Power Window Control (Diagnostics - Introduction): Diagnosis Lexus LX J200

HOW TO PROCEED WITH TROUBLESHOOTING

HINT

1. Use these procedures to troubleshoot the power window control system.
2. *: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. INSPECT BATTERY VOLTAGE Standard voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding. NEXT: Go to next step
3. CHECK FOR DTC* Check for DTCs and make a note of any codes that are output. Clear the DTCs. Recheck for DTCs. Based on the DTCs output in the first step, try to force output of the same DTC by simulating the symptoms indicated by the DTC. RESULT Result Proceed to No DTCs are output A B2311 is output B B2312 is output B B2313 is output B CAN communication system DTCs are output C LIN communication system DTCs are output D B --> GO TO DIAGNOSTIC TROUBLE CODE CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-385302-S04756974342011021400000) C --> GO TO CAN COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-385222-S04985080032011021400000) D --> GO TO LIN COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-385260-S41337605402011021400000) A: Go to next step
4. PROBLEM SYMPTOMS TABLE Refer to the Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE»(ref-385302-S07001091362011021400000) . RESULT Result Proceed to Fault not listed in problem symptoms table A Fault listed in problem symptoms table B B --> GO TO STEP 6 A: Go to next step
5. OVERALL ANALYSIS AND TROUBLESHOOTING* Operation Check. Refer to «OPERATION CHECK»(ref-385302-S42322832312011021400000) . Terminals of ECU. Refer to «TERMINALS OF ECU»(ref-385302-S02695159912011021400000) . Data List / Active Test. Refer to «DATA LIST / ACTIVE TEST»(ref-385302-S21828315982011021400000) . NEXT: Go to next step
6. REPAIR OR REPLACE RESULT Result Proceed to Door window regulator and power window regulator motor assembly is replaced or removed/installed. A Door window regulator and power window regulator motor assembly is not replaced or removed/installed. B B --> GO TO STEP 8 A: Go to next step
7. RESET POWER WINDOW REGULATOR MOTOR If a power window switch LED is blinking, initialize the power window regulator motor. Refer to «INITIALIZATION»(ref-385302-S05202602432011021400000) . NEXT: Go to next step
8. CONFIRMATION TEST NEXT --> END

Scheme 102

Scheme 103

1. CHECK WINDOW LOCK SWITCH HINT: Before performing the window lock switch operation check, make sure that the window lock switch is off (the switch is not pushed in). Check that the front passenger side power window and the rear power windows cannot be operated when the window lock switch of the multiplex network master switch is pressed. OK Operation of front passenger side power window and rear power windows are disabled. Check that the front passenger side power window and the rear power windows can be operated when the window lock switch is pressed again. OK Front passenger side power window and rear power windows can be operated.
2. CHECK MANUAL UP/DOWN FUNCTION Check that the driver side power window operates as follows: OK Condition Multiplex Network Master Switch Switch Operation Power Window Engine switch on (IG) Driver side Pulled halfway up Up (Closes) Pushed halfway down Down (Opens) Check that the front passenger side and rear power windows operate as follows: OK Condition Power Window Regulator Switch Switch Operation Power Window Engine switch on (IG) Window lock switch off Front passenger side Pulled halfway up Up (Closes) Pushed halfway down Down (Opens) Rear LH side Pulled halfway up Up (Closes) Pushed halfway down Down (Opens) Rear RH side Pulled halfway up Up (Closes) Pushed halfway down Down (Opens)
3. CHECK AUTO UP/DOWN FUNCTION Check that the driver side power window operates as follows: OK Condition Multiplex Network Master Switch Switch Operation Power Window Engine switch on (IG) Driver side Pulled up (One touch operation) Auto up (Closes) Pushed down (One touch operation) Auto down (Opens) Check that the front passenger side and rear power windows operate as follows: OK Condition Power Window Regulator Switch Switch Operation Power Window Engine switch on (IG) Window lock switch off Front passenger side Pulled up (One touch operation) Auto up (Closes) Pushed down (One touch operation) Auto down (Opens) Rear LH side Pulled up (One touch operation) Auto up (Closes) Pushed down (One touch operation) Auto down (Opens) Rear RH side Pulled up (One touch operation) Auto up (Closes) Pushed down (One touch operation) Auto down (Opens)
4. CHECK REMOTE MANUAL UP/DOWN FUNCTION Check that the front passenger side and rear power windows operate as follows: OK Condition Multiplex Network Master Switch Switch Operation Power Window Engine switch on (IG) Window lock switch off Front passenger side Pulled halfway up Up (Closes) Pushed halfway down Down (Opens) Rear LH side Pulled halfway up Up (Closes) Pushed halfway down Down (Opens) Rear RH side Pulled halfway up Up (Closes) Pushed halfway down Down (Opens)
5. CHECK REMOTE AUTO UP/DOWN FUNCTION Check that the front passenger side and rear power windows operate as follows: OK Condition Multiplex Network Master Switch Switch Operation Power Window Engine switch on (IG) Window lock switch off Front passenger side Pulled up (One touch operation) Auto up (Closes) Pushed down (One touch operation) Auto down (Opens) Rear LH side Pulled up (One touch operation) Auto up (Closes) Pushed down (One touch operation) Auto down (Opens) Rear RH side Pulled up (One touch operation) Auto up (Closes) Pushed down (One touch operation) Auto down (Opens)
6. CHECK POWER WINDOW OPERATION FUNCTION AFTER ENGINE SWITCH OFF Check that all the power windows can be operated with the multiplex network master switch after the engine switch is turned off. Check that the key-off operation function does not operate after a front side door is opened. Check that all the power windows cannot be operated after more than approximately 45 seconds have elapsed since the engine switch was turned off.
7. CHECK TRANSMITTER-LINKED FUNCTION Check that all power windows operate as follows when operating the transmitter. OK Condition Transmitter Operation Power Window No key is inside vehicle, and all doors are closed and locked. Unlock switch pressed for more than 3.0 sec. Down (Opens) No key is inside vehicle, and all doors are closed and locked. Unlock switch released. Stop
8. CHECK KEY-LINKED FUNCTION USING DRIVER SIDE DOOR KEY CYLINDER Check that all power windows operate as follows. OK Condition Door Key Cylinder Operation Power Window No key is inside vehicle, and all doors are closed. Turned to lock for more than 2.3 sec. Up (Closes) No key is inside vehicle, and all doors are closed. Returned to neutral position. Stop No key is inside vehicle, and all doors are closed. Turned to unlock for more than 2.3 sec. Down (Opens) No key is inside vehicle, and all doors are closed. Returned to neutral position. Stop
9. CHECK ENTRY LOCK SWITCH-LINKED CLOSE FUNCTION Check that all power windows operate as follows when the entry lock switch is pressed and held. OK Condition Switch Operation Power Window No key is inside vehicle, and all doors are closed. Entry lock switch pressed for more than 3.0 sec. Up (Closes) No key is inside vehicle, and all doors are closed. Entry lock switch released. Stop
10. CHECK JAM PROTECTION FUNCTION Check the basic function. WARNING: The jam protection function is operative during both the auto up and manual up operation. Do not put your fingers between the door frame and door glass to check functions. Also, prevent any part of your body from being caught during inspection. HINT: The jam protection function is operative during both the auto up and manual up operation while the engine is running or the engine switch is on (IG), and also 45 seconds after the engine switch is turned off. Fully open the window. Hold a thick book wrapped with cloth in the position shown in the illustration. Operate the auto up or manual up function to check that the power window goes down when the window contacts the book, and stops when the opening reaches approximately 200 mm (7.87 in.). HINT: The power window moves down approximately 125 mm (4.93 in.). However, when the opening does not reach 200 mm (7.87 in.), the power window continues to go down until the opening reaches 200 mm (7.87 in.) or until approximately 5 seconds have elapsed. While the power window is moving down, check that the door glass cannot be moved up even when the power window regulator switch is used.
11. CHECK POWER WINDOW REGULATOR SWITCH LED ILLUMINATION Inspect the power window switch LED illumination for each seat when turning the window lock switch on/off. Driver Seat: When the window lock switch is on, check that all LEDs of the multiplex network master switch turn off except for the LED of the switch corresponding to the driver seat. When the window lock switch is off, check that all LEDs of the multiplex network master switch turn on. Front passenger, rear left and rear right seats: When the window lock switch is on, check that the power window regulator switch LED of each seat turns off. When the window lock switch is off, check that the power window regulator switch LED of each seat turns on.

PROBLEM SYMPTOMS TABLE

HINT

1. Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. Inspect the fuses and relays related to this system before inspecting the suspected areas below.

POWER WINDOW CONTROL SYSTEM

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

1. CHECK FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH Disconnect the I12 motor connector. Measure the resistance and voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition I12-2 (B) - I12-1 (GND) L - W-B Battery power supply Always 11 to 14 V I12-1 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the I12 motor connector. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition I12-10 (UP) - I12-1 (GND) L - W-B Power window up operation Engine switch on (IG), multiplex network master switch off --> up 11 to 14 V --> Below 1 V I12-10 (UP) - I12-1 (GND) L - W-B Power window up operation Engine switch on (IG), door glass fully open --> power window auto up operation --> door glass fully closed 11 to 14 V --> Below 1 V --> 11 to 14 V I12-7 (DOWN) - I12-1 (GND) B - W-B Power window down operation Engine switch on (IG), multiplex network master switch off --> down 11 to 14 V --> Below 1 V I12-7 (DOWN) - I12-1 (GND) B - W-B Power window down operation Engine switch on (IG), door glass fully closed --> power window auto down operation --> door glass fully open 11 to 14 V --> Below 1 V --> 11 to 14 V If the result is not as specified, the motor may be malfunctioning.
2. CHECK FRONT POWER WINDOW REGULATOR MOTOR RH Disconnect the I4 motor connector. Measure the resistance and voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition I4-2 (B) - I4-1 (GND) L - W-B Battery power supply Always 11 to 14 V I4-1 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the I4 motor connector. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition I4-10 (UP) - I4-1 (GND) L - W-B Power window up operation Engine switch on (IG), power window regulator switch off --> up 11 to 14 V --> Below 1 V I4-10 (UP) - I4-1 (GND) L - W-B Power window up operation Engine switch on (IG), door glass fully open --> power window auto up operation --> door glass fully closed 11 to 14 V --> Below 1 V --> 11 to 14 V I4-7 (DOWN) - I4-1 (GND) B - W-B Power window down operation Engine switch on (IG), power window regulator switch off --> down 11 to 14 V --> Below 1 V I4-7 (DOWN) - I4-1 (GND) B - W-B Power window down operation Engine switch on (IG), door glass fully closed --> power window auto down operation --> door glass fully open 11 to 14 V --> Below 1 V --> 11 to 14 V If the result is not as specified, the motor may be malfunctioning.
3. CHECK REAR POWER WINDOW REGULATOR MOTOR LH Disconnect the J11 motor connector. Measure the resistance and voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J11-2 (B) - J11-1 (GND) L - W-B Battery power supply Always 11 to 14 V J11-1 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the J11 motor connector. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J11-10 (UP) - J11-1 (GND) L - W-B Power window up operation Engine switch on (IG), power window regulator switch off --> up 11 to 14 V --> Below 1 V J11-10 (UP) - J11-1 (GND) L - W-B Power window up operation Engine switch on (IG), door glass fully open --> power window auto up operation --> door glass fully closed 11 to 14 V --> Below 1 V --> 11 to 14 V J11-7 (DOWN) - J11-1 (GND) B - W-B Power window down operation Engine switch on (IG), power window regulator switch off --> down 11 to 14 V --> Below 1 V J11-7 (DOWN) - J11-1 (GND) B - W-B Power window down operation Engine switch on (IG), door glass fully closed --> power window auto down operation --> door glass fully open 11 to 14 V --> Below 1 V --> 11 to 14 V If the result is not as specified, the motor may be malfunctioning.
4. CHECK REAR POWER WINDOW REGULATOR MOTOR RH Disconnect the J4 motor connector. Measure the resistance and voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J4-2 (B) - J4-1 (GND) L - W-B Battery power supply Always 11 to 14 V J4-1 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the J4 motor connector. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J4-10 (UP) - J4-1 (GND) L - W-B Power window up operation Engine switch on (IG), power window regulator switch off --> up 11 to 14 V --> Below 1 V J4-10 (UP) - J4-1 (GND) L - W-B Power window up operation Engine switch on (IG), door glass fully open --> power window auto up operation --> door glass fully closed 11 to 14 V --> Below 1 V --> 11 to 14 V J4-7 (DOWN) - J4-1 (GND) B - W-B Power window down operation Engine switch on (IG), power window regulator switch off --> down 11 to 14 V --> Below 1 V J4-7 (DOWN) - J4-1 (GND) B - W-B Power window down operation Engine switch on (IG), door glass fully closed --> power window auto down operation --> door glass fully open 11 to 14 V --> Below 1 V --> 11 to 14 V If the result is not as specified, the motor may be malfunctioning.
5. CHECK MULTIPLEX NETWORK MASTER SWITCH Disconnect the I11 master switch connector. Measure the resistance and voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition I11-11 (B) - I11-12 (GND) L - W-B Battery power supply Always 11 to 14 V I11-12 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the I11 master switch connector. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition I11-20 (UP) - I11-12 (GND) L - W-B Power window up operation Engine switch on (IG), multiplex network master switch off --> up 11 to 14 V --> Below 1 V I11-20 (UP) - I11-12 (GND) L - W-B Power window up operation Engine switch on (IG), door glass fully open --> power window auto up operation --> door glass fully closed 11 to 14 V --> Below 1 V --> 11 to 14 V I11-15 (DOWN) - I11-12 (GND) B - W-B Power window down operation Engine switch on (IG), multiplex network master switch off --> down 11 to 14 V --> Below 1 V I11-15 (DOWN) - I11-12 (GND) B - W-B Power window down operation Engine switch ON (IG), door glass fully closed --> power window auto down operation --> door glass fully open 11 to 14 V --> Below 1 V --> 11 to 14 V If the result is not as specified, the master switch may be malfunctioning.
6. CHECK POWER WINDOW REGULATOR SWITCH Disconnect the I3 switch connector. Measure the resistance according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition I3-5 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the I3 switch connector. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition I3-2 (UP) - I3-5 (GND) L - W-B Power window up operation Engine switch on (IG), power window regulator switch off --> up 11 to 14 V --> Below 1 V I3-10 (DOWN) - I3-5 (GND) B - W-B Power window down operation Engine switch on (IG), power window regulator switch off --> down 11 to 14 V --> Below 1 V I3-4 (AUTO) - I3-5 (GND) R - W-B Power window up operation Engine switch on (IG), and door glass fully open --> power window auto up operation --> door glass fully closed 11 to 14 V --> Below 1 V --> 11 to 14 V I3-4 (AUTO) - I3-5 (GND) R - W-B Power window down operation Engine switch on (IG), door glass fully closed --> power window auto down operation --> door glass fully open 11 to 14 V --> Below 1 V --> 11 to 14 V If the result is not as specified, the switch may be malfunctioning.
7. CHECK REAR POWER WINDOW REGULATOR SWITCH LH Disconnect the J10 switch connector. Measure the resistance according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J10-5 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the J10 switch connector. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J10-2 (UP) - J10-5 (GND) L - W-B Power window up operation Engine switch on (IG), power window regulator switch off --> up 11 to 14 V --> Below 1 V J10-10 (DOWN) - J10-5 (GND) B - W-B Power window down operation Engine switch on (IG), power window regulator switch off --> down 11 to 14 V --> Below 1 V J10-4 (AUTO) - J10-5 (GND) R - W-B Power window up operation Engine switch on (IG), door glass fully open --> power window auto up operation --> door glass fully closed 11 to 14 V --> Below 1 V --> 11 to 14 V J10-4 (AUTO) - J10-5 (GND) R - W-B Power window down operation Engine switch on (IG), door glass fully closed --> power window auto down operation --> door glass fully open 11 to 14 V --> Below 1 V --> 11 to 14 V If the result is not as specified, the switch may be malfunctioning.
8. CHECK REAR POWER WINDOW REGULATOR SWITCH RH Disconnect the J3 switch connector. Measure the resistance according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J3-5 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the J3 switch connector. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J3-2 (UP) - J3-5 (GND) L - W-B Power window up operation Engine switch on (IG), power window regulator switch off --> up 11 to 14 V --> Below 1 V J3-10 (DOWN) - J3-5 (GND) B - W-B Power window down operation Engine switch on (IG), power window regulator switch off --> down 11 to 14 V --> Below 1 V J3-4 (AUTO) - J3-5 (GND) R - W-B Power window up operation Engine switch on (IG), door glass fully open --> power window auto up operation --> door glass fully closed 11 to 14 V --> Below 1 V --> 11 to 14 V J3-4 (AUTO) - J3-5 (GND) R - W-B Power window down operation Engine switch on (IG), door glass fully closed --> power window auto down operation --> door glass fully open 11 to 14 V --> Below 1 V --> 11 to 14 V If the result is not as specified, the switch may be malfunctioning.
9. CHECK MAIN BODY ECU (COWL SIDE JUNCTION BLOCK LH) Disconnect the 2A, 2C,2D, E1, E2 and E3 ECU connectors. Measure the resistance and voltage according to value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition E3-1 (GND3) - 2D-62 (GND2) BR - W-B Ground Always Below 1 ohms 2D-62 (GND2) - Body ground W-B - Body ground Ground Always Below 1 ohms 2A-1 (IG) - Body ground B - Body ground IG power supply Always 11 to 14 V E2-1 (AM2) - Body ground W - Body ground Battery power supply Always 11 to 14 V E1-6 (AM1) - Body ground W - Body ground Battery power supply Always 11 to 14 V E1-24 (DCTY) - Body ground L - Body ground Driver side door courtesy light switch input Driver side door open Below 1 ohms Driver side door closed 10 kohms or higher E2-21 (PCTY) - Body ground Y - Body ground Front passenger side door courtesy light switch input Front passenger side door open Below 1 ohms Front passenger side door closed 10 kohms or higher E2-7 (RCTY) - Body ground G - Body ground Rear RH side door courtesy light switch input Rear RH side door open Below 1 ohms Rear RH side door closed 10 kohms or higher 2C-2 (LCTY) - Body ground W - Body ground Rear LH side door courtesy light switch input Rear LH side door open Below 1 ohms Rear LH side door closed 10 kohms or higher If the result is not as specified, the wire harness side may have a malfunction.

DTC CHECK / CLEAR

1. CHECK DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / (desired system) / Trouble Codes. Check for DTCs by following the directions on the Techstream screen. HINT: Refer to the Techstream operator's manual for further details.
2. CLEAR DTC Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / (desired system) / Trouble Codes. Clear the DTCs by following the directions on the Techstream screen. HINT: Refer to the Techstream operator's manual for further details.

Scheme 113

Scheme 114

Scheme 115

Scheme 116

1. POWER WINDOW OPERATION IN FAIL-SAFE MODE HINT: If the pulse sensor built into the power window regulator motor malfunctions, the power window control system enters fail-safe mode. The pulse sensor for the jam protection function has problems and the window position or the learned value is abnormal. HINT: The power window control system prohibits the following power window operations when the pulse sensor for the jam protection function has problems and the window position or the learned value is abnormal. MULTIPLEX NETWORK MASTER SWITCH Power Window Operation Condition Engine Switch on (IG) Engine Switch off (Key-off operation permitted) Engine Switch off (Key-off operation prohibited) Manual up (Driver side door window) X X - Manual down (Driver side door window) o*1 X - Auto up (Driver side door window) (hold switch at auto up position) o*2 X - Auto up (Driver side door window) X X - Auto down (Driver side door window) X X - Manual up (Remote switch operation) X X - Manual down (Remote switch operation) X X - Auto up (Remote switch operation) (hold switch at auto up position) X X - Auto up (Remote switch operation) X X - Auto down (Remote switch operation) X X - Door key interlock - X X Wireless interlock - X X Smart interlock - X X HINT: o: Operative X: Operation prohibited *1: Jam protection not operative *2: In manual mode and jam protection not operative POWER WINDOW REGULATOR SWITCH (FOR FRONT PASSENGER SIDE, REAR LH AND REAR RH) Power Window Operation Condition Engine Switch on (IG) Engine Switch off (Key-off operation permitted) Engine Switch off (Key-off operation prohibited) Manual up X X - Manual down o*1 X - Auto up (hold switch at auto up position) o*2 X - Auto up X X - Auto down X X - Door key interlock - X X Wireless interlock - X X Smart interlock - X X HINT: o: Operative X: Operation prohibited *1: Jam protection not operative *2: In manual mode and jam protection not operative Power window switch LED control HINT: During normal operation (fail-safe is not operating), or during fail-safe mode when there is a pulse sensor malfunction or the window position or learned value is abnormal, the LED illuminates as shown in the illustration. for driver side: for front passenger side, rear LH and rear RH: Fail-safe Deactivation Condition When the pulse sensor is normal, to deactivate fail-safe mode, pull up the power window switch to the auto up position and hold it for at least 1 second to fully close the window from the fully open position. As a result, the auto up/down function will return. Initialization failure HINT: During initialization of the power window regulator motor ECU, when the window position or initialization complete status cannot be properly read from the EEPROM, the power window control system prohibits the following operations. MULTIPLEX NETWORK MASTER SWITCH Power Window Operation Condition Engine Switch on (IG) Engine Switch off (Key-off operation permitted) Engine Switch off (Key-off operation prohibited) Manual up (Driver side door window) X X - Manual down (Driver side door window) o*1 X - Auto up (Driver side door window) (hold switch at auto up position) o*2 X - Auto up (Driver side door window) X X - Auto down (Driver side door window) X X - Manual up (Remote switch operation) X X - Manual down (Remote switch operation) X X - Auto up (Remote switch operation) (hold switch at auto up position) X X - Auto up (Remote switch operation) X X - Auto down (Remote switch operation) X X - Door key interlock - X X Wireless interlock - X X Smart interlock - X X HINT: o: Operative X: Operation prohibited *1: Jam protection not operative *2: In manual mode and jam protection not operative POWER WINDOW REGULATOR SWITCH (FOR FRONT PASSENGER SIDE, REAR LH AND REAR RH) Power Window Operation Condition Engine Switch on (IG) Engine Switch off (Key-off operation permitted) Engine Switch off (Key-off operation prohibited) Manual up X X - Manual down o*1 X - Auto up (hold switch at auto up position) o*2 X - Auto up X X - Auto down X X - Door key interlock - X X Wireless interlock - X X Smart interlock - X X HINT: o: Operative X: Operation prohibited *1: Jam protection not operative *2: In manual mode and jam protection not operative Power window switch LED control HINT: During initialization of the power window regulator motor ECU, when the window position or initialization complete status cannot be properly read from the EEPROM during fail-safe mode, the LED illuminates as shown in the illustration. for driver side: for front passenger side, rear LH and rear RH: LIN communication failure HINT: If the LIN communication line malfunctions (communication stop), the power window control system prohibits the following operations. MULTIPLEX NETWORK MASTER SWITCH Power Window Operation Engine Switch on (IG) Manual up o*1 Manual down o*2 Auto up (hold switch at auto up position) X Auto up X Auto down X HINT: o: Operative X: Operation prohibited *1: Jam protection operative *2: Jam protection not operative Remote up/down function does not operate. POWER WINDOW REGULATOR SWITCH (FOR FRONT PASSENGER SIDE, REAR LH AND REAR RH) Power Window Operation Engine Switch on (IG) Manual up o*1 Manual down o*2 Auto up (hold switch at auto up position) o*1 Auto up o*1 Auto down o*2 HINT: o: Operative X: Operation prohibited *1: Jam protection operative *2: Jam protection not operative LIN communication failure and pulse sensor failure HINT: If the LIN communication line malfunctions (communication stop) and the pulse sensor for the jam protection function has problems, the power window control system prohibits the following operations. MULTIPLEX NETWORK MASTER SWITCH Power Window Operation Always Manual up X Manual down X Auto up (hold switch at auto up position) X Auto up X Auto down X HINT: o: Operative X: Operation prohibited Driver side door window: When there is no jam protection control due to a LIN communication failure, the manual up and auto up functions will not operate. Remote switch operation: Not operative during LIN communication failure. POWER WINDOW REGULATOR SWITCH (FOR FRONT PASSENGER SIDE, REAR LH AND REAR RH) Power Window Operation Always Manual up X Manual down X Auto up (hold switch at auto up position) X Auto up X Auto down X HINT: o: Operative X: Operation prohibited LIN communication failure and displacement of non-detection range in direction window opens or initialization failure HINT: If the LIN communication line malfunctions (communication stop) and the window position or the learned value is abnormal, the power window control system prohibits the following operations. MULTIPLEX NETWORK MASTER SWITCH Power Window Operation Always Manual up o*1 Manual down o*2 Auto up (hold switch at auto up position) - Auto up - Auto down - HINT: o: Operative *1: Jam protection operative and window reverses direction upon reaching the fully closed position *2: Jam protection not operative Remote switch operation: Operation is not possible during a LIN communication failure. POWER WINDOW REGULATOR SWITCH (FOR FRONT PASSENGER SIDE, REAR LH AND REAR RH) Power Window Operation Always Manual up o*1 Manual down o*2 Auto up (hold switch at auto up position) o*1 Auto up X Auto down X HINT: o: Operative X: Operation prohibited *1: Jam protection operative and window reverses direction upon reaching the fully closed position *2: Jam protection not operative

DATA LIST / ACTIVE TEST

1. READ DATA LIST HINT: Using the Techstream to read the Data List allows values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / (desired system) / Data List. According to the display on the Techstream, read the Data List. MASTER SWITCH Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door P/W Auto SW Driver side power window auto up/down signal / ON or OFF ON: While operating driver side power window auto up/down switch on multiplex network master switch OFF: While not operating driver side power window switch on multiplex network master switch - P Door P/W Auto SW Front passenger side power window remote auto up/down signal / ON or OFF ON: While operating front passenger side power window remote auto up/down switch on multiplex network master switch OFF: While not operating power window regulator switch on multiplex network master switch - RR Door P/W Auto SW Rear power window RH remote auto up/down signal / ON or OFF ON: While operating rear power window RH remote auto up/down switch on multiplex network master switch OFF: While not operating rear power window switch RH on multiplex network master switch - RL Door P/W Auto SW Rear power window LH remote auto up/down signal / ON or OFF ON: While operating rear power window LH remote auto up/down switch on multiplex network master switch OFF: While not operating rear power window switch LH on multiplex network master switch - P Door P/W Up SW Front passenger side power window remote manual up signal / ON or OFF ON: While operating front passenger side power window remote manual up switch on multiplex network master switch OFF: While not operating power window regulator switch on multiplex network master switch - RR Door P/W up switch Rear power window RH remote manual up signal / ON or OFF ON: While operating rear power window RH remote manual up switch on multiplex network master switch OFF: While not operating rear power window switch RH on multiplex network master switch - RL Door P/W up switch Rear power window LH remote manual up signal / ON or OFF ON: While operating rear power window LH remote manual up switch on multiplex network master switch OFF: While operating not rear power window switch LH on multiplex network master switch - P Door P/W Down SW Front passenger side power window remote manual down signal / ON or OFF ON: While operating front passenger side power window remote manual down switch on multiplex network master switch OFF: While not operating power window regulator switch on multiplex network master switch - RR Door P/W Down SW Rear power window RH remote manual down signal / ON or OFF ON: While operating rear power window RH remote manual down switch on multiplex network master switch OFF: While operating rear power window switch RH on multiplex network master switch - RL Door P/W Down SW Rear power window LH remote manual down signal / ON or OFF ON: While operating rear power window LH remote manual down switch on multiplex network master switch OFF: While not operating rear power window switch LH on multiplex network master switch - Window Lock Switch Status Power window lock switch / ON or OFF ON: Power window lock switch on OFF: Power window lock switch off - Number of Trouble Codes Number of trouble codes / Min.: 0, Max.: 255 Number of DTCs will be displayed - D-DOOR MOTOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door P/W Auto SW Driver side power window auto up/down signal / ON or OFF ON: While operating driver side power window auto up/down switch OFF: While not operating driver side power window switch - D Door P/W Up SW Driver side power window manual up signal / ON or OFF ON: While operating driver side power window manual up switch OFF: While not operating driver side power window switch - D Door P/W Down SW Driver side power window manual down signal / ON or OFF ON: While operating driver side power window manual down switch OFF: While not operating driver side power window switch - Glass Position (Close-1/4) Jam protection status of window glass within range of fully closed to 1/4 open position / OK or Caution OK: Motor normally operates between fully closed to 1/4 open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Glass Position (1/4-2/4) Jam protection status of window glass within range of 1/4 to 1/2 open position / OK or Caution OK: Motor normally operates between 1/4 to 1/2 open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Glass Position (2/4-3/4) Jam protection status of window glass within range of 1/2 to 3/4 open position / OK or Caution OK: Motor normally operates between 1/2 to 3/4 open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Glass Position (3/4-Open) Jam protection status of window glass within range of 3/4 to fully open position / OK or Caution OK: Motor normally operates between 3/4 to fully open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Number of Trouble Codes Number of trouble codes / Min.: 0, Max.: 255 Number of DTCs will displayed - P-DOOR MOTOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note P Door P/W Auto SW Front passenger side power window auto up/down signal / ON or OFF ON: While operating front passenger side power window auto up/down switch OFF: While not operating power window regulator switch - P Door P/W Up SW Front passenger side power window manual up signal / ON or OFF ON: While operating front passenger side power window manual up switch OFF: While not operating power window regulator switch - P Door P/W Down SW Front passenger side power window manual down signal / ON or OFF ON: While operating front passenger side power window manual down switch OFF: While not operating power window regulator switch - Glass Position (Close-1/4) Jam protection status of window glass within range of fully closed to 1/4 open position / OK or Caution OK: Motor normally operates between fully closed to 1/4 open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Glass Position (1/4-2/4) Jam protection status of window glass within range of 1/4 to 1/2 open position / OK or Caution OK: Motor normally operates between 1/4 to 1/2 open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Glass Position (2/4-3/4) Jam protection status of window glass within range of 1/2 to 3/4 open position / OK or Caution OK: Motor normally operates between 1/2 to 3/4 open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Glass Position (3/4-Open) Jam protection status of window glass within range of 3/4 to fully open position / OK or Caution OK: Motor normally operates between 3/4 to fully open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Number of Trouble Codes Number of trouble codes / Min.: 0, Max.: 255 Number of DTCs will be displayed - RL-DOOR MOTOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note RL Door P/W Auto SW Rear power window LH auto up/down signal / ON or OFF ON: While operating rear power window LH auto up/down switch OFF: While not operating rear power window LH switch - RL Door P/W Up SW Rear power window LH manual up signal / ON or OFF ON: While operating rear power window LH manual up switch OFF: While not operating rear power window LH switch - RL Door P/W Down SW Rear power window LH manual down signal / ON or OFF ON: While operating rear power window LH manual down switch OFF: While not operating rear power window LH switch - Glass Position (Close-1/4) Jam protection status of window glass within range of fully closed to 1/4 open position / OK or Caution OK: Motor normally operates between fully closed to 1/4 open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Glass Position (1/4-2/4) Jam protection status of window glass within range of 1/4 to 1/2 open position / OK or Caution OK: Motor normally operates between 1/4 to 1/2 open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Glass Position (2/4-3/4) Jam protection status of window glass within range of 1/2 to 3/4 open position / OK or Caution OK: Motor normally operates between 1/2 to 3/4 open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Glass Position (3/4-Open) Jam protection status of window glass within range of 3/4 to fully open position / OK or Caution OK: Motor normally operates between 3/4 to fully open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Number of Trouble Codes Number of trouble codes / Min.: 0, Max.: 255 Number of DTCs will be displayed - RR-DOOR MOTOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note RR Door P/W Auto SW Rear power window RH auto up/down signal / ON or OFF ON: While operating rear power window RH auto up/down switch OFF: While not operating rear power window RH switch - RR Door P/W Up SW Rear power window RH manual up signal / ON or OFF ON: While operating rear power window RH manual up switch OFF: While not operating rear power window RH switch - RR Door P/W Down SW Rear power window RH manual down signal / ON or OFF ON: While operating rear power window RH manual down switch OFF: While not operating rear power window RH switch - Glass Position (Close-1/4) Jam protection status of window glass within range of fully closed to 1/4 open position / OK or Caution OK: Motor normally operates between fully closed to 1/4 open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Glass Position (1/4-2/4) Jam protection status of window glass within range of 1/4 to 1/2 open position / OK or Caution OK: Motor normally operates between 1/4 to 1/2 open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Glass Position (2/4-3/4) Jam protection status of window glass within range of 1/2 to 3/4 open position / OK or Caution OK: Motor normally operates between 1/2 to 3/4 open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Glass Position (3/4-Open) Jam protection status of window glass within range of 3/4 to fully open position / OK or Caution OK: Motor normally operates between 3/4 to fully open position Caution: Jam protection function operates due to detection of foreign object or irregular movement - Number of Trouble Codes Number of trouble codes / Min.: 0, Max.: 255 Number of DTCs will be displayed - MAIN BODY Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door Courtesy SW Driver side door courtesy signal / ON or OFF ON: Driver door open OFF: Driver door closed - P Door Courtesy SW Front passenger side door courtesy signal / ON or OFF ON: Front passenger door open OFF: Front passenger door closed - RL Door Courtesy SW Rear LH side door courtesy signal / ON or OFF ON: Rear LH side door open OFF: Rear LH side door closed - RR Door Courtesy SW Rear RH side door courtesy signal / ON or OFF ON: Rear RH side door open OFF: Rear RH side door closed - Communication D-Door Motor Connection status between power window regulator motor (for driver side) and main body ECU / OK or STOP OK: Connection STOP: No connection - Communication P-Door Motor Connection status between power window regulator motor (for front passenger side) and main body ECU / OK or STOP OK: Connection STOP: No connection - Communication RR-Door Motor Connection status between rear power window regulator motor LH and main body ECU / OK or STOP OK: Connection STOP: No connection - Communication RL-Door Motor Connection status between rear power window regulator motor RH and main body ECU / OK or STOP OK: Connection STOP: No connection - Communication Master SW Connection status between master switch and main body ECU / OK or STOP OK: Connection STOP: No connection - The Number of DTC Number of trouble codes / Min.: 0, Max.: 255 Number of DTCs will be displayed
2. PERFORM ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / (desired system) / Active Test. According to the display on the Techstream, perform the Active Test. WARNING: Be careful to avoid injuries as this test causes vehicle parts to move. During the Active Test, the jam protection function does not operate. D-DOOR MOTOR Tester Display Test Part Control Range Diagnostic Note Power Window Driver side power window OFF/UP/DOWN - P-DOOR MOTOR Tester Display Test Part Control Range Diagnostic Note Power Window Front passenger side power window OFF/UP/DOWN - RL-DOOR MOTOR Tester Display Test Part Control Range Diagnostic Note Power Window Rear LH side power window OFF/UP/DOWN - RR-DOOR MOTOR Tester Display Test Part Control Range Diagnostic Note Power Window Rear RH side power window OFF/UP/DOWN

DIAGNOSTIC TROUBLE CODE CHART
