POWER WINDOW SWITCH CONTINUITY TEST (DRIVER'S SIDE SWITCH)
Using an ohmmeter, check continuity between specified terminals with driver's side power window switch in specified position. See POWER WINDOW SWITCH CONTINUITY TEST (DRIVER'S SIDE) table. (Scheme 1) If continuity does not exist at specified terminals, replace power window switch.
| Application & Position | (1) Terminal No. | ||
|---|---|---|---|
| Driver's Side Switch (Locked & Unlocked) | |||
| UP | 1, 2 & 13; 6, 7 & 8 | ||
| OFF | 1, 2, 6 & 13 | ||
| DOWN | 1, 2 & 6; 7, 8 & 13 | ||
| Passenger Side Switch | |||
| Locked | |||
| UP | 7, 8 & 12 | ||
| OFF | 5 & 12 | ||
| DOWN | 5, 7 & 8 | ||
| Unlocked | |||
| UP | 1, 2 & 5; 7, 8 & 12 | ||
| OFF | 1, 2, 5 & 12 | ||
| DOWN | 1, 2 & 12; 5, 7 & 8 | ||
| Left Rear Switch | |||
| Locked | |||
| UP | 7, 8 & 10 | ||
| OFF | 9 & 10 | ||
| DOWN | 7, 8 & 9 | ||
| Unlocked | |||
| UP | 1, 2 & 9; 7, 8 & 10 | ||
| OFF | 1, 2, 9 & 10 | ||
| DOWN | 1, 2 & 10; 7, 8 & 9 | ||
| Right Rear Switch | |||
| Locked | |||
| UP | 7, 8 & 11 | ||
| OFF | 11 & 14 | ||
| DOWN | 7, 8 & 14 | ||
| Unlocked | |||
| UP | 1, 2 & 14; 7, 8 & 11 | ||
| OFF | 1, 2, 11 & 14 | ||
| DOWN | 1, 2 & 11; 7, 8 & 14 | ||
| (1) (Scheme 1) | |||
| (1) | (Scheme 1) |
POWER WINDOW SWITCH CONTINUITY TEST (DRIVER'S SIDE)
Scheme 1
POWER WINDOW SWITCH CONTINUITY TEST (PASSENGER SIDE & REAR SWITCHES)
Using an ohmmeter, check continuity between specified terminals with power window switch in specified position. See the POWER WINDOW SWITCH CONTINUITY TEST (PASSENGER SIDE & REAR) table. (Scheme 2) If continuity does not exist at specified terminals, replace appropriate power window switch.
| Application & Position | (1) Terminals No. |
|---|---|
| UP | 1 & 5; 3 & 4 |
| OFF | 1 & 2; 3 & 4 |
| DOWN | 1 & 2; 4 & 5 |
| (1) (Scheme 2) | |
| (1) | (Scheme 2) |
POWER WINDOW SWITCH CONTINUITY TEST (PASSENGER SIDE & REAR)
Scheme 2
POWER WINDOW SYSTEM CURRENT TEST
- Disconnect connector from driver's side power window switch. Connect positive lead of ammeter to driver's side power window switch connector (harness side) terminal No. 6.
- Connect ammeter negative lead to negative terminal of 12-volt battery. Connect jumper wire from positive battery terminal to driver's side power window switch connector terminal No. 13. (Scheme 1)
- While lowering driver's side window, current should be about 7 amps. When window operation is stopped, current should increase to about 14.5 amps or more. If current is as described, replace driver's side power window switch. If current is not as described, check and repair appropriate circuit.
