ALL WINDOWS & POWER DOOR LOCKS INOPERATIVE
Check for defective fuse (GAUGE, POWER), power main relay, ignition switch, integration relay, door lock control relay, driver's side power window switch or wiring harness.
ALL WINDOWS INOPERATIVE, BUT POWER DOOR LOCKS OPERATE
Check for defective fuse (GAUGE, POWER), ignition switch, integration relay, door lock control relay, driver's side power window switch, power main relay or wiring harness.
LOCK SWITCH INOPERATIVE
Check driver's side power window lock switch.
WINDOW LOCK ILLUMINATION DOES NOT OPERATE
Check driver's side power window switch.
ONE-TOUCH FEATURE IS INOPERATIVE
Check driver's side power window switch.
ONE WINDOW DOES NOT OPERATE
Check driver's side power window switch for appropriate window, power window switch, power window motor and wiring harness for appropriate window.
WINDOW DOES NOT OPERATE WITH KEY OFF
Check for defective fuse (GAUGE, POWER), ignition switch, door courtesy switch or wiring harness.
Note. For door lock control relay and integration relay testing, see DOOR LOCKS - POWER article. For ignition switch testing, see appropriate STEERING COLUMN SWITCHES article.
POWER WINDOW MAIN RELAY
- Remove power window main relay, located in relay block No. 1 at left side kick panel.
- Using an ohmmeter, check continuity between power window main relay terminals No. 1 and 3. Continuity should exist. (Scheme 4) Apply battery voltage to terminal No. 1 and ground terminal No. 3. Continuity should exist at terminals No. 2 and 4. If relay does not test as described, replace power window main relay.
Scheme 4
(Front Doors)
Using a 12-volt battery, connect jumper wire from positive battery terminal to terminal No. 1 of power window motor. (Scheme 5) Connect jumper wire from negative battery terminal to terminal No. 3 of power window motor. Motor should operate clockwise. Reverse jumper wire positions. Motor should operate counterclockwise. If motor does not test as described, replace motor.
