

Scheme 47

Scheme 47: INSPECTION PROCEDURE
Scheme 47: INSPECTION PROCEDURE
  1. INSPECT STEREO COMPONENT AMPLIFIER Disconnect the stereo component amplifier connectors. Measure the resistance according to the values in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition GND - Body ground Always Below 1 ohms GND2 - Body ground (*2) Always Below 1 ohms Measure the voltage according to the values in the table below. Standard voltage VOLTAGE SPECIFICATION Tester connection Condition Specified condition B+ - GND ( (1) ) Always 10 to 14 V +B - GND ( (2) ) Always 10 to 14 V +B2 - GND ( (2) ) Always 10 to 14 V ACC - GND Ignition switch in the ACC position 10 to 14 V (1) with Front Center Speaker (2) without Front Center Speaker NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This is the power source circuit to operate the gateway ECU.

Scheme 48

Scheme 48: WIRING DIAGRAM
Scheme 48: WIRING DIAGRAM

Scheme 49

Scheme 49: INSPECTION PROCEDURE
Scheme 49: INSPECTION PROCEDURE
  1. INSPECT GATEWAY ECU Disconnect the gateway ECU connector G3. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition GND - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION Tester connection Condition Specified condition BATT - GND Always 10 to 14 V ACC - GND Ignition switch in the ACC position 10 to 14 V IG - GND Ignition switch in the ON position 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

SYSTEM DESCRIPTION

  1. OUTLINE As a unique feature of the Rear Seat Entertainment (RSE) system, the front and rear seat occupants can enjoy different audio-visual modes at the same time. Thus, this system offers enhanced entertainment to the rear seat occupants. The rear seat occupants can control the audio-visual modes with the remote controller (switch assembly), and listen to the audio using wired or wireless headphones. The RSE system is controlled by the television display assembly, and the communication between the audio head unit or multi-display and the television display assembly is established via an AVC-LAN (Audio Visual Communication-Local Area Network). The RSE system can play discs recorded entirely in the MP3 format, as well as music discs containing a mixture of CD data (CD-DA files) and MP3 data. HINT: MP3 is short for MPEG1 (Moving Picture Expert Group Phase 1) & 2 Audio Layer 3. It is an audio compression standard set by a working group (MPEG) of the ISO (International Standards Organization). MP3 is able to compress audio data to about 1/10 the level of a conventional disc.
  2. FUNCTION OF MAIN COMPONENTS MAIN COMPONENTS FUNCTION CHART Components Function Television display assembly Control panel DVD player Headphone terminal Displays DVD and video images. Receives signals from the remote controller. Outputs audio signals to the wireless headphones in the form of infrared signals. Outputs audio signals to the wired headphones that are connected. Adjusts the volume of the wired headphones in accordance with volume control. Multi-display ( (1) ) Displays DVD and video images in accordance with Video signals from the television display assembly. Enables or disables the function of the remote controller for the television display assembly. Radio receiver Receives audio signals from the television display assembly and outputs them to the stereo component amplifier. Enables or disables the function of the remote controller for the television display assembly. ( (2) ) Remote controller (Switch assembly) Outputs various control signals of the RSE system to the television display assembly in the form of infrared signals. Wireless headphones Receives the audio signals from the television display assembly in the form of infrared signals. Volume adjustment of the wireless headphones can be done by using the volume control on the wireless headphones. VTR terminal This terminal is for connecting a video player's video and audio output terminals. (1) with Navigation System (2) without Navigation System

This is the sound signal circuit from the video (video adapter) terminal to the television display assembly.

Scheme 50

Scheme 50: WIRING DIAGRAM
Scheme 50: WIRING DIAGRAM

Scheme 51

Scheme 51: INSPECTION PROCEDURE
Scheme 51: INSPECTION PROCEDURE

Scheme 52

Scheme 52
Scheme 52
  1. CHECK HARNESS AND CONNECTOR (TELEVISION DISPLAY ASSEMBLY - VIDEO TERMINAL) Disconnect the connectors from the video (video adapter) terminal and television display assembly. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition SGND - SGND Always Below 1 ohms VAR+ - R1+ Always Below 1 ohms VAL+ - L1+ Always Below 1 ohms ADPG - ADPG Always Below 1 ohms VAR+ - Body ground Always 10 kohms or higher VAL+ - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: GO TO next step.
  2. INSPECT VIDEO TERMINAL Reconnect the video (video adapter) terminal connector. Using an oscilloscope, check the signal waveform between each terminal and body ground according to the conditions in the table below. HINT: An external device system is playing (when the video (video adapter) terminal is used). Signal waveform SIGNAL WAVEFORM REFERENCE Tester connection Condition Specified condition VAL+ - Body ground Sound is being produced A waveform synchronized with sound is output VAR+ - Body ground Sound is being produced A waveform synchronized with sound is output NG: REPLACE VIDEO TERMINAL OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This is the display signal circuit from the video terminal to the television display assembly.

Scheme 53

Scheme 53: WIRING DIAGRAM
Scheme 53: WIRING DIAGRAM

Scheme 54

Scheme 54: INSPECTION PROCEDURE
Scheme 54: INSPECTION PROCEDURE

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56
  1. CHECK HARNESS AND CONNECTOR (TELEVISION DISPLAY ASSEMBLY - VIDEO TERMINAL) Disconnect the connectors from the video terminal and television display assembly. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition ADPG - ADPG Always Below 1 ohms VV+ - VV+ Always Below 1 ohms VV- - VV- Always Below 1 ohms CE - SGN2 Always Below 1 ohms VV+ - Body ground Always 10 kohms or higher VV- - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: GO TO next step.
  2. INSPECT VIDEO TERMINAL Reconnect the video (video adapter) terminal connector. Measure the waveform according to the table below. OK WAVEFORM REFERENCE Tester connection Condition Specified condition VV+ - VV- External device is playing A waveform synchronized with display signals is output HINT: The waveform pattern may differ from that shown in the illustration below due to differences in oscilloscope setting. A normal video terminal operating condition can be determined if any waveform is output. Reference: Oscilloscope waveform Terminal: VV+ - Body ground Setting: 200 mV/DIV, 10 μs/DIV Condition: DVD display is ON. NG: REPLACE VIDEO TERMINAL OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

This is the power source circuit to operate the television display assembly.

Scheme 57

Scheme 57: WIRING DIAGRAM
Scheme 57: WIRING DIAGRAM

Scheme 58

Scheme 58: INSPECTION PROCEDURE
Scheme 58: INSPECTION PROCEDURE
  1. INSPECT TELEVISION DISPLAY ASSEMBLY Disconnect the connector from the television display assembly. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition GND - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION Tester connection Condition Specified condition +B - GND Always 10 to 14 V ACC - GND Ignition switch in the ACC position 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

Scheme 59

Scheme 59: COMPONENTS
Scheme 59: COMPONENTS

Scheme 60

Scheme 60: REMOVAL
Scheme 60: REMOVAL

Scheme 61

Scheme 61
Scheme 61

Scheme 62

Scheme 62
Scheme 62
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
  2. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/gauges-instrument-panels/#instrument-panel) )
  3. REMOVE CONSOLE PANEL UPPER FRONT (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/gauges-instrument-panels/#instrument-panel) )
  4. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/gauges-instrument-panels/#instrument-panel) )
  5. REMOVE RADIO RECEIVER Remove the 4 bolts. Disengage the 2 claws and the 2 clips. Disconnect the connectors. Remove the radio receiver with bracket. Remove the 3 screws and the No.1 radio bracket. Remove the 3 screws and the No.2 radio bracket.

Scheme 63

Scheme 63: INSTALLATION
Scheme 63: INSTALLATION

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65
  1. INSTALL RADIO RECEIVER Install the No.2 radio bracket with the 3 bolts. Install the No. 1 radio bracket with the 3 bolts. Connect the connectors. Engage the 2 claws and the 2 clips. Install the radio receiver with bracket with the 4 bolts.
  2. INSTALL INSTRUMENT PANEL FINISH PANEL LOWER (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/gauges-instrument-panels/#instrument-panel) )
  3. INSTALL CONSOLE PANEL UPPER FRONT (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/gauges-instrument-panels/#instrument-panel) )
  4. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY
  5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  6. PERFORM INITIALIZATION NOTE: Some systems need initialization when disconnecting the cable from negative battery terminal. (See «INITIALIZATION» )

Scheme 66

Scheme 66: COMPONENTS
Scheme 66: COMPONENTS

Scheme 67

Scheme 67: REMOVAL
Scheme 67: REMOVAL
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
  2. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/gauges-instrument-panels/#instrument-panel) )
  3. REMOVE CONSOLE PANEL UPPER FRONT (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/gauges-instrument-panels/#instrument-panel) )
  4. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/gauges-instrument-panels/#instrument-panel) )
  5. REMOVE RADIO RECEIVER (See «REMOVAL» )
  6. REMOVE MULTI-DISPLAY Remove the 2 bolts and disengage the 4 clips. Disconnect the connectors. Remove the multi-display.

Scheme 68

Scheme 68: INSTALLATION
Scheme 68: INSTALLATION
  1. INSTALL MULTI-DISPLAY Connect the connectors. Engage the 4 clips and install the multi-display with the 2 bolts.
  2. INSTALL RADIO RECEIVER (See «INSTALLATION» )
  3. INSTALL INSTRUMENT PANEL FINISH PANEL LOWER (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/gauges-instrument-panels/#instrument-panel) )
  4. INSTALL CONSOLE PANEL UPPER FRONT (See «INSTALLATION»(/lexus/rx/ii-2006-2009/remont/gauges-instrument-panels/#instrument-panel) )
  5. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY
  6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
  7. PERFORM INITIALIZATION NOTE: Some systems need initialization when disconnecting the cable from negative battery terminal. (See «INITIALIZATION» )

Scheme 69

Scheme 69: COMPONENTS
Scheme 69: COMPONENTS

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71

Scheme 72

Scheme 72: REMOVAL
Scheme 72: REMOVAL

Scheme 73

Scheme 73
Scheme 73

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75
Scheme 75

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77
Scheme 77
  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
  2. REMOVE TONNEAU COVER ASSEMBLY
  3. REMOVE DECK BOARD SUB-ASSEMBLY (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
  4. REMOVE JACK CARRIER ASSEMBLY (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
  5. REMOVE FRONT DECK FLOOR BOX (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
  6. REMOVE REAR DECK FLOOR BOX (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
  7. REMOVE NO. 2 DECK BOARD SUB-ASSEMBLY (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
  8. REMOVE NO. 3 DECK BOARD SUB-ASSEMBLY (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
  9. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
  10. REMOVE SIDE DECK TRIM BOX LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
  11. REMOVE SIDE DECK TRIM BOX RH
  12. REMOVE REAR FLOOR FINISH SIDE PLATE LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
  13. REMOVE REAR FLOOR FINISH SIDE PLATE RH
  14. REMOVE SIDE DECK TRIM COVER LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
  15. REMOVE SIDE DECK TRIM COVER RH
  16. REMOVE REAR DOOR SCUFF PLATE LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
  17. REMOVE REAR SEAT SIDE COVER LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
  18. REMOVE REAR DOOR SCUFF PLATE RH
  19. REMOVE REAR SEAT SIDE COVER RH
  20. REMOVE ROPE HOOK (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
  21. REMOVE SIDE DECK TRIM PANEL ASSEMBLY LH (See «REMOVAL»(/lexus/rx/ii-2006-2009/remont/exteriorinterior-trim/#interior) )
  22. REMOVE SIDE DECK TRIM PANEL ASSEMBLY RH
  23. REMOVE REAR SEAT SUB FLOOR PANEL ASSEMBLY Remove the 3 nuts. Remove the 3 bolts and the rear seat sub floor panel assembly.
  24. REMOVE STEREO COMPONENT AMPLIFIER (w/o Front Center Speaker) Remove the 2 bolts and the nut. Disconnect each connector and remove the stereo component amplifier.
  25. REMOVE STEREO COMPONENT AMPLIFIER (w/ Front Center Speaker) Remove the 2 bolts and the nut. Disconnect each connector and remove the stereo component amplifier. Remove the 2 bolts and the No. 1 amplifier bracket. Remove the 2 bolts and the No. 2 amplifier bracket.

See also:
• AIRBAG SYSTEM
• REMOVAL
• REMOVAL

More articles — Audio / Visual
