DESCRIPTION

This DTC is stored when a failure of the automatic light control sensor circuit is detected.

DTC CodeDTC Detection ConditionTrouble Area
B1244When either condition below is met: Malfunction of the light sensor. Open or short of the light sensor circuit.Automatic light control sensor Main body ECU Harness or connector

Scheme 150

Scheme 150: WIRING DIAGRAM

This DTC is stored when the main body ECU detects malfunctions in the inner rear view mirror.

DTC CodeDTC Detection ConditionTrouble Area
B124AMalfunction in inner rear view mirrorInner rear view mirror
B124CMalfunction in inner rear view mirror camera portionInner rear view mirror

Scheme 151

Scheme 151: WIRING DIAGRAM

This DTC is stored when the main body ECU detects malfunctions in the automatic high beam system.

DTC CodeDTC Detection ConditionTrouble Area
B124BMalfunction in automatic high beam systemCAN communication system Inner rear view mirror
  1. DTC B124D is stored when the main body ECU detects malfunctions in the LIN communication system.
  2. DTC B2432 is stored when the AFS ECU detects malfunctions in the LIN communication system.
DTC CodeDTC Detection ConditionTrouble Area
B124DMalfunction in LIN communication systemInner rear view mirror Harness or connector AFS ECU (headlight swivel ECU)
B2432Malfunction in LIN communication systemInner rear view mirror Harness or connector AFS ECU (headlight swivel ECU)

Scheme 152

Scheme 152: WIRING DIAGRAM

This DTC is stored when the main body ECU detects malfunctions in the turn signal flasher relay circuit.

DTC CodeDTC Detection ConditionTrouble Area
B124EMalfunction in turn signal flasher relay circuitTurn signal flasher Main body ECU Harness or connector Headlight dimmer switch

Scheme 153

Scheme 153: WIRING DIAGRAM

These DTCs are stored when the AFS ECU detects errors in its own communications with the headlight swivel motor.

DTC CodeDTC Detection ConditionTrouble Area
B2410The AFS ECU detects errors in its own communications with the headlight swivel motor LH.AFS ECU (headlight swivel ECU) Headlight swivel motor LH Headlight unit LH Harness or connector
B2411The AFS ECU detects errors in its own communications with the headlight swivel motor RH.AFS ECU (headlight swivel ECU) Headlight swivel motor RH Headlight unit RH Harness or connector

Scheme 154

Scheme 154: WIRING DIAGRAM

The headlight swivel motor receives a signal from the AFS ECU to operate and sends a signal indicating the direction of the headlight and condition of the headlight swivel motor to the AFS ECU.

DTC CodeDTC Detection ConditionTrouble Area
B2412When either condition below is met: Malfunction in the headlight swivel motor LH. Open or short in the headlight swivel motor LH circuit.AFS ECU (headlight swivel ECU) Headlight swivel motor LH Harness or connector Headlight unit LH
B2413When either condition below is met: Malfunction in the headlight swivel motor RH. Open or short in the headlight swivel motor RH circuit.AFS ECU (headlight swivel ECU) Headlight swivel motor RH Harness or connector Headlight unit RH

Scheme 155

Scheme 155: WIRING DIAGRAM

The AFS ECU receives signals indicating the steering angle from the steering angle sensor using CAN communication.

DTC CodeDTC Detection ConditionTrouble Area
B2414Malfunction in the steering angle sensor.Steering angle sensor AFS ECU (headlight swivel ECU)

Scheme 156

Scheme 156: WIRING DIAGRAM

The AFS ECU receives signals indicating the front wheel speed from the skid control ECU using CAN communication.

DTC CodeDTC Detection ConditionTrouble Area
B2415Malfunction in the vehicle speed sensor.Skid control ECU AFS ECU (headlight swivel ECU)

Scheme 157

Scheme 157: WIRING DIAGRAM

The AFS ECU receives signals indicating the height of the vehicle from the suspension control ECU.

DTC CodeDTC Detection ConditionTrouble Area
B2416When either condition below is met: Malfunction in the suspension control ECU. Open or short in the suspension control ECU circuit.Suspension control ECU Active height control suspension system

Scheme 158

Scheme 158: WIRING DIAGRAM

The headlight swivel motor (leveling portion) receives a signal from the AFS ECU to operate. The AFS ECU receives a signal indicating the operating conditions of the headlight swivel motor (leveling portion).

DTC CodeDTC Detection ConditionTrouble Area
B2417When either condition below is met: Malfunction in the headlight swivel motor LH (leveling portion). Open or short in the headlight swivel motor LH (leveling portion) circuit.AFS ECU (headlight swivel ECU) Headlight swivel motor LH (leveling portion) Harness or connector Headlight unit LH
B2418When either condition below is met: Malfunction in the headlight swivel motor RH (leveling portion). Open or short in the headlight swivel motor RH (leveling portion) circuit.AFS ECU (headlight swivel ECU) Headlight swivel motor RH (leveling portion) Harness or connector Harness unit RH

Scheme 159

Scheme 159: WIRING DIAGRAM

When the AFS ECU detects a malfunction in itself, this DTC is stored.

DTC CodeDTC Detection ConditionTrouble Area
B2420Malfunction of the AFS ECU.AFS ECU (headlight swivel ECU)

This DTC is stored if the AFS ECU is not installed properly.

DTC CodeDTC Detection ConditionTrouble Area
B2423AFS ECU installation error.AFS ECU (headlight swivel ECU)

The headlight swivel motor (leveling portion) operates by receiving a signal from the AFS ECU. The AFS ECU detects the headlight swivel motor (leveling portion) status using the signal from the headlight swivel motor (leveling portion).

DTC CodeDTC Detection ConditionTrouble Area
B2424When either condition below is met: Malfunction in the headlight swivel motor (leveling portion) LH. Open or short in the headlight swivel motor LH (leveling portion) communication circuit.AFS ECU (headlight swivel ECU) Headlight leveling motor LH (leveling portion) Headlight unit LH Harness or connector
B2425When either condition below is met: Malfunction in the headlight swivel motor (leveling portion) RH. Open or short in the headlight swivel motor RH (leveling portion) communication circuit.AFS ECU (headlight swivel ECU) Headlight leveling motor RH (leveling portion) Headlight unit RH Harness or connector

Scheme 160

Scheme 160: WIRING DIAGRAM
  1. The AFS ECU receives an engine running status signal and shift position signal from the ECM using CAN communication.
  1. The AFS ECU receives front speed sensor LH and RH signals from the skid control ECU using CAN communication.
  1. The AFS ECU receives the headlight status signal from the main body ECU using CAN communication.
  1. The AFS ECU sends an AFS OFF indicator light on or off demand signal to the combination meter ECU using CAN communication.
DTC CodeDTC Detection ConditionTrouble Area
B2427When either condition below is met: Malfunction in the CAN communication system. Malfunction in the AFS ECU.CAN communication system AFS ECU (headlight swivel ECU)

The AFS ECU receives steering wheel position information (turned to the right or left) from the main body ECU via CAN communication.

DTC CodeDTC Detection ConditionTrouble Area
B2429Steering wheel position information malfunction.AFS ECU (headlight swivel ECU) Main body ECU

Scheme 161

Scheme 161: WIRING DIAGRAM

The main body ECU receives a headlight switch information signal from the light control switch, and illuminates the headlight low beam.

Scheme 162

Scheme 162: WIRING DIAGRAM

The main body ECU receives light control switch and dimmer switch information signals from the headlight dimmer switch, and illuminates the headlight high beam.

Scheme 163

Scheme 163: WIRING DIAGRAM

Scheme 164

Scheme 164

The main body ECU receives a front fog light switch information signal from the light control switch (front fog switch), and illuminates the front fog lights.

Scheme 165

Scheme 165: WIRING DIAGRAM

The park/neutral position switch turns on when the shift lever is moved to R, causing the back-up lights to illuminate.

Scheme 166

Scheme 166: WIRING DIAGRAM

When the stop light switch is turned on, current flows to the stop lights to illuminate them.

Scheme 167

Scheme 167: WIRING DIAGRAM
