PRECAUTION

Note. Because the compressor operates at high voltages, wear electric insulated gloves and pull out the service plug to cut the high-voltage circuit before inspection.

Scheme 266

Scheme 267

Scheme 268

1. DO NOT HANDLE REFRIGERANT IN AN ENCLOSED AREA OR NEAR AN OPEN FLAME.
2. ALWAYS WEAR EYE PROTECTION
3. BE CAREFUL NOT TO GET LIQUID REFRIGERANT IN YOUR EYES OR ON YOUR SKIN If liquid refrigerant gets in your eyes or on your skin: Wash the area with lots of cold water. CAUTION: Do not rub your eyes or skin. Apply clean petroleum jelly to the skin. Go immediately to a hospital or see a physician for professional treatment.
4. NEVER HEAT CONTAINER OR EXPOSE IT TO OPEN FLAME
5. BE CAREFUL NOT TO DROP CONTAINER OR APPLY PHYSICAL SHOCKS TO IT
6. DO NOT OPERATE COMPRESSOR WITHOUT ENOUGH REFRIGERANT IN REFRIGERANT SYSTEM If there is not enough refrigerant in the A/C system, oil lubrication will be insufficient and the compressor may be damaged. Necessary care should be taken to avoid this.
7. DO NOT OPEN HIGH PRESSURE MANIFOLD VALVE WHILE COMPRESSOR IS OPERATING Open and close only the low pressure valve. If the high pressure values are opened, refrigerant flows in the reverse direction causing the charging cylinder to rupture. If the high pressure valve is opened, refrigerant flows in the reverse direction causing the charging cylinder to rupture.
8. BE CAREFUL NOT TO OVERCHARGE SYSTEM WITH REFRIGERANT If refrigerant is overcharged, it causes problems such as insufficient cooling, poor fuel economy, engine overheating, etc.
9. NOTICE FOR INITIALIZATION: When disconnecting the negative (-) battery terminal, initialize the following systems after the terminal is reconnected. INITIALIZATION SYSTEM REFERENCE System Name See procedure Lighting System «INITIALIZATION»(ref-282976-S16822617822008041400000) Power Window Control System Power Back Door System Power Door Lock Control System Back Door Closer System Electrical Back Door Outside Handle System SFI System
10. NOTICES FOR HYBRID SYSTEM ACTIVATION: When the warning light is illuminated or the HV battery has been disconnected and reconnected/turning the ignition switch may not start the system on the first try. If so, turn the ignition switch again.
11. PRECAUTIONS TO BE OBSERVED WHILE SERVICING NOTE: Only use ND-OIL11 on the electric inverter compressor of the air conditioning system. Using other A/C oils may be dangerous, as they may conduct electricity. Electrical insulation performance may decrease significantly if even a small amount of the oil other than ND-OIL11 is used (or enters) in the refrigeration cycle, causing a DTC to be output. If other oil is accidentally used and a DTC is output, collect the compressor oil in the compressor and replace it with ND-OIL11 to increase the ND-OIL 11 ratio amount. Replace the main components (evaporator, condenser, and compressor) if a large amount of oil other than ND-OIL11 enters the system. Failing to do so may cause electrical insulation performance to remain low, causing a DTC to be output. CAUTION: Always use electric insulating gloves and remove the service plug clip before beginning inspection, as inspection of the air conditioning system requires disconnecting high voltage connectors. (See «DTC B1471/71 A/C INVERTER HIGH VOLTAGE POWER RESOURCE SYSTEM MALFUNCTION»(ref-283012-S36630675942008041400000) )
12. GENERAL PRECAUTION While using the battery during inspection, do not bring the positive and negative tester probes too close to each other as a short circuit may occur.

Scheme 269

Scheme 270

Scheme 271

Scheme 272

COMMUNICATION REFERENCE

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

Scheme 279

Scheme 280

1. General The air conditioning system has the following features: An ES27 type electric inverter compressor is used on the RX400h. This compressor is driven by the alternating current that is supplied by the A/C inverter, which is integrated with the compressor. As a result, the air conditioning system is actuated without depending on the operation of the engine, thus realizing a comfortable air conditioning system and low fuel consumption. A compact, lightweight, and highly efficient electrical water pump is used in order to ensure the proper heater performance while the engine is stopped. A left/right independent temperature control and neural network control have been adopted to make air conditioner control available to suit the perception of the persons in the driver seat and in the passenger seat. Automatic air conditioner is standard in all models. A semi-center location air conditioner unit, in which the evaporator and heater core are placed in the vehicle's longitudinal direction, is used. A compact, lightweight, and highly efficient straight flow (full-path flow) aluminum heater core is used. A revolutionary slim structure evaporator is used. A humidity sensor function has been added to the room temperature sensor in order to optimize the amount of dehumidification effort during the operation of the air conditioning system. A deodorizing function that eliminates the exhaust gas smell that enters the cabin from the outside has been added to the conventional clean air filter. The air conditioning ECU is equipped with a self-diagnosis function. If there is a malfunction in the system, it stores the DTCs (Diagnostic Trouble Codes) in its memory.
2. Mode Position and Damper Operation Function of Main Damper *1: Auto FOOT Mode *2: Manual FOOT Mode
3. Air Outlets and Air Volume Rations The size of the circle O indicates the proportion of airflow volume.
4. Compressor General Along with the installation of the hybrid unit on the RX400h, an ES27 electric inverter compressor that is driven by a built-in DC motor is used. The basic construction and operation of this compressor are the same as the ordinary scroll compressor, except that it is driven by an electric motor. The A/C inverter has been integrated with the compressor. The electric motor is actuated by the alternating current power (288 V) supplied by the A/C inverter. As a result, the air conditioner control system on the RX400h is actuated without depending on the operation of the engine, thus realizing a comfortable air conditioning system and low fuel consumption. Due to the use of an electric inverter compressor, the compressor speed can be controlled at the required speed calculated by the A/C ECU. Thus, the cooling and dehumidification performance and power consumption have been optimized. Low-moisture permeation hoses are used for the suction and discharge hoses at the compressor in order to minimize the entry of moisture into the refrigeration cycle. The compressor uses high-voltage alternating current. If a short or open circuit occurs in the compressor wiring harness, the hybrid vehicle control ECU will cut off A/C inverter circuit in order to stop the power supply to the compressor. For details on the Electric Inverter Compressor control effected by the A/C ECU. Service Tip: In order to ensure the proper insulation of the internal high-voltage portion of the compressor and the compressor housing, the RX400h has adopted a compressor oil (ND11) with a high level of insulation performance. Therefore, never use a compressor oil other than the ND11 type compressor oil or its equivalent. Construction The Electric Inverter Compressor consists of a spirally wound fixed scroll and variable scroll that form a pair, a brushless motor, an oil separator, a motor shaft and A/C inverter. The fixed scroll is integrated with the housing. Because the rotation of the shaft causes the variable scroll to remove while maintaining the same posture, the volume of the space that is partitioned by both scrolls varies to perform the suction, compression, and the discharge of the refrigerant gas. Locating the suction port directly above the scrolls enables direct suction, thus realizing improved suction efficiency. Containing a built-in oil separator, this compressor is able to separate the compressor oil that is intermixed with the refrigerant and circulates in the refrigeration cycle, thus realizing a reduction in the oil circulation rate. This inverter converts the HV battery's nominal voltage of DC 288 V into AC 288 V and supplies power to operate the compressor. System Diagram: Electric Inverter Compressor Control The A/C ECU calculates the target compressor speed based on the target evaporator temperature (calculated from the room temperature sensor, humidity sensor, ambient temperature sensor, and solar sensor (automatic light control sensor)) and the actual evaporator temperature detected by the evaporator temperature sensor. Then, the A/C ECU transmits the target speed to the hybrid vehicle control ECU controls the A/C inverter based on the target speed data in order to control the compressor to a speed that suits the operating condition of the air conditioning system. The A/C ECU calculates the target evaporator temperature, which includes corrections based on the vehicle interior humidity (which is obtained from the humidity sensor) and the windshield glass inner surface humidity (which is calculated from the humidity sensor, solar sensor (automatic light control sensor), room temperature sensor, mode damper position, and wiper operation condition). Accordingly, the A/C ECU controls the compressor speed to an extent that does not inhibit the proper cooling performance or defogging performance. As a result, comfort and low fuel consumption can be realized.

CUSTOMIZE PARAMETERS

HINT

The following items can be customized.

Note. After confirming whether the items of the customer's request are applicable or not for the customized items, perform the customize operation. Be sure to record the current value before customizing. In case of performing the troubleshooting, pay attention as there is a possibility that the function is set to OFF by customizing. (Example: In case of the symptom in which "The wireless operation does not function" is displayed, check that the wireless operation is not set to OFF by customizing, then perform the troubleshooting.)

AIR CONDITIONER

AIR CONDITIONER CUSTOMIZE PARAMETERS
