Brake Control: Removal & Installation Lexus RX II рестайлинг

REMOVAL

Note. If brake fluid spills on any painted surface, wash or otherwise remove it completely.

Scheme 153

Scheme 154

Scheme 155

Scheme 156

Scheme 157

Scheme 158

Scheme 159

Scheme 160

Scheme 161

Scheme 162

1. PERFORM ACCUMULATOR ZERO DOWN (See «BLEEDING»(ref-282988-S03980551392008041400000) )
2. REMOVE ABS MOTOR RELAY Remove the 2 ABS motor relays with the ignition switch off in order to disable brake control. NOTE: If the pump motor operates while air remains inside the brake reservoir tube No.1 hose, air will enter the actuator, and this will make bleeding the brakes more difficult. NOTE: After the brake actuator assembly has been replaced, remove the ABS motor relay before bleeding the brakes.
3. DRAIN BRAKE FLUID
4. REMOVE FRONT FENDER TO COWL SIDE SEAL RH
5. REMOVE FRONT FENDER TO COWL SIDE SEAL LH
6. REMOVE FRONT WIPER ARM AND BLADE ASSEMBLY RH (See «REMOVAL»(ref-282998-S30117535582008041400000) )
7. REMOVE FRONT WIPER ARM AND BLADE ASSEMBLY LH (See «REMOVAL»(ref-282998-S30117535582008041400000) )
8. REMOVE COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY (See «REMOVAL»(ref-282998-S30117535582008041400000) )
9. REMOVE WIND SHIELD WIPER MOTOR ASSEMBLY (See «REMOVAL»(ref-282998-S30117535582008041400000) )
10. REMOVE COWL PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-282992-S02024628612008041400000) )
11. REMOVE BRAKE MASTER CYLINDER RESERVOIR ASSEMBLY Disconnect the warning switch connector. Separate the brake actuator hose from the clamp. Remove the 2 clips and brake actuator hose. Remove the 2 clips and 2 reservoir tubes from the brake master cylinder reservoir assembly. Remove the 2 bolts and the brake master cylinder reservoir assembly.
12. REMOVE FRONT WHEEL RH
13. REMOVE BRAKE ACTUATOR ASSEMBLY WITH BRAKE ACTUATOR BRACKET ASSEMBLY Remove the bolt and the brake actuator bracket No. 7 with clamp. Using SST, disconnect the 6 brake tubes from the actuator assembly with brake actuator bracket assembly. SST 09023-00101 Use tags or make a memo to identify the places to reconnect. Using SST, disconnect the front brake No. 8 tube. SST 09023-00101 Release the lock lever and disconnect the actuator connector. Remove the bolt from the brake tube bracket. Remove the 3 nuts and brake actuator assembly with brake actuator bracket assembly. NOTE: Do not damage the brake tubes.

Scheme 163

1. REMOVE BRAKE ACTUATOR ASSEMBLY Remove the 2 nuts and brake actuator assembly from the actuator bracket. Remove the 2 brake actuator bolt holders.

INSTALLATION

1. INSTALL REAR SPEED SENSOR Install the rear speed sensor with the bolt. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) NOTE: Prevent foreign matter from attaching to the sensor tip. Install the sensor harness clamps with the 2 bolts to the body and the shock absorber bracket. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) NOTE: Do not twist the sensor wire when installing the sensor. Push in the sensor wire harness with the grommet. NOTE: When installing the grommet, do not pull the sensor wire. Only pull the grommet. Connect the rear speed sensor connector.
2. INSTALL REAR WHEEL Torque: 103 N*m (1,050 kgf*cm, 76 ft.*lbf)
3. INSTALL REAR SEAT SIDE COVER (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
4. INSTALL DECK SIDE TRIM COVER (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
5. INSTALL REAR DOOR OPENING TRIM WEATHER STRIP
6. INSTALL REAR DOOR SCUFF PLATE (See «INSTALLATION»(ref-282982-S40679876012008041400000) )
7. CHECK SPEED SENSOR SIGNAL (See «DIAGNOSIS SYSTEM»(ref-282978-S01335280922008041400000) )

Scheme 164

Scheme 165

HINT

1. Do not use a dropped or damaged yaw rate sensor.
2. Prevent foreign matter from attaching between the yaw rate sensor bracket and body.
3. Confirm that the sensor direction is correct.

Scheme 166

1. REMOVE SEAT TRACK BRACKET COVER OUTER FRONT LH (See «REMOVAL»(ref-283009-S32523970282008041400000) )
2. REMOVE SEAT TRACK BRACKET COVER INNER FRONT LH (See «REMOVAL»(ref-283009-S32523970282008041400000) )
3. REMOVE SEAT TRACK COVER RH (See «REMOVAL»(ref-283009-S32523970282008041400000) )
4. REMOVE SEAT TRACK COVER LH (See «REMOVAL»(ref-283009-S32523970282008041400000) )
5. REMOVE FRONT SEAT ASSEMBLY RH (See «REMOVAL»(ref-283009-S32523970282008041400000) )
6. REMOVE SHIFT LEVER KNOB (See «REMOVAL»(ref-282983-S14613677712008041400000) )
7. REMOVE CONSOLE PANEL UPPER FRONT (See «REMOVAL»(ref-282983-S14613677712008041400000) )
8. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER (See «REMOVAL»(ref-282983-S14613677712008041400000) )
9. REMOVE FRONT DOOR SCUFF PLATE RH (See «REMOVAL»(ref-282983-S14613677712008041400000) )
10. REMOVE FRONT DOOR SCUFF PLATE LH (See «REMOVAL»(ref-282982-S27013933812008041400000) )
11. REMOVE REAR DOOR SCUFF PLATE RH
12. REMOVE CENTER PILLAR GARNISH LOWER RH
13. REMOVE COWL SIDE TRIM SUB-ASSEMBLY RH (See «REMOVAL»(ref-282983-S14613677712008041400000) )
14. REMOVE COWL SIDE TRIM SUB-ASSEMBLY LH (See «REMOVAL»(ref-282983-S14613677712008041400000) )
15. REMOVE INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY LOWER (See «REMOVAL»(ref-282983-S14613677712008041400000) )
16. REMOVE INSTRUMENT PANEL NO.2 UNDER COVER SUB-ASSEMBLY (See «REMOVAL»(ref-282983-S14613677712008041400000) )
17. REMOVE GLOVE COMPARTMENT DOOR ASSEMBLY (See «REMOVAL»(ref-282983-S14613677712008041400000) )
18. REMOVE FLOOR CARPET COVER CENTER LH (See «REMOVAL»(ref-282983-S14613677712008041400000) )
19. REMOVE FLOOR CARPET COVER CENTER RH (See «REMOVAL»(ref-282983-S14613677712008041400000) )
20. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER CENTER (See «REMOVAL»(ref-282983-S14613677712008041400000) )
21. REMOVE CONSOLE BOX HOLE COVER (See «REMOVAL»(ref-282983-S04245816122008041400000) )
22. REMOVE CONSOLE BOX HOLE NO.2 COVER (See «REMOVAL»(ref-282983-S04245816122008041400000) )
23. REMOVE CONSOLE BOX ASSEMBLY (See «REMOVAL»(ref-282983-S04245816122008041400000) )
24. REMOVE CONSOLE COVER LOWER (See «REMOVAL»(ref-283011-S28107747872008041400000) )
25. REMOVE YAW RATE SENSOR ASSEMBLY Turn back the floor carpet, and remove the bolt, nut, clamp and yaw rate sensor assembly. Disconnect the yaw rate sensor assembly connector. NOTE: Do not remove the yaw rate sensor assembly from the yaw rate sensor bracket.
