Steering Column (Service Information): Diagnosis Lexus LX J200 рестайлинг

Steering Column 2 illustrations ~343 words

INSPECTION [01/2012 - ]

WARNINGThe vehicle is equipped with an SRS (Supplemental Restraint System) which includes components such as airbags. Before servicing (including removal or installation of parts), be sure to read the PRECAUTION in the SRS. Refer to PRECAUTION [01/2012 - ] .

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20
  1. INSPECT STEERING PAD SWITCH ASSEMBLY (w/ Dynamic Radar Cruise Control System) Disconnect the z35 switch connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 6 (AU1) - 8 (EAU) No switch is pushed 100 kohms 6 (AU1) - 8 (EAU) Seek+ switch pushed Below 2.5 ohms 6 (AU1) - 8 (EAU) Seek- switch pushed 329 ohms 6 (AU1) - 8 (EAU) Volume+ switch pushed 1000 ohms 6 (AU1) - 8 (EAU) Volume- switch pushed 3110 ohms 7 (AU2) - 8 (EAU) No switch is pushed 100 kohms 7 (AU2) - 8 (EAU) MODE switch pushed Below 2.5 ohms 7 (AU2) - 8 (EAU) ON Hook switch pushed 329 ohms 7 (AU2) - 8 (EAU) OFF Hook switch pushed 1000 ohms 7 (AU2) - 8 (EAU) Voice switch pushed 3110 ohms 7 (+DP) - 8 (EAU) DISP switch pushed Below 2.5 ohms 10 (ECC) - 2 (DIST) ACC switch pushed Below 2.5 ohms If the result is not as specified, replace the steering switch assembly.
  2. INSPECT STEERING PAD SWITCH ASSEMBLY (w/o Dynamic Radar Cruise Control System) Disconnect the z35 switch connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 6 (AU1) - 8 (EAU) No switch is pushed 100 kohms 6 (AU1) - 8 (EAU) Seek+ switch pushed Below 2.5 ohms 6 (AU1) - 8 (EAU) Seek- switch pushed 329 ohms 6 (AU1) - 8 (EAU) Volume+ switch pushed 1000 ohms 6 (AU1) - 8 (EAU) Volume- switch pushed 3110 ohms 7 (AU2) - 8 (EAU) No switch is pushed 100 kohms 7 (AU2) - 8 (EAU) MODE switch pushed Below 2.5 ohms 7 (AU2) - 8 (EAU) On hook switch pushed 329 ohms 7 (AU2) - 8 (EAU) Off hook switch pushed 1000 ohms 9 (+DP) - 8 (EAU) DISP switch pushed Below 2.5 ohms If the result is not as specified, replace the steering pad switch assembly.
