Removal
- Oil cooler is mounted on side of cylinder block. (Scheme 45) Drain cooling system. Remove air intake hose with airflow meter and air cleaner cover. Remove exhaust pipe with front catalytic converter and gasket from between exhaust manifolds and rear catalytic converter and exhaust pipe.
- Remove heat insulator, No. 1 (front) exhaust manifold and gasket from cylinder head. see scheme 8 Remove oil pressure switch for access to oil cooler. Remove oil cooler cover-to-cylinder block bolts/nuts, oil cooler cover, oil cooler and gasket from cylinder block. see scheme 47
- Remove oil cooler-to-oil cooler cover nuts. Separate oil cooler and gaskets from oil cooler cover. Remove oil cooler relief valve plug, gasket, spring and relief valve.
Installation
To install, reverse removal procedure. Use NEW gaskets. Tighten bolts/nuts to specification. Fill cooling system.
