Audio / Visual: Removal & Installation Lexus RX II рестайлинг

INSTALLATION

1. INSTALL STEREO COMPONENT AMPLIFIER (w/ Front Center Speaker) Install the No. 2 amplifier bracket with the 2 bolts. Install the No. 1 amplifier bracket with the 2 bolts. Connect each connector. Install the stereo component amplifier with the 2 bolts and the nut.
2. INSTALL STEREO COMPONENT AMPLIFIER (w/o Front Center Speaker) Connect each connector. Install the stereo component amplifier with the 2 bolts and the nut.
3. INSTALL REAR SEAT SUB FLOOR PANEL ASSEMBLY Install the 3 bolts. Install the rear seat sub floor panel assembly with the 3 nuts.
4. INSTALL SIDE DECK TRIM PANEL ASSEMBLY LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
5. INSTALL SIDE DECK TRIM PANEL ASSEMBLY RH
6. INSTALL ROPE HOOK (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
7. INSTALL REAR SEAT SIDE COVER LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
8. INSTALL REAR DOOR SCUFF PLATE LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
9. INSTALL REAR SEAT SIDE COVER RH
10. INSTALL REAR DOOR SCUFF PLATE RH
11. INSTALL SIDE DECK TRIM COVER LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
12. INSTALL SIDE DECK TRIM COVER RH
13. INSTALL REAR FLOOR FINISH SIDE PLATE LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
14. INSTALL REAR FLOOR FINISH SIDE PLATE RH
15. INSTALL SIDE DECK TRIM BOX LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
16. INSTALL SIDE DECK TRIM BOX RH
17. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
18. INSTALL NO. 3 DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
19. INSTALL NO. 2 DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
20. INSTALL REAR DECK FLOOR BOX (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
21. INSTALL FRONT DECK FLOOR BOX (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
22. INSTALL JACK CARRIER ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
23. INSTALL DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
24. INSTALL TONNEAU COVER ASSEMBLY
25. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
26. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the cable to the negative battery terminal (See «INITIALIZATION»(ref-282976-S16822617822008041400000) ).

Scheme 138

Scheme 139

Scheme 140

Scheme 141

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE TELEVISION BASE Disengage the 4 clips and remove the television base.
3. REMOVE TELEVISION DISPLAY Disconnect the connector. Remove the 4 bolts. Disengage the 2 claws and 2 clips, and then remove the television display.

Scheme 142

1. INSTALL TELEVISION DISPLAY Engage the 2 claws and the 2 clips. Install the television display with the 4 bolts. HINT: Tighten the bolts in the order shown in the illustration. Connect the connector.
2. INSTALL TELEVISION BASE Engage the 4 clips and install the television base.
3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
4. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the cable to the negative battery terminal. (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

Scheme 156

Scheme 157

Scheme 158

1. BOLT, SCREW AND NUT TABLE (See «REMOVAL»(ref-282983-S14613677712008041400000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait for 90 seconds after disconnecting the cable to prevent the airbag working. (See «AIRBAG SYSTEM»(ref-283011-S05295089212008041400000) )
3. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (See «REMOVAL»(ref-282983-S14613677712008041400000) )
4. REMOVE CONSOLE PANEL UPPER FRONT (See «REMOVAL»(ref-282983-S14613677712008041400000) )
5. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER (See «REMOVAL»(ref-282983-S14613677712008041400000) )
6. REMOVE RADIO RECEIVER (See «REMOVAL»(ref-283015-S03132760252008041400000) )
7. REMOVE CENTER CLUSTER INTEGRATION SWITCH (w/o Navigation System) (See «REMOVAL»(ref-283012-S26044168802008041400000) )
8. REMOVE MULTI-DISPLAY (w/ Navigation System) (See «REMOVAL»(ref-283015-S30546451792008041400000) )
9. REMOVE STEERING WHEEL NO.2 COVER LOWER (See «REMOVAL»(ref-283011-S03937588232008041400000) )
10. REMOVE STEERING WHEEL NO.3 COVER LOWER (See «REMOVAL»(ref-283011-S03937588232008041400000) )
11. REMOVE STEERING PAD (See «REMOVAL»(ref-283011-S03937588232008041400000) )
12. REMOVE STEERING WHEEL ASSEMBLY (See «REMOVAL»(ref-282987-S14044869812008041400000) )
13. REMOVE STEERING COLUMN COVER (See «REMOVAL»(ref-282987-S14044869812008041400000) )
14. REMOVE TILT & TELESCOPIC SWITCH (w/ Power Tilt and Power Telescopic) (See «REMOVAL»(ref-282987-S28963031112008041400000) )
15. REMOVE TURN SIGNAL SWITCH ASSEMBLY WITH SPIRAL CABLE SUB-ASSEMBLY (See «REMOVAL»(ref-282987-S28963031112008041400000) )
16. REMOVE FRONT DOOR SCUFF PLATE LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
17. REMOVE COWL SIDE TRIM SUB-ASSEMBLY LH (See «REMOVAL»(ref-282983-S14613677712008041400000) )
18. REMOVE DRIVER SIDE KNEE AIRBAG ASSEMBLY (See «REMOVAL»(ref-283011-S00687956492008041400000) )
19. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-282983-S14613677712008041400000) )
20. REMOVE COMBINATION METER ASSEMBLY (See «REMOVAL»(ref-282979-S28121840672008041400000) )
21. REMOVE FRONT DOOR SCUFF PLATE RH (See «REMOVAL»(ref-282983-S14613677712008041400000) )
22. REMOVE COWL SIDE TRIM SUB-ASSEMBLY RH (See «REMOVAL»(ref-282983-S14613677712008041400000) )
23. REMOVE INSTRUMENT PANEL NO.2 UNDER COVER SUB-ASSY (See «REMOVAL»(ref-282983-S14613677712008041400000) )
24. REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY (See «REMOVAL»(ref-282983-S14613677712008041400000) )
25. REMOVE FLOOR CARPET COVER CENTER LH (See «REMOVAL»(ref-282983-S14613677712008041400000) )
26. REMOVE FLOOR CARPET COVER CENTER RH (See «REMOVAL»(ref-282983-S14613677712008041400000) )
27. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER CENTER (See «REMOVAL»(ref-282983-S14613677712008041400000) )
28. REMOVE FRONT PILLAR GARNISH LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
29. REMOVE FRONT PILLAR GARNISH RH (See «REMOVAL»(ref-282983-S14613677712008041400000) )
30. REMOVE INSTRUMENT PANEL NO.1 REGISTER ASSEMBLY (See «REMOVAL»(ref-282983-S14613677712008041400000) )
31. REMOVE INSTRUMENT PANEL NO.1 REGISTER ASSEMBLY LOWER (See «REMOVAL»(ref-282983-S14613677712008041400000) )
32. REMOVE INSTRUMENT PANEL ASSEMBLY (See «REMOVAL»(ref-282983-S14613677712008041400000) )
33. REMOVE NO.2 RADIO ANTENNA CORD (w/o Navigation System) Disengage the 6 clamps and remove the No.2 radio antenna cord.
34. REMOVE NO.2 RADIO ANTENNA CORD (w/ Navigation System) Remove the 2 screws and the navigation antenna. Disengage the 6 clamps and remove the No.2 radio antenna cord.
35. REMOVE TONNEAU COVER ASSEMBLY
36. REMOVE DECK BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
37. REMOVE JACK CARRIER SUPPORT
38. REMOVE JACK ASSEMBLY
39. REMOVE JACK CARRIER ASSEMBLY
40. REMOVE DECK FLOOR BOX FRONT (See «REMOVAL»(ref-282982-S27013933812008041400000) )
41. REMOVE DECK FLOOR BOX REAR (See «REMOVAL»(ref-282982-S27013933812008041400000) )
42. REMOVE DECK NO.3 BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
43. REMOVE DECK NO.2 BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
44. REMOVE BACK DOOR WEATHERSTRIP
45. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(ref-282982-S27013933812008041400000) )
46. REMOVE DECK SIDE TRIM BOX LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
47. REMOVE DECK SIDE TRIM BOX RH
48. REMOVE REAR SEAT TRACK BRACKET COVER (See «REMOVAL»(ref-283009-S07504066712008041400000) )
49. REMOVE REAR SEAT ASSEMBLY LH (See «REMOVAL»(ref-283009-S07504066712008041400000) )
50. REMOVE REAR SEAT TRACK BRACKET COVER (See «REMOVAL»(ref-283009-S26161021142008041400000) )
51. REMOVE REAR SEAT ASSEMBLY RH (See «REMOVAL»(ref-283009-S26161021142008041400000) )
52. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP LH
53. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP RH
54. REMOVE REAR DOOR SCUFF PLATE LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
55. REMOVE REAR DOOR SCUFF PLATE RH
56. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH
57. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
58. REMOVE LAP BELT OUTER ANCHOR COVER (See «REMOVAL»(ref-282982-S27013933812008041400000) )
59. SEPARATE FRONT SEAT OUTER BELT ASSEMBLY LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
60. SEPARATE FRONT SEAT OUTER BELT ASSEMBLY RH
61. REMOVE CENTER PILLAR GARNISH LOWER LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
62. REMOVE CENTER PILLAR GARNISH LOWER RH
63. REMOVE CENTER PILLAR GARNISH LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
64. REMOVE CENTER PILLAR GARNISH RH
65. REMOVE DECK SIDE TRIM COVER LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
66. REMOVE DECK SIDE TRIM COVER RH
67. SEPARATE REAR NO.1 SEAT BELT ASSEMBLY OUTER LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
68. SEPARATE REAR NO.1 SEAT BELT ASSEMBLY OUTER RH
69. REMOVE REAR SEAT SIDE COVER LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
70. REMOVE REAR SEAT SIDE COVER RH
71. REMOVE REAR FLOOR FINISH SIDE PLATE LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
72. REMOVE REAR FLOOR FINISH SIDE PLATE RH
73. REMOVE ROPE HOOK (See «REMOVAL»(ref-282982-S27013933812008041400000) )
74. REMOVE DECK TRIM SIDE PANEL ASSEMBLY LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
75. REMOVE DECK TRIM SIDE PANEL ASSEMBLY RH
76. REMOVE NO.2 ROOM LIGHT ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
77. REMOVE ROOF SIDE GARNISH ASSEMBLY INNER LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
78. REMOVE ROOF SIDE GARNISH ASSEMBLY INNER RH
79. REMOVE TELEVISION BASE (w/ Rear Seat Entertainment System) (See «TELEVISION DISPLAY»(ref-283015-S09592654432008041400000) )
80. REMOVE TELEVISION DISPLAY (w/ Rear Seat Entertainment System) (See «REMOVAL»(ref-283015-S16210194742008041400000) )
81. REMOVE ASSIST GRIP SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
82. REMOVE RAIN SENSOR (w/ Rain Sensor) (See «RAIN SENSOR»(ref-282998-S34960244762008041400000) )
83. REMOVE NO.1 ROOM LIGHT ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
84. REMOVE MAP LIGHT ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
85. REMOVE LH VISOR ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
86. REMOVE RH VISOR ASSEMBLY
87. REMOVE VISOR HOLDER (See «REMOVAL»(ref-282982-S27013933812008041400000) )
88. REMOVE ROOF HEADLINING ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
89. REMOVE RADIO ANTENNA CORD Remove the tape and radio antenna cord from the roof headlining assembly.
90. REMOVE BACK WINDOW PANEL TRIM UPPER (w/o Power Back Door) (See «DISASSEMBLY»(ref-283005-S05685971372008041400000) )
91. REMOVE BACK DOOR TRIM BOARD LH (w/ Power Back Door) (See «DISASSEMBLY»(ref-283005-S05685971372008041400000) )
92. REMOVE BACK WINDOW PANEL TRIM UPPER (w/ Power Back Door) (See «DISASSEMBLY»(ref-283005-S05685971372008041400000) )
93. REMOVE BACK DOOR TRIM PANEL ASSEMBLY UPPER (See «DISASSEMBLY»(ref-283005-S05685971372008041400000) )
94. REMOVE BACK DOOR TRIM PANEL ASSEMBLY (See «DISASSEMBLY»(ref-283005-S05685971372008041400000) )
95. REMOVE BACK DOOR TRIM COVER LH (See «DISASSEMBLY»(ref-283005-S05685971372008041400000) )
96. REMOVE BACK DOOR TRIM COVER RH (See «DISASSEMBLY»(ref-283005-S05685971372008041400000) )
97. REMOVE NO.3 RADIO ANTENNA CORD Disconnect the connector. Disengage the 11 clamps. Remove the bolt and the No.3 radio antenna cord.

1. INSTALL NO.3 RADIO ANTENNA CORD Install the No.3 radio antenna cord with the bolt. Engage the 11 clamps and connect the connector.
2. INSTALL BACK DOOR TRIM COVER RH
3. INSTALL BACK DOOR TRIM PANEL ASSEMBLY
4. INSTALL BACK DOOR TRIM PANEL ASSEMBLY UPPER
5. INSTALL WINDOW PANEL TRIM UPPER (w/ Power Back Door)
6. INSTALL BACK DOOR TRIM BOARD LH (w/ Power Back Door)
7. INSTALL BACK WINDOW PANEL TRIM UPPER (w/o Power Back Door)
8. INSTALL RADIO ANTENNA CORD Tape the radio antenna cord at the position of the roof headlining assembly shown in the illustration.
9. INSTALL ROOF HEADLINING ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
10. INSTALL VISOR HOLDER
11. INSTALL LH VISOR ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
12. INSTALL RH VISOR ASSEMBLY
13. INSTALL MAP LIGHT ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
14. INSTALL NO.1 ROOM LIGHT ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
15. INSTALL RAIN SENSOR (w/ Rain Sensor) (See «RAIN SENSOR»(ref-282998-S34960244762008041400000) )
16. INSTALL ASSIST GRIP SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
17. INSTALL TELEVISION DISPLAY (w/ Rear Seat Entertainment System) (See «INSTALLATION»(ref-283015-S42102710622008041400000) )
18. INSTALL TELEVISION BASE (w/Rear Seat Entertainment System) (See «TELEVISION DISPLAY»(ref-283015-S09592654432008041400000) )
19. INSTALL ROOF SIDE GARNISH ASSEMBLY INNER LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
20. INSTALL ROOF SIDE GARNISH ASSEMBLY INNER RH
21. INSTALL NO.2 ROOM LIGHT ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
22. INSTALL DECK TRIM SIDE PANEL ASSEMBLY LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
23. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH
24. INSTALL ROPE HOOK (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
25. INSTALL REAR FLOOR FINISH SIDE PLATE LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
26. INSTALL REAR FLOOR FINISH SIDE PLATE RH
27. INSTALL REAR SEAT SIDE COVER LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
28. INSTALL REAR SEAT SIDE COVER RH
29. INSTALL REAR NO.1 SEAT BELT ASSY OUTER LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
30. INSTALL REAR NO.1 SEAT BELT ASSY OUTER RH
31. INSTALL DECK SIDE TRIM COVER LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
32. INSTALL DECK SIDE TRIM COVER RH
33. INSTALL CENTER PILLAR GARNISH LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
34. INSTALL CENTER PILLAR GARNISH RH
35. INSTALL CENTER PILLAR GARNISH LOWER LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
36. INSTALL CENTER PILLAR GARNISH LOWER RH
37. INSTALL FRONT SEAT OUTER BELT ASSEMBLY LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
38. INSTALL FRONT SEAT OUTER BELT ASSEMBLY RH
39. INSTALL LAP BELT OUTER ANCHOR COVER (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
40. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP LH
41. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP RH
42. INSTALL REAR DOOR SCUFF PLATE LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
43. INSTALL REAR DOOR SCUFF PLATE RH
44. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH
45. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP RH
46. INSTALL REAR SEAT ASSEMBLY LH (See «INSTALLATION»(ref-283009-S24398621582008041400000) )
47. INSTALL REAR SEAT TRACK BRACKET COVER
48. INSTALL REAR SEAT ASSEMBLY RH (See «INSTALLATION»(ref-283009-S26085320402008041400000) )
49. INSTALL REAR SEAT TRACK BRACKET COVER
50. INSTALL DECK SIDE TRIM BOX LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
51. INSTALL DECK SIDE TRIM BOX RH
52. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
53. INSTALL BACK DOOR WEATHERSTRIP
54. INSTALL NO.2 DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
55. INSTALL NO.3 DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
56. INSTALL DECK FLOOR BOX REAR (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
57. INSTALL DECK FLOOR BOX FRONT (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
58. INSTALL DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
59. INSTALL TONNEAU COVER ASSEMBLY
60. INSTALL NO.2 RADIO ANTENNA CORD (w/ navigation system) Engage the 6 clamps and install the No.2 radio antenna cord. Install the navigation antenna with the 2 screws.
61. INSTALL NO.2 RADIO ANTENNA CORD (w/o Navigation System) Engage the 6 clamps and install the No.2 radio antenna cord.
62. INSTALL INSTRUMENT PANEL ASSEMBLY (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
63. INSTALL INSTRUMENT PANEL REGISTER NO.1 ASSEMBLY LOWER (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
64. INSTALL INSTRUMENT PANEL NO.1 REGISTER ASSEMBLY (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
65. INSTALL FRONT PILLAR GARNISH LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
66. INSTALL FRONT PILLAR GARNISH RH (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
67. INSTALL INSTRUMENT PANEL FINISH PANEL LOWER CENTER (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
68. INSTALL FLOOR CARPET COVER CENTER LH (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
69. INSTALL FLOOR CARPET COVER CENTER RH (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
70. INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
71. INSTALL INSTRUMENT PANEL NO.2 UNDER COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
72. INSTALL COWL SIDE TRIM SUB-ASSEMBLY RH (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
73. INSTALL FRONT DOOR SCUFF PLATE RH (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
74. INSTALL COMBINATION METER ASSEMBLY (See «INSTALLATION»(ref-282979-S29399985512008041400000) )
75. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
76. INSTALL DRIVER SIDE KNEE AIRBAG ASSEMBLY (See «INSTALLATION»(ref-283011-S28375978062008041400000) )
77. INSTALL INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY LOWER (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
78. INSTALL COWL SIDE TRIM SUB-ASSEMBLY LH (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
79. INSTALL FRONT DOOR SCUFF PLATE LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
80. INSTALL TURN SIGNAL SWITCH ASSEMBLY WITH SPIRAL CABLE SUB-ASSEMBLY (See «INSTALLATION»(ref-282987-S24791530072008041400000) )
81. INSTALL TILT & TELESCOPIC SWITCH (w/ Power Tilt and Power Telescopic) (See «INSTALLATION»(ref-282987-S32261621332008041400000) )
82. INSTALL STEERING COLUMN COVER (See «INSTALLATION»(ref-282987-S24791530072008041400000) )
83. INSTALL STEERING WHEEL ASSEMBLY (See «INSTALLATION»(ref-282987-S24791530072008041400000) )
84. INSTALL STEERING PAD (See «INSTALLATION»(ref-283011-S23707824402008041400000) )
85. INSTALL STEERING WHEEL NO.3 COVER LOWER (See «INSTALLATION»(ref-283011-S23707824402008041400000) )
86. INSTALL STEERING WHEEL NO.2 COVER LOWER (See «INSTALLATION»(ref-283011-S23707824402008041400000) )
87. INSTALL MULTI-DISPLAY (w/ Navigation System) (See «INSTALLATION»(ref-283015-S05130167002008041400000) )
88. INSTALL CENTER CLUSTER INTEGRATION SWITCH (w/o Navigation System) (See «INSTALLATION»(ref-283012-S37767002692008041400000) )
89. INSTALL RADIO RECEIVER (See «INSTALLATION»(ref-283015-S06499123572008041400000) )
90. INSTALL INSTRUMENT PANEL FINISH PANEL LOWER (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
91. INSTALL CONSOLE PANEL UPPER FRONT (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
92. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY
93. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
94. PERFORM INITIALIZATION NOTE: Some systems need initialization when disconnecting the cable from negative battery terminal. (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )
95. INSPECT STEERING PAD (See «INSTALLATION»(ref-283011-S23707824402008041400000) )
96. INSPECT SRS WARNING LIGHT (See «DIAGNOSIS SYSTEM»(ref-283011-S15035190092008041400000) )

Scheme 159

Scheme 160

1. REMOVE RADIO ANTENNA POLE Remove the radio antenna pole turning it in the direction of the arrow shown in the illustration.

Scheme 161

1. INSTALL RADIO ANTENNA POLE Install the radio antenna pole turning it in the direction of the arrow shown in the illustration.

Scheme 162

Scheme 163

Scheme 164

Scheme 165

Scheme 166

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE TONNEAU COVER ASSEMBLY
3. REMOVE DECK BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
4. REMOVE JACK CARRIER SUPPORT
5. REMOVE JACK ASSEMBLY
6. REMOVE JACK CARRIER ASSEMBLY
7. REMOVE DECK FLOOR BOX FRONT (See «REMOVAL»(ref-282982-S27013933812008041400000) )
8. REMOVE DECK FLOOR BOX REAR (See «REMOVAL»(ref-282982-S27013933812008041400000) )
9. REMOVE DECK NO.3 BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
10. REMOVE DECK NO.2 BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
11. REMOVE BACK DOOR WEATHERSTRIP
12. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(ref-282982-S27013933812008041400000) )
13. REMOVE DECK SIDE TRIM BOX LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
14. REMOVE DECK SIDE TRIM BOX RH
15. REMOVE REAR SEAT TRACK BRACKET COVER (See «REMOVAL»(ref-283009-S07504066712008041400000) )
16. REMOVE REAR SEAT ASSEMBLY LH (See «REMOVAL»(ref-283009-S07504066712008041400000) )
17. REMOVE REAR SEAT TRACK BRACKET COVER (See «REMOVAL»(ref-283009-S26161021142008041400000) )
18. REMOVE REAR SEAT ASSEMBLY RH (See «REMOVAL»(ref-283009-S26161021142008041400000) )
19. REMOVE FRONT DOOR SCUFF PLATE LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
20. REMOVE FRONT DOOR SCUFF PLATE RH
21. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP LH
22. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP RH
23. REMOVE REAR DOOR SCUFF PLATE LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
24. REMOVE REAR DOOR SCUFF PLATE RH
25. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH
26. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
27. REMOVE FRONT PILLAR GARNISH LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
28. REMOVE FRONT PILLAR GARNISH RH
29. REMOVE LAP BELT OUTER ANCHOR COVER (See «REMOVAL»(ref-282982-S27013933812008041400000) )
30. SEPARATE FRONT SEAT OUTER BELT ASSEMBLY LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
31. SEPARATE FRONT SEAT OUTER BELT ASSEMBLY RH
32. REMOVE CENTER PILLAR GARNISH LOWER LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
33. REMOVE CENTER PILLAR GARNISH LOWER RH
34. REMOVE CENTER PILLAR GARNISH LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
35. REMOVE CENTER PILLAR GARNISH RH
36. REMOVE DECK SIDE TRIM COVER LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
37. REMOVE DECK SIDE TRIM COVER RH
38. SEPARATE REAR NO.1 SEAT BELT ASSEMBLY OUTER LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
39. SEPARATE REAR NO.1 SEAT BELT ASSEMBLY OUTER RH
40. REMOVE REAR SEAT SIDE COVER LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
41. REMOVE REAR SEAT SIDE COVER RH
42. REMOVE REAR FLOOR FINISH SIDE PLATE LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
43. REMOVE REAR FLOOR FINISH SIDE PLATE RH
44. REMOVE ROPE HOOK (See «REMOVAL»(ref-282982-S27013933812008041400000) )
45. REMOVE DECK TRIM SIDE PANEL ASSEMBLY LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
46. REMOVE DECK TRIM SIDE PANEL ASSEMBLY RH
47. REMOVE NO.2 ROOM LIGHT ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
48. REMOVE ROOF SIDE GARNISH ASSEMBLY INNER LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
49. REMOVE ROOF SIDE GARNISH ASSEMBLY INNER RH
50. REMOVE TELEVISION BASE (w/Rear Seat Entertainment System) (See «TELEVISION DISPLAY»(ref-283015-S09592654432008041400000) )
51. REMOVE TELEVISION DISPLAY (w/ Rear Seat Entertainment System) (See «REMOVAL»(ref-283015-S16210194742008041400000) )
52. REMOVE ASSIST GRIP SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
53. REMOVE RAIN SENSOR (w/ Rain Sensor) (See «RAIN SENSOR»(ref-282998-S34960244762008041400000) )
54. REMOVE NO.1 ROOM LIGHT ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
55. REMOVE MAP LIGHT ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
56. REMOVE LH VISOR ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
57. REMOVE RH VISOR ASSEMBLY
58. REMOVE VISOR HOLDER (See «REMOVAL»(ref-282982-S27013933812008041400000) )
59. REMOVE ROOF HEADLINING ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
60. REMOVE AMPLIFIER ANTENNA Disconnect the 2 connectors and disengage the 3 clamps. Remove the antenna nut. Disengage the 2 claws and remove the amplifier antenna.

Scheme 167

1. INSTALL AMPLIFIER ANTENNA Set the amplifier antenna into the hole on the roof, and place the antenna cord in the cutout on the amplifier antenna. Install the amplifier antenna with the antenna nut. Torque: 4.5 N*m (46 kgf*cm, 40 in.*lbf) Engage the 3 clamps and connect the 2 connectors.
2. INSTALL RADIO ANTENNA POLE (See «RADIO ANTENNA POLE»(ref-283015-S26154844132008041400000) )
3. INSTALL ROOF HEADLINING ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
4. INSTALL VISOR HOLDER
5. INSTALL LH VISOR ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
6. INSTALL RH VISOR ASSEMBLY
7. INSTALL MAP LIGHT ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
8. INSTALL NO.1 ROOM LIGHT ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
9. INSTALL RAIN SENSOR (w/ Rain Sensor) (See «RAIN SENSOR»(ref-282998-S34960244762008041400000) )
10. INSTALL ASSIST GRIP SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
11. INSTALL TELEVISION DISPLAY (w/ Rear Seat Entertainment System) (See «INSTALLATION»(ref-283015-S42102710622008041400000) )
12. INSTALL TELEVISION BASE (w/Rear Seat Entertainment System) (See «TELEVISION DISPLAY»(ref-283015-S09592654432008041400000) )
13. INSTALL ROOF SIDE GARNISH ASSEMBLY INNER LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
14. INSTALL ROOF SIDE GARNISH ASSEMBLY INNER RH
15. INSTALL NO.2 ROOM LIGHT ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
16. INSTALL DECK TRIM SIDE PANEL ASSEMBLY LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
17. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH
18. INSTALL ROPE HOOK (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
19. INSTALL REAR FLOOR FINISH SIDE PLATE LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
20. INSTALL REAR FLOOR FINISH SIDE PLATE RH
21. INSTALL REAR SEAT SIDE COVER LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
22. INSTALL REAR SEAT SIDE COVER RH
23. INSTALL REAR NO.1 SEAT BELT ASSEMBLY OUTER LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
24. INSTALL REAR NO.1 SEAT BELT ASSEMBLY OUTER RH
25. INSTALL DECK SIDE TRIM COVER LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
26. INSTALL DECK SIDE TRIM COVER RH
27. INSTALL CENTER PILLAR GARNISH LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
28. INSTALL CENTER PILLAR GARNISH RH
29. INSTALL CENTER PILLAR GARNISH LOWER LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
30. INSTALL CENTER PILLAR GARNISH LOWER RH
31. INSTALL FRONT SEAT OUTER BELT ASSEMBLY LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
32. INSTALL FRONT SEAT OUTER BELT ASSEMBLY RH
33. INSTALL LAP BELT OUTER ANCHOR COVER (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
34. INSTALL FRONT PILLAR GARNISH LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
35. INSTALL FRONT PILLAR GARNISH RH
36. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP LH
37. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP RH
38. INSTALL REAR DOOR SCUFF PLATE LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
39. INSTALL REAR DOOR SCUFF PLATE RH
40. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP RH
41. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH
42. INSTALL FRONT DOOR SCUFF PLATE LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
43. INSTALL FRONT DOOR SCUFF PLATE RH
44. INSTALL REAR SEAT ASSEMBLY LH (See «INSTALLATION»(ref-283009-S24398621582008041400000) )
45. INSTALL REAR SEAT TRACK BRACKET COVER
46. INSTALL REAR SEAT ASSEMBLY RH (See «INSTALLATION»(ref-283009-S26085320402008041400000) )
47. INSTALL REAR SEAT TRACK BRACKET COVER
48. INSTALL DECK SIDE TRIM BOX LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
49. INSTALL DECK SIDE TRIM BOX RH
50. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
51. INSTALL BACK DOOR WEATHERSTRIP
52. INSTALL DECK NO.3 BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
53. INSTALL DECK NO.2 BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
54. INSTALL DECK FLOOR BOX REAR (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
55. INSTALL DECK FLOOR BOX FRONT (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
56. INSTALL JACK CARRIER ASSEMBLY
57. INSTALL JACK ASSEMBLY
58. INSTALL JACK CARRIER SUPPORT
59. INSTALL DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
60. INSTALL TONNEAU COVER ASSEMBLY
61. INSPECT SLIDE ADJUSTER LOCK (See «INSTALLATION»(ref-283009-S24398621582008041400000) )
62. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
63. PERFORM INITIALIZATION NOTE: Some systems need initialization when disconnecting the cable from negative battery terminal. (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )

Scheme 168

Scheme 169

Scheme 170

1. INSPECT VOLTAGE INVERTER HINT: Remove interior parts so that the voltage inverter can be seen. Disconnect the voltage inverter connector. Measure the voltage according to the values in the fable below. Input voltage INPUT VOLTAGE SPECIFICATION Tester connection Condition Specified condition 16 (V13-1) - E (V13-4) Ignition switch ON 10 to 16 V E (V13-4) - Body ground Always Below 1 V If the result is not as specified, repair or replace harness or connector. Reconnect the voltage inverter connector. Measure the voltage according to the values in the table below. Output voltage OUTPUT VOLTAGE SPECIFICATION Tester connection Condition Specified condition AC1 (V13-3) - AC2 (V13-7) Ignition switch ON Main switch ON AC 115 V If the result is not as specified, replace the voltage inverter.

Scheme 171

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE REAR DOOR SCUFF PLATE LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
3. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH
4. REMOVE DECK BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
5. REMOVE TONNEAU COVER ASSEMBLY
6. REMOVE JACK CARRIER SUPPORT
7. REMOVE JACK ASSEMBLY
8. REMOVE JACK CARRIER ASSEMBLY
9. REMOVE DECK FLOOR BOX FRONT (See «REMOVAL»(ref-282982-S27013933812008041400000) )
10. REMOVE DECK FLOOR BOX REAR (See «REMOVAL»(ref-282982-S27013933812008041400000) )
11. REMOVE DECK NO.2 BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
12. REMOVE DECK NO.3 BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
13. REMOVE BACK DOOR WEATHERSTRIP
14. REMOVE DECK SIDE TRIM BOX LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
15. REMOVE DECK SIDE TRIM BOX RH
16. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(ref-282982-S27013933812008041400000) )
17. REMOVE REAR FLOOR FINISH SIDE PLATE LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
18. REMOVE DECK SIDE TRIM COVER LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
19. SEPARATE REAR NO.1 SEAT BELT ASSEMBLY OUTER LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
20. REMOVE REAR SEAT SIDE COVER LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
21. REMOVE ROPE HOOK (See «REMOVAL»(ref-282982-S27013933812008041400000) )
22. REMOVE DECK TRIM SIDE PANEL ASSEMBLY LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
23. REMOVE VOLTAGE INVERTER Remove the 3 nuts and the voltage inverter. Disconnect the connector.

1. INSTALL VOLTAGE INVERTER Connect the connector. Install the voltage inverter with the 3 nuts.
2. INSTALL DECK TRIM SIDE PANEL ASSEMBLY LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
3. INSTALL ROPE HOOK (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
4. INSTALL REAR SEAT SIDE COVER LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
5. INSTALL REAR NO.1 SEAT BELT ASSEMBLY OUTER LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
6. INSTALL DECK SIDE TRIM COVER LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
7. INSTALL REAR FLOOR FINISH SIDE PLATE LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
8. INSTALL REAR FLOOR FINISH PLATE
9. INSTALL DECK SIDE TRIM BOX LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
10. INSTALL DECK SIDE TRIM BOX RH
11. INSTALL BACK DOOR WEATHERSTRIP
12. INSTALL DECK NO.3 BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
13. INSTALL DECK NO.2 BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
14. INSTALL DECK FLOOR BOX REAR (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
15. INSTALL DECK FLOOR BOX FRONT (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
16. INSTALL JACK CARRIER ASSEMBLY
17. INSTALL JACK ASSEMBLY
18. INSTALL JACK CARRIER SUPPORT
19. INSTALL TONNEAU COVER ASSEMBLY
20. INSTALL DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
21. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP LH
22. INSTALL REAR DOOR SCUFF PLATE LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
23. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
24. PERFORM INITIALIZATION NOTE: Some systems need initialization when disconnecting the cable from negative battery terminal. (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )

Scheme 172

Scheme 173

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE REAR DOOR SCUFF PLATE RH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
3. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
4. REMOVE DECK BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
5. REMOVE TONNEAU COVER ASSEMBLY
6. REMOVE JACK CARRIER SUPPORT
7. REMOVE JACK ASSEMBLY
8. REMOVE JACK CARRIER ASSEMBLY
9. REMOVE DECK FLOOR BOX FRONT (See «REMOVAL»(ref-282982-S27013933812008041400000) )
10. REMOVE DECK FLOOR BOX REAR (See «REMOVAL»(ref-282982-S27013933812008041400000) )
11. REMOVE DECK NO.2 BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
12. REMOVE DECK NO.3 BOARD SUB-ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
13. REMOVE BACK DOOR WEATHERSTRIP
14. REMOVE DECK SIDE TRIM BOX LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
15. REMOVE DECK SIDE TRIM BOX RH
16. REMOVE DECK SIDE TRIM COVER RH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
17. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(ref-282982-S27013933812008041400000) )
18. REMOVE REAR FLOOR FINISH SIDE PLATE RH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
19. SEPARATE REAR NO.1 SEAT BELT ASSEMBLY OUTER RH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
20. REMOVE REAR SEAT SIDE COVER RH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
21. REMOVE ROPE HOOK (See «REMOVAL»(ref-282982-S27013933812008041400000) )
22. REMOVE DECK TRIM SIDE PANEL ASSEMBLY RH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
23. REMOVE NO.2 ROOM LIGHT ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
24. REMOVE NO.1 TONNEAU COVER HOLDER CAP
25. REMOVE ROOF SIDE GARNISH ASSEMBLY INNER RH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
26. REMOVE VIDEO TERMINAL Disengage the 4 claws and remove the video terminal.

1. INSTALL VIDEO TERMINAL Engage the 4 claws and install the video terminal.
2. INSTALL ROOF SIDE GARNISH ASSEMBLY INNER RH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
3. INSTALL NO.1 TONNEAU COVER HOLDER CAP
4. INSTALL NO.2 ROOM LIGHT ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
5. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
6. INSTALL ROPE HOOK (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
7. INSTALL REAR SEAT SIDE COVER RH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
8. INSTALL REAR NO.1 SEAT BELT ASSEMBLY OUTER RH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
9. INSTALL REAR FLOOR FINISH SIDE PLATE RH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
10. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
11. INSTALL DECK SIDE TRIM COVER RH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
12. INSTALL DECK SIDE TRIM BOX LH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
13. INSTALL DECK SIDE TRIM BOX RH
14. INSTALL BACK DOOR WEATHERSTRIP
15. INSTALL DECK NO.3 BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
16. INSTALL DECK NO.2 BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
17. INSTALL DECK FLOOR BOX REAR (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
18. INSTALL DECK FLOOR BOX FRONT (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
19. INSTALL JACK CARRIER ASSEMBLY
20. INSTALL JACK ASSEMBLY
21. INSTALL JACK CARRIER SUPPORT
22. INSTALL TONNEAU COVER ASSEMBLY
23. INSTALL DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
24. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP RH
25. INSTALL REAR DOOR SCUFF PLATE RH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
26. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
27. PERFORM INITIALIZATION NOTE: Some systems need initialization when disconnecting the cable from negative battery terminal. (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )

Scheme 174

Scheme 175

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE FRONT DOOR SCUFF PLATE RH (See «REMOVAL»(ref-282983-S14613677712008041400000) )
3. REMOVE COWL SIDE TRIM SUB-ASSEMBLY RH (See «REMOVAL»(ref-282983-S14613677712008041400000) )
4. REMOVE NO.2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «REMOVAL»(ref-282983-S14613677712008041400000) )
5. REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY (See «REMOVAL»(ref-282983-S14613677712008041400000) )
6. REMOVE NETWORK GATEWAY ECU Disconnect the connector. Remove the screw and the network gateway ECU.

1. INSTALL NETWORK GATEWAY ECU Install the network gateway ECU with the screw. Connect the connector.
2. INSTALL GLOVE COMPARTMENT DOOR ASSEMBLY (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
3. INSTALL NO.2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
4. INSTALL COWL SIDE TRIM SUB-ASSEMBLY RH (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
5. INSTALL FRONT DOOR SCUFF PLATE RH (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
7. PERFORM INITIALIZATION NOTE: Some systems need initialization when disconnecting the cable from negative battery terminal. (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )

Scheme 176

Scheme 177

Scheme 178

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: Wait for 90 seconds after disconnecting the cable to prevent the airbag working. (See «AIRBAG SYSTEM»(ref-283011-S05295089212008041400000) )
2. REMOVE NO.2 STEERING WHEEL COVER LOWER (See «REMOVAL»(ref-283011-S03937588232008041400000) )
3. REMOVE NO.3 STEERING WHEEL COVER LOWER (See «REMOVAL»(ref-283011-S03937588232008041400000) )
4. REMOVE STEERING PAD (See «REMOVAL»(ref-283011-S03937588232008041400000) )
5. REMOVE STEERING PAD SWITCH LH Disconnect the connector. Remove the screw. Disengage the 2 claws and the pin. Remove the steering pad switch LH.
6. REMOVE STEERING PAD SWITCH RH Disconnect the connector. Remove the screw. Disengage the 2 claws and the pin. Remove the steering pad switch RH.

Scheme 179

Scheme 180

Scheme 181

1. INSPECT STEERING PAD SWITCH LH Measure the resistance according to the values in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition AU1 - EAU No switch is pushed Approx. 100 kohms AU1 - EAU SEEK+ switch: push Approx. 0 ohms AU1 - EAU SEEK- switch: push Approx. 0.3 kohms AU1 - EAU VOL+ switch: push Approx. 1 kohms AU1 - EAU VOL- switch: push Approx. 3.2 kohms AU2 - EAU No switch is pushed Approx. 100 kohms AU2 - EAU MODE switch: push Approx. 0 ohms If the result is not as specified, replace the steering pad switch LH.
2. INSPECT STEERING PAD SWITCH CABLE SUB-ASSEMBLY Measure the resistance according to the values in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition A-1 - B-1 Always Below 1 ohms A-2 - B-2 Always Below 1 ohms A-3 - B-3 Always Below 1 ohms A-4 - B-4 Always Below 1 ohms A-5 - B-5 Always Below 1 ohms A-6 - B-6 Always Below 1 ohms A-7 - B-7 Always Below 1 ohms A-8 - B-8 Always Below 1 ohms If the result is not as specified, replace the steering pad switch cable sub-assembly.
3. INSPECT STEERING PAD SWITCH RH Measure the resistance according to the values in the table below. Standard resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition AU2 - EAU No switch is pushed Approx. 100 kohms AU2 - EAU VOICE switch: push Approx. 3.2 kohms AU2 - EAU ON HOOK switch: push Approx. 0.3 kohms AU2 - EAU OFF HOOK switch: push Approx. 1.0 kohms If the result is not as specified, replace the steering pad switch RH.

1. INSTALL STEERING PAD SWITCH LH Engage the 2 claws and the pin. Install the steering pad switch LH with the screw. Connect the connector.
2. INSTALL STEERING PAD SWITCH RH Engage the 2 claws and the pin. Install the steering pad switch RH with the screw. Connect the connector.
3. INSTALL STEERING PAD (See «INSTALLATION»(ref-283011-S23707824402008041400000) )
4. INSTALL NO.3 STEERING WHEEL COVER LOWER (See «INSTALLATION»(ref-283011-S23707824402008041400000) )
5. INSTALL NO.2 STEERING WHEEL COVER LOWER (See «INSTALLATION»(ref-283011-S23707824402008041400000) )
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
7. PERFORM INITIALIZATION NOTE: Some systems need initialization when disconnecting the cable from the negative battery terminal. (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )
8. INSPECT STEERING PAD (See «INSTALLATION»(ref-283011-S23707824402008041400000) )
9. INSPECT SRS WARNING LIGHT (See «DIAGNOSIS SYSTEM»(ref-283011-S15035190092008041400000) )

Scheme 182

Scheme 183

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE MAP LIGHT ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
3. REMOVE MICROPHONE Disconnect the connector. Remove the screw and microphone bracket. Remove the microphone.

1. INSTALL MICROPHONE Install the microphone. Install the microphone bracket with the screw. Connect the connector.
2. INSTALL MAP LIGHT ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
4. PERFORM INITIALIZATION NOTE: Some systems need initialization when disconnecting the cable from negative battery terminal. (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )

Scheme 184

Scheme 185

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE MAP LIGHT ASSEMBLY (See «REMOVAL»(ref-282982-S27013933812008041400000) )
3. REMOVE MICROPHONE AMPLIFIER Disconnect the connector. Remove the screw and the microphone amplifier.

1. INSTALL MICROPHONE AMPLIFIER Install the microphone amplifier with the screw. Connect the connector.
2. INSTALL MAP LIGHT ASSEMBLY (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
3. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
4. PERFORM INITIALIZATION NOTE: Some systems need initialization when disconnecting the cable from negative battery terminal. (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )

Scheme 186

Scheme 187

1. INSPECT WINDOW GLASS ANTENNA WIRE NOTE: When cleaning the glass, wipe it in the direction of the wire with a soft and dry cloth. Take care not to damage the wire. Do not use detergents or glass cleaners with abrasive ingredients. When measuring voltage, wind a piece of tin foil around the tip of the tester probe and press the foil against the wire with your finger, as shown in the illustration. Check the continuity at the center of each antenna wire, as shown in the illustration.

Scheme 188

Scheme 189

1. REPAIR WINDOW GLASS ANTENNA WIRE Clean the broken wire tips with a grease, wax and silicone remover. Place the masking tape along both sides of the wire to be repaired. Thoroughly mix the repair agent. Using a fine tip brush, apply a small amount of the mixture to the wire. After a few minutes, remove the masking tape. Do not repair the defogger wire for at least 24 hours.

Scheme 190

1. INSTALL FRONT NO.1 SPEAKER Install the front No.1 speaker with the 4 bolts. Connect the connector.
2. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY
3. INSTALL FRONT DOOR LOWER FRAME BRACKET GARNISH
4. INSTALL DOOR ARMREST COVER
5. INSTALL POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY
6. INSTALL FRONT DOOR INSIDE HANDLE BEZEL PLUG

Scheme 191

Scheme 192

Scheme 193

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait for 90 seconds after disconnecting the cable to prevent the airbag working. (See «AIRBAG SYSTEM»(ref-283011-S05295089212008041400000) )
2. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (See «REMOVAL»(ref-282983-S14613677712008041400000) )
3. REMOVE CONSOLE PANEL UPPER FRONT (See «REMOVAL»(ref-282983-S14613677712008041400000) )
4. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER (See «REMOVAL»(ref-282983-S14613677712008041400000) )
5. REMOVE RADIO RECEIVER (See «RADIO RECEIVER»(ref-283015-S06251590422008041400000) )
6. REMOVE MULTI-DISPLAY (See «REMOVAL»(ref-283015-S30546451792008041400000) )
7. REMOVE NO.1 SPEAKER HOLE COVER Disengage the 4 clips. Remove the No.1 speaker hole cover by pushing it up from the under side of the instrument panel.
8. REMOVE FRONT NO.2 SPEAKER Remove the 2 bolts. Disconnect the connector and front No.2 speaker.

Scheme 194

1. INSTALL FRONT NO.2 SPEAKER Connect the connector. Install the front No.2 speaker with the 2 bolts.
2. INSTALL NO.1 SPEAKER HOLE COVER Engage the 4 clips and install the No.1 speaker hole cover.
3. INSTALL MULTI-DISPLAY (See «INSTALLATION»(ref-283015-S05130167002008041400000) )
4. INSTALL RADIO RECEIVER (See «INSTALLATION»(ref-283015-S06499123572008041400000) )
5. INSTALL INSTRUMENT PANEL FINISH PANEL LOWER (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
6. INSTALL CONSOLE PANEL UPPER FRONT (See «INSTALLATION»(ref-282983-S36897133672008041400000) )
7. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY
8. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
9. PERFORM INITIALIZATION NOTE: Some systems need initialization when disconnecting the cable from the negative battery terminal. (See «INITIALIZATION»(ref-282976-S16822617822008041400000) )

Scheme 195

Scheme 196

Scheme 197

1. REMOVE FRONT PILLAR GARNISH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
2. REMOVE NO.1 INSTRUMENT PANEL SPEAKER PANEL SUB-ASSEMBLY Disengage the 2 clips and the 2 claws. Remove the No.1 instrument panel speaker sub-assembly
3. REMOVE FRONT NO.2 SPEAKER Remove the 2 bolts and the front No.2 speaker. Disconnect the connector.

1. INSTALL FRONT NO.2 SPEAKER Connect the connector. Install the front No.2 speaker with the 2 bolts.
2. INSTALL NO.1 INSTRUMENT PANEL SPEAKER PANEL SUB-ASSEMBLY Engage the 2 clips and the 2 claws and install the No.1 instrument panel speaker panel sub-assembly.
3. INSTALL FRONT PILLAR GARNISH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )

Scheme 198

Scheme 199

1. REMOVE FRONT PILLAR GARNISH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
2. REMOVE FRONT STEREO COMPONENT SPEAKER Disconnect the connector. Remove the bolt and disengage the claw. Remove the front stereo component speaker.

1. INSTALL FRONT STEREO COMPONENT SPEAKER Engage the claw and install the front stereo component speaker with the bolt. Connect the connector.
2. INSTALL FRONT PILLAR GARNISH (See «INSTALLATION»(ref-282982-S40679876012008041400000) )

Scheme 200

1. INSTALL REAR SPEAKER Install the rear speaker with the 3 bolts. Connect the connector.
2. INSTALL REAR DOOR TRIM BOARD SUB-ASSEMBLY
3. INSTALL REAR DOOR ARMREST COVER
4. INSTALL REAR DOOR INSIDE HANDLE BEZEL PLUG
5. INSTALL REAR DOOR ARMREST BASE PANEL ASSEMBLY
